ADB SPADE SPATIAL DATA ANALYSES EXPLORER GeoNode summit 2019 Viareggio, Italy Ries Kluskens 11 June 2019 Introduction - Royal HaskoningDHV Engineering consultancy firm Active in aviation, buildings, energy, industry,

slide-1
SLIDE 1

ADB SPADE

SPATIAL DATA ANALYSES EXPLORER

Ries Kluskens 11 June 2019

GeoNode summit 2019

Viareggio, Italy

slide-2
SLIDE 2

ADB SPADE | GeoNode Summit | 11 June 2019

Introduction - Royal HaskoningDHV

◼ Engineering consultancy firm ◼ Active in aviation, buildings, energy, industry, infrastructure, maritime,

mining, rural and urban development and water.

◼ Employing 6,000 professionals worldwide ◼ Digital Services Department

2

◼ Dedicated department specialized

in GIS, Geo-ICT & Information Management (ca. 50 persons growing towards 125 people in the next 2 years)

◼ ESRI Gold Partner & company-

wide ESRI EULA

slide-3
SLIDE 3

ADB SPADE | GeoNode Summit | 11 June 2019

slide-4
SLIDE 4

ADB SPADE | GeoNode Summit | 11 June 2019

slide-5
SLIDE 5

ADB SPADE | GeoNode Summit | 11 June 2019 5

◼ SPADE is developed for the Asian Development Bank under the Urban

Climate Change Trust Fund (UCCRTF).

◼ The UCCRTF’s priority is to help build resilience to the effects of climate

variability and climate change

In collaboration with knowledge partners:

slide-6
SLIDE 6

ADB SPADE | GeoNode Summit | 11 June 2019

Strategy Identification

SPADE Support to ADB Business Operations

Implementation Evaluation

  • Policy dialogue
  • Scenario mapping

through Futures and Foresight tools

  • Option/Choices for

decision making

  • Country level

assessments

  • Setting priority sectors

and cities

  • Cross-sector teams

design project

  • Technology providers

identified

  • Climate risk and

vulnerability assessment

  • Align KSTA with TRTA
  • Developing integrated

plans

  • Preparing detailed

engineering designs

  • Conducting Safeguard

assessment

  • Preparing Contract

packages

  • Training and capacity

building

  • Progress monitoring

reports

  • Process and results

monitoring

  • Evaluating of results
  • Planning for Future

projects

  • Multi – (layers, criteria

and dimensions) for decision analysis

Concept Paper Project Preparation Study (TRTA) Project Loan Documents (RRP) Approval and Implementation Progress monitoring Monitoring and Evaluation Reports Country Partner Strategy Regional Cooperation Strategy Knowledge & Support TA

slide-7
SLIDE 7

ADB SPADE | GeoNode Summit | 11 June 2019

Strategy Identification

SPADE Support to ADB Business Operations

Implementation Evaluation

Concept Paper Project Preparation Study (TRTA) Project Loan Documents (RRP) Approval and Implementation Progress monitoring Monitoring and Evaluation Reports Country Partner Strategy Regional Cooperation Strategy KSTA

Digital and non- digital data are being collected from different sources to inform project identification process

slide-8
SLIDE 8

ADB SPADE | GeoNode Summit | 11 June 2019

Strategy Identification

SPADE Support to ADB Business Operations

Implementation Evaluation

Concept Paper Project Preparation Study (TRTA) Project Loan Documents (RRP) Approval and Implementation Progress monitoring Monitoring and Evaluation Reports Country Partner Strategy Regional Cooperation Strategy KSTA

  • Baseline Maps
  • Data sets from

safeguards and socio-economic surveys

  • Climate change

impact assessments

slide-9
SLIDE 9

ADB SPADE | GeoNode Summit | 11 June 2019

SPADE in Project design (ADB Use Case)

9

SPADE is used for Project Design and analysis on Secondary Cities Environment Improvement Project. Available digital and non-digital city/town profile information were collected from provincial line departments and plugged into the SPADE.

slide-10
SLIDE 10

ADB SPADE | GeoNode Summit | 11 June 2019

Projects in Dong Xoai

◼ Map of Dong Xoai with

Protected Areas (Blue Shade)

◼ Project officers needed to

know if projects in the area are falling within or

  • utside the protected

area

10

Protected Area

slide-11
SLIDE 11

ADB SPADE | GeoNode Summit | 11 June 2019

Digital and non-digital data were collected from different sources

11

Paper based map of river embankment Digital data of Facilities in Dong Xoai

slide-12
SLIDE 12

ADB SPADE | GeoNode Summit | 11 June 2019

Paper based maps were digitized, while digital maps not in GIS format were converted and uploaded to SPADE

12

slide-13
SLIDE 13

ADB SPADE | GeoNode Summit | 11 June 2019

SPADE aids project officers in planning and project design

◼ Water facilities plan overlayed to the

map with protected areas

◼ It was concluded that water facilities

component is outside of the protected area

13

Protected Area

◼ Paper based river embankment was

digitized and georeferenced to have its location on the map

◼ It was concluded that River

embankment is outside of the protected area Protected Area

slide-14
SLIDE 14

ADB SPADE | GeoNode Summit | 11 June 2019 14

Platform to structure and visualize urban planning and climate data

slide-15
SLIDE 15

ADB SPADE | GeoNode Summit | 11 June 2019 15

At the start, SPADE contained data for 5 Cities (Ha Giang, Vin Yenh, Hue, Patuakhali and Bagerhat). Since then, data is gradually added to the platform and now SPADE contains information for more than 18 Cities in Pakistan, India, Cambodia, Bangladesh, Philippines, Vietnam and China.

