SLIDE 1
Unit composed of 44 x 22 tank HR 300 pump 110 kW Two hydrocyclones Ø 1000 Dewaterer N° 14 Sand production : 350 to/h
With over 20 years on site experience SOTRES SOTRES is specialised - - PowerPoint PPT Presentation
With over 20 years on site experience SOTRES SOTRES is specialised - - PowerPoint PPT Presentation
59, rue Fernand Forest Tel : + 33 (0) 4 73 26 49 17 BP 321 - Romagnat Fax: + 33 (0) 4 73 27 57 88 63543 Beaumont cedex E-mail: sotres@sotres.fr With over 20 years on site experience SOTRES SOTRES is specialised in washing and preparing
SLIDE 2
SLIDE 3
Washing and processing : Concrete sand and industrial sand Washing : Sand from sewer sludge and sand from dredging sludge Water clarification by flocculation Sludge pressing / Filter press Bentonite sludge sand removal Liquid solid separation
SLIDE 4
Sand treatment unit 300 to/h
SLIDE 5
SOTRES SOTRES designs and manufactures sand washing units based
- n samples analysed in our laboratory or on the results of analyses
supplied by the client . These elements mean that we can offer units designed to meet quality requirements ( particle size curve , cleanliness , etc . ) The sand processing units are composed of modular elements which means that we can produce standard assemblies for the simplest installations or adapt the sand processing units to suit each site ’s requirements and the matter to be treated.
SLIDE 6
Sand treatment unit 100 to/h
SLIDE 7
Rep.:1 Rep.:4 Rep.:6 Rep.:5 Rep.:3 Rep.:2
Rep:6 Rep:5 Rep:3 Rep:4 Rep:1 Rep:2
SLIDE 8
WORKING PRINCIPLE WORKING PRINCIPLE
The water and sand are collected in the tank, item 1. The pulpe which is conveyed by a centrifugal pump, item 2, feeds the cyclone, item 3 , tangentially . The centrifugal movement inside it causes liquid - solid separation. The clay, waste and ultra-fine particules are removed by suction by the overflow , item 4. Centrifugal force makes the solids and heavy elements spiral down the cone and are rejected onto the dewaterer, item 5. With a rising slope and fitted with 2 vibrating motors and slotted screens, the dewaterer track makes the sand move along its wholes length. The outlet chute, item 6 , collects the dried sand. Dewaterer undersize elements return to the tank.
SLIDE 9
Sand treatment unit 120 to/h
SLIDE 10
Sand pump units
Sand hydrocyclone - gangway
Dewaterer retractable rear chute Hydro-separator
SLIDE 11
Industrial sand Rotating vacuum dryer Rotating dryer unit
SLIDE 12
Rotating vacuum dryer Industrial sand
SLIDE 13
Rotating dryer unit
SLIDE 14
Hydroseparator
SLIDE 15
Hydroseparator
SLIDE 16
Sand treatment unit 80 to/h
SLIDE 17
Sand treatment unit 120 to/h
SLIDE 18
Sand treatment unit 300 to/h
SLIDE 19
Treatment plant with sand separation
SLIDE 20
Treatment plant with sand separation on dewaterer
SLIDE 21
Sand treatment unit 140 to/h
SLIDE 22
Double cycloning treatment unit
SLIDE 23
Sand treatment unit 120 to/h
SLIDE 24
Double cycloning treatment unit
SLIDE 25
Double cycloning treatment unit
SLIDE 26
Sand treatment unit 60 to/h
SLIDE 27
Sand treatment unit on dredge
SLIDE 28
Sand dewaterer 60 to/h
SLIDE 29
Sand treatment unit on dredge
SLIDE 30
Sand dewaterer 40 to/h
SLIDE 31
Sand dewaterer : 2 sands
SLIDE 32
Sand dewaterers : 2 x 120 to/h
SLIDE 33
Sand treatment unit 2 x 120 to/h
SLIDE 34
Sand separation unit with static screen
SLIDE 35
Hydrocyclone Static screen Dewaterer
Sand separation
SLIDE 36
Sand separation with static screen, double cycloning.
SLIDE 37
Static screen
SLIDE 38
Static screen
SLIDE 39
Static screen
SLIDE 40
Erection of a sand treatment plant ( triple cycloning ) Sand : 150 to/h Water : 800 m3/h
SLIDE 41
Erection of a glass sand treatment plant Sand : 2 x 120 to/h Water : 800 m3/h
SLIDE 42
Double cycloning treatment unit 100 to/h Water treatment 350 m3/h
SLIDE 43
Sand treatment unit 220 to/h
SLIDE 44
Sand treatment unit 220 to/h Water treatment 800 m3/h
SLIDE 45
Sand treatment plant with sand separation
- n dewaterer and static screens : 200 to/h
