OBIS 6-Laser Remote
The OBIS laser with shutter, OBIS Remote key switch, interlock and 5- second delay allows the OBIS laser system to conform to CDRH Class 3b laser safety requirements.
SLIDE 4
Superior Reliability & Performance August 2009
- P. 4
Superior Reliability & Performance January 30, 2013
- P. 4
Superior Reliability & Performance
- P. 4
OBIS 6-Laser Remote
The OBIS 6-Laser Remote can provide an easy installation for power and on/off operation. Includes key switch and interlock.
SLIDE 5
Superior Reliability & Performance August 2009
- P. 5
Superior Reliability & Performance January 30, 2013
- P. 5
Superior Reliability & Performance
- P. 5
OBIS 6-Laser Remote
The OBIS 6-Laser Remote comes with wavelength tags to identify each laser connected.
SLIDE 6
Superior Reliability & Performance August 2009
- P. 6
Superior Reliability & Performance January 30, 2013
- P. 6
Superior Reliability & Performance
- P. 6
OBIS 6-Laser Remote
CDRH safety features such as interlock, key switch and emission indicators.
SLIDE 7
Superior Reliability & Performance August 2009
- P. 7
Superior Reliability & Performance January 30, 2013
- P. 7
Superior Reliability & Performance
- P. 7
OBIS 6-Laser Remote
Each laser can be individually selected of power on/off.
SLIDE 8
Superior Reliability & Performance August 2009
- P. 8
Superior Reliability & Performance January 30, 2013
- P. 8
Superior Reliability & Performance
- P. 8
OBIS 6-Laser Remote
Color coded cables included.
SLIDE 9
Superior Reliability & Performance August 2009
- P. 9
Superior Reliability & Performance January 30, 2013
- P. 9
Superior Reliability & Performance
- P. 9
OBIS 6-Laser Remote
Single power supply included to drive six lasers with remote. Power supply capable of driving six OBIS lasers simultaneously.
SLIDE 10
Superior Reliability & Performance August 2009
- P. 10
Superior Reliability & Performance January 30, 2013
- P. 10
Superior Reliability & Performance
- P. 10
OBIS 6-Laser Remote Power Supply Dimensions
Power Supply Dimensions. Includes on/off switch and IEC-320 input.
CONNECTOR 6-PIN MALE MOLEX P/N 43025-0600 6X CONTACT PIN, MOLEX P/N 43030-009 Pins 1,2,3 Ground Pins 4,5,6 at 12 VDC
SLIDE 11
Superior Reliability & Performance August 2009
- P. 11
Superior Reliability & Performance January 30, 2013
- P. 11
Superior Reliability & Performance
- P. 11
OBIS 6-Laser Remote
Six remote-to-laser power cables included. Color coded for easy installation and identification. One meter length.
SLIDE 12
Superior Reliability & Performance August 2009
- P. 12
Superior Reliability & Performance January 30, 2013
- P. 12
Superior Reliability & Performance
- P. 12
OBIS 6-Laser Remote – Purchased Separately, 1203909
6-Laser Remote Laser-to-Remote Cables 6-Laser Power Supply and Cord
Mounting Hardware for Remote
Memory Stick includes User Manual Laser Safety Pamphlet Interlock for Remote Keys for Remote Wavelength Labels
The OBIS 6-Laser Remote can add to your laser purchase the following to complete the system.
Laser Not Included
USB Cable
Not Included
Bolts and Washers Not Included
SLIDE 13
Superior Reliability & Performance August 2009
- P. 13
Superior Reliability & Performance January 30, 2013
- P. 13
Superior Reliability & Performance
- P. 13
OBIS Single Laser Remote compared to 6-Laser Remote
OBIS Six Laser Remote
Advantages:
- Control of up to 6 OBIS Laser
- Simple power cable to the laser
- NO SDR cable required
- Single Power Supply for 6 lasers
Remarks
- Does not support modulation
- Does not support RS-232
- Customer can get USB from the laser
OBIS Single Laser Remote
Advantages:
- Full control features and status
indicators
- Analog and digital modulation inputs
- USB and RS-232 at the Remote I/O
connections Remarks
- Only used with one laser at a time
- SDR cable required to connect to
laser
SLIDE 14
Superior Reliability & Performance August 2009
- P. 14
Superior Reliability & Performance January 30, 2013
- P. 14
Superior Reliability & Performance
