Access Control Products

Application Scenario

Office Building School Transportation Government Office Bank Prison

Door Station / indoor Station Standalone Terminal Multi-door Access Controller

Video Intercom Access Control

iVMS-4200 iVMS-5200E

Video Surveillance PC Software Web Software

LAN DVR/NVR

Hikvision One Stop Integrated Solution!

Alarm System

Intrusion Alarm panel

Hardware Family

Controller, Card Reader, Finger/Face Reader, Electric Lock, Button, Accessories

Management Center

Cloud

Local Area Network(TCP/IP) UTP RS-485 Wiegand USB

Wiegand Reader

Lock Safety Module

Exit Button Standalone Terminal FP Reader Card Reader

Lock

Exit Button FP Issuer Card Issuer

Central Server Mobile APP

Controller

RVV Controller System Framework Standalone Terminal Framework

Desktop Server

GPRS

System Framework

Pro Controller Eco Controller Pro FP/Card Reader Eco Card Reader Pro Terminal

Eco Terminal

Face recognition

Access Control Hardware Family

Swing Barrier

DS-K2600 Series

TCP/IP, RS485 uplink RS485, Wiegand Reader Support Anti Pass back, Door Interlocking, First Card Video Surveillance linkage 200K expandable

UTP RS-485 Wiegand USB RVV

RS485 Reader

Lock

Wiegand Reader

DS-K260X Controller Card Issuer LAN (TCP/IP) iVMS4200 FP Issuer

Professional access controller

600K expandable 100K cards 300K events CE, FCC, UL Optional backup battery

DS-K2601 / DS-K2602 / DS-K2604

Alarm Input/Output, Tamper-proof

Features Specification Configuration

Fire Panel Integration

DS-K2800 Series

TCP/IP, RS485 uplink Wiegand Reader Support Abundant event linkage 10K cards 50K events CE, FCC Alarm, Tamper-proof

Economic access controller

Lock

Wiegand Reader

DS-K260X Controller Card Issuer LAN (TCP/IP) iVMS4200

DS-K2801 / DS-K2802 / DS-K2804 Features Specification Configuration

UTP Wiegand USB RVV

Comparison - Card Reader

DS-K1101 DS-K1102 DS-K1103 DS-K1104 DS-K1107 DS-K1108 DS-K1201 DS-K1801 DS-K1802 Pro Pro Pro Pro Pro Pro Pro Eco Eco Wiegand 26 & 34 Wiegand 26 & 34 Wiegand 26 & 34 Wiegand 26 & 34 Wiegand 26 & 34 Wiegand 26 & 34

• Wiegand

26 & 34 Wiegand 26 & 34 RS-485 RS-485 RS-485 RS-485 RS-485 RS-485 RS-485

• IK10
• IP 64

IP 64 IP 64 IP 65 IP 65 IP 65 IP 65 IP 65 IP 65 Mifare-1 13.56MHz Mifare-1 13.56MHz Mifare-1 13.56MHz Mifare-1 13.56MHz Mifare-1 13.56MHz Mifare-1 13.56MHz Mifare-1 13.56MHz Mifare-1 13.56MHz Mifare-1 13.56MHz

• EM 125KHz

EM 125KHz EM 125KHz EM 125KHz EM 125KHz EM 125KHz EM 125KHz EM 125KHz Gang box 120 Gang box 86 or 120 Gang box 120 Gang box 86 or 120 Gang box Not Support Gang box 86 or 120 Gang box Not Support Gang box 86 Gang box Not Support

DS-K1T201

RS485 Reader

Lock Card Issuer LAN (TCP/IP) iVMS4200 FP Issuer

Standalone access control terminal DS-K1T201EF/EF-C/MF/MF-C

100K cards 300K events 5000 Fingerprints EM / Mifare card 2 MP Camera (optional) CE, FCC

Exit Button

DS-K1T201

Replace the discontinued Model: DS-K1T200 series Features Specification Configuration

UTP RS-485 Wiegand USB RVV

TCP/IP, RS485 uplink WIFI, USB Wiegand 26/34 uplink RS485 downlink (Reader mode) Face detection, photo capture Alarm, Tamper-proof

WIFI , USB

DS-K1T804

Wiegand Reader Lock Card Issuer LAN (TCP/IP) iVMS4200

Standalone access control terminal DS-K1T804F/EF/MF

TCP/IP uplink 3K cards 100K events 3000 Fingerprints Wiegand 26/34 uplink RS485 for security module. Wiegand 26 / 34 for exit card reader EM / Mifare card Alarm, Tamper-proof CE, FCC

