FAAC J Series Bollards Table of Contents FAAC J Series Concept - - PowerPoint PPT Presentation

FAAC J Series Bollards

• FAAC J Series “Concept”
• FAAC Offer
• Vehicular access control in RESIDENTIAL applications
• Vehicular access control in TRAFFIC applications
• PERIMETER PROTECTION applications

Table of Contents

FAAC approached the bollards’ business with an open minded attitude and innovative spirit, introducing a sharp technical landmarks in FAAC R&D activity on bollards. The latter generated a number of “technical keywords” that have been implemented in all FAAC J Series bollards. The most relevant keywords are:

• Integrated hydraulic unit
• FAAC hydraulic technology
• Easy maintenance

and today represents clear trademarks of FAAC offer

FAAC J Series “Concept”

FAAC J series HA bollards are all conceived with an integrated hydraulic unit On the contrary, many competitors place the hydraulic pump (and EFO accumulator) in a deported cabinet FAAC integrated hydraulic concept Deported hydraulic concept

FAAC J Series “Concept”



Integrated hydraulic unit

FAAC Competition No need to place a voluminous cabinet near the bollard -max 10m distance to avoid pressure loss  No need of free spot to place the cabinet  Cost saving -cabinet cost and installation  No need to protect the cabinet from tampering/vandalism

FAAC J Series “Concept”



Integrated hydraulic unit

FAAC J Series “Concept”



Integrated hydraulic unit

No need to place underground pipes to connect hydraulic unit (cabinet) and piston (cylinder)  No need to trace back oil leakage along underground pipes  No risks of damages due to the soil natural movements (or sabotage)

FAAC Hydraulic technology is an outstanding excellence and represent the core component of J Series Bollards

FAAC J Series “Concept”



FAAC hydraulic technology

FAAC J Series “Concept”



Easy maintenance

FAAC J Series bollards are specifically designed to ease maintenance operations. Access to core components is very easy In FAAC J Series bollard the maintenance operations can be realized with the bollard still in place - no need of forklifts

• FAAC J Series “Concept”
• FAAC Offer
• Vehicular access control in RESIDENTIAL applications
• Vehicular access control in TRAFFIC applications
• PERIMETER PROTECTION applications

Table of Contents

VEHICULAR ACCESS CONTROL IN TRAFFIC APPLICATIONS PERIMETER PROTECTION APPLICATIONS

FAAC Offer

BUSINESS SECTORS VEHICULAR ACCESS CONTROL IN RESIDENTIAL APPLICATIONS

VEHICULAR ACCESS CONTROL IN TRAFFIC APPLICATIONS PERIMETER PROTECTION APPLICATIONS

FAAC Offer

BUSINESS SECTORS VEHICULAR ACCESS CONTROL IN RESIDENTIAL APPLICATIONS BUSINESS SECTORS VEHICULAR ACCESS CONTROL IN RESIDENTIAL APPLICATIONS

FAAC Offer – RESIDENTIAL applications

J200 RANGE: J200HA - Hydraulic Automatic

• J200HA H600 Painted steel
• J200HA H600 Satin finish stainless steel

J200SA - Semi-Automatic

• J200SA H600 Painted steel
• J200SA H600 Satin finish stainless steel

J200F - Fixed

• J200F H600 Painted steel
• J200F H600 Satin finish stainless

FAAC Offer – RESIDENTIAL applications J200HA Hydraulic Automatic

Self sustaining structure: J200 bollards do not require the usage of a pit. The bollard installation is realized in a single step. This allows a huge cost saving in terms of civil works

FAAC Offer – RESIDENTIAL applications J200HA Hydraulic Automatic

Configurable accessories set, for an easier price optimization: To obtain an even more competitive price positioning, J200 HA is supplied with a light product configuration. All optional are available as separated accessories. PIT HEATER KIT ELECTRO VALVE + PRESSURE SWITCH BUZZER LED LIGHTS KIT

FAAC Offer – RESIDENTIAL applications J200HA Hydraulic Automatic

Easy transportation and stock management thanks to the product rationalization: J200HA is designed as a complete product in a single selling reference. The frame is a self-supporting structure, therefore does not require the usage of an additional pit. Moreover the low weight allows an easy transportation and laying

