Workshop FF

Best Practices & Case Study … Successful Energy Efficiency & Energy Reduction at Kent State University & The Ohio State University

Wednesday, February 20, 2019 11:15 a.m. to 12:30 p.m.

Biographical Information Robert Misbrener, Project Manager II, Office of the University Architect Kent State University, 615 Loop Rd, Kent, OH 44242 Phone: 330-672-9653 rmisbren@kent.edu

Robert Misbrener is a Project Manager on the Mechanical Engineering Team at Kent State University and has been in the capacity since 1999. He is the lead project manager for the majority of energy conservation projects that began in earnest in 2009 for Kent Campus and all Regional campuses in Ohio. Prior to Kent State, Robert worked at Scheeser Buckley Mayfield Consulting Engineers in mechanical design engineering for northeast Ohio for nearly 19 years. Robert has enjoyed nearly 39 years of experience in the mechanical engineering field for numerous infrastructures, new building, renovation, renewable energy and energy conservation

• projects. Many projects under his management were in the multi-million to over $20 million-dollar
• range. Robert is tasked with helping the University maximize the use of new/existing

equipment/capacity to serve the dynamic renovation and new buildings integrated on the

• campuses. Annual Electricity usage at Kent campus is the same as usage in 2012 despite

improving (adding A/C etc.) nearly 1 million GSF and new builds of nearly 350,000 GSF since

• 2012. The reliability of the Kent State academic mission has drastically increased due to the new

equipment and efficiency improvements of the energy conservation projects. The Deferred Maintenance component of Kent State has also benefitted from the energy projects, retiring over $38 million since 2009.

Allan Leary, Senior Energy Engineer Office of Student Life Energy Management & Sustainability The Ohio State University, 1800 Cannon Dr. Columbus, OH 43210 614.514,5871 Leary.90@osu.edu

Allan began his duties as Senior Energy Engineer for The Ohio State University’s Office of Student Life Energy Management & Sustainability in May 2018. There, he monitors the energy and water usage for Ohio State’s residence halls, dining facilities, recreation center, student union and other buildings at all of Ohio State’s campuses throughout Ohio. He works with staff members and students to develop and review plans, looking for more efficient resources usage and developing real-time energy dashboards to facilitate decisions concerning energy and water usage. Previously Allan spent 7 years at DNV GL Energy working in Program Development and Implementation, providing AEP Ohio electric customers with energy use and efficiency consultation along with measurement and verification of projects. He also provided engineering analysis for new program offerings for compressed air, HVAC and grocery refrigeration systems. Allan also spent 3 year at Africa University in Mutare, Zimbabwe as a Technical Adviser training technician on the operation and maintenance of HVAC system. He was also instrumental in the implementation of several solar thermal and solar electric projects. In his free time, Allan enjoys hiking, camping and backpacking with his family and coaching youth soccer.

Biographical Information

• H. Kelly Tisdale, General Manager, Energy Services Division

The Brewer-Garrett Company, 6800 Eastland Rd., Middleburg Heights, OH 44130 Phone: 440-243-3535 ktisdale@brewer-garrett.com

Kelly Tisdale is the General Manager of The Energy Services Division of The Brewer-Garrett Company, a premier provider of Energy Services Performance Contracting and Facilities Management Services to the Commercial and Industrial marketplace. Kelly is a Certified Energy Manager (CEM), Leadership in Energy and Environmental Design, (LEED AP), Distributed Generation Certified Professional (DGCP), Certified Demand-Side Management Professional (CDSM) and Certified Sustainable Design Professional (CSDP). He received a Bachelor of Science from Kent State University. He has over 29 years’ experience in project development, system design, service and auditing, and implementation of many of the most innovative programs in his industry. He has personally been involved in over half a billion dollars in performance contracts. Kelly has appeared on TV, radio, in newspapers and trade magazines, and has presented at countless conferences and workshops on innovative energy

• topics. He also served as Chairman for the Energy Division and board member of Cleveland

Engineering Society and is a member of the Association of Energy Engineers (AEE).