DS-K1T804 Exit Button

Local Attendance, export report to USB pen drive

FP Issuer

Replace the discontinued Model: DS-K1T803 series Features Specification Configuration

UTP Wiegand USB RVV

Features Specification Configuration

DS-K1A802

LAN (TCP/IP)

Card Issuer iVMS4200

Standalone attendance terminal DS-K1A802F/EF/MF (With Battery DS-K1A802F/MF/EF-B)

TCP/IP uplink 3K cards 100K events 3000 Fingerprints WIFI, USB EM / Mifare card CE, FCC Time Attendance

FP Issuer

Replace the discontinued Model: DS-K1A801 series

UTP USB

Inbuilt Lithium Battery 3-4 HR ( DS-K1A802F/MF/EF-B)

DS-K1T105 DS-K1T201 DS-K1T804 DS-K1T804-1 DS-K1T802 DS-K1A802-1 DS-K1T802 DS-K1T801 FP Number

• 5000

3000 3000 3000 800

• Card Number

100K 100K 3K 3K 3K 3K 3K 3K Event Log 300K 300K 100K 100K 100K 100K 10K

• Wi-Fi

Yes Yes Yes No Yes No

• Secure Model

Yes Yes Yes No Yes

• Face Detection

Optional Optional

• External Reader

Wiegand RS485 Wiegand RS485 Wiegand No

• Note

No Lock Control No Lock Control No LAN Port

Comparison - Terminal

Key Products For RD Business (DS-K1A802 Series & DS-K1T804 Series)

Attendance Solution

DS-K1A802F/EF/MF-1

• 800 Fingerprint & Card
• 1,00,000 Transactions
• TCP/IP & USB
• Super Eco Series
• Predefined Report by USB

DS-K1A802F/EF/MF

• 3000 Fingerprint & Card
• 1,00,000 Transactions
• TCP/IP, Wi-Fi & USB
• Exit Reader Support
• Predefined Report by USB

DS-K1A802F/EF/MF-B

• 3000 Fingerprint & Card
• 1,00,000 Transactions
• TCP/IP, Wi-Fi & USB
• Predefined Report by USB
• 4Hr Inbuilt Battery Backup

Standalone Access + Attendance Solution

DS-K1T804F/EF/MF-1

• 3000 Fingerprint & Card
• 1,00,000 Transactions
• TCP/IP & USB
• Super Eco Series
• Predefined Report by USB

DS-K1T804F/EF/MF

• 3000 Fingerprint & Card
• 1,00,000 Transactions
• TCP/IP, Wi-Fi & USB
• Predefined Report by USB

DS-K2601/2/4

• 1/2/4 Door Control
• 2/4/8* Card/Finger Reader
• 100K User & 300K Transaction
• Advance Access Feature
• CE, FCC, UL*
• Dedicated Fire Integration

DS-K2801/2/4

• 1/2/4 Door Control
• 2/4/4 Card/Finger Reader
• 10K User & 30K Transaction
• Eco Series (Limited Feature)
• CE, FCC

DS-K1101/2/4 Series DS-K1801 Series DS-K1201 Series

• Std Weigand Interface
• RS 485 Interface*
• IP 64 & IP 65
• CE, FCC

Standalone Access + Attendance Solution

DS-K1T201EF/MF (-C)

• 5000 Fingerprint
• 1,00,000 Cards
• 1,00,000 Transactions
• TCP/IP, Wifi & USB
• 2 MP Camera (optional)
• CE, FCC

DS-K1T105E/M (-C)

• 1,00,000 Cards
• 1,00,000 Transactions
• TCP/IP, Wifi & USB
• 2 MP Camera (optional)
• CE, FCC

Key Products For Project Business (Controller + Reader & Standalone)

Controller + Reader Solution

DS-K1T605 Series

• Face + Finger + Card + PIN
• 2000 Face Capacity
• 5000 Finger Capacity
• 1,00,000 Transactions
• TCP/IP, Wi-Fi & USB
• Inbuilt Battery Backup (DS-K1T605MF-B)

DS-K1T606M/MF Series

• Face + Finger + Card
• 3000 Face Capacity
• 5000 Finger Capacity
• 1,00,000 Transactions
• TCP/IP, Wi-Fi & USB
• Protection Level - IP 65

Face Readers (Swing Barrier Solution)