FAAC Offer – RESIDENTIAL applications J200SA Semi-Automatic

J200SA Semi-Automatic represents FAAC offer for the traffic regulation in residential areas difficult to wire

FAAC Offer – RESIDENTIAL applications J200F Static

J200 Static (F) represents FAAC offer to permanently close a passage or to complete the installation with retractable models in full respect of the aesthetic coherency between static and retractable models

VEHICULAR ACCESS CONTROL IN TRAFFIC APPLICATIONS PERIMETER PROTECTION APPLICATIONS

FAAC Offer

BUSINESS SECTORS VEHICULAR ACCESS CONTROL IN RESIDENTIAL APPLICATIONS VEHICULAR ACCESS CONTROL IN TRAFFIC APPLICATIONS BUSINESS SECTORS

FAAC Offer – TRAFFIC applications

J275 RANGE: J275HA V2- Hydraulic Automatic

• J275HA V2 H600 Painted steel
• J275HA V2 H600 Satin finish stainless steel
• J275HA V2 H800 Painted steel
• J275HA V2 H800 Satin finish stainless steel

J275SA - Semi-Automatic

• J275SA H600 Painted steel
• J275SA H600 Satin finish stainless steel

J275F - Static

• J275F H600 Painted steel
• J275F H600 Satin finish stainless steel
• J275F H800 Painted steel
• J275F H800 Satin finish stainless steel

In J275 HA V2 bollard the hydraulic unit is positioned upside down within the bollard cylinder The core components are therefore kept away from stagnating water and dirt

• Positioning of the Hydraulic unit

within the cylinder itself

FAAC Offer – TRAFFIC applications J275HA V2 Hydraulic Automatic

FAAC Offer – TRAFFIC applications J275HA V2 Hydraulic Automatic

• Gentle stop function

J275 HA V2 are supplied with an hydraulic device to command an automatic slowdown in the last 3cm of the lowering movement This guarantees a soft impact while arriving on the low limit and therefore:

• Lower noise while opening
• Less mechanical stress on the system

FAAC Offer – TRAFFIC applications J275HA V2 Hydraulic Automatic

• Automatic detection and reverse if an
• bstacle (i.e. a car) is hit while rising

FAAC Offer – TRAFFIC applications J275HA V2 Hydraulic Automatic

• Automatic lowering in case of blackout:

In case of blackout, J275 HA V2 automatically lowers, to leave free access to emergency vehicles NOTE: this option can be disabled, if not required

FAAC Offer – TRAFFIC applications J275SA Semi-Automatic

J275SA Semi-Automatic bollard represents FAAC offer to regulate the traffic in areas difficult to wire

J275F represents FAAC offer to complete the installation with retractable models in full respect of the aesthetic coherency between fixed and retractable models

FAAC Offer – TRAFFIC applications J275F Static

FAAC Offer

VEHICULAR ACCESS CONTROL IN TRAFFIC APPLICATIONS PERIMETER PROTECTION APPLICATIONS BUSINESS SECTORS VEHICULAR ACCESS CONTROL IN RESIDENTIAL APPLICATIONS PERIMETER PROTECTION APPLICATIONS BUSINESS SECTORS

The current social environment is generating a low level of perceived security It’s becoming usual to include adequate perimeter protection systems in the projects of big buildings, infrastructures and public areas, not only sensitive sites, like military or govern buildings.

FAAC Offer – PERIMETER PROTECTION

Source: red24.com

FAAC Offer – PERIMETER PROTECTION

The generic need for Perimeter protection moved toward a «structuration and standardization» of the need itself Two countries specifically –UK and USA- worked on the standardization

FAAC Offer – PERIMETER PROTECTION

The U.S. Department of State (DOS) Bureau of Diplomatic Security (DS) had a precise need: defines the requirements for the protection of the perimeter of DOS facilities (military and diplomatic sites) against vehicular attacks. For this reason, in 1985 the SD-STD-02.01 standard was issued, defining:

