YJ New Product Presentation Content YJ New Product Presentation 1.Product Roadmap 2. New Product-SMD Bridge 3. New Product-Low VF

slide-1
SLIDE 1

客户信任 激情创新 勤简守信 坦诚感恩

扬杰科技

YJ New Product Presentation

扬州扬杰电子科技股份有限公司

slide-2
SLIDE 2

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Content

YJ New Product Presentation 1.Product Roadmap

  • 2. New Product-SMD Bridge
  • 3. New Product-Low VF Series

4.New Product-TO252 Diode

  • 5. New Product-Small Signal Diode
slide-3
SLIDE 3

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

2~4A Surface Mount Bridge

4~10A Surface Mount Bridge Year

Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4

2018 2019 2020 2021 2022

YBS4 Package

YBSL2006~ YBSL2010 YBSL3006~ YBSL3010 YBSL4006~ YBSL4010

YBS3 Package

YBSM4006~ YBSM4010

4~6A SMD Bridge 8~10A SMD Bridge 6~8A SMD Bridge YBS3 Package

YBSL6010

SMD Bridge Rectifier

Product Roadmap

slide-4
SLIDE 4

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Low VF SKY for TO Series

Year

Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4

2018 2019 2020 2021 2022

TO-220 Package

MBRL3100 MBRL1080 MBRL10100 MBRL1580 MBRL15100 MBRL1080CT MBRL2080CT MBRL20100CT MBRL3080CT MBRL30100CT

TO-263 Package

MBRL3100M MBRL1080M MBRL10100M MBRL1580M MBRL15100M MBRL6100CM MBRL1080CM MBRL2080CM MBRL20100CM MBRL3080CM MBRL30100CM

10~30A TSBD Schottky 10~30A TSBD Schottky

Product Roadmap

Low VF Diode

slide-5
SLIDE 5

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Low VF SKY for TO Series PDFN5060

Year

Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4

2018 2019 2020 2021 2022

TO-252 Package

MBRL3100D MBRL1080D MBRL10100D MBRL1580D MBRL15100D MBRL6100CD MBRL1080CD MBRL2080CD MBRL20100CD MBRL3080CD MBRL30100CD

Low VF Diode

10~30A TSBD Schottky 5~10A VR(20~200V) Schottky Diodes 5~100A BVDSS(20~1200V) MOS

Product Roadmap

slide-6
SLIDE 6

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Switching Diodes

Year

Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4

2018 2019 2020 2021 2022

SOD-123 Package

1N4148W

SOD-323 Package

1SS355 BAS16WX BAS316 BAV19WS BAV20WS BAV21WS

SOD-523 Package

1N4448X 1SS400

SOT-23 Package

BAW56

150~400mW, VR 75~200V SOD-123 150~400mW, VR 75~200V SOD-323 150~400mW, VR 75~200V SOD-523 150~400mW, VR 75~200V SOT-23

Small Signal Diode

Product Roadmap

slide-7
SLIDE 7

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Schottky Barrier Rectifiers

Year

Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4

2018 2019 2020 2021 2022

SOD-123 Package

B5817W B5818W B5819W MBR0520 MBR0530 MBR0540 MBR0560 MBR0580

SOD-323 Package

B5817WS B5818WS B5819WS BSR106WS RB551V-30

SOT-23 Package

BAS40 BAS40-04 BAS40-05 BAS40-06

IF 0.5~1A, VR 20~40V SOD-123 IF 0.5~1A, VR 60~200V SOD-123 IF 0.5~1A, VR 20~40V SOD-323 IF 0.5~1A, VR 20~40V SOT-23 IF 0.5~1A, VR 60~200V SOD-323 IF 0.5~1A, VR 60~200V SOT-23

Product Roadmap

Small Signal Diode

slide-8
SLIDE 8

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Zener Diodes

Year

Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4

2018 2019 2020 2021 2022

SOD-123 Package

BZT52C2V4 BZT52C2V7 BZT52C3V0 BZT52C4V7 BZT52C5V1 BZT52C5V6 BZT52C6V2 BZT52C6V8 BZT52C7V5 BZT52C8V2 BZT52C9V1 BZT52C10 BZT52C11

