ArrowSpan Wireless Mesh Network Solutions Wireless Mesh and Point-to-point Bridging Application (US) Confidential Material Aug 2007 Page: 1

MeshBackhaul 2600 / MeshAP 3100 Wireless Mesh Point-to-point Bridging Application � MA3100 = MB2600 + built-in Client AP � Point-to-Point Device Deployment Tools � Remote Antenna Locator (RAL) Real time HTML GUI indicator detect remote antenna � Signal Strength Tuner (SST) Fine tuning Antenna position to maximize node-to-node signal quality � User adjustable Tx power to meet the needs for deployment Page: 2

Point-to-Point Wireless Bridging Application In a point-to-point bridging scenario, a MB2600 or MA3100 Series can be used to extend a network distance by using high gain directional antennas MA3100 Mesh 2.4GHz Manager MB2600/ MA3100 5GHz MA3100 ~km @54Mbps* Internet 5GHz 5GHz Rural MA3100 Area 5GHz 5GHz Mesh 2.4GHz Station High Gain MA3100 Directional (Manual Mode) Antenna * For detail of Tx Power, Antenna, and Distance, check the RF Table on Slide 6 Page: 3

Wireless Backhaul Bridging Application Multiple MB2600s could relay link connections around the environmental obstructions to the MA3100 Series to form wireless mesh network. High Gain Mesh Directional High Gain Station Antenna for Directional MB2600/ Point-to-point Antenna for MA3100 Point-to-point MA3100 (Manual Mode) 2.4GHz 5GHz Internet 5GHz 2.4GHz Environmental Mesh 5GHz Obstruction 5GHz Manager 5GHz MB2600/ Mesh MA3100 Station MA3100 MA3100 (Manual Mode) MA3100 Page: 4

Fault-tolerance Point-to-point Bridging Application Fault-tolerance is critical under the point-to-point bridging scenario. Multiple MeshAP Managers and Stations could be setup to backup the vital link between the link. 1 Mesh Manager MB2600/MA3100 Broken Link 5GHz 5GHz RJ-45 Internet Backup Link Ethernet Mesh (RJ-45) Station MA3100 2 (Manual Mode) Mesh Manager High Gain MB2600/MA3100 Directional Antenna Page: 5

RF Power Option (point-to-point antenna) 1/2 Product: MA3100-A / MB2600-A [5.745-5.805GHz] MA3100-A / MB2600-A [5.745-5.805GHz] Based on US FCC regulations Antenna Gain 19dBi 23dBi 26dBi 29dBi Data Rate Tx Power Maximum Node-to-Node Distance (Throughput) 15dBm 1.3Km 2.4Km 3.8Km 5.8Km 54Mbps 16dBm 1.4Km 2.6km 4.1Km 6Km (30Mbps) 17dBm 1.5Km 2.8Km 4.4Km 6.5Km 18dBm 1.7Km 3Km 4.8Km 7Km 15dBm 2Km 3.8Km 6Km 9.2Km 16dBm 2.2Km 4Km 6.4Km 9.8Km 48Mbps 17dBm 2.4Km 4.3Km 6.9Km 10.8Km (27Mbps) 18dBm 2.6Km 4.7Km 7.4Km 11.7Km 19dBm 2.8Km 5.1Km 8Km * 15dBm 3Km 5.6Km 8.5Km 13.5Km 16dBm 3.3Km 5.9Km 9.2Km 14.5Km 36Mbps 17dBm 3.6Km 6.4Km 10Km 15.5Km (20Mbps) 18dBm 3.9Km 6.9Km 10.8Km 16.5Km 19dBm 4.1Km 7.4Km 11.6Km * 20dBm 4.4Km 8Km 12.5Km * 17dBm 4.4Km 8Km 12.5Km 18.5Km 24Mbps 18dBm 4.8Km 8.5Km 13.5Km 20Km (13Mbps) 19dBm 5.2Km 9.2Km 14.5Km * 20dBm 5.5Km 10Km 15.5Km * *Exceeds FCC maximum EIRP Limit, it’s illegal to implement such settings in USA. Page: 6

