www.osram.com LiDAR Teach-In OSRAM Licht AG | June 20, 2018 | Munich Light is OSRAM Agenda Introduction Autonomous driving LIDAR technology deep-dive LiDAR@OS: Emitter technologies Outlook OSRAM Licht AG 2 LiDAR Tech

slide-1
SLIDE 1

LiDAR Teach-In

OSRAM Licht AG | June 20, 2018 | Munich Light is OSRAM

www.osram.com

slide-2
SLIDE 2

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

2

Agenda

  • Introduction
  • Autonomous driving
  • LIDAR technology deep-dive
  • LiDAR@OS: Emitter technologies
  • Outlook
slide-3
SLIDE 3

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

3

OSRAM has extensive autonomous driving expertise

Rear light Interior lighting Ambient lighting Adaptive cruise control system (LIDAR) Gesture recognition Pre crash sensing (LIDAR) Rain sensor LED/Laser head- up display Daytime running light 3-D environment detection (LIDAR) Side view and lane detection Ambient light sensor Driver monitoring Headlamp (e.g. laser, matrix)

LED – Non visible LED – Visible

slide-4
SLIDE 4

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

4

OS is a long-time partner for lasers in the automotive industry

905 nm pulse Laser, 75 W, 20 ns OS with pioneer role and a proven track record

  • LiDAR Laser supplier to automotive

industry for over 10 years

  • ver 10 million LiDAR lasers in the field

(~ 200 billion km ) without chip failures

  • zero field failures for 7 million bare dies
  • more than 20 LiDAR design-ins and -wins

with OS lasers Technology USP

  • Highest Efficiency (30%)
  • Best thermal resistance
  • First automotive grade pulse laser on the

market More than 10 car OEMs use laser based AEB1 systems with OSRAM´s 905nm laser already today Short-range-LiDAR – Cam System First use of LiDAR since early 2000s

1) AEB: Auto emergency breaking

slide-5
SLIDE 5

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

5

Agenda

  • Introduction
  • Autonomous driving
  • LIDAR technology deep-dive
  • LiDAR@OS: Emitter technologies
  • Outlook
slide-6
SLIDE 6

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

6

L0

Driver Only

There are 6 levels of autonomous driving, between no automation (L0) up to full control by system (L5)

L1 L4 L5 L2 L3 Humans always monitor driving functions Humans do not always monitor driving functions

Driving Assistance High Automation System Only Partial Automation Conditioned Automation

Role of driver Role of system None Driver always with full control Some automation by electronics Driver always in charge of monitoring Driving assis- tance in specific and limited situations Driver needs to be ready to regain control Perform driving functions and recognize limits Driver only needs to act in specific driving conditions Full control in defined driving conditions No driver needed Full control Eyes + hands on Eyes on + hands temporary off Eyes + hands temporary off Eyes + hands off Eyes + hands + mind off

slide-7
SLIDE 7

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

7

All of today‘s potential sensor solutions for ADAS have specific strengths and weaknesses; hence all are needed to guarantee full functionality

LIDAR Camera Radar

Surround view Surround view Environment Mapping Environment Mapping Environment Mapping Environment Mapping Environment Mapping Surround view Traffic Sign recognition Lane departure warning Emergengy braking Pedestrian detection Collision avoidance Environment mapping

Value propositions of different technologies (selection) Camera Color vision and ability to recognise signs Radar Speed detection and ability to function in unfavorable weather conditions / darkness LiDAR 3D capability and ability to function in unfavorable weather conditions / darkness

  • The vehicles ability to ‚see‘ (= sense its environment)

strongly depends on the environmental conditions, such as day time or weather

  • Full functionality at any environmental condition therefore

requires different and redundant sensors

  • In addition, redundancy is being generated using intelligent

algorithms (sensor fusion)

Cross traffic alert Blind spot detection Rear collision warning

slide-8
SLIDE 8

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

8

Only the combination of Camera, Radar and LiDAR will provide the capabilities required for autonomous driving.

Camera Radar LiDAR Combination of all three systems Range Resolution / Accuracy 3D capability Immunity to weather (rain / fog / snow) Works in dark Works in very bright light Interference effects Price Detection of speed of objects Inherent technical capabilities Environmental conditions Other Size Read signs and see colors

Status today Status today

  • Only the combination of all three systems will provide all technical capabilities needed for autonomous driving
  • In addition, redundancies are desired to increase accuracy and mitigate risk through potential technical failures

Detector systems

slide-9
SLIDE 9

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

9

LiDAR will be required for autonomous driving; 6 or more LiDAR modules for L4/L5

  • Co-existence of LIDAR, RADAR and

camera sensors in Autonomous Driving (L3 upwards)