SOD-323 Package

BZT52C3V3 BZT52C3V6 BZT52C3V9 BZT52C4V3

500mW, VR 2.4~11V BE：SOD-123 500mW, VR 2.4~11V BE：SOD-323

Product Roadmap

Small Signal Diode

slide-9
SLIDE 9

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Bipolar Transistors

Year

Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4

2018 2019 2020 2021 2022

SOT-23 Package

2CS1623-L5 2CS1623-L6 2CS1623-L7 BC807-16 BC807-25 BC817-40 BC817-16 BC817-25 BC817-40 MMBT2222A MMBT3904 MMBT4401 MMBT4403 MMBTA05 MMBTA06 MMBTA55 MMBTA56

0.3W，0.5A，50V SOT-23 0.3W，0.5A，50V SOT-323

Product Roadmap

Small Signal Diode

slide-10
SLIDE 10

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

ESD Protection Devices

Year

Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4

2018 2019 2020 2021 2022

SOD-323 Package

ESD5V0D3 ESD12VD3 ESDLC3V3D3B ESDLC5V3D3B ESDLC12VD3B ESDLC3V3D3 SD05C

SOD-523 Package

ESD3V3D5 ESD5V0D5 ESD7V0D5 ESD12V0D5 ESD5V0D5B

3.3~12V SOD-523 3.3~12V SOD-323

Product Roadmap

Small Signal Diode

slide-11
SLIDE 11

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Ready Plan Develop

Segme nt Platform 2017 Q1 Q2 Q3 Q4 2018 Q1 Q2 Q3 Q4 2019 Q1 Q2 Q3 Q4 LV-MOS MV-MOS HV-MOS

0.9um pitch High-Rsp G1 12-30V N/P Trench 5Mask 40-200V N/P Trench 30-200V SGT MOS 0.9um pitch High-Rsp G2 0.6um shrink pitch(CT self- aligned) High-Rsp G3 5Masks 40- 100V Trench G1 60V SGT MOS G1 30-40V SGT MOS G1 30-100V SGT MOS G2 (High- Rsp) 100-200V SGT MOS G3 (Big current) 5Masks 40-100V Trench G2(Big current & Strong ) 500-900V Planar MOS 500-900V SJ MOS 500-900V Planar G1(Single Ring) 500-900V Planar G2 (Big Current ) 500-900V SJMOS G1(11um pitch) 500-900V SJ MOS G2(9um pitch) 500-900V SJ MOS G3(Big current)

Product Roadmap

Mosfet

slide-12
SLIDE 12

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

製品（新）のご紹介

SMD Bridge：YBS/YBSL Package

PCB become smaller: GBP/KBP/D3K→YBS/ YBSL Manual manufacture can be upgraded to automatic production

6.7mm*8.6mm*1.5mm GBP Package YBS Package

Power supply become thinner ＊In 2018、4A~6A SMD bridge rectifier will be in mass production

New Product—SMD Bridge

slide-13
SLIDE 13

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Bridge reference

Application recommendation

Input V Adaptor Charger LED CFL

90~264V <45W <25W <25W <35W 220V <65W <35W <35W <45W

SMD Bridge：YBS/YBSL Package New Product—SMD Bridge

slide-14
SLIDE 14

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Part Dice size Specification Mass Production Capacity Io(A) IFSM(A) VF(V) VR(V) IR(uA) YBS2006 70mil 2.0 75 1.02 600 5 Yes 3KK/M YBS2008 70mil 2.0 75 1.02 800 5 Yes 3KK/M YBS2010 70mil 2.0 75 1.02 1000 5 Yes 3KK/M YBS2206 80mil 2.2 90 1.02 600 5 Yes 3KK/M YBS2208 80mil 2.2 90 1.02 800 5 Yes 3KK/M YBS2210 80mil 2.2 90 1.02 1000 5 Yes 3KK/M YBS3006 80mil 3.0 110 1.02 600 5 Yes 3KK/M YBS3008 80mil 3.0 110 1.02 800 5 Yes 3KK/M YBS3010 80mil 3.0 110 1.02 1000 5 Yes 3KK/M YBS3006A 84mil 4.0 110 1.0 600 5 Yes 3KK/M YBS3008A 84mil 4.0 110 1.0 800 5 Yes 3KK/M YBS3010A 84mil 4.0 110 1.0 1000 5 Yes 3KK/M