slide-16
SLIDE 16

ADB SPADE | GeoNode Summit | 11 June 2019 16

Simple analyses tools - comparing scenarios

slide-17
SLIDE 17

ADB SPADE | GeoNode Summit | 11 June 2019 17

SPADE now also utilizes external data: NASA Black Marble

slide-18
SLIDE 18

ADB SPADE | GeoNode Summit | 11 June 2019 18

SPADE now also utilizes external data: Landcover

slide-19
SLIDE 19

ADB SPADE | GeoNode Summit | 11 June 2019 19

SPADE now also utilizes external data: Rainfall intensity

slide-20
SLIDE 20

ADB SPADE | GeoNode Summit | 11 June 2019

SPADE 1.0 Architecture

20

slide-21
SLIDE 21

ADB SPADE | GeoNode Summit | 11 June 2019

SPADE 1.0 Online platform

21

◼ Open source technology

◼

Geonode 2.8, Geoserver 2.13

◼

PostgreSQL, PostGIS

◼

Leaflet / Javascript Client

◼

Django

◼ Maximize out-of-the box, minimize

customization

◼ Scalable and flexible cloud based

infrastructure (Amazon Web Services)

◼ Secured webservices ◼ Easy Backup & Recovery

GeoNode (Application Server) GIS Server Database server

Geoserver Geoweb cache PostGIS PostgreSQL

Leaflet / Javascript Client (SSL)

Web users (Browser)

Desktop Users (QGIS)

Backup tooling Secured Amazon Web Services

slide-22
SLIDE 22

ADB SPADE | GeoNode Summit | 11 June 2019

SPADE Testing, Acceptance, Production

DEVELOPMENT

  • Local Virtual

Manchine

ACCEPTANCE

  • Amazon EC2
  • www.acc.adb-space.org

PRODUCTION

  • Amazon EC2
  • www.adb-spade.org

22

Centralized code Repository

Development Testing Release update or new version

slide-23
SLIDE 23

ADB SPADE | GeoNode Summit | 11 June 2019

Safeguards in SPADE

23

Use of safeguards app is piloted on Philippine Cities, with the result

  • f the assessment uploaded to SPADE
slide-24
SLIDE 24

ADB SPADE | GeoNode Summit | 11 June 2019

Safeguards app was used in the field to collect data, then uploaded to SPADE

24

App Interface Select REA Form Fill up Form

slide-25
SLIDE 25

ADB SPADE | GeoNode Summit | 11 June 2019

Parts of the Rapid Env. Assessment (REA) Form

25

slide-26
SLIDE 26

ADB SPADE | GeoNode Summit | 11 June 2019

REA Forms are uploaded to SPADE

26

slide-27
SLIDE 27

ADB SPADE | GeoNode Summit | 11 June 2019

Since we have the assessed location geotagged by the app, then data can be reflected in SPADE. Hazard layers (like flood hazard) can then be

  • verlayed over the location of the assessed area

27

slide-28
SLIDE 28

ADB SPADE | GeoNode Summit | 11 June 2019

SP3 Climate Resiliency Officer Updates in SPADE

28

slide-29
SLIDE 29

ADB SPADE | GeoNode Summit | 11 June 2019

SPADE Evolution

SPADE 1.0 2016-2019

SPADE beyond 2022

SPADE 2.0 2019-2021

29

Drone Technology Street Change Place Pulse

slide-30
SLIDE 30

ADB SPADE | GeoNode Summit | 11 June 2019

Towards SPADE 2.0 – Mapstore integration

30

slide-31
SLIDE 31

ADB SPADE | GeoNode Summit | 11 June 2019

Implementation challenges

◼ Use of external (wms/wmts) data sources is not always stable ◼ SLD style creation to meet Geoserver’s requirements ◼ It sometimes happens that layers duplicate themselves when using

GeoNode’s front-end to upload layers (in bulk)

◼ We weren’t able to get the printing function to work ◼ User groups and user rights

31

slide-32
SLIDE 32

ADB SPADE | GeoNode Summit | 11 June 2019

Concluding remarks

◼ Open source solutions like GeoNode are a very good alternative for

proprietary software

◼ Applications need to be intuitive and self explanatory (look and feel are very

important aspects)

◼ SPADE is being used more and more within the ADB and helps project

  • fficers with their project planning and project design because it can integrate

various spatial data sources

◼ SPADE currently serves as a common system/platform within ADB that

integrates data from over 700 different data layers for analysis

32

slide-33
SLIDE 33

ADB SPADE | GeoNode Summit | 11 June 2019

linkedin.com/company/royal-haskoningdhv @RHDHV facebook.com/RoyalHaskoningDHV

33

Further information on SPADE visit: https://development.asia/explainer/using-spatial-cloud-computing-build-livable-cities If you have any questions, do not hesitate to contact us: ries.kluskens@rhdhv.com erwin.sterrenburg@rhdhv.com huong.phan@rhdhv.com bhs.pintor@gmail.com bmasangcay.consultant@adb.org