Noah A. Brewer PE, CEM, DGCP, Senior Energy Engineer The Brewer-Garrett Company, 6800 Eastland Rd., Middleburg Heights, OH 44130 Phone: 440-243-3535 NBrewer@Brewer-Garrett.com

Noah Brewer is a Senior Energy Engineer at The Brewer-Garrett Company, a premier provider of Energy Services Performance Contracting and Facilities Management Services to the Commercial and Industrial marketplace. Noah began his career at The Brewer-Garrett Company in 2010 as an Energy Auditor. During his nine years with the company, his responsibilities have included the assessment and energy auditing for over $60 million dollars’ worth of guaranteed energy savings. He has performed numerous Measurement and Verification tests on multiple energy conservation projects and developed many original projects leading to millions of dollars in utility savings for various facilities and industries. Noah is a Certified Energy Manager and a registered Professional Engineer in Ohio. He is a graduate of Case Western Reserve University with a Bachelor of Science in Mechanical Engineering.

Successful Energy Efficiency & Energy Reduction at Kent State University & The Ohio State University

Robert Misbrener, Project Manager Kent State University Kelly Tisdale, Energy Services General Manager, Brewer‐Garrett Noah Brewer, Senior Energy Engineer, Brewer‐Garrett Allan Leary, Senior Energy Engineer, Office of Student Life, The Ohio State University

February 20, 2019

Agenda

• KSU Overview
• CHP History
• CHP currently at KSU
• Control Systems Used
• Resilience experience at KSU

Combustion Turbines Old Plant

• Heating plant was a 1940s design, coal and natural gas

boilers, efficiency/operations issues, no central chilled water facility, old electrical distribution system, land locked, required major upgrades to meet EPA guidelines.

• Starting considering CHP concept in the mid 1990s;

pivotal point was in 1997; issues with how to build a new plant/system while maintaining current operations and construction of the new facility

• New equipment/system would provide benefits, but

realized the advantages of CHP to lower electrical costs, improve efficiencies, etc. Further advantage was having ability to secure high pressure gas eliminating need for gas compressors for combustion turbines.

• Construction started in 2000; first unit GT1 installed in

2003, second unit installed in 2004; steam driven vapor compression chiller installed 2005.

Changes

• Natural gas price volatility; Hurricanes Katrina and Rita 2005; 2008 Credit

Crunch and Economic Meltdown; 2011 Shale gas takes off; cold weather periods.

• KSU starts multiyear risk management/hedge strategy to obtain natural gas

requirements in 2008.

• Electricity customer choice is available; FE part of PJM; other changes in

industry

• KSU’s new paradigm started in 2009.
• First 10 years regulated
• Risk adverse
• 2009 – 2013: transitioned moved to deregulated
• 2013 – 2015: optimized participation in the new markets

CHP Currently at KSU

• Spark spread difference between

buying vs. producing.

• Available when generating due to

tariff, gas prices, and generally low heat rates.

• Positive impact on PJM capacity

costs by using turbines, chiller fleet, energy management system, etc. appropriately.

• Positive impact on ATSI transmission

costs with the Now Market Based (NMB) Pilot Transmission Program by using turbines, chiller fleet, energy management system, etc. appropriately.

CHP Currently at KSU (Continued)

• Participate in the Emergency

Capacity Demand Response Program.

• Participate in the Economic Load

Demand Response Program.

• Will be entering Synchronous

Demand Response Program soon.

• Numerous energy conservation

projects throughout the campus.

• Can Island Mode.

CHP Currently at KSU (Continued)

• Can Black Start but not fully developed at this time.
• Cannot export into grid due to technical/equipment issues – will be

working on this.

• More items being explored.

Control Systems Used at KSU

• Multiple resources available for

support.

• Hierarchical and decentralized system

with all units capable of operating with local controls if necessary. Ethernet ring for communications. Can operate equipment from control room or remotely on operating floor with proper equipment/connection.

• Isolated private network with secure

access controls data flow into and out

• f plant.
• Rockwell PLCs in Power Plant using Wonderware for

boilers, turbines and BOP equipment.

