2018/10/24 1 2018/10/24 2 SAFE DEAD WORK SAFE DEAD WORK.. What is this? There are two practical options.. NRS 097-2-1 compliance (switch off and break before you make) What is the Dead Grid Safety Lock?


slide-1
SLIDE 1

2018/10/24 1

slide-2
SLIDE 2

2018/10/24 2

slide-3
SLIDE 3

SAFE DEAD WORK

  • “SAFE DEAD WORK”………….. What is this?
  • There are two practical options…..
  • NRS 097-2-1 compliance (switch off and break before

you make)

  • What is the Dead Grid Safety Lock?
  • How does the Dead Grid Safety Lock work?
  • Is installation net-energy throttling functions as a safety

feature?

slide-4
SLIDE 4
slide-5
SLIDE 5

Electrical Installation Regulations

Point of Supply Point of Control

slide-6
SLIDE 6

Two Points of Supply

Utility Point of Supply EG Point of Supply

slide-7
SLIDE 7

LV Dead - Safe Work Practice

  • Identify circuit
  • Open circuit
  • Isolate circuit
  • Tag circuit
  • Lock out circuit
  • ( DO NOT USE EARTHING & BONDING )
  • Test at location
  • Work

7

slide-8
SLIDE 8

Locked Out and Tagged

slide-9
SLIDE 9

Typical LV Locking and Tagging Equipment

2018/10/24 9

slide-10
SLIDE 10

Test to Proof Voltage = 0 Volt = Safe

2018/10/24 10

slide-11
SLIDE 11

Single Customers per MV-LV Transformer

  • Employ standard LV safe procedure

as given above:

  • I.e. Isolation of the installation

2018/10/24 11

slide-12
SLIDE 12

Multi-Customer LV Networks

2018/10/24 12

Complex and Impossible to Employ the normal safe work procedure

slide-13
SLIDE 13

Typical Over Head LV Networks

2018/10/24 13

slide-14
SLIDE 14

Where are the EG ?

2018/10/24 14

The only feasible Approach: Secure - Automated Safety Systems

slide-15
SLIDE 15

How do we automate this?

2018/10/24 15

Contactor

C NO

With the Utility side dead, a live EG cannot feed power back Simple example of one embodiment of the principle.

UTILITY NETWORK CUSTOMER INSTALLATION

slide-16
SLIDE 16

Automated LV Safe Work Practice

  • Normal upstream safety

procedure

  • Test at location + Automated

Dead-Grid Lock

  • Work

16

slide-17
SLIDE 17

2018/10/24 17

slide-18
SLIDE 18

Dead-Grid Lock The Purpose of the DEAD-GRID LOCK is to ensure that power cannot flow back from a EG once a utility worker has proofed that this part of the LV network is safe to work on. It relies on the EG to power down automatically when the utility power fails. ( Anti-islanding and out of bounds requirements)

slide-19
SLIDE 19

Dead-Grid Lock If this does not happen, the safe work procedure will detect the condition and further steps is to be taken to make the installation safe. The sole purpose of this device is to secure that once the network is proven to be safe to work on- that it remains so, regardless of any actions or failure of equipment during this time on the EG’s side.

slide-20
SLIDE 20

Test to Proof Voltage = 0 Volt

2018/10/24 20

The Critical Step : Test – once dead AND Utility supply locked

  • ut –

The automatic Dead Grid Safety Lock ensures safety from the EG’s side.

slide-21
SLIDE 21

Cable to EG

On / Off AC Disconnector

Dead-Grid Safety-Lock

slide-22
SLIDE 22

Dead-Grid Safety-Lock

2018/10/24 22

slide-23
SLIDE 23

8.9 kVA On PF .98

DC side Arresters

PV String Installation

Main DB Connection

Inverter

DGSL Installation on a PV Inverter

slide-24
SLIDE 24

Safe Even when it is DEAD

24

slide-25
SLIDE 25

2018/10/24 25

slide-26
SLIDE 26

LV Live - Safe Work Practice

2018/10/24 26

slide-27
SLIDE 27

Multi customer feeder - Minimum Safety Requirements

MAIN DB POS POC Locked in Grid-Tied-Mode EG - DB PE PE

Structural lighting protection and bonding of PV panels
