An alternating current is passed through a coil A.C. generates an alternating field Alternating field generates eddy currents in conductors An alternating current is passed through a coil A.C. generates an alternating field


slide-1
SLIDE 1
slide-2
SLIDE 2
  • An alternating current is passed

through a coil

  • A.C. generates an

alternating field

  • Alternating field

generates eddy currents in conductors

slide-3
SLIDE 3
  • An alternating current is passed

through a coil

  • A.C. generates an

alternating field

  • Alternating field

generates eddy currents in conductors

  • Eddy currents generate
  • pposing field which

modifies current in coil

slide-4
SLIDE 4

Defects will interrupt the eddy current Interruption in the coil current is displayed on the set

slide-5
SLIDE 5

Equipme pment

slide-6
SLIDE 6

Electrical currents induced in metals by alternating magnetic fields

The size of the current is affected by

  • Electrical conductivity
  • Stand off distance
  • Flaws
  • Permeability
  • Specimen dimensions
slide-7
SLIDE 7
  • Sensitive to surface defects
  • Can detect through several layers
  • Can detect through surface coatings
  • Accurate conductivity measurements
  • Can be automated
  • Little pre-cleaning required
  • Portability
slide-8
SLIDE 8
  • Very susceptible to permeability changes
  • Only on conductive materials
  • Will not detect defects parallel to surface
  • Not suitable for large areas and/or complex geometry's
  • Signal interpretation required
  • No permanent record (unless automated)
  • Expensive equipment
slide-9
SLIDE 9
slide-10
SLIDE 10
  • High frequency sound

sound waves are introduced into a material

  • Reflected sound gives

information on the material under test and signals displayed on a CRT

Principle

slide-11
SLIDE 11

The presence of a Defect in the material shows up on the screen of the flaw detector with a less distance than the bottom of the material The BWE signal Defect signal Defect

slide-12
SLIDE 12

The depth of the defect can be read with reference to the marker on the screen 0 10 20 30 40 50 60 60 mm

slide-13
SLIDE 13

A A B B C C The THINNER the material the less distance the sound travel The closer the reflector to the surface, the signal will be more to the left of the screen The thickness is read from the screen 68 46 30

slide-14
SLIDE 14
slide-15
SLIDE 15
slide-16
SLIDE 16
slide-17
SLIDE 17
slide-18
SLIDE 18

May 1999: tmin = 29.6 mm

  • Dec. 1999: tmin = 29.6 mm

June 2000: tmin = 29.4 mm April 2001: tmin = 29.2 mm

slide-19