YBS Package Product List New Product—SMD Bridge

slide-15
SLIDE 15

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Part Dice size Specification Mass Production Capacity Io(A) IFSM(A) VF(V) VR(V) IR(uA) YBSL2006 70mil 2.0 75 1.0 600 5 Yes 3KK/M YBSL2008 70mil 2.0 75 1.0 800 5 Yes 3KK/M YBSL2010 70mil 2.0 75 1.0 1000 5 Yes 3KK/M YBSL3006 80mil 3.0 95 1.0 600 5 Yes 3KK/M YBSL3008 80mil 3.0 95 1.0 800 5 Yes 3KK/M YBSL3010 80mil 3.0 95 1.0 1000 5 Yes 3KK/M YBSL4006 84mil 4.0 110 1.0 600 5 Yes 3KK/M YBSL4008 84mil 4.0 110 1.0 800 5 Yes 3KK/M YBSL4010 84mil 4.0 110 1.0 1000 5 Yes 3KK/M

YBSL Package Product List New Product—SMD Bridge

slide-16
SLIDE 16

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

YBS (2A,3A) Introduction

Specification: Io: 2A, 2.2,3A VR: 50~1200V Chip Size: 70mil, 80mil IFSM: 75~90A Junction Temperature: 150 degree C Application: Adapter, Charge, LED Replacement: D3K, GBP, KBP Strength: Low Cost, High Assembly Productivity

New Product—SMD Bridge

slide-17
SLIDE 17

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

YBSL(2A, 3A,4A) Introduction

Specification: Io: 3A~4A VR: 50~1200V Chip Size: 84~95mil IFSM: 110~150A Junction Temperature: 150 degree C Application: Adapter, Charge, LED Replacement: D3K, GBU, GBL Strength: Low Cost, High Assembly Productivity

New Product—SMD Bridge

slide-18
SLIDE 18

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

YBSL (6A) Introduction

Specification: Two half of bridge to do a full bridge. Io: 6A~8A VR: 50~1200V Chip Size: 95~120mil IFSM: 110~180A Junction Temperature: 150 degree C Application: Adapter, Charge, LED Replacement: D3K, GBU, GBL Strength: Low Cost, High Assembly Productivity

New Product—SMD Bridge

slide-19
SLIDE 19

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Low VF Bridge Forward VF comparison（GBJ2506 VS GBJL2506）

VF less 100mV@12.5A

Low VF SMD Forward VF comparison （SKY VS Low VF SKY）

VF less 100~150mV@Io

Since 2016, we develop Low VF product to reduce power loss New Product—LOW VF Series

slide-20
SLIDE 20

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

① Low VF Bridge List

GBU KBJ6

Part Dice size Io(A) VR(V) VF(V) IFSM(A) IR(uA) GBUL4 120*140 4 600/800 0.85 280 10 GBUL6 120*140 6 600/800 0.9 280 10 GBUL8 120*140 8 600/800 0.9 280 10 GBUL10 120*140 10 600/800 0.92 280 10 GBJL10 120*140 10 600/800 0.92 300 10 GBJL15 120*140 15 600/800 0.92 300 10 GBJL25 180*220 25 600 0.92 420 10 GBJL35 180*220 35 600 0.95 420 10

