Bus Ramps Public Outreach Presentation
September 10, 2014
1
CM/GC: Webcor -Obayashi Contractor: Shimmick Construction Construction Oversight: Turner Construction Owner: TJPA
Bus Ramp Team
2
Bus Ramps Public Outreach Presentation September 10, 2014 1 Bus - - PowerPoint PPT Presentation
Bus Ramps Public Outreach Presentation September 10, 2014 1 Bus - - PowerPoint PPT Presentation
Bus Ramps Public Outreach Presentation September 10, 2014 1 Bus Ramp Team Webcor -Obayashi CM/GC: Shimmick Construction Contractor: Construction Turner Construction Oversight: TJPA Owner: 2 Bus Ramp Scope of Work Bus Ramps Overall
SLIDE 2
SLIDE 3
Bus Ramps Overall Site Plan
Bus Ramp Scope of Work
3
SLIDE 4
Bus Ramps Alignment
Bus Ramp Project Scope of Work
Howard St. 4
SLIDE 5
Bus Ramps Overall Site Plan
Bus Ramp Scope of Work
5
SLIDE 6
Bus Ramp Timeline Summary
Demolition and CIDH Drilled Piles Substructures CIDH Drilled Piles, Foundations, Bents etc. Cable Stay Bridge Overhead Concrete Viaduct Bus Ramp Lights, paving and finishes
SLIDE 7
Bus Ramp Demolition
7
SLIDE 8
CIDH Pile Equipment Staging
- (17) CIDH piles
- 8 ft. & 9 ft. diameters
- Length 65-150 ft.
8
SLIDE 9
CIDH Pile Installation
CIDH starter casing installation CIDH rebar cage installation
9
SLIDE 10
Tehama and Howard St. CIDH Piles
New CIDH Piles
Tehama St. Howard St. CIDH Pile Foundation 10
SLIDE 11
Folsom St. and Clementina St. CIDH Piles
New CIDH Piles
Folsom St. Clementina St. 11
SLIDE 12
Cast In Drilled Hole (CIDH) Piles
Bus Ramp Construction - Cast In Drilled Hole Piles
Lot Location CIDH Piles Qty.
- Typ. 9 foot
diameter- Pile Depth Target Start Date Target End Date H Clementina -Tehama 5 90-100 ft. 10/1/2014 10/27/2014 I Clementina -Folsom 5 75-100 ft. 10/28/2014 11/30/2014 A Folsom- Harrison 1 < 65 ft. 12/1/2014 12/7/2014 G Tehama-Howard 6 120-150 ft. 12/8/2014 1/18/2015 12
SLIDE 13
Bus Ramp Project Underground Construction Hours
Permitted Hours of Demolition: Monday - Friday 13 Hours per day Saturday 7AM - 8PM No Sunday. Permitted Hours of CIDH Piers Monday - Friday : 24 Hours per day Saturday 7AM - 11PM No Sunday.
13
SLIDE 14
Tehama St. and Howard St. Overcrossings
Bridge Pylon 9 (2) Barrette Piles
Tehama St. Howard St. Barrette Pile Foundation 14
SLIDE 15
Barrette Pile Equipment Howard and Tehama St.
15
SLIDE 16
Bridge Pylon 9 Barrette Pile Installation
Slurry batch plant Excavation Panel cage
16
SLIDE 17
Bridge Pylon 9 Barrette Pile Installation
Barrette Pile Schematic
17
SLIDE 18
Bus Ramp Concrete Viaduct
Howard St. Clementina Harrison Folsom Tehama Concrete Viaduct connects to Cable Stay Bridge at Howard Street
18
SLIDE 19
Bus Ramp Concrete Viaduct
Tehama St. Howard St. Folsom St. Clementina St. Natoma St.
19
SLIDE 20
Bus Ramp Overcrossing Viaduct Falsework
Typical roadway falsework Typical roadway falsework
20
SLIDE 21
Concrete Viaduct and Overcrossings
- Bay Bridge off-ramp to Transbay Transit Center :
1. Tehama Overcrossing (Frame 3): Dec. 2014 – June 2015 2. Clementina Overcross (Frame 2): April 2015 – Feb. 2016 3. Bay Bridge Off-ramp (Essex): May 2015 – Dec. 2015 4. Folsom St. Overcross (Frame 1): Sept. 2015 – Feb. 2016 5. Howard St. Superstructure (Frame 4): Dec. 2014 –Feb. 2016 6. Connection to Transit Center( Frame 5): Jan. 2016 –May. 2016
21
SLIDE 22
Bus Ramp Project Construction Hours
Permitted Hours of Demolition: Monday - Friday 13 Hours per day Saturday 7AM - 8PM No Sunday. Permitted Hours of CIDH Piers Monday - Friday : 24 Hours per day Saturday 7AM - 11PM No Sunday. Permitted Hours of Falsework and Viaduct Construction: Monday - Friday Hours TBD (will require some 24 hour per day at overcrossings) Saturday 7AM-8PM No Sunday.
22
SLIDE 23
Bay Bridge/Harrison Ave Concrete Viaduct
Construction Schedule Bay Bridge Off-ramp:
- Harrison St. Demolition: Oct. 2014 – Dec. 2014
- CIDH Piles( 3) 7 ft. diameter: Dec. 2014 – Feb. 2015
- CIDH Piles (8) 24” diameter: Dec. 2014 – Feb. 2015
- Abutment Construction: Jan. 2015 - May 2015
- Harrison St. AWSS Utility Relocate: Dec. 2014–June 2015
- Harrison St. Superstructure Viaduct: May 2015- Dec. 2015
23
SLIDE 24
Harrison St. Retaining Walls
Bus Ramp New Foundations
Harrison St. 24
SLIDE 25
Harrison St. Foundations
Bus Ramps New Foundations
25
SLIDE 26
Howard Street Cable Stay Bridge
Cable Stay Bridge Construction Schedule
Howard Street – Frame 4 Cable Stayed Bridge:
- Demolition: June 2014 - October 2014
- Substructure: June 2014 - October 2014
- Bridge Pylon 9: October 2014 – June 2015
- Superstructure: December 2014 –November 2015
- Cable Installation: Sept. 2015 – February 2016
Bridge Connection Frame 5 to Transit Center:
- West Connection: Jan. 2016 – May 2016
- East Connection: Feb. 2016 – May 2016
26
SLIDE 27
SLIDE 28
Cable Stayed Bridge and Green Space
28
SLIDE 29
FOLSOM ST. HOWARD ST. 1ST ST. TEHAMA ST. CLEMENTINA ST. ESSEX ST. TRANSBAY TRANSIT CENTER
29
Overhead Ramps
Under-Ramp Park
29
SLIDE 30
FOLSOM ST. HOWARD ST. 1ST ST. TEHAMA ST. CLEMENTINA ST. ESSEX ST.
30
Illustrative Plan
Under-Ramp Park
30
SLIDE 31
Questions?
