Victron Global Remote Victron Ethernet Remote

Contents

• System overview diagrams
• Detailed connection schematics
• Examples of Text messages (SMS)
• vrm.victronenergy.com: free online portal
• Configuring GPRS
• VGR Configure software
• Remote VEConfigure

Overview - Victron Global Remote

Overview - Victron Ethernet Remote

System schematics

There are four main different configurations possible:

• VGR with BMV and/or VE.Bus
• VGR with BMV and/or VE.Bus and IO Extender
• VER with BMV
• VER with VE.Bus

VGR with BMV and/or VE.Bus

VGR with BMV and/or VE.Bus and IO Ext.

VER with BMV

VER with VE.Bus

Text messaging

Send message to VGR: Reply message:

info System state: inverter Alarms: none Warnings: none DC: 48.97V 16.71A in AC in: 0.0V 0.0A 0.0Hz AC out: 229.9V 3.8A 60Hz Battery: 26.6V, -017A Level: 98%, -8Ah TTG: 240h Information from BMV Information from Multi

Text messaging – IO Extender

Send message to VGR: Showing the IO Extender status Reply message:

io IO OUT1: open OUT2: open IN1: open IN2: open IN3: closed Temperature: 39C/102F

Text messaging – IO Extender

Send message to VGR: Closing one of the two contacts. To start, for example, a generator. Reply message:

• utput 1 closed

IO OUT1: open OUT2: closed IN1: open IN2: open IN3: closed Temperature: 39C/102F

Text messaging – gsm network status

Send message to VGR: Reply message:

gsm GSM imei: 354662030005820 sim: OK signal: -67dB ber: 0 network: home (Vodafone ES) SMS from: +31646077489 60dB is full signal 113dB is no signal

Online portal

The Victron Global Remote can log information to our online portal. Necessary: a working internet connection:

• Victron Global Remote: GPRS
• Victron Ethernet Remote: Ethernet / LAN

Online portal

https://vrm.victronenergy.com Demo account: demo@victronenergy.com / vrmdemo

Online portal: GPRS

Get the GPRS status: Reply message:

gprs GPRS user: vodafone pass: vodafone apn: office.vodafone.nl state: connected ip: 109.32.239.49 Necessary to log information to the website Victron Global Remote2: A GPRS Connection is necessary to send the information to the online database. Victron Ethernet Remote: It will send the information via the LAN. The LAN needs to have internet access.

Online portal: GPRS configuration

To configure GPRS, you need the following information from your telecom provider: APN Required Username Optional Password Optional Proxy address and port Optional To find this information, you can also search Google. For example search for “GPRS Vodafone APN”. After looking around you will find the following information: APN: live.vodafone.com Username: vodafone Password: vodafone

Online portal: GPRS Configuration

Configuration with APN only: Reply message:

gprs apn live.vodafone.com on GPRS user: username pass: password apn: live.vodafone.com state: connected ip: 109.32.239.49

Configuration with APN and user Reply message:

gprs apn live.vodafone.com user vodafone pass vodafone on GPRS user: vodafone pass: vodafone apn: live.vodafone.com state: connected ip: 109.32.239.49

Online portal: GPRS Configuration

Some providers also use a proxy. One example is KPN in the Netherlands. Configuration with proxy: Reply message:

gprs apn portalmmm.nl proxy 10.10.100.20 port 5080 on GPRS user: username pass: password apn: portalmmm.nl proxy: 10.10.100.20 port: 5080 state: connected ip: 109.32.239.49

To remove the proxy configuration:

gprs proxy # GPRS user: username pass: password apn: portalmmm.nl state: connecting

Online portal: log interval

Send message to VGR: Log interval configuration. And info when the last data was pushed to the database (https://vrm.victronenergy.com) Very useful to check of the gprs connection is OK! Reply message:

log LOG Period: 5min Extra: off Last log: 1 minutes 3 seconds ago

VGR Configure software

• Necessary to configure Victron Ethernet Remote,

since you cannot send text messages to it, unless you put a sim-card in the Ethernet Remote.

• Available for download on our website

VGR Configure software

General Settings:

VGR Configure software

GSM settings:

VGR Configure software

Network settings:

VGR Configure software

Reset to factory settings:

Remote VEConfigure

• Change VEConfigure settings over the air
• Can be done with the Victron Global Remote 2 and the Victron

Ethernet Remote

• This is not possible with old Global Remote’s (“Victron Global

Remote”)

• Make sure to use the latest version of VEConfigure2
• See also the manual on our website at the VGR and VER pages:

“Manual – Remote VEConfigure”.

Remote VEConfigure – procedure example

• 1. Read settings
• 2. Go to the VRM website and download the .VSC

file

• 3. Change the settings in VEConfigure
• 4. Upload them back to the website

veconf read Veconf in progress… Reading .vsc for dev 1 is succeeded

Remote VEConfigure – procedure example

• 5. Write settings

Finished! Now the VE.Bus system has been updated with the new settings made.

veconf write Veconf in progress… Writing .vsc for dev 1 succeeded

Remote VEConfigure – procedure example

How can we found out how many devices are in a system?

veconf devnum Number of devs is 1!
