What is a mesh network? A mesh network is created when many devices have established communication between them in more than one way. Any device with an appropriate wireless node can participate in a mesh network. Initialising

What is a mesh network? • A mesh network is created when many devices have established communication between them in more than one way. • Any device with an appropriate wireless node can participate in a mesh network.
Initialising communication Each device establishing communication with neighbouring devices
Mesh network Connection to Gateway can follow many routes
Connection with Cloud • The Cloud service : Lighting control management • Hosted on a remote server. • Accessible through the Internet. • It can manage several projects either assigned to a single customer or to multiple ones. • Accessing the service requires the appropriate credentials.
System overview • Access through WWW • Only pr preapproved devices can access the application
System overview Controlling software
Wireless node options • Option available to selected products Embedded node • Option suitable to facilitate switching from wired to wireless control system. • Universal approach. • Easy maintenance Luminaire + Cable + External node
SYSTEM OVERVIEW NOT TO SCALE
ORDER CODES ACCESSORY DESCRIPTION H3D.WIR Wireless Remote Attachment Box H3D.FL.HAL Interface Lead Haloprism configured for DALI H3D.FL.IBL Interface Lead I-Beam configured for DALI H3D.FL.HOL Interface Lead HOL configured for 1-10V Plug for H3D.WIR with 1M Flying Lead (Prismashield Elite) H3D.FL1.PLUG configured for DALI H3D.PLUG Plug for H3D.WIR Only (Vantage LED and HAL.WL2) NOTE: ALL INTERFACE LEADS HAVE 600MM CABLE LENGTH EXCEPT H3D.FL1.PLUG
Luminaires and accessories with wireless option Description Wireless option Haloprism with DALI control and integrated wireless node HAL.L3947.C1.WI Wireless remote presence detection sensor H3D.PD.WI Wireless remote daylight sensor H3D.RDS.WI Holos 3 wireless Gateway H3D.GATE Holos 3 wireless Cloud based control interface H3D.CLOUD
Products list: Products that can be configured with wireless option: • Haloprism • HOL capsule • Prismashield elite (PSE) • Prismashield elite Emergency (PSE.Lxxx.xx.ME) • I-Beam (IBL) • I-Beam Emergency (IBL.Lxxx.xx.ME)
