You are a Game Bot: Uncovering Game Bots in MMORPGs via Self-similarity in the Wild Eunjo Lee (NCSOFT) Jiyoung Woo (Korea University) Hyoungshick Kim (Sungkyunkwan University) Aziz Mohaisen (State University of New York at Buffalo) Huy Kang

slide-1
SLIDE 1

You are a Game Bot:

Uncovering Game Bots in MMORPGs via Self-similarity in the Wild

Eunjo Lee (NCSOFT) Jiyoung Woo (Korea University) Hyoungshick Kim (Sungkyunkwan University) Aziz Mohaisen (State University of New York at Buffalo) Huy Kang Kim (Korea University)

slide-2
SLIDE 2

2 / 45

Contents

Introduction Feature selection and modeling Experiments Model maintenance Real-World deployment Conclusions

slide-3
SLIDE 3

3 / 45

Introduction

slide-4
SLIDE 4

4 / 45

Introduction

Game BOT

  • Program that plays a game autonomously

(instead of human users)

Bot configurations

slide-5
SLIDE 5

5 / 45

Introduction

Real Money Trading (RMT)

  • Collect valuable items and monetize it by trading item to others

Game World Virtual Assets Virtual Assets Real Money

slide-6
SLIDE 6

6 / 45

Introduction

Gold Farming Group (GFG)

slide-7
SLIDE 7

7 / 45

Introduction

Game BOT https://www.youtube.com/watch?v=k6tk8_R2w08

slide-8
SLIDE 8

8 / 45

Introduction

Game BOT

  • Widespread cheating in online games
  • Collapse of an in-game economy
  • Cause a human users’ churn
  • Reduce the revenue
slide-9
SLIDE 9

9 / 45

Introduction

Countermeasures

  • Client-side
  • Bot process detection using anti-malware programs
  • Server-side
  • Bot classification using game log analysis
slide-10
SLIDE 10

10 / 45

Machine Learning-based Approach

Introduction

Prediction Model

Character ID T1 T2 T3 Response 686042 854209 1 1 1 3 1032131 1049483 1 1 1 3 1340479 1352850 1771815 1 1 1 3 1832497 1884884 1 1 1 3 2130576 1 1 1 3 2445903 1 1

Game Logs Ground Truth Feature Selection Learning Algorithm

slide-11
SLIDE 11

11 / 45

Introduction

Challenges Raw data collection Preproce ssing Cleaning Visual- izing …

Game Bots’ Pattern

slide-12
SLIDE 12

12 / 45

Introduction

Challenges

Raw data collection Preproce ssing Cleanin g Visual- izing …

Game A Bots’ Pattern

Raw data collection Preproce ssing Cleanin g Visual- izing …

Game B Bots’ Pattern

High cost time consuming

slide-13
SLIDE 13

13 / 45

Introduction

Challenges Consistent maintenance

Game update Bot change

slide-14
SLIDE 14

14 / 45

Introduction

Our proposals

  • Using self-similarity as a generic feature
  • Focus on the repetitive activities of game bots, not specific behavior
  • Proposing framework to maintain a prediction model autonomously
  • Detect the change in performance of the prediction model and retrain it
slide-15
SLIDE 15

15 / 45

Feature Selection and Modeling

slide-16
SLIDE 16

16 / 45

Definition

  • Measurement of the similarity of periodic actions per user

Self-similarity

slide-17
SLIDE 17

17 / 45

Motivation and consideration

  • Intrinsic attributes
  • Bot programs repeat routines using predetermined settings
  • Human users may exhibit similar behavior, but not for long period of time
  • Stability
  • Little effect of game update or bot program changes
  • Considering various actions rather than a single action
  • Computing efficiency
  • Easy to apply distributed algorithms (i.e. MapReduce) for log processing

Self-similarity

slide-18
SLIDE 18

18 / 45

Detailed process

  • Generating log vectors
  • Measuring cosine similarity
  • Measuring self-similarity

