ADC and DAC on Red Pitaya

• Goal:
• Review the ADC and DAC digital interfaces.
• Understand the modifications to the Base

Design to enable the ADC and DAC on the dev board.

• Meeting timing.
• Differences between 2017.2 and 2019.1.
• These are things that can drive you crazy as a

designer.

• Testing.
• The board specific code was obtained

and modified from Red Pitaya Github and is intended for Vivado 2017.2.

ADC Data Interface

ADC Interface

• Data is latched in FPGA/HDL with

always@(posedge ADCCLK) begin ADC_DA <= ADA; ADC_DB <= ADB; end Could use different clock sources No access to SPI for configuration.

Timing Constraints

• If (clock pad to CLK path) > (data pad to D + set_input_delay)

then there is a timing violation. _ _______________ _______________ ____________ DATA _X_______________X_______________X____________ |-------->| input delay _______ _______ ______ CLK _______/ \_______/ \_______/

Timing Constraints

__ ____________ ____________ ________ DATA __XXXXX____________XXXXX____________XXXXX________ |------>| | input delay min | | |------------>| input delay max __ ________ ________ ____ CLK \_______/ \_______/ \_______/

ADC Timing

• Based on the info here I

would expect input delay to vary between 4 and 4.6 ns.

• Actual value from board

manufacturer is 3.4 ns.

ADC Clock Adjustments

ADC Constraints

### ADC # ADC data set_property IOSTANDARD LVCMOS18 [get_ports {adc_da_i[*]}] set_property IOB TRUE [get_ports {adc_da_i[*]}] set_property IOSTANDARD LVCMOS18 [get_ports {adc_db_i[*]}] set_property IOB TRUE [get_ports {adc_db_i[*]}] # ADC A data set_property PACKAGE_PIN Y17 [get_ports {adc_da_i[0]}] ... set_property PACKAGE_PIN V16 [get_ports {adc_da_i[13]}] # ADC B data set_property PACKAGE_PIN R18 [get_ports {adc_db_i[0]}] ... set_property PACKAGE_PIN Y18 [get_ports {adc_db_i[13]}] set_property IOSTANDARD DIFF_HSTL_I_18 [get_ports adc_clk_i[*]] set_property PACKAGE_PIN U18 [get_ports adc_clk_i[1]] set_property PACKAGE_PIN U19 [get_ports adc_clk_i[0]] # Output ADC clock set_property IOSTANDARD LVCMOS18 [get_ports {adc_clk_o[*]}] set_property SLEW FAST [get_ports {adc_clk_o[*]}] set_property DRIVE 8 [get_ports {adc_clk_o[*]}] #set_property IOB TRUE [get_ports {adc_clk_o[*]}] set_property PACKAGE_PIN N20 [get_ports {adc_clk_o[0]}] set_property PACKAGE_PIN P20 [get_ports {adc_clk_o[1]}] # ADC clock stabilizer set_property IOSTANDARD LVCMOS18 [get_ports adc_cdcs_o] set_property PACKAGE_PIN V18 [get_ports adc_cdcs_o] set_property SLEW FAST [get_ports adc_cdcs_o] set_property DRIVE 8 [get_ports adc_cdcs_o] create_clock -period 8.000 -name adc_clk [get_ports adc_clk_i[1]] set_input_delay -clock adc_clk 3.400 [get_ports adc_da_i[*]] set_input_delay -clock adc_clk 3.400 [get_ports adc_db_i[*]]

Data Format

• Two’s complement is better for FPGA/DSP so

need to convert.

• Can’t access SPI on the ADC so this is

done in HDL.

//Verilog code //------------------------------------------------------------------// // ADC -------------------------------------------------------------// //------------------------------------------------------------------// wire adc_clk; IBUFDS i_clk (.I (adc_clk_i[1]), .IB (adc_clk_i[0]), .O (adc_clk)); assign adc_clk_o = 2'b10; // generating ADC clock is disabled assign adc_cdcs_o = 1'b1; //ADC clock duty cycle stabilizer is enabled //sync adc input data to adc_clk reg signed [13:0] adc_db_raw; reg signed [13:0] adc_da_raw; always@(posedge adc_clk) begin adc_db_raw <= {~adc_db_i[13], adc_db_i[12:0]}; //convert offset binary to signed (two's complement) adc_da_raw <= {~adc_da_i[13], adc_da_i[12:0]}; //convert offset binary to signed (two's complement) end //------------------------------------------------------------------//

Works in 18.1 but not 19.1?

• Need to look at:
• Timing Summary.
• Implementation.