New chip developed

New Product—LOW VF Series

slide-21
SLIDE 21

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Low VF SBD List

SMA/SMB

Part Dice size Io(A) VR(V) VF(V) IFSM(A) IR(mA) SSL14A 32MIL 1 40 0.4 28 0.5 SSL16A 32MIL 1 60 0.55 28 0.5 SSL110A 32MIL 1 100 0.6 28 0.5 SSL24A 44MIL 2 40 0.47 50 0.5 SSL26A 44MIL 2 60 0.55 50 0.5 SSL210A 44MIL 2 100 0.75 50 0.5 SSL34A 58MIL 3 40 0.45 60 0.5 SSL36A 58MIL 3 60 0.45 60 0.5 SSL310A 58MIL 3 100 0.55 60 0.5 SSL34B 58MIL 3 40 0.45 60 0.5 SSL36B 58MIL 3 60 0.45 60 0.5 SSL310B 58MIL 3 100 0.55 60 0.5

② SMD package series

Trench Chip developed

New Product—LOW VF Series

slide-22
SLIDE 22

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Low VF SBD List

ITO-220AB

③ TO/ITO 220 Package series

Part Dice size Io(A) VR(V) VF(V) IFSM(A) IR(mA) Mass Production MBRL10100F 1*82MIL 10 100 0.72@10A 150 0.5 Yes MBRL10100 1*82MIL 10 100 0.72@10A 150 0.5 Yes MBRL20100FCT 2*82MIL 20 100 0.72@10A 150 0.5 Yes MBRL20100CT 2*82MIL 20 100 0.72@10A 150 0.5 Yes

Trench Chip developed

ITO-220AC

New Product—LOW VF Series

slide-23
SLIDE 23

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

TO-252 package is coming soon.....

Power supply become thinner

PCB can become smaller Application range expand（TV Power supply ）--End customer: LG

New Product— TO-252 Diode

slide-24
SLIDE 24

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

TO-252 SBD Product List

Datasheet, Sample available

Chip Type Part Chip Size IF VR VF IR IFSM Tj Mass Production Capacity SKY MBR1060CD 65MIL* 2 10A 60V 0.7V 0.1uA 120A 175℃ Yes 2KK/M MBR10100CD 65MIL* 2 10A 100V 0.85V 0.1uA 120A 175℃ Yes 2KK/M MBR10200CD 65MIL* 2 10A 200V 0.9V 0.1uA 120A 175℃ Yes 2KK/M Trench MBRL1060D 82MIL 10A 60V 0.66V 0.1uA 200A 150℃ Yes 2KK/M MBRL10100D 82MIL 10A 100V 0.8V 0.1uA 200A 150℃ Yes 2KK/M MBRL10200D 82MIL 10A 200V 1.3V 0.1uA 200A 150℃ Yes 2KK/M

New Product— TO-252 Diode

slide-25
SLIDE 25

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

TO-252 SBD Product List

Datasheet, Sample available

Chip Type Part Chip Size IF VR VF IR IFSM Tj Mass Production Capacit y SKY MBR2060CD 108MIL双 胞胎 20A 60V 0.80V 0.1uA 150A 175℃ Yes 2KK/M MBR20100CD 108MIL双 胞胎 20A 100V 0.90V 0.1uA 150A 175℃ Yes 2KK/M MBR20200CD 108MIL双 胞胎 20A 200V 1.0V 0.1uA 150A 175℃ Yes 2KK/M Trench MBRL2060D 102MIL 20A 60V 0.66V 0.1uA 200A 150℃ Yes 2KK/M MBRL20100D 102MIL 20A 100V 0.87V 0.1uA 200A 150℃ Yes 2KK/M MBRL20200D 102MIL 20A 200V 1.3V 0.1uA 200A 150℃ Yes 2KK/M

New Product— TO-252 Diode

slide-26
SLIDE 26

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Small Signal product

Product diversify

Less than 1A product development（Product diversify） From AC-DC develop to DC-DC

New Product develop in priority Application Range

PC power supply Communication Security Motor Home Appliance

Item Zener TVS Switching Transistor SKY Mos SOD123

△ △ △ △

SOD323

△ △ △ △

SOD523

√ √ √ √

SOT23

△ △ △

SOT323

□ □ □ ∆ △ 2018. Q1

√ 2018. Q2

□

  • 2018. Q3

New Product— Small Signal

slide-27
SLIDE 27

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Small Signal Part Supply Status New Product— Small Signal