Self-similarity

slide-19
SLIDE 19

19 / 45

Generating log vectors

Game logs Game logs in User A distributed by users

time Event id Character info. Other info. 15/08/13 12:00:12.131 1205 AAA, 34 N/A 15/08/13 12:00:14.237 1204 AAA, 34 N/A 15/08/13 12:00:59.436 1208 AAA, 34 Ogre 15/08/13 12:00:59:436 1208 AAA, 34 Ogre 15/08/13 12:00:59.857 1208 AAA, 34 Troll 15/08/13 12:01:17.019 1022 AAA, 34 Ring 15/08/13 12:01:21.341 1022 AAA, 34 Sword 15/08/13 12:01:23.151 1205 AAA, 34 N/A 15/08/13 12:01:54.354 1204 AAA, 34 N/A 15/08/13 12:01:56.445 1208 AAA, 34 Wolf 15/08/13 12:02:07.351 1205 AAA, 34 N/A 15/08/13 12:02:41.847 1204 AAA, 34 N/A 15/08/13 12:02:47.650 1208 AAA, 34 Ogre 15/08/13 12:03:09.353 1208 AAA, 34 Ogre Time period (hour:min) Log count per event id 1022 1204 1205 1208 12:00 1 1 3 12:01 2 1 1 1 12:02 1 1 1 12:03 1

Game logs in User B Game logs in User C

Self-similarity

slide-20
SLIDE 20

20 / 45

Measuring the cosine similarity between log vector(Vt) and unit vector(E) Frequency

  • f event B

Frequency

  • f event A

Vt (2,1) E (1,1) cos(θ) cos(θ) =

𝐵∙𝐶 𝐵 | 𝐶 | = 𝐵𝑗×𝐶𝑗 (𝐵𝑗)2 × (𝐶𝑗)2

=

(2×1 +1×1) 2×2+1×1 × 1×1+1×1

=

3 5 × 2

≒ 0.948

Self-similarity

slide-21
SLIDE 21

21 / 45

Measuring self-similarity

  • Measuring std. of cosine similarity and transforming using the following model
  • 𝐼 = 1 −

1 2 𝜏, (0.5 ≤ 𝐼 ≤ 1, 𝜏: 𝑡𝑢𝑒. 𝑒𝑓𝑤𝑗𝑏𝑢𝑗𝑝𝑜 𝑝𝑔 𝑑𝑝𝑡𝑗𝑜𝑓 𝑡𝑗𝑛𝑗𝑚𝑏𝑠𝑗𝑢𝑧)

Self-similarity

slide-22
SLIDE 22

22 / 45

Modeling

  • Logistic regression
  • Calculating the probability of a character being a game bot

Modeling and Evaluation

slide-23
SLIDE 23

23 / 45

Experiments

slide-24
SLIDE 24

24 / 45

Datasets

Experiments

Lineage Aion B&S Release year 1997 2008 2012 Daily active users 300K 200K 100K Concurrent users 150K 80K 50K

slide-25
SLIDE 25

25 / 45

  • Bots have cosine similarities with fewer variations than human users

Bots Humans Cosine similarities

Experiments

slide-26
SLIDE 26

26 / 45

Self-similarity

  • Almost bots have higher values than human users

Lineage Aion B&S

Experiments

slide-27
SLIDE 27

27 / 45

Additional feature selection

  • Exceptional cases – short time playing or no activities over long time
  • Outliers

No. Field name Description 1 self_sim Self-similarity 2 cosim_count Count of a set of log vectors 3 cosim_uniq_count Unique count of a set of log vectors 4 cosim_zero_count Count of data in which cosine similarity is zero 5 cosim_mode Count of data that appears most often in a set of log vectors 6 total_log_count Total count of logs generated by user 7 main_char_level Character level 8 total_use_time_min Play time during certain period per user 9 npc_kill_count NPC kill count 10 trade_get_count Count of trade in which user takes item 11 trade_give_count Count of trade in which user gives items 12 retrieve_count Count of activity in which user retrieve items from warehouse 13 deposit_count Count of activity in which user deposits items to warehouse 14 log_count_per_min Average count of logs are generated per minute