Min Delay Paths

• Slack (VIOLATED) : -0.935ns (arrival time - required time)

Source: adc_da_i[13] Destination: adc_da_raw_reg[13]/D

• Bits [12:0]
• Delay is added
• No violation
• Bit [13]

Work-Around

//Verilog code //------------------------------------------------------------------// // ADC -------------------------------------------------------------// //------------------------------------------------------------------// wire adc_clk; IBUFDS i_clk (.I (adc_clk_i[1]), .IB (adc_clk_i[0]), .O (adc_clk)); assign adc_clk_o = 2'b10; // generating ADC clock is disabled assign adc_cdcs_o = 1'b1; //ADC clock duty cycle stabilizer is enabled //sync adc input data to adc_clk reg [13:0] adc_db_raw; reg [13:0] adc_da_raw; always@(posedge adc_clk) begin adc_db_raw <= adc_db_i; adc_da_raw <= adc_da_i; end wire signed [13:0] adc_db; wire signed [13:0] adc_da; assign adc_db = {~adc_db_raw[13], adc_db_raw[12:0]}; //convert offset binary to signed (two's comp) assign adc_da = {~adc_da_raw[13], adc_da_raw[12:0]}; //convert offset binary to signed (two's comp) //------------------------------------------------------------------//

DAC Data Interface

DAC Data Interface

• Need 250 MHz to generate IQWRT and IOCLK.
• Need 125 MHz to generate DATA_IN and IQ_SEL.
• Use a PLL and ADC clk.

Constraints

### DAC # data set_property IOSTANDARD LVCMOS33 [get_ports {dac_dat_o[*]}] set_property SLEW SLOW [get_ports {dac_dat_o[*]}] set_property DRIVE 4 [get_ports {dac_dat_o[*]}] #set_property IOB TRUE [get_ports {dac_dat_o[*]}] set_property PACKAGE_PIN M19 [get_ports {dac_dat_o[0]}] set_property PACKAGE_PIN M20 [get_ports {dac_dat_o[1]}] set_property PACKAGE_PIN L19 [get_ports {dac_dat_o[2]}] set_property PACKAGE_PIN L20 [get_ports {dac_dat_o[3]}] set_property PACKAGE_PIN K19 [get_ports {dac_dat_o[4]}] set_property PACKAGE_PIN J19 [get_ports {dac_dat_o[5]}] set_property PACKAGE_PIN J20 [get_ports {dac_dat_o[6]}] set_property PACKAGE_PIN H20 [get_ports {dac_dat_o[7]}] set_property PACKAGE_PIN G19 [get_ports {dac_dat_o[8]}] set_property PACKAGE_PIN G20 [get_ports {dac_dat_o[9]}] set_property PACKAGE_PIN F19 [get_ports {dac_dat_o[10]}] set_property PACKAGE_PIN F20 [get_ports {dac_dat_o[11]}] set_property PACKAGE_PIN D20 [get_ports {dac_dat_o[12]}] set_property PACKAGE_PIN D19 [get_ports {dac_dat_o[13]}] # control set_property IOSTANDARD LVCMOS33 [get_ports dac_wrt_o] set_property SLEW FAST [get_ports dac_wrt_o] set_property DRIVE 8 [get_ports dac_wrt_o] set_property IOSTANDARD LVCMOS33 [get_ports dac_sel_o] set_property SLEW FAST [get_ports dac_sel_o] set_property DRIVE 8 [get_ports dac_sel_o] set_property IOSTANDARD LVCMOS33 [get_ports dac_clk_o] set_property SLEW FAST [get_ports dac_clk_o] set_property DRIVE 8 [get_ports dac_clk_o] set_property IOSTANDARD LVCMOS33 [get_ports dac_rst_o] set_property SLEW FAST [get_ports dac_rst_o] set_property DRIVE 8 [get_ports dac_rst_o] #set_property IOB TRUE [get_ports dac_*_o] set_property PACKAGE_PIN M17 [get_ports dac_wrt_o] set_property PACKAGE_PIN N16 [get_ports dac_sel_o] set_property PACKAGE_PIN M18 [get_ports dac_clk_o] set_property PACKAGE_PIN N15 [get_ports dac_rst_o]

DAC Data Interface

• Need 250 MHz to generate IQWRT
• IQCLK nees -45 degree phase offset for 500 ps.
• Need 125 MHz to generate DATA_IN and IQ_SEL.
• Use a PLL and ADC clk.
• Use ODDR SelectIO Resourse to interleave signals.