• A precise way of testing perimeter barriers and

gates

• A precise way of expressing the results

K4, K8, K12 quickly became usual terms on the perimeter security market

FAAC Offer – PERIMETER PROTECTION

Then in 2007 ASTM (American Society for Testing and Materials) released a new standard that incorporated and replaced the former SD-STD-02.01 standard F 2656 Standard Test Method for Vehicle Crash Testing of Perimeter Barriers F 2656 Standard introduces:

• More classes of resistance
• The penetration rate value

The former K4, K8, K12 ranks became M30, M40 M50 ranks in ASTM standard

FAAC Offer – PERIMETER PROTECTION

The UK Government’s National Security Advice Center (NSAC) –then merged into Center for the Protection of National Infrastructures (CPNI)- defined the guidelines for the protection

• f national infrastructures against terroristic attacks and cyber

threats. For this reason commissioned to Transport Research Laboratory (TRL) and British Standard Institute (BSI) the development of a standard. In 2005 the Publicly Available Specification was issued (PAS 68) Impact test specifications for vehicle security barrier systems Again a mean to define:

• A precise way of testing HVM barriers (Hostile

Vehicle Mitigation)

• A precise way of expressing the results

FAAC Offer – PERIMETER PROTECTION

Nowadays there are 2 similar standard , with similar targets: PAS 68:2013 - Impact test specifications for vehicle security barrier systems ASTM F2656-15- Standard Test Method for Vehicle Security Barriers (Formerly DOS SD-STD-02.01)

FAAC Offer – PERIMETER PROTECTION

Test Vechicle classification Test classification kg-km/h Test Speed km/h Equivalent tests speed (nominal) (mph) Impact angle (°) (±2°) 1500-16 16±2 10 1500-32 32±2 20 1500-48 48±3 30 1500-64 64±3 40 1500-80 80±5 50 1500-96 96±5 60 1500-112 112±5 70 2500-16 16±2 10 2500-32 32±2 20 2500-48 48±3 30 2500-64 64±3 40 2500-80 80±5 50 2500-96 96±5 60 2500-112 112±5 70 3500-16 16±2 10 3500-32 32±2 20 3500-48 48±3 30 3500-64 64±3 40 3500-80 80±5 50 3500-96 96±5 60 7500-16 16±2 10 7500-32 32±2 20 7500-48 48±3 30 7500-64 64±3 40 7500-80 80±5 50 7500-96 96±5 60 7500-16 16±2 10 7500-32 32±2 20 7500-48 48±3 30 7500-64 64±3 40 7500-80 80±5 50 30000-16 16±2 10 30000-32 32±2 20 30000-48 48±3 30 30000-64 64±3 40 30000-80 80±5 50 Car 4x4 pick-up (crew cab design) M1 N1G 0° to 90° with 5° intervals 0° to 90° with 5° intervals Day cab vehicles 0° to 90° with 5° intervals 3500kg flat bed (RWD) N1 7500kg flat bed (RWD) N2 0° to 90° with 5° intervals 18000kg 2-axle rigid N3 0° to 90° with 5° intervals 32000kg 4-axle rigid N3 0° to 90° with 5° intervals

ASTM F2656-15 PAS 68: 2013

Test Vechicle classification Mass (kg) Condition Designation Speed (km/h) Nominal Impact Energy (KJ) 1.100 SC30 50 106 1.100 SC40 65 179 1.100 SC50 80 271 1.100 SC60 100 424 2.100 FS30 50 203 2.100 FS40 65 342 2.100 FS50 80 519 2.100 FS60 100 810 2.300 PU30 50 222 2.300 PU40 65 375 2.300 PU50 80 568 2.300 PU60 100 887 6.800 M30 50 656 6.800 M40 65 1.110 6.800 M50 80 1.680 7.200 C730 50 673 7.200 C740 65 1.199 7.200 C750 80 1.872 29.500 H30 50 2.845 29.500 H40 65 4.810 29.500 H50 80 7.280

Heavy goods vehicle (H)

ASTM 2656-15

Small passenger car (SC) Full Size Sedan (FS) Pickup truck (PU) Standard Test Truck (M) Class 7 Cabover (C7)