Switching Series Datasheet Sample Mass Production 1N4148W SOD-123 Yes Yes Yes BAV19W SOD-123 Yes Yes Yes BAV20W SOD-123 Yes Yes Yes BAV21W SOD-123 Yes Yes Yes MMSD914 SOD-123 2018.2 2018.2 2018.4 BAS16W SOD-123 2018.2 2018.2 2018.4 1SS355 SOD-323 Yes Yes Yes 1N4148WS SOD-323 Yes Yes Yes 1N4448WS SOD-323 Yes Yes Yes BAS16WS SOD-323 2018.2 2018.2 2018.4 BAS316 SOD-323 2018.2 2018.2 2018.4 BAV19WS SOD-323 Yes Yes Yes BAV20WS SOD-323 Yes Yes Yes BAV21WS SOD-323 Yes Yes Yes 1N4448W SOD-523 Yes Yes Yes

slide-28
SLIDE 28

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Small Signal Part Supply Status New Product— Small Signal

SBD Series Datasheet Sample Mass Production BAT54W SOD-123 2018.2 2018.2 2018.4 B5817W SOD-123 2018.2 2018.2 2018.4 B5818W SOD-123 2018.2 2018.2 2018.4 B5819W SOD-123 2018.2 2018.2 2018.4 SD103AW SOD-123 2018.2 2018.2 2018.4 SD103BW SOD-123 2018.2 2018.2 2018.4 SOD103CW SOD-123 2018.2 2018.2 2018.4 BAT54WS SOD-323 Yes Yes Yes B5817WS SOD-323 Yes Yes Yes B5818WS SOD-323 Yes Yes Yes B5819WS SOD-323 Yes Yes Yes RB551V-30 SOD-323 2018.2 2018.2 2018.4 RB751V-40 SOD-323 2018.2 2018.2 2018.4 RB521S-30 SOD-523 2018.2 2018.2 2018.4 RB520S-40 SOD-523 2018.2 2018.2 2018.4 BAV70 SOT-23 2018.2 2018.2 2018.4 BAT54 SOT-23 2018.2 2018.2 2018.4

slide-29
SLIDE 29

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Small Signal Part Supply Status New Product— Small Signal

Zener Series Datasheet Sample Mass Production BZT52C2V4~11 SOD-123 2018.2 2018.2 2018.4 BZT52C2V4S~39S SOD323 Yes Yes Yes Transistor Series Datasheet Sample Mass Production MMBT3904 SOT-23 Yes Yes Yes MMBT3906 SOT-23 Yes Yes Yes MMBT 2907A SOT-23 2018.2 2018.2 2018.4 MMBT5401 SOT-23 2018.2 2018.2 2018.4 SI3400A SOT-23 2018.2 2018.2 2018.4 SI3401A SOT-23 2018.2 2018.2 2018.4 SI2301A SOT-23 Yes Yes Yes SI2302A SOT-23 2018.2 2018.2 2018.4 MOS Series Datasheet Sample Mass Production 2N7002 SOT23 2018.2 2018.2 2018.4 2N7002K SOT23 Yes Yes Yes 2N7002KA SOT23 Yes Yes Yes

slide-30
SLIDE 30

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Small Signal Line Future Capacity and Roadmap

100 200 300 400 500 600 700 800 900 1000 2018.4 2018.10 2019.3 2019.12 2020.6 Unit: KKpcs

Capacity Plan (2018~2010) Product Roadmap (2018~2019)

New Product— Small Signal

slide-31
SLIDE 31

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Synchronous rectification MOSFET（SGT）

100V SGT ＆Trench MOS Product comparison

2 4 6 8 1 0 1 2 扬杰Split-Gate-Trench MOS 国内普通Trench MOS

Rdson@Vgs= 1 0 V( m R)