Control Systems Used (Continued)

• JCI Metasys used on chillers
• Hierarchical and

decentralized system with all units capable of

• perating with local controls

if necessary. Ethernet network for

• communications. Can
• perate equipment from

Energy Management Office

• r remotely with proper

equipment/connection.

• Isolated private network.

Control Systems Used (Continued)

• Proper and good quality communications required between Power

Plant, Energy Management, and UFM.

• Recently installed math based Model Predictive Control system to
• ptimize plant operations. JCI EOS
• Minor adjustment to equipment/operations are done with local

controls or EOS commands.

• Major adjustments are a combination of EOS commands, EMG

commands, or decisions by Power Plant personnel.

Resilience Experience at KSU

• The ability to routinely test and train personnel in

Island Mode and Black Start operations has been

• challenging. This is required and needs to be done

with routine frequency. A single test or multiple tests with extraordinary assistance is not a realistic test.

• Consider the impact of inrush current and

equipment capabilities. Consider alternative system designs to avoid problems and allow for maintenance activities. Consider a mix of generation resources to alleviate issues. Research any EPA ramifications.

• Determine what level of service is actually required

and size equipment, with ample contingencies, and install it. Be realistic and anticipate problems. Adequately communicate the expected level of service including anticipated curtailments.

Resilience Experience at KSU (Continued)

• People have experience on the

consumption side but there is limited experience on the production side. There can be misunderstandings on how the two merge with less than desirable results. Make sure your people are adequately trained.

• As mentioned earlier, KSU can

Black Start but this will require additional effort to resolve the

• issues. However, we have had

multiple positive experiences recently with Island Mode.

Resilience Experience at KSU (Continued)

• KSU’s Island Mode Experiences:
• We have been able to test Island Mode on a yearly basis, typically on the

celebrated Veterans Day for the campus, or as required for other time

• periods. This process has been “formalized” and helps to reduce the anxiety
• f this event. Further, we perform the required maintenance on the controls

and instrumentation as required.

• For some time periods, campus load reductions will not be required, but

during other time periods load reductions are necessary.

• Emergency generators are tested routinely and changes are made as

required.

• We identified each load/feeder breaker with a priority number. This is

reviewed annually to accommodate any changes on campus.

Resilience Experience at KSU (Continued)

• KSU’s Island Mode Experiences:
• Load control is accomplished by several methods to prevent the turbines from

tripping.

• Minor load changes can be done by JCI Metasys by the Energy Management Group.

These are a combination of shutting off unneeded equipment, lights, etc.

• An “all stop” switch is available in the Power Plant Control Room to shutdown a wide

array of equipment quickly, if required.

• A load control program is operated by EMG that shuts down additional equipment if
• required. The parameters of this program can be changed to meet the conditions.
• A Load Shed program with variable/selectable inputs automatically curtails load by
• pening load/feeder breakers to the campus. This is done by tripping the lowest priority

load first and will continue every 3 seconds until the load is within parameters.

RPAC Complex

The Ohio State University

17

Consist of 4 buildings

• ver 1/2 million SF

Recreational & Physical Activity Center Physical Activity & Education Services (PAES) RPAC Aquatic Center McCorkle Aquatic Pavilion

Energy Management & Sustainability

18

No Direct Control of Energy Systems

RecSports Facility Operations & Development (FOD) Student Life

Aged BAS

Not networked, only one access point

Aged sensors, controls, and valves

Calibration, nonfunctional, blow by

Energy Management & Sustainability

Challenges

19

Director level buy in

Involved Directors from RecSports, FOD, and Student Life

Communication

Multiple departments involved

Constant monitoring

Keep the ball rolling; strive to complete one task each week

Energy Management & Sustainability

Keys to Success

20 Energy Management & Sustainability

Results

50 100 150 200 250 300 350 400 450 50000000 100000000 150000000 200000000 250000000 300000000 2014 2015 2016 2017 2018

EUI (kbtu/SF) kbtu Year

kbtu & EUI

kbtu EUI

21 Energy Management & Sustainability

More Graphs

22 Energy Management & Sustainability

More Graphs