FAAC Offer – PERIMETER PROTECTION

ES: M30 P1 Capable of withstanding impact by a: Medium Duty Truck M (6.800kg) Impact speed : 30 mph Penetration rate: P1 <1m beyond the original position of the rear face of the bollard

ASTM F2656-15

1 2 3 Test vehicle Classification Test Speed (mph) Penetration Rate

FAAC Offer – PERIMETER PROTECTION

PAS 68: 2013

ES: PAS 68: 2013 Fixed Bollard V/7500 (N2)/48/90:1.7/5.2 Vehicle security Barrier system tipe: Fixed Bollard Tested using: Vehicle impact method Capable of withstanding impact by a: 7.500kg day cab vehicle -vehicle classification N2 Impact speed: 48km/h Impact angle: 90° Vehicle penetration: 1,7m beyond the original position of the rear face of the bollard Major debris landed at 5,2m beyond the original position of the rear face of the bollard

FAAC Offer – PERIMETER PROTECTION

IWA 14-1:2013 - Vehicle security barriers has been released trying to unify US and UK standards and get to a supranational standard

ASTM F2656-15 PAS 68: 2013 IWA 14-1: 2013 Vehicle Type Mass Vehicle Type Mass Vehicle Type Mass

(SC) Small car 1.100kg 1.100kg ±20kg (M1) Car 1.500kg 1.500kg ±50kg (M1) Car 1.500kg 1.500kg ±75kg (FS) Full Size Sedan 2.300kg 2.100kg ±50kg (PU) Pickup truck 2.300kg 2.300kg ±50kg (N1G) 4x4 pick-up 2.500kg 2.500kg ±50kg (N1G) 4x4 pick-up 2.500kg 2.500kg ±75kg (N1) Day cab flat bed 3.500kg 3.500kg ±100kg (N1) Day cab flat bed 3.500kg 3.500kg ±100kg (M) Standard Test Truck 6.800kg 6.800kg ±140kg (N2) Day cab flat bed 7.500kg 7.500kg ±150kg (N2A) Day cab flat bed 7.500kg 7.200kg ±400kg (C7) Class 7 Cabover 13.500kg 7.200kg ±150kg (N2B) Day cab flat bed 12.000kg 7.200kg ±400kg (N3) Day cab 2-axle rigid 18.000kg 7.500kg ±150kg (N3C) Day cab 2-axle rigid 18.000kg 7.200kg ±400kg (N3D) Day cab 2-axle rigid 15.000kg 12.000kg ±400kg (H) Heavy goods vehicle 29.500kg 29.500kg ±590kg (N3E) Day cab 3-axle rigid 29.500kg 24.000kg ±400kg (N3) Day cab 4-axle rigid 32.000kg 30.000kg ±600kg (N3F) Day cab 4-axle rigid 32.000kg 30.000kg ±400kg

FAAC Offer – PERIMETER PROTECTION

To match the different requirements of perimeter protection, FAAC segmented his anti- crash offer in 3 different lines: J355 M50 J355 M30 J275 2K

Ø275mm H800mm Sp.12mm Ø355mm H1000mm Sp.16mm Ø355mm H1200mm Sp.30mm

FAAC Offer – PERIMETER PROTECTION

300000 600000 900000 1200000 1500000 1800000 2100000

287.000 414.000 656.000 1.852.000

CRASH RESISTANCE (J) IN SINGLE UNIT CONFIGURATION

STAINLESS STEEL PAINTEDS STEEL

J355 M50 J355 M30 J275 2K

FAAC Offer – PERIMETER PROTECTION

287.000 414.000 656.000 1.852.000

Crash Resistance:

Car (1.100kg) driving at:

• 80km/h
• 100km/h (Inox)

Truck (6.800kg) driving at:

• 50km/h

Truck (7.500kg) driving at:

• 80km/h

J355 M50 J355 M30 J275 2K

FAAC Offer – PERIMETER PROTECTION

J275 2K

287.000 414.000 1.852.000

Dual installation of J275 2K bollards guarantee a resistance class M30, therefore the capability to stop a 6.800kg truck driving at the speed of 50km/h

Truck (6.800kg) driving at:

• 50km/h

Truck (7.500kg) driving at:

• 80km/h

J355 M50 J355 M30 J275 2K Dual install.