PLL Instantiation

PLLE2_ADV #( .BANDWIDTH ("OPTIMIZED"), .COMPENSATION ("ZHOLD" ), .DIVCLK_DIVIDE ( 1 ), //VCO is at 125 x 8 = 1000.00 MHz (between 600 and 1200 MHz) .CLKFBOUT_MULT ( 8 ), .CLKFBOUT_PHASE ( 0.000 ), .CLKOUT0_DIVIDE ( 8 ), .CLKOUT0_PHASE ( 180.000 ), .CLKOUT0_DUTY_CYCLE ( 0.5 ), .CLKOUT1_DIVIDE ( 8 ), .CLKOUT1_PHASE ( 180.000 ), .CLKOUT1_DUTY_CYCLE ( 0.5 ), .CLKOUT2_DIVIDE ( 4 ), .CLKOUT2_PHASE ( 0.000 ), .CLKOUT2_DUTY_CYCLE ( 0.5 ), .CLKOUT3_DIVIDE ( 4 ), .CLKOUT3_PHASE (-45.000 ), .CLKOUT3_DUTY_CYCLE ( 0.5 ), .CLKOUT4_DIVIDE ( 4 ), // 4->250MHz .CLKOUT4_PHASE ( 0.000 ), .CLKOUT4_DUTY_CYCLE ( 0.5 ), .CLKOUT5_DIVIDE ( 4 ), .CLKOUT5_PHASE ( 0.000 ), .CLKOUT5_DUTY_CYCLE ( 0.5 ), .CLKIN1_PERIOD ( 8.000 ), .REF_JITTER1 ( 0.010 )) pll ( // Output clocks .CLKFBOUT (clk_fb ), .CLKOUT0 (adc_clk ), .CLKOUT1 (dac_clk_1x), .CLKOUT2 (dac_clk_2x), .CLKOUT3 (dac_clk_2p), // Input clock control .CLKFBIN (clk_fb ), .CLKIN1 (clk125 ), .CLKIN2 (1'b0 ), // Tied to always select the primary input clock .CLKINSEL (1'b1 ), // Ports for dynamic reconfiguration .DADDR (7'h0 ), .DCLK (1'b0 ), .DEN (1'b0 ), .DI (16'h0 ), .DO ( ), .DRDY ( ), .DWE (1'b0 ), // Other control and status signals .PWRDWN (1’b0 ), .RST (~FRSTN ));

Port Description and ODDR

//14-bit 125 MHz Dual DAC

• utput wire [13:0] dac_dat_o, // DAC combined data for channel A & B (DDR)
• utput wire dac_wrt_o, // DAC write
• utput wire dac_sel_o, // DAC channel select
• utput wire dac_clk_o, // DAC clock
• utput wire dac_rst_o, // DAC reset

... //------------------------------------------------------------------// // DAC -------------------------------------------------------------// //------------------------------------------------------------------// reg [13:0] dac_db = 0; reg [13:0] dac_da = 0; wire dac_rst; assign dac_rst = 1'b0; //generate a ramp for now always@(posedge dac_clk_1x) dac_db <= dac_db+1; always@(posedge dac_clk_1x) dac_da <= dac_da+1; // output signal rising falling clock enable reset ??? ODDR oddr_dac_clk (.Q(dac_clk_o ), .D1(1'b0 ), .D2(1'b1 ), .C(dac_clk_2p), .CE(1'b1), .R(1'b0 ), .S(1'b0)); ODDR oddr_dac_wrt (.Q(dac_wrt_o ), .D1(1'b0 ), .D2(1'b1 ), .C(dac_clk_2x), .CE(1'b1), .R(1'b0 ), .S(1'b0)); ODDR oddr_dac_sel (.Q(dac_sel_o ), .D1(1'b1 ), .D2(1'b0 ), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); ODDR oddr_dac_rst (.Q(dac_rst_o ), .D1(dac_rst ), .D2(dac_rst ), .C(dac_clk_1x), .CE(1'b1), .R(1'b0 ), .S(1'b0)); ODDR oddr_dac_d13 (.Q(dac_dat_o[13]), .D1(dac_da[13]), .D2(dac_db[13]), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); ODDR oddr_dac_d12 (.Q(dac_dat_o[12]), .D1(dac_da[12]), .D2(dac_db[12]), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); ODDR oddr_dac_d11 (.Q(dac_dat_o[11]), .D1(dac_da[11]), .D2(dac_db[11]), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); ODDR oddr_dac_d10 (.Q(dac_dat_o[10]), .D1(dac_da[10]), .D2(dac_db[10]), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); ODDR oddr_dac_d09 (.Q(dac_dat_o[09]), .D1(dac_da[09]), .D2(dac_db[09]), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); ODDR oddr_dac_d08 (.Q(dac_dat_o[08]), .D1(dac_da[08]), .D2(dac_db[08]), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); ODDR oddr_dac_d07 (.Q(dac_dat_o[07]), .D1(dac_da[07]), .D2(dac_db[07]), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); ODDR oddr_dac_d06 (.Q(dac_dat_o[06]), .D1(dac_da[06]), .D2(dac_db[06]), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); ODDR oddr_dac_d05 (.Q(dac_dat_o[05]), .D1(dac_da[05]), .D2(dac_db[05]), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); ODDR oddr_dac_d04 (.Q(dac_dat_o[04]), .D1(dac_da[04]), .D2(dac_db[04]), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); ODDR oddr_dac_d03 (.Q(dac_dat_o[03]), .D1(dac_da[03]), .D2(dac_db[03]), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); ODDR oddr_dac_d02 (.Q(dac_dat_o[02]), .D1(dac_da[02]), .D2(dac_db[02]), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); ODDR oddr_dac_d01 (.Q(dac_dat_o[01]), .D1(dac_da[01]), .D2(dac_db[01]), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); ODDR oddr_dac_d00 (.Q(dac_dat_o[00]), .D1(dac_da[00]), .D2(dac_db[00]), .C(dac_clk_1x), .CE(1'b1), .R(dac_rst), .S(1'b0)); //------------------------------------------------------------------//

Loopback