  • LIDAR crucial for long-range detection

in AD, no different substitute technology available, specifically for object identification

  • Six or more LiDAR modules expected

for L4/L5 LiDAR will play a key role in autonomous driving (especially L3 upwards)

≥ 8 2 ≥ 1

none1

≥ 6 ≤ 1 ≥ 3 ≥ 6 ≥ 10

Number of modules needed by automation level Camera Radar LiDAR Level of automation L2 L3 L4/5

1) Optional for collision warning, AEB

slide-10
SLIDE 10

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

10

MaaS - Mobility as a Service path (e.g. waymo)

Two different approaches to autonomous driving: Mobility providers starting with L5 short term, traditional OEMs evolve from L1 to L5

L3 L5

  • Two completely different approaches to

autonomous driving with different dynamics driven by two distinct groups of players – mobility-as-a-Service providers (MaaS) and traditional car manufacturers

  • MaaS providers pushing for early

introduction of fully autonomous vehicles today in significant numbers

  • Traditional car manufacturers

moving to L3; introduction of fully autonomous cars expected for 2024+

  • However, in the long run there will likely be a

convergence of the two approaches ILLUSTRATIVE

  • Robo cars

Convergence L1-2 ADAS1 Level 2018 2020 2022 2024 2026 2000

10

1) Advanced driver assistance systems

slide-11
SLIDE 11

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

11

The LiDAR (emitter) market will see two waves of growth

2015 2022 2021 2020 2019 2018 2017 2016 2023 2024 2025 LiDAR emitter market – total number of laser channels ILLUSTRATIVE MaaS1:

  • Short- and medium-term volume driver with

early introduction of L5 cars

  • Consumer-like business with steep ramps,

driven by Tec companies

  • AM qualification less important
  • Long-range and short-range scanning LiDAR;

large field of view, high resolution Traditional L3-L5:

  • Long-term volume driver: Evolution of

traditional car mass production from L3 to L5

  • Mainly traditional OEMs, quality and AM

qualification very important

  • Long-range scanning or Solid State LiDAR,

short range FLASH Traditional – AEB2

  • Existing LiDAR business since early 2000s
  • Collision mitigation system
  • Traditional OEMs
  • Short range FLASH LiDAR

1) MaaS: Mobility as a Service 2) AEB: Auto emergency breaking

slide-12
SLIDE 12

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

12

Agenda

  • Introduction
  • Autonomous driving
  • LIDAR technology deep-dive
  • LiDAR@OS: Emitter technologies
  • Outlook
slide-13
SLIDE 13

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

13

LiDAR uses reflected light to measure distance to objects; it can be used for short-range up to a distance of ~300m

Detection principle: A very short laser pulse travels from the LiDAR sensor to an object and

  • back. The sensor measures the

travelling time of the laser pulse and determines the distance and relative velocity of the object. 100 m distance  0,6 ms LiDAR (Light Detection and Ranging) – a Time of Flight measurement

slide-14
SLIDE 14

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

14

Multiple module system to dominate – combination of short / mid range and long range LIDARs

  • ptional for

collision warning, AEB 2-4 SRL for 360° sensing Depending on L-level, different LiDAR systems are used # SRL1 # LRL2 0-2 0-1 1 LRL to the front rear LRL for fast on coming vehicles 1-2 2-4 SRL for 360° sensing

  • ptional

2) Long range LIDAR 1) Short range LIDAR

L1, L2 L3 L5 L4 Lidars can be used for different distances and use cases

20m 100m

Short range (<20m) Medium range (20 to 100m) Long range (>100m)

  • Stop & Go
  • Automatic Emergency

Breaking (AEB)

  • Pre-crash sensing
  • Lane departure warning
  • Blind spot detection
  • Adaptive cruise control (ACC)
  • Long Range LiDAR (LRL) for

autonomous vehicles (L4/L5)

slide-15
SLIDE 15

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

15

Laser

A LiDAR system consists of different building blocks

Process captured signal and feedback time stamps to emitter ASIC1 Capture the reflected photons Photo Detector L e n s

DETECTOR

L e n s Illuminate the scene in front EMITTER Data visualization

  • r interpretation,

analysis, filter, localization and control signals PROCESSING & CONTROL LiDAR system overview

  • The emitter is triggered by the

ASIC (application specific integrated circuit) and sends out invisible light

  • The light is reflected from objects in

the field of view and the signal captured by the detector

  • The signal is then processed by the

ASIC1 and forwarded to the processing unit

  • Here, analysis of the signal takes

place, potentially taking signals from other sensors (e.g. radar or camera) into account Key steps for signal acquisition

