slide-1
SLIDE 1

2 wires digital BUS

by

April 2015

slide-2
SLIDE 2

Capacidad del sistema:

Main features. Door entry panels – EL632/GB2 video module. Power supply and distributors. GB2 Monitors. Memory module: MM-GB2 & Call transfer unit: GSM-GB2. Diagrams. References available. Coming UP.

= Golmar BUS 2

slide-3
SLIDE 3

Características principales: Main Features

Characteristics:

  • Full digital transmission of audio, video and data.
  • 2 wires, no polarized BUS.
  • Up to 22 monitors in a system (expandable using RD-GB2).
  • Up to 4 entry panels Nexa with buttons.
  • Up to 160 meters distance: from panel to last monitor.
  • Suitable for retrofit, very flexible with cabling type.

Benefits: Saves time and installation mistakes. Installation costs saving. More profit for all parties.

slide-4
SLIDE 4

NEXA MODULAR INOX NEXA MODULAR ALUMINIUM

Entry panels – EL632/GB2 video module

slide-5
SLIDE 5

Characteristics:

  • Inox and aluminium versions available, from Nexa series.
  • Up to 22 buttons.
  • Single or double buttons. Permanent light on name tags.
  • Visual signalization of panel status for hearing aided people.
  • Vocal messages in 5 different languages for people with low vision.
  • Wide angle camera (105º).
  • Automatic camera leds activation in low light conditions.
  • Communication and volume adjustments with no need to open the panel.

Entry panels – EL632/GB2 video module

Call is in progress Communication started Door is open System is busy

slide-6
SLIDE 6

Características principales:

  • Set to “Villa” or “Building” mode.
  • Door panel code programming, (00-03) through dip switches (total 4 panels).
  • 2 relays for door lock. 2 exit buttons input (one per relay).
  • 12Vdc output to power CV-14/DC door lock.
  • NO/NC relays.
  • Plug to connect EL610D module.
  • Two call buttons included in the module.
  • Wide angle camera (105º).
  • White Leds activated only in low light conditions.
  • Vocal messages for panel status confirmation, specially for people with visual problems.
  • Visual signalization through leds for panel status confirmation, specially for hearing aided people.

Entry panels – EL632/GB2 video module

AP1 AP2

Villa Building

Up to 16 monitors per family. Up to 2 family houses. Up to 4 monitors per apartment. Up to 22 monitors in a system.

In case of using 2 exit buttons, add one power supply.

slide-7
SLIDE 7

Características principales: Power supply and distributors

  • 110-230 Vac input.
  • Protected agains: Short-circuits, overload, over voltage.
  • Placed in between the entry panel BUS and the monitors.
  • Relay for staircase lights controlled from the monitors.

Mains

FA-GB2

FA-GB2

2

slide-8
SLIDE 8

Power supply and distributors

Door panel switcher. Floor video distributor.

Mains

  • Up to 4 entry panels.
  • Can be used also as floor distributor.
  • 2 outputs.
  • End line resistor.
  • Small case.

To monitor To monitor To next floor / D2L-GB2

DP-GB2

D2L-GB2 2 2 2 2 2 DP-GB2 FA-GB2 D2L-GB2 2 2

slide-9
SLIDE 9

3,9”

GB2 monitors handsfree

VESTA GB2

7”

T-562

  • Easy programming through dip switches.
  • Magnetic bracket for an easy installation.
  • Detachable connectors
  • Sound repeater output.
  • Door bell input.
  • ptional

THERA GB2

slide-10
SLIDE 10

GB2 Monitors

V E S T A G B 2

  • Induction loop speaker available.(VESTA GB2/H).
  • Friendly to use and easy to navigate through the menu.
  • Big buttons at the front for the main functions.

Door open Answer button / self activation Backlit notification icons Capacitive buttons 3,9 inch screen 82 (W) 82 (H) 19 (D) mm

Surface box available

slide-11
SLIDE 11

GB2 Monitors – VESTA GB2

Intercom with the apartment monitors. Intercom with other apartment monitors. Selective self-activation of the entry panels. Additional camera activation (CAM-GB2 required). Call divert to a telephone through the GSM network. Video recording of the incoming calls. Activation of staircase lights. Direct call to the monitor set as “Guard monitor”. Selectable call melody and volume adjustments. Language selection, simplified menu or intercom disable.

slide-12
SLIDE 12

Características principales: Memory module – MM-GB2

  • Connected directly to the FA-GB2 power supply.
  • Records all coming calls from the entry panel.
  • Video composite output with trigger signal.
  • Test buttons to check the recorded videos.
  • Possibility to connect 2 extra cameras CAM-GB2 to this module.
  • Available only for “Villa mode” and for Vesta 7inch. monitors.

Mains

MM-GB2

2 2 2 2

FA-GB2 MM-GB2 CAM-GB2 CAM-GB2

slide-13
SLIDE 13

Call transfer module – GSM-GB2

  • One unit for all the apartment monitors from the system.
  • To be connected at any point of the installation (BUS-in BUS-out).
  • SIM card slot for the GSM call forwarding.
  • Supplied with a small antena.
  • Each monitor can choose its own call divert number.
  • Can be set in three modes: Divert always, no divert, divert if no answer.
  • Buttons for testing purposes. Network status and test call.

Ant

GSM-GB2 FA-GB2

GSM-GB2

2 2 2

slide-14
SLIDE 14

Características principales: Diagrams – Villa mode

Mains GSM-GB2 VESTA DP-GB2 CAM-GB2 MM-GB2 FA-GB2 THERA THERA Antena EL632/GB2 EL632/GB2 EL632/GB2 EL632/GB2 CAM-GB2 DP-GB2 VESTA

2 2 2 2 2 2 2 2 2 2

slide-15
SLIDE 15

Características principales: Diagrams – building mode

Mains GSM-GB2 THERA VESTA DP-GB2 FA-GB2 VESTA THERA Antena EL632/GB2 + EL610D

2 2 2 2 2 2 2 2 2

DP-GB2

slide-16
SLIDE 16

Características principales: References available

EL632/GB2: Door panel video module for GB2 system. DP-GB2: 4 inputs door panel switcher. D2L-GB2: 2 outputs floor video distributors. FA-GB2: Power supply. VESTA GB2: 3,9 inch handsfree monitor. THERA GB2: 7 inch handsfree monitor. MM-GB2: Memory module. CAM-GB2: 2 wires extra camera to be conected to MM-GB2. GSM-GB2: Call transfer unit through GSM. N5110/Vesta: Kit with Nexa aluminium and Vesta monitor. N5220/Vesta: Kit with Nexa aluminium and 2 units of Vesta monitor. NX5110/Thera: Kit with Nexa INOX and Thera monitor. NX5220/Thera: Kit with Nexa INOX and 2 units of Thera monitor.

slide-17
SLIDE 17

Características principales: Coming UP

RD-GB2: Digital repeater for GB2. T-562:Tekna audio handset for GB2. Surface Panel: Surface panel in a compact format for villa kits. D-CAM-GB2: 4 inputs for analogue CCTV cameras.

slide-18
SLIDE 18

Thanks for your attention!!
