1 8 0 3 H A L L A M D R I V E DESIGN DEVELOPMENT PRESENTATION 12.05.2019 D E S I G N C O N C E P T E X T E R I O R Facia Paint SW7048 Urbane Bronze Exterior Stone Exterior Siding Stucco Color SW7015 Repose Gray Front Door- Right

SLIDE 1

1 8 0 3 H A L L A M D R I V E

DESIGN DEVELOPMENT PRESENTATION 12.05.2019

SLIDE 2

D E S I G N C O N C E P T

SLIDE 3

E X T E R I O R

Front Door- Right Hinged Full Lite Finish: Dark Bronze Facia Paint SW7048 Urbane Bronze Stucco Color SW7015 Repose Gray Driveway Pavers Exterior Stone Exterior Siding

SLIDE 4

G E N E R A L / L I V I N G

Typical Door Hardware Typical second floor door- white painted single panel Satin Nickel Finish 7.5” H Baseboard

Typ. Wood Floors

SLIDE 5

S T A I R C A S E

Glass railing with stained handrail and steel stringers

SLIDE 6

F A M I L Y R O O M

SLIDE 7

F A M I L Y R O O M - F I R E P L A C E

Montigo – Prodigy Series 72”W x 20”H

SLIDE 8

37”Diam. X 36”H 78” Max Height Carbide Black and Polished Nickel 36”Diam. X 3.5” Shade H 12’ Field Cuttable Cable Matte Black and Weathered Oak

E N T R Y / F A M I L Y / D I N I N G

55”L x 28”W x 14.75”H Black

SLIDE 9

37”Diam. X 36”H 78” Max Height Carbide Black and Polished Nickel 36”Diam. X 3.5” Shade H 12’ Field Cuttable Cable Matte Black and Weathered Oak

E N T R Y / F A M I L Y / D I N I N G

48”L x 12.9”W x 48”H Black

SLIDE 10

Island Countertop Calacatta Boheme, 3cm Perimeter Cabinetry Stain Island Cabinetry Paint Backsplash

Air Switch Matte Black Single Basin Undermount Sink 18G Stainless Steel 30” x 18” x 10”

Perimeter Countertop 3cm, Honed

M A I N K I T C H E N

Main Sink Faucet Matte Black Finish

Island Pendants

Qty. 3

SLIDE 11

M A I N K I T C H E N

SLIDE 12

C H E F ’ S K I T C H E N

Chef’s Kitchen Sink Faucet Matte Black Finish Air Switch Matte Black Single Basin Undermount Sink 18G Stainless Steel 30” x 18” x 10” Glass Tile Backsplash Glass Tile Backsplash Island Cabinetry Paint White Countertop 3cm, Honed

SLIDE 13

M A S T E R B A T H

Marble Floor Shower Floor Tile Shower Tile, 6 x 6 - reselect Light Stained Cabinetry 3cm Calacatta Diamond Countertop and Shower Bench Top, Polished Wall Paint

SLIDE 14

M A S T E R B A T H

Deck Mounted Faucet Satin Stainless 7-3/8” Spout Height Lever Handle White Undermount Sink Interior Dimensions: 20-7/8” x 13-1/8” x 5-3/4” Finish: White Wall Sconce 4 ¼” W x 2 ¾” D x 29 ¾” H Satin Nickel

SLIDE 15

M A S T E R B A T H S H O W E R

Recessed Rainhead Brushed Stainless Steel 11-1/4”W x 7-7/8”D Rain Jet Showerhead Satin Stainless 2.36” Diam. Thermostatic with Two Volume Controls Cross Handles Satin Stainless 2.56” Diam. Wall-Mount Handshower Satin Stainless Tile Over Drain 5” Square Satin Stainless Wall-Mount Tub Filler Satin Stainless 6.7” Projection Lever Handle Rain Jet Showerhead Satin Stainless 2.36” Diam. Thermostatic with Two Volume Controls Cross Handles Satin Stainless 2.56” Diam. Freestanding Tub Solid Surface 66” L x 32” W x 23” H

SLIDE 16

P O W D E R B A T H

Wall Mounted Faucet Polished Chrome 6-1/4” Projection White Undermount Sink Interior Dimensions: 18-1/8” x 12-3/8” x 5-3/4” Finish: White Wall Paint Mitered Drop Edge Countertop 3cm, Honed

Typ. Wood Floors

Backlit Vanity Mirror 12 x 36 Wall Tile

SLIDE 17

B A T H 2

Pewter 9-7/8” Spout Height Pressure Balance Shower Set Pewter 6” Diam. Trim 12 x 24 Floor Tile 2 x 6 Shower Wall Tile Stained Cabinet 3cm Countertop Honed Wall Sconces Graphite White Undermount Sink 18-1/8” x 12-3/8” x 5-3/4”

SLIDE 18

B A T H 3

White Undermount Sink 18-1/8” x 12-3/8” x 5-3/4” Single Lever Lavatory Faucet Burnished Nickel 6” Spout Height Pressure Balance Shower Set Burnished Nickel 6” Diam. Trim 12 x 24 Floor Tile 7 x 7 Shower Wall Tile 3cm Countertop Honed Cabinet Paint Wall Sconces Brushed Steel