1) Application specific integrated circuit

slide-16
SLIDE 16

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

16

A LiDAR system consists of different building blocks

Process captured signal and feedback time stamps to emitter ASIC1 Capture the reflected photons Photo Detector L e n s

DETECTOR

Laser L e n s Illuminate the scene in front EMITTER PROCESSING & CONTROL LiDAR system overview

  • The emitter is triggered by the

ASIC (application specific integrated circuit) and sends out invisible light

  • The light is reflected from objects in

the field of view and the signal captured by the detector

  • The signal is then processed by the

ASIC1 and forwarded to the processing unit

  • Here, analysis of the signal takes

place, potentially taking signals from other sensors (e.g. radar or camera) into account Key steps for signal acquisition Focus today Data visualization

  • r interpretation,

analysis, filter, localization and control signals

1) Application specific integrated circuit

slide-17
SLIDE 17

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

17

There are two basic LiDAR technical implementations – flash and scanning LiDAR

Scanning LiDAR Flash LiDAR

  • The whole FOV is illuminated at once using a

wide-angle beam

  • No moving parts in the LiDAR module
  • Scanning, narrow emitter beam which is being moved

across the FOV over time

  • Mechanical solution or micro-mirrors used for beam steering

EMITTER EMITTER

  • High to very high

power needed to illuminate the whole scene with one laser beam

  • In the future, laser

bars (edge emitting laser) with high power for longer distances or potential use of VCSEL for SRL

  • Highly directional

beam with high power needed

  • Good thermal

performance for high repetition rate

  • Today and in

future edge emitting lasers

  • perating at

905nm expected to dominate

slide-18
SLIDE 18

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

18

Agenda

  • Introduction
  • Autonomous driving
  • LIDAR technology deep-dive
  • LiDAR@OS: Emitter technologies
  • Outlook
slide-19
SLIDE 19

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

19

Edge emitting lasers at 905nm are the best overall fit for LiDAR requirements in terms of cost position, efficiency and output

Laser technology VCSEL Comparison of basic laser technology and wavelength Fit to LiDAR requirements

  • Light emitted from surface
  • f laser die

Component cost

  • Temp. stability1)

Conclusion Output power Efficiency Potential use for short range LiDAR Eye safety Technology too expensive Best overall fit to requirements

  • In most cases, edge

emitting laser @905nm expected to be the winning technology

  • 1550nm with better eye

safety, but otherwise lagging behind and too expensive for customer requirements

  • VCSEL potentially

useful for short range LiDAR, but yet to be automotive qualified Edge emitting laser

  • Light emitted from a small area in the side of the laser die

<1000nm2) Emitting area >1000nm typically <1000nm

1) With regard to power 2) typically 905nm

slide-20
SLIDE 20

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

20

Osram: we offer solutions for all relevant LiDAR technologies based on 905 nm Lasers

FLASH Smart Laser 4 channel SMT Highest Power: Laser Bars 1 channel SMT 1 or 4 channel SMT Integrated versions Customized laser bars OSRAM is in discussion with all relevant players from the LiDAR ecosystem and we further develop our portfolio based

  • n their needs

bare laser dies Today 2018/19 OS product roadmap for different LiDAR technologies

  • First AM grade pulse

laser on market

  • Best performance in the

market

  • Very short pulses

(1ns demonstrated)

  • Increased
  • utput power
  • More laser channels
  • AM qualified

packages

  • Customization
  • Integrated solutions
  • Multichannel

versions / laser bars Beyond Evolution of 905nm edge emitting laser SELECTIVE MEMS / Solid state Mecha- nical Scanning Chip- and package variations based on OS Platform

slide-21
SLIDE 21

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

21

Agenda

  • Introduction
  • Autonomous driving
  • LIDAR technology deep-dive
  • LiDAR@OS: Emitter technologies
  • Outlook
slide-22
SLIDE 22

OSRAM Licht AG LiDAR Tech Teach-In | June 20, 2018

22

  • Strong position in

emitter lasers

  • Evaluating portfolio

fit of detectors

  • Signal processing

OSRAM is well positioned to participate in the LiDAR market

Next to our strong position in emitter lasers for LiDAR systems, we are evaluating to extend our portfolio in the area of detector components and smart modules, concentrating on the essentials of data fusion:

  • working closely together with LeddarTech in order to assess the industrialization of LiDAR modules for the automotive mass market.

Specific focus is on affordable long-range LiDAR modules

  • acquired a strategic stake in the LiDAR start-up company Blickfeld. Its particular strengths lie in beam steering technology, which

permits a full scanning of the surrounding environment

  • smaller, purely financial investment in the start-up company Tetravue, which uses a unique approach for high-resolution depth images
  • Optics and beam

control

  • High resolution

depth images

  • Additional

application fields beyond automotive