Tx Power Option (point-to-multipoint antenna) 2/2 Product: MA3100-A / MB2600-A [5.745-5.805GHz] MA3100-A / MB2600-A [5.745-5.805GHz, 8dBi ANT-ODA5108 antenna] Wireless Rate (Throughput) Maximum Node-to- 54Mbps 48Mbps 36Mbps 24Mbps 18Mbps Node Distance (30Mbps) (27Mbps) (20Mbps) (13Mbps) (10Mbps) 5dBm 74 m 140 m 240 m 320 m 460 m 6dBm 83 m 155 m 270 m 350 m 500 m 7dBm 93 m 175 m 300 m 390 m 550 m 8dBm 102 m 200 m 320 m 420 m 600 m 9dBm 113 m 220 m 350 m 460 m 660 m 10dBm 125 m 240 m 390 m 500 m 720 m 11dBm 140 m 270 m 420 m 550 m 780 m 12dBm 155 m 300 m 460 m 600 m 840 m Tx 13dBm 175 m 320 m 500 m 660 m 900 m Power 14dBm 200 m 350 m 550 m 720 m 1,000 m 15dBm 220 m 390 m 600 m 780 m 1,070 m 16dBm 240 m 420 m 660 m 840 m 1,150 m 17dBm 270 m 460 m 720 m 900 m 1,250 m 18dBm 300 m 500 m 780 m 980 m 1,350m 19dBm N/A 550 m 840 m 1,060 m 1,450 m 20dBm N/A 900 m 1,150 m 1,600 m N/A 21dBm N/A N/A N/A N/A 1,700 m 22dBm 1,800 m N/A N/A N/A N/A *Distance Data based on non-interference environment Page: 7

RF Power Option (point-to-point antenna) 1/2 Product: MA3100-AX / MB2600-AX [5.745-5.805GHz] MA3100-AX / MB2600-AX [5.745-5.805GHz] Based on US FCC regulations Antenna Gain 19dBi 23dBi 26dBi 29dBi Data Rate Tx Power Maximum Node-to-Node Distance (Throughput) 18dBm 2.6 km 4.9 km 7.7 km 12Km 19dBm 2.9 km 5.3 km 8.1 km * 54Mbps 20dBm 3.1 km 5.7 km 8.8 km * (30Mbps) 21dBm 3.4 km 6.1 km 9.6 km * 22dBm 3.6km 6.6 km * * 18dBm 3.4 km 6.1 km 9.6 km 15 km * 19dBm 3.6 km 6.5 km 10.3 km 48Mbps 20dBm 3.9 km 7.0 km 11km * (27Mbps) 21dBm 4.2 km 7.7 km 12 km * 22dBm 4.6 km 8.3 km * * 23dBm 5 km 9 km * * 18dBm 5.3 km 9.5 km 15 km 23 km 19dBm 5.7 km 10.3 km 16.2 km * 20dBm 6.1 km 11.1 km 17.5 km * 36Mbps * 21dBm 6.6 km 12 km 19 km 22dBm 7.1 km 13 km * * (20Mbps) 23dBm 7.6 km 14 km * * 24dBm 8.2 km 15 km * * 25dBm 9 km * * * 18dBm 6.7 km 12 km 18.5 km 30 km 19dBm 7.1 km 13 km 20 km * 20dBm 7.7 km 14 km 22 km * * 21dBm 8.3 km 15.2 km 24 km 24Mbps 22dBm 8.9 km 16.5 km * * (13Mbps) 23dBm 9.5 km 17.7 km * * * * 24dBm 10.2 km 19 km 25dBm 11 km * * * 26dBm 12 km * * * Page: 8 27dBm 13 km * * * *Exceeds FCC maximum EIRP Limit, it’s illegal to implement such settings in USA.

Tx Power Option (point-to-multipoint antenna) 2/2 Product: MA3100-AX / MB2600-AX [5.745-5.805GHz] MA3100-AX / MB2600-AX [5.745-5.805GHz, 8dBi ANT-ODA5108 antenna] Wireless Rate (Throughput) Maximum Node-to-Node 54Mbps 48Mbps 36Mbps 24Mbps 18Mbps Distance (30Mbps) (27Mbps) (20Mbps) (13Mbps) (10Mbps) 18dBm (63mW) 450 m 600 m 980 m 1,250m 1,700 m 19dBm (79mW) 500 m 650 m 1,050m 1,350 m 1,800 m 20dBm (100mW) 550 m 700 m 1,150 m 1,450 m 1,950 m 21dBm (126mW) 600 m 770 m 1,250 m 1,550 m 2,100 m Tx 22dBm (159mW) 650 m 840 m 1,350 m 1,700 m 2,250 m Power 23dBm (200mW) 700 m 910 m 1,450 m 1,800 m 2,450 m 24dBm (251mW) N/A 980 m 1,550 m 1,950 m 2,600 m 26dBm (398mW) N/A N/A 1,800 m 2,250 m 3,000 m 28dBm (631mW) N/A N/A N/A 2,600 m 3,500 m *Distance Data based on non-interference environment Page: 9