Qty. 2

SLIDE 19

B A T H 4

White Undermount Sink 18-1/8” x 12-3/8” x 5-3/4” Pressure Balance Shower Set Matte Black 6” Diam. Trim 14 x 16 Hex Floor Tile Stained Cabinet 3cm, Countertop, Polished 2 x 6 Wall Tile Wall Sconces Bronze Finish

Qty. 2

Sink Faucet Matte Black 9-7/8” Spout Height Knurled Handle

SLIDE 20

B A T H 5

Sink Faucet Polished Chrome 8-1/2” Spout Height White Undermount Sink 18-1/8” x 12-3/8” x 5-3/4” Alcove Tub 60” x 32” x 19-1/4”H Pressure Balance Tub/Shower Set Polished Chrome 7-1/2” Projection Lever Handle 3 x 12 Picket Tub Wall Tile 12 x 24 Floor Tile 3cm, Countertop, Honed Cabinet Paint Wall Sconces Polished Chrome

SLIDE 21

B A T H 6

Sink Faucet Pewter 8-1/2” Spout Height Blade Cross Handle White Undermount Sink 18-1/8” x 12-3/8” x 5-3/4” Handshower Pewter Thermostatic Trim with Vol. Control Pewter 12 x 24 Floor Tile 3 x 6 Wall Tile

Wall Paint Cabinet Paint

3cm, Countertop, Polished

24” Sconce Satin Black

SLIDE 22

P O O L B A T H

8 ¾” x 10” Wall Tile 12 x 24 Floor Tile 3cm Countertop Cabinet Paint White Undermount Sink 8-1/8” x 12-3/8” x 5-3/4” Single Lever Lavatory Faucet Satin White 6” Spout Height Pressure Balance Shower Set Satin White 6” Diam. Trim Reselect - Pendant

SLIDE 23

U T I L I T Y R O O M

Brushed Nickel Finish 14-1/8” H Single Bowl Undermount Brushed Stainless Steel 18G 23” x 18” x 10” White Countertop 3cm, Honed 3 x 24 Matte Chevron Floor Tile 3 x 12 Matte Wall Tile

Cabinet Paint

SLIDE 24

G A M E R O O M W E T B A R

Wet Bar Sink Faucet Matte Black Finish Single Bowl Bar Sink Concrete - Slate Interior: 13” x 13” x 7.25” Exterior: 15” x 15” x 8” Brilliant Black Quartzite Countertop Splash Wall Tile Stained Cabinet

SLIDE 25

P O W D E R B A T H 2

Wall Mounted Faucet Polished Chrome 6-1/4” Projection White Undermount Sink 18-1/8” x 12-3/8” x 5-3/4” Finish: White Vanity Light Polished Nickel

Qty. 1

Brilliant Black Quartzite Countertop 12 x 24 Floor Tile Stained Cabinet

SLIDE 26

S T U D I O B A T H 8

White Undermount Sink 18-1/8” x 12-3/8” x 5-3/4” Matte Black Finish 6-3/4” Spout Height Lift Drain Included Pressure Balance Shower Set Matte Black Finish 6” Square 12 x 24 Floor Tile 8-1/2 x 10 Hex Wall Tile Matte

Cabinet Paint

3cm Countertop Honed Bath Pendant

SLIDE 27

P O O L

Pool Waterline Tile

SLIDE 28

P O O L

Pool Waterline Tile Pool Plaster French Gray Mini- StoneScapes Design Inspiration Gray lueder coping Tile Color

SLIDE 29

P O O L

Pool Plaster French Gray-QuartzScapes Design Inspiration Gray lueder coping Pool Waterline Tile Tile Color

SLIDE 30

O U T D O O R K I T C H E N

Utility Room Sink Faucet Polished Chrome Finish 14-1/8” H Single Bowl Undermount Sink Brushed Stainless Steel 18G 23” x 18” x 10” Air Switch Satin Nickel 12 x 24 Floor Tile 3cm Countertop Wall Paint

SLIDE 31

SLIDE 32

K I T C H E N – S C H E M E A

Combination of paint and stain grain cabinetry, mid-tone natural stone Stained cabinetry with waterfall stone top on the island

SLIDE 33

K I T C H E N – S C H E M E B

Slab-front warm gray cabinetry; natural stone Modern pendants with warm metal accents Slab-front warm gray cabinetry; waterfall natural stone

SLIDE 34

D I N I N G R O O M

SLIDE 35

S T U D Y 2

Study 2 bath inspiration Study 2 wall treatment inspiration

SLIDE 36

C H E F ’ S K I T C H E N

Chef’s Kitchen Sink Faucet Matte Black Finish Air Switch Matte Black Single Basin Undermount Sink 18G Stainless Steel 30” x 18” x 10” Painted glass backsplash 9 x 18 Glass Tile