656.000 Truck (6.800kg) driving at:

• 50km/h

656.000

FAAC Offer – PERIMETER PROTECTION

J355 M50 J355 M30 J275 2K

Truck(6.800kg) at: 50km/h Dual installation Truck(6.800kg) at: 50km/h Truck (7.500kg) at: 80km/h 656.000J 656.000J 1.852.000J ASTM F2656 Dynamic Impact Simulation ASTM F2656 Crash Test PAS68 and IWA 14-1 Crash Test 800mm 1.000mm 1.200mm

Tested according to: Able to arrest a: Equivalent impact energy: Cylinder Height: Cylinder wall thickness:

12mm 16mm 30mm

FAAC Offer – PERIMETER PROTECTION

J355 M50 J355 M30 J275 2K

J275HA 2K H800 PAINTED STEEL J275HA 2K H800 STAINLESS STEEL J355HA M30-P1 H1.000 PAINTED STEEL J355HA M30-P1 H1.000 ST. STEEL J355HA M50 H1.200 PAINTED STEEL J355HA M50 H1.200 ST. STEEL

Hydraulic Automatic range (HA) Hydraulic Automatic EFO range (HA-EFO) Static range (F)

J275F 2K H800 PAINTED STEEL J275F 2K H800 STAINLESS STEEL J355F M30-P1 H1.000 PAINTED STEEL J355F M30-P1 H1.000 ST. STEEL J355F M50 H1.200 PAINTED STEEL J355F M50 H1.200 ST. STEEL J355HA M30-P1 H1.000 PA.STEEL_EFO J355HA M30-P1 H1.000 ST.STEEL_EFO J355HA M50 H1.200 PA.STEEL_EFO J355HA M50 H1.200 ST.STEEL_EFO

FAAC Offer – PERIMETER PROTECTION

J275 2K RANGE J275HA 2K - Hydraulic Automatic

• J275HA 2K H800 Painted Steel
• J275HA 2K H800 Satin finish stainless steel

J275F 2K H800 - Static

• J275F 2K H800 Painted Steel
• J275F 2K H800 Satin finish stainless steel

FAAC Offer – PERIMETER PROTECTION

J275 2K bollard resistance have been verified by the notified laboratory Karagozian&Case by means of a dynamic impact simulation according to ASTM F2656 standard

FAAC Offer – PERIMETER PROTECTION J275HA 2K Hydraulic Automatic

• Tested in Dual installation:

The detected resistance in dual installations is ranked as M30 class = able to stop a 6800 Kg truck driving at ~50 Km/h (~30 Mph)

FAAC Offer – PERIMETER PROTECTION J275HA 2K Hydraulic Automatic

• Tested in Dual installation:

J275HA 2K replicates the technical solution already implemented in J275HA V2, but focused

• n the usage for perimeter protection.
• J275HA V2 Re-engineering

FAAC Offer – PERIMETER PROTECTION J275HA 2K Hydraulic Automatic

J275HA V2 and 2K share some of the most appreciated features, like:

• Hydraulic unit integrated within the cylinder
• Easy maintenance
• “Gentle Stop” function
• Emergency manual release

And also use the same installation complements:

• Pit
• Accessories (pit heater and control boards)
• Main spare parts
• j275HA V2 Re-engineering

FAAC Offer – PERIMETER PROTECTION J275HA 2K Hydraulic Automatic

The solution introduced specifically for the usage in Perimeter Security are:

• Higher thickness cylinder

To sustain impacts at high energy

FAAC Offer – PERIMETER PROTECTION J275HA 2K Hydraulic Automatic

• Reinforcement steel plate
• n the cylinder’s guide

The cylinder guide is reinforced with a steel plate to better sustain the impact and avoid deformations The solution introduced specifically for the usage in Perimeter Security are:

FAAC Offer – PERIMETER PROTECTION J275HA 2K Hydraulic Automatic

• High power hydraulic unit

To lift the thicker (heavier) cylinder The solution introduced specifically for the usage in Perimeter Security are:

FAAC Offer – PERIMETER PROTECTION J275HA 2K Hydraulic Automatic

• Anti-burglar head

The manual release access is protected by an armored lock with coded key. To avoid un- authorized lowering The solution introduced specifically for the usage in Perimeter Security are:

FAAC Offer – PERIMETER PROTECTION J275HA 2K Hydraulic Automatic

• Reinforced foundations

J275HA 2K bollard is supplied with dedicated instructions that explains in details how to realize the foundation cage to guarantee the declared impact resistance The solution introduced specifically for the usage in Perimeter Security are:

FAAC Offer – PERIMETER PROTECTION J275HA 2K Hydraulic Automatic

• Safety and pressure switch not

supplied These devices are not supplied by default like for J275HA V2 In fact they’re function is not aligned with perimeter security usage (those devices privilege safety against security) Their usage is possible (optional), but Not recommended The solution introduced specifically for the usage in Perimeter Security are:

FAAC Offer – PERIMETER PROTECTION J275HA 2K Hydraulic Automatic

J275F 2K replicates the technical features successfully employed in J355F:

• Flexibility of installation

The underground support structures of near J275F 2K bollards can be linked together to create unique or discrete perimeter barriers. This allows to adapt the installation to the peculiarities of the specific perimeter.

FAAC Offer – PERIMETER PROTECTION J275F 2K Static

• «Shallow Mount» concept

J275F 2K requires a minimal excavation depth; 270mm are sufficient to allocate the complete product and its reinforcing structure 270mm J275F 2K replicates the technical features successfully employed in J355F:

FAAC Offer – PERIMETER PROTECTION J275F 2K Static

J355 M30 RANGE J355HA M30-P1 – Hydraulic Automatic

• J355HA M30-P1 H1.000 Painted steel
• J355HA M30-P1 H1.000 Satin finish stainless steel

J355HA M30-P1 EFO – Hydraulic Automatic EFO (Emergency Fast Operation):

• J355HA M30-P1 H1.000 EFO Painted steel
• J355HA M30-P1 H1.000 EFO Satin finish stainless steel

J355F M30-P1 - Static

• J355F M30-P1 H1.000 Painted steel
• J355F M30-P1 H1.000 Satin finish stainless steel

FAAC Offer – PERIMETER PROTECTION

J355 M30-P1 has been certified in accordance with ASTM F2656 The crash test has been carried out and passed in a single unit configuration, with impact condition designations M30

• CERTIFIED Crash resistance in single unit configuration:

FAAC Offer – PERIMETER PROTECTION J355HA M30-P1 Hydraulic Automatic

M30 class resistance Impact with a 6800 Kg truck driving at ~50 Km/h (~30 Mph) Equivalent energy: 656.000j

• CERTIFIED Crash resistance in single unit configuration:

FAAC Offer – PERIMETER PROTECTION J355HA M30-P1 Hydraulic Automatic

Penetration limit for P1 class Reference Point

• 3m
• 4m

1m

• 1m

2m

• 2m

3m 4m 5m 6m 7m Reference Point Penetration Measure point

• 3m
• 4m

1m

• 1m

2m

• 2m

3m 4m 5m 6m 7m Detected Penetration

J355 M30-P1 bollard successfully passed the test and has been ranked at the top class penetration ranking (P1) P1 Penetration Rating

• CERTIFIED Crash resistance in single unit configuration:

FAAC Offer – PERIMETER PROTECTION J355HA M30-P1 Hydraulic Automatic

• CERTIFIED Crash resistance in single unit configuration:

FAAC Offer – PERIMETER PROTECTION J355HA M30-P1 Hydraulic Automatic

J355 M50 RANGE J355HA M50 - Automatic

• J355HA M50 H1.200 Painted steel
• J355HA M50 H1.200 Satin finish stainless steel

J355HA M50 - Automatic EFO (Emergency Fast Operation):

• J355HA M50 H1.200 EFO Painted steel
• J355HA M50 H1.200 EFO Satin finish stainless steel

J355F M50 - Static

• J355F M50 H1.200 Painted steel
• J355F M50 H1.200 Satin finish stainless steel

FAAC Offer – PERIMETER PROTECTION

J355 M50 has been certified in accordance with:

• PAS 68
• IWA 14-1:2013

The crash test has been carried out and passed in a single unit configuration, with performance classifications:

• PAS 68:2013 - V/7500[N3]/80/90:4.7/10.9
• IWA 14-1:2013 - V/7200[N3C]/80/90 :5.0
• CERTIFIED Crash resistance in single unit configuration:

FAAC Offer – PERIMETER PROTECTION J355HA M50 Hydraulic Automatic

PAS 68:2013 – V/7500[N3]/80/90:4.7/10.9

2-axle rigid Daily cab (7.500kg mass) at ~80 Km/h

Impact with a 18.000 Kg 2-axle rigid Daily cab (7.500kg mass), driving at a speed of ~80 Km/h (~50 Mph) Equivalent energy: 1.852.000j

• CERTIFIED Crash resistance in single unit configuration:

FAAC Offer – PERIMETER PROTECTION J355HA M50 Hydraulic Automatic

The penetration of the vehicle is measured, not simply ranked into classes, like for ASTM This value is the maximum detected distance between the leading edge of the load platform and the original rear face of the bollard

Reference Point Penetration Measure point

PAS 68:2013 – V/7500[N3]/80/90:4.7/10.9

1m

• 1m

2m

• 2m

3m 4m

• 3m
• 4m

5m 6m 7m

• 5m

10m11m

• CERTIFIED Crash resistance in single unit configuration:

FAAC Offer – PERIMETER PROTECTION J355HA M50 Hydraulic Automatic

Detected Penetration

The detected values for J355 M50 bollard resulted to be:

• Penetration: 4,7m
• Major debris distance: 10,9m

Reference Point Major debris distance

PAS 68:2013 – V/7500[N3]/80/90:4.7/10.9

1m

• 1m

2m

• 2m

3m 4m

• 3m
• 4m

5m 6m 7m

• 5m

10m11m

• CERTIFIED Crash resistance in single unit configuration:

FAAC Offer – PERIMETER PROTECTION J355HA M50 Hydraulic Automatic

J355HA E.F.O. -Emergency Fast Operation- versions are supplied with a dedicated hydraulic circuit to quickly rise the bollard in case of emergency This circuit commands the cylinder rise in ~1.5 (the standard rising speed is ~6s) and therefore guarantees an extra safety features for the protection of sensitive areas

FAAC Offer – PERIMETER PROTECTION E.F.O. (Emergency Fast Operation)

Control Valve Hydraulic Accumulator J355 bollards with E.F.O. option have an hydraulic accumulator integrated in the bollard structure and connected to a control valve During the standard functioning the accumulator is charged; 2/3 cycles are enough to fully charge it. In case of emergency, operating the control valve, the accumulator release oil with high pressure in the circuit to quickly rise the cylinder

FAAC Offer – PERIMETER PROTECTION E.F.O. (Emergency Fast Operation)

FAAC J355F bollards Crash resistance have been verified by the notified laboratory Karagozian&Case by means of a dynamic impact simulation according to ASTM F2656 standard

J355 SERIES: for Perimeter Security J355F Static

J355F M30-P1 bollard has been tested in dual installations with M30 class, which represents the capability to stop a 6800 Kg truck driving at ~50 Km/h,

J355 SERIES: for Perimeter Security J355F Static

J355F M50 bollard has been tested in triple installations with M50 class, which represents the capability to stop a 6800 Kg truck driving at ~80 Km/h.

J355 SERIES: for Perimeter Security J355F Static

350mm «Shallow Mount» concept: A minimal excavation depth is required; 350mm are sufficient to allocate the complete product and its reinforcing structure

J355 SERIES: for Perimeter Security J355F Static

Modular supporting structure: Maximum logistic efficiency and easiness of transportation, thanks to the modular assembly of bollard and underground reinforcing girders

J355 SERIES: for Perimeter Security J355F Static

Modular supporting structure: Maximum easiness of installation, thanks to the modular assembly of bollard and underground reinforcing girders

J355 SERIES: for Perimeter Security J355F Static

Total aesthetic coherency with retractable models : Possibility to realize mixed installations with fixed and retractable versions

J355 SERIES: for Perimeter Security J355F Static

• www. faacbollard.com