Rdson ( 100V SGT MOS VS 100VTrench MOS) 40% Down

1 0 0 2 0 0 3 0 0 4 0 0 5 0 0 6 0 0 7 0 0 8 0 0 扬杰Split-Gate-Trench MOS 国内普通Trench MOS

FOM( m R* nC)

FOM( Rdson* Qg) ( 100V SGT MOS VS 100VTrench MOS) 52% Down

New Product— Mosfet

slide-32
SLIDE 32

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Synchronous rectification SGT SR MOS Product：

SOP-8 DFN5*6

Low power loss

Application

Charger Adapter Plug MAV PC power supply Communication

。。。。。。

New Product— Mosfet

Platform Part Package Configuratio n N/P VDSS (V) ID (A) Pd VGS (V) VTH(V ) Rdson(mΩ ) @VGS10V Rdson(mΩ ) @VGS4.5 V Rdson(mΩ) @VGS2.5V Mass Productio n Typ Typ Max Typ Max Typ Max Low Voltage MOS YJL2302A SOT-23 Single die N 20 4.3 1 ±10 0.85 21 27 29 44 Yes YJL2300A SOT-23 Single die N 20 4.5 1 ±10 0.7 19.5 25 25 38 Yes YJS8205B TSSOP-8 Dual die N 20 6 2 ±10 0.7 19.5 25 25 36 Yes

slide-33
SLIDE 33

扬杰科技 300373

追求品质 持续创新 勤简守信 忠诚感恩

Platform Part Package Configuration N/P VDSS (V) ID (A) Pd VGS (V) VTH(V) Rdson(mΩ) @VGS10V Rdson(mΩ) @VGS4.5V Rdson(mΩ) @VGS2.5V Mass Production Typ Typ Max Typ Max Typ Max Low Voltage MOS YJL2312A SOT-23 Single die N 20 6.8 1.2 ±10 0.65 16 21 20 30 Yes YJS8205C SOT23-6 Dual die N 20 6.8 1.2 ±10 0.65 16 21 20 30 Yes YJS8205A TSSOP-8 Dual die N 20 6 1.6 ±10 0.7 19.5 23 24 29 Yes YJL3400A SOT-23 Single die N 30 5.6 1.2 ±12 1.05 24 31 27 35 41 62 Yes YJL3404A SOT-23 Single die N 30 5.5 1.2 ±20 1.5 25 33 30 39 Yes YJQ50N03A DFN3.3x3.3 Single die N 30 50 38 ±20 1.3 4.3 5.6 5.4 7.0 Yes YJG50N03A DFN5x6 Single die N 30 50 38 ±20 1.3 4.3 5.6 5.4 7.0 Yes YJL2301D SOT-23 Single die P

  • 15
  • 3.8

1 ±10

  • 0.7

40 52 52 78 Yes YJL2305A SOT-23 Single die P

  • 15
  • 5.6

1.2 ±10

  • 0.7

28 36 35 53 Yes YJL2301E SOT-23 Single die P

  • 20
  • 3

0.9 ±10

  • 0.7

65 80 75 90 Yes YJL2305B SOT-23 Single die P

  • 20
  • 5.4

1.2 ±10

  • 0.7

35 46 46 69 Yes YJL2301C SOT-23 Single die P

  • 20
  • 3.4

1 ±10

  • 0.7

49 64 59 89 Yes YJL3401A SOT-23 Single die P

  • 30
  • 4.4

1.2 ±12

  • 0.9 45.5

59 52 68 64 96 Yes YJL3407A SOT-23 Single die P

  • 30
  • 4.1

1.2 ±20

  • 1.5

46 60 58 75 Yes YJS4953A SOP-8 Dual die P

  • 30
  • 5.1

2.5 ±20

  • 1.5

46 60 58 75 Yes

New Product— Mosfet

slide-34
SLIDE 34

追求品质 持续创新 勤简守信 忠诚感恩

扬杰科技 YJ International Sales