DS-K5603-Z

• Face + Card Based Reader
• 10,000 Face Capacity
• 50,000 Transactions
• TCP/IP & USB
• Protection Level - IP 65
• Application – Indoor/Outdoor
• Can be Integrated with 3rd Party Turnstiles*

DS-K3B601 + DS-K5603-Z

• Face + Card Based Solution
• 10000 Face Capacity
• 50000 Card Capacity
• 50,000 Transactions
• 30 – 40 passage frequency
• Protection Level - IP 54

Key Products For Project Business (Face Reader & Swing Barrier)

Face Readers (Wall Mounting)

Card & Finger issuer

DS-K1F100-D8E

EM card, Mifare card USB 2.0 Windows OS

Support Mifare card encryption.

Only DS-2600 series controller and DS-1100 series card reader can support Mifare card encryption.

DS-K1F820-F

508 dpi USB 2.0 Windows OS

For all the Hikvision FP devices

Software

iVMS-4200 iVMS-5200E – Access Control Module

Software Family

How to choose software

iVMS-4200

• Only Client
• ACS + Attendance + CCTV + VDP + Alarm
• LAN & Ehome
• Not support customize
• Up to 64 Devices/Doors

iVMS-5200E

• Server + Client + Web
• ACS + Attendance + CCTV + VDP + Alarm
• LAN & Ehome
• Support customize
• Up to 1000 Doors

iVMS-4200

All-in-one desktop client Access Control Module Time Attendance Module

• Max. 10000 users and 10000 cards
• Max. 64 doors or 64 Terminals

Ehome Supported (Similar to Push Data)* 100+ Access + Attendance Reports Access Control & CCTV Integration Live Door Status Monitoring on MAP Daily/Monthly Report send on Email Complete ACS Alarm Management

Key Products For RD Business (Software)

*In Ehome Centralize Enrollment Recommended

iVMS-4200

Time Attendance Module

Basic Settings (Month Start Day , Sign & Color Code) Attendance Rule Settings (Late, Early, Grace, Overtime) Device Selection for Attendance Management Holiday and Leave Type Settings Check in/Check out Time Correction Leave/Business Trip Entry Attendance Summary (Person Wise, Report, Export) Attendance Details (Filter Late, Early, Absent, etc. Abnormal & Overtime Attendance Calculation Card Swiping Logs Report Sending on Email (Schedule Settings) Shift Management (Dept./Person wise, Multiple, Export)

iVMS-4200

Other Advance Functions (Live Door Monitoring, Alarm, Event, Linkage…..)

Door Status (Remote Open, Close, Remain Open/Close) Real-time Swipe Records Access Control Alarm & Alarm History Reports Real-Time Alarm Management Alarm Event ( Live View, Alarm Source,etc.) Live Access Control Monitoring on Emap Access Control Event Linkage Access Card Linkage Alarm Input Linkage (Input Output Settings) Log Search ( Audit Log, Log Filter, Backup log) Alarm Sound Setting

iVMS-4200

Wizard – Only you have to Click Next!!!

Access Control Setting Wizard Step 1 – Add Devices (Server & Remote Configuration) Step 2 – Add Person (Import User, Finger Enrolment,etc.) Add Organization ( Company, Location, Department) Step 3 – Add Permission (Who, When, Where Rules) Step 4 – Add Backup Setting Attendance Settings Wizard Step 1 – Create Shift , Shift Setting Step 2 - Set Attendance Parameters Late, Early Setting , Check in & Check out Time Settings Configuration Completed

iVMS-4200 Reports

Attendance Reports

Attendance Monthly Report (PDF & Excel) Attendance Summary Department Attendance Report (Department wise) Abnormal Attendance Attendance Daily Report Attendance Details Card Swiping Log Overtime Details Monthly Report Overtime Record Start End-Work Time Report Total Overtime Monthly Report Valid Card Swiping Record Report (Excel) First Check-in and Last Check-out Report (First In Last Out)

iVMS-5200E

All-in-one Web client Access Control Module Time Attendance Module

• Max. 50000 users and 100K cards
• Max. 1000 doors or 500 Terminals

Ehome Supported (Similar to Push Data) 3rd Party Software Integration Access Control & CCTV Integration Live Door Status Monitoring on MAP Visitor Management & Elevator Control Complete ACS Alarm Management

Key Products For Project Business (Software)

Head Office Branches Branches Branches Branches Branches

Central Management – Ehome

Thanks!
