SLIDE 1
What is [Block]? Motivation At home Hands occupied Kneading dough - - PowerPoint PPT Presentation
What is [Block]? Motivation At home Hands occupied Kneading dough - - PowerPoint PPT Presentation
What is [Block]? Motivation At home Hands occupied Kneading dough Babysitting Quality time with family Limit personal phone use Important notifications Improves quality of your home experience Features
SLIDE 2
SLIDE 3
Motivation
- At home
- Hands occupied
○ Kneading dough ○ Babysitting ○ Quality time with family
- Limit personal phone use
- Important notifications
- Improves quality of your home experience
SLIDE 4
SLIDE 5
Features
- Smartphone notification passing
- Bluetooth communications
- Gesture control scrolling
- At a glance display
- Light show
SLIDE 6
Android Phone
How does it all work?
Arduino Mega RGB Panel NeoPixel LEDs Bluetooth Dongle Ultrasonic Sensors
SLIDE 7
State Machines
post? app in curr? index = app curr.append(app) index = app total++ total-- index = (index - 1) % total curr.delete(app)
Detecting right swipes Notification update logic
SLIDE 8
Look & Feel
SLIDE 9
SLIDE 10
SLIDE 11
Software Details
- Android
○ JodaTime ○ NotificationListenerService & Bluetooth LE, targets android API 18 +
- Arduino Libraries
○ Adafruit_NeoPixel.h ○ Adafruit_GFX.h ○ RGBmatrixPanel.h ○ Adafruit_BLE_UART.h
SLIDE 12
Performance Analysis
Performance Notification receive time ~1000ms Bluetooth connection speed ~200ms Ultrasonic sensor response time per reading ~20 - 30 ms Minimum time to recognize gesture 4 readings per gesture = ~80ms Ultrasonic sensor range ~200 mm
SLIDE 13
Performance Notification receive time ~1000ms Bluetooth connection speed ~200ms Ultrasonic sensor response time per reading ~20 - 30 ms Minimum time to recognize gesture 4 readings per gesture = ~80ms Ultrasonic sensor range ~200 mm
SLIDE 14
Challenges
- Gesture Control
ഠ LeapMotion → Ultrasonic
- Not Enough DIO/PWM Pins
ഠ Uno x3 → BT, LEDs, Ultrasonic ഠ Arduino Uno → Arduino Mega
- Insufficient Power Supply
ഠ USB → Regulated 5V/10A ഠ Impacted sensor readings
SLIDE 15
Usability
- PCB for cleaner housing
- Interactive sensors
○
clear notifications
- Informative actuators
○
display notification details
○
audio feedback (read messages)
Extensions
- Phone calls & Voice commands
- User modes
Aesthetics
- Color customization
- Improved UI e.g. sliding animations
Improvements
SLIDE 16
SLIDE 17
OTHER DRAFTED MATERIALS
SLIDE 18
SLIDE 19
Arduino Mega
RGB Panel NeoPixel LEDs Android Phone Ultrasonic Sensors
Inputs Outputs System
Bluetooth Module Notifications
SLIDE 20
Right Sensor Left Sensor 20 40 60 80 100 120 140 160 180 200
SLIDE 21
post? app in curr? index = app curr.append(app) index = app total++ total-- index = (index - 1) % total curr.delete(app)