Feature selection

slide-28
SLIDE 28

28 / 45

Performance evaluation

  • Model1: using only self-similarity. Model2: using all features

Game BOT Human AUC (model 1) AUC (model 2) Lineage 128 149 0.8967 0.9455 Aion 186 160 0.9557 0.9942 B&S 131 129 0.8280 0.9399

Experiments

Lineage Aion B&S

slide-29
SLIDE 29

29 / 45

Model Maintenance

slide-30
SLIDE 30

30 / 45

Motivation and consideration

  • How to optimize the time for retraining
  • Too often -> high cost
  • Too rare -> obsolete model
  • How to retrain a model autonomously

Model maintenance

slide-31
SLIDE 31

31 / 45

System Flow

Inspector Ground Truth Modeler Preprocessor Predictor Change Detector Model (PMML) Game Logs BOT Detection System

Model maintenance

slide-32
SLIDE 32

32 / 45

Logic Flow

  • If change is detected, retraining the model
  • Notifying to operator, if new model is invalid
  • r change is detected consecutively

Calculate bot probability Notify to operator Model retraining Change detected? Already retraining? End Validation check End no yes yes no invalid valid

Model maintenance

slide-33
SLIDE 33

33 / 45

  • If change is detected, retraining the model
  • Notifying to operator, if new model is invalid
  • r change is detected consecutively

Logic Flow

Calculate bot probability Notify to operator Model retraining Change detected? Already retraining? End Validation check End no yes yes no invalid valid

EWMA Algorithm

Model maintenance

slide-34
SLIDE 34

34 / 45

EWMA algorithm User Bot probability (time t) Bot probability (time t-1) A 0.99 0.95 B 0.95 0.92 C 0.23 0.25 D 0.55 0.55 … … …

  • Calculating the correlation coefficient of bot probability between time t and t-1

Correlation coefficient

Model maintenance

slide-35
SLIDE 35

35 / 45

EWMA algorithm

  • Calculating the correlation coefficient of bot probability between time t and t-1
  • Calculating the weighted moving average of coefficients

(X: coefficient, Z: moving average)

Model maintenance

slide-36
SLIDE 36

36 / 45

EWMA algorithm

Model maintenance

  • Calculating the correlation coefficient of bot probability between time t and t-1
  • Calculating the weighted moving average of coefficients
  • Measuring upper an lower control limits
slide-37
SLIDE 37

37 / 45

EWMA algorithm

Model maintenance

  • Calculating the correlation coefficient of bot probability between time t and t-1
  • Calculating the weighted moving average of coefficients
  • Measuring upper an lower control limits
  • Retraining the model, unless 𝑀𝐷𝑀 < 𝑎𝑢 < 𝑉𝐷𝑀
slide-38
SLIDE 38

38 / 45

Real-World Deployment

slide-39
SLIDE 39

39 / 45

BOT detection system – dashboard

Real-World Deployment

  • Provide the trend of numbers or rates of BOT, and the chart of BOT

statistics by main activity zone

The trend of bot The trend of bot rate The trend of bot rate at specific zone Bot statistics by activity zone

slide-40
SLIDE 40

40 / 45

BOT detection system – search and filter

Real-World Deployment

  • Search and filter the list of accounts to ban

Fill in the conditions to filter accounts to ban Print the list of accounts to ban according to the search conditions

slide-41
SLIDE 41

41 / 45

Conclusion

slide-42
SLIDE 42

42 / 45

  • We proposed self-similarity as a feature and demonstrated its effectiveness

with real datasets

  • We proposed a bot detection framework that includes a detection model

maintenance process

  • We implemented the proposed framework and utilized it for live MMORPGs

Conclusion

Contributions

slide-43
SLIDE 43

43 / 45

Future works – short-time playing bot

  • Undetected massive number of bots playing for less than 10 hours per week
  • Star-shaped trading network structure

Conclusion

VS Short-time playing BOT Human users

slide-44
SLIDE 44

44 / 45

Future works – occasional bot users

  • Human players playing for hours and then turning on a bot for a few hours
  • Self-similarities have pulse, if we use short period of time for aggregation

Conclusion

slide-45
SLIDE 45

Questions and Answers
