WHAT DEPTH ? Drillers Depth Determination Harald Bolt 1 45 th General Meeting March 17 th , 2017 The Hague, The Netherlands Wellbore Positioning Technical Section Speaker Information Harald Bolt What Depth ? March 17, 2017

slide-1
SLIDE 1

45th General Meeting March 17th, 2017 The Hague, The Netherlands

Wellbore Positioning Technical Section

WHAT DEPTH ?

Driller’s Depth Determination

Harald Bolt

1

slide-2
SLIDE 2

45th General Meeting March 17th, 2017 The Hague, The Netherlands

Wellbore Positioning Technical Section

  • Harald Bolt
  • What Depth ?
  • March 17, 2017
  • ICT Europe

Speaker Information

2

slide-3
SLIDE 3

Speaker Bio

  • B.Sc. (Comb.Hons), MBA, SPE, SPWLA, EAGE
  • Since 1982 open-, cased-hole, production logging
  • Focus on depth measurement since 1984
  • First SPWLA presentation, Taos, 1997
  • “Wireline Depth Determination”, Rev. 4
  • www.wirelinedepth.com
  • Authored/co-authored 14 along-hole depth-related papers and presentations
  • Team leader for API RP-78 Depth QA-QC
  • Consultant on along-hole depth technologies, methodologies, discrepancies

and issue resolution and data-user/data-supplier audit

Harald Bolt 3

slide-4
SLIDE 4
  • Focus on depth determination
  • Consulting, operations, reconciliation, audit, training
  • Driller’s depth
  • Wireline depth
  • Uncertainty
  • API RP-78 depth data compliance

ICT Europe

slide-5
SLIDE 5

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

What Depth ?

What issue ?? Issue to who ? What accuracy looks like API RP-78 – requirement for uncertainty Driller’s and wireline differences & similarities The issue of correction Tension regime and correction Way-point – for wireline and driller’s Can you now know what depth is ? …..

5

What Depth ? presented by Harald Bolt

slide-6
SLIDE 6

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

Driller’s versus wireline depths Deeper = bigger the difference Deeper = bigger spread Equal spread between wireline companies

Forsyth 2013 SPWLA New Orleans

6

Can we rely on depth data ?

What Is The Issue With Depth ?

slide-7
SLIDE 7

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

7

Measurement use Domain relevance Method Measurement method @10,000 ft Trueness +/- @10,000 ft Precision +/- Geological mapping Major geological events Seismic 2-way time, time/depth conversion = Indicated depth 100 ft 20 ft Well construction Significant reservoir events Driller’s depth Drill pipe = Indicated depth 50 ft 6 ft Mechanical service

  • perations

Minor reservoir events LWD depth Drill pipe = Calibrated depth 30 ft 3 ft Reservoir geometry Major bed events Wireline Measurehead only = Calibrated depth 15 ft 1 ft OWC/GWC mapping Minor bed events Measurehead onlt w/ st.line = Corrected depth 5 ft 0.5 ft Detailed OWC/GWC, fracture mapping Minor bed events

  • Mag. Marks w/ way-point

= Corrected depth 2 ft 0.2 ft Detailed fluid characteristics Detailed petrophysics, compaction events Mag.marks, way-point w/ st.coeff = Corrected depth 1 ft 0.1 ft

  • Different Methods Give Different Results
slide-8
SLIDE 8

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

Seismic from 2-way time = 2.5 – 2.6 miles Log depth = 4,103.753 m

8

How far from Centraal Station to here ?

What Do We Mean With “Accuracy” ?

slide-9
SLIDE 9

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

5:1,000

9

2:1,000 1:1,000 “Accuracy” is more than a number: it is a reality

What Does Accuracy Look Like ?

slide-10
SLIDE 10

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

Is This What We Want Or What We Need ?

8:10,000

10

5:10,000 1:10,000

What is wanted ? Who is prepared to pay for it ?

slide-11
SLIDE 11

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

API RP-78 Depth QA-QC

11

Objective: To recommend standard practices that deliver consistency and accuracy in along-hole depth information, by minimizing errors associated with depth measurement systems, and provide data reporting standards. Result: API RP-78 conformant along-hole depth data will include an uncertainty statement.

slide-12
SLIDE 12

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

Wireline Versus Driller’s Depth

12

driller defined pipe lengths compression/stretch thermal expansion buckling torque buoyancy linear drag rotational friction ballooning hydraulic forces WOB measurement system thermal correction elastic stretch wireline 4 ¼” DP

slide-13
SLIDE 13

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

Drill Pipe Length Calibration

13

+/- 0.2”/31’ ? ≈ 5:10,000 ?? (you’d be lucky !!)

  • max. 1:1,000 more likely

Manual Strapping Laser Length Tally

from Digi-Tally spec.s, ≈ 1.5:10,000 (shop environment ?)

  • max. 2:10,000 more likely

Issues: temperature, vertical/horizontal, consistency, tally management

slide-14
SLIDE 14

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

Wireline Length Calibration

14 IS NOT A CALIBRATION typically 5:10,000 claimed/implied no verification 1:1,000 more likely

Dual-wheel “Wheels-only” Magnetic Marking

up to 1:10,000 shop calibration 2:10,000 more likely

Issues: temperature, tension, calibration stability

slide-15
SLIDE 15

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

Wireline Depth Operations

15

  • enc. 1
  • enc. 2
dual wheel measurehead line surface tension wireline drum

Magnetic mark detector

cablehead tension

dual wheel measurehead

5 : 10,000 implied, but based on what ?? 1 : 10,000 possible

One time correction made prior to Main Log D Down Log to Up Log Log Up depth with correction Log Down depth surface HUD

Wheels-only Magnetic marks

  • enc. 1
  • enc. 2
wireline drum
slide-16
SLIDE 16

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

The Issue Is Correction

16

Drill Pipe Corrections Wireline Corrections

  • model used, parameters
  • verification
  • model used, parameters
  • repeatability of drilling

measurement, verification,

  • thermal expansion
  • compression/stretch, WOB
  • torque, helical buckling,

sinusoidal buckling

  • hydraulic forces, buoyancy,

fluid flow,

  • rotation friction, sliding friction
slide-17
SLIDE 17

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

Why Is Correction An Issue ?

17

correction % of calibrated along-hole depth low uncertainty moderate uncertainty high uncertainty highest uncertainty

slide-18
SLIDE 18

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

Pull Out Of Hole Correction

18

driller defined pipe lengths compression/stretch thermal expansion buckling torque buoyancy linear drag rotational friction ballooning hydraulic forces WOB

✔ ✔ ✔ ✔ ✔

✗ ✗✗✗ ✗ ✗✗ ✗ ✗

measurement system thermal correction elastic stretch wireline 4 ¼” DP

slide-19
SLIDE 19

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

Correction Based On POOH Tension

19

Tension regime describes the tension behaviour per section of the well bore Correction per ft/m is not constant per section Sum of correction of all sections is the total correction Tension is repeatable

various tension regime segments

Cablehead Tension

slide-20
SLIDE 20

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

Way-point Principle Applied

20

Calibrated Line Length Sections

LWD sensor response

Patent Pending GB1702825.9

  • enc. 1
  • enc. 2
dual wheel measurehead line surface tension wireline drum

Magnetic mark detector

cablehead tension

slide-21
SLIDE 21

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

The Main Corrections

21

Thermal correction Elastic stretch correction

ElasticStretch.Corr = Surf.Ten+CHT 2 æ è ç ö ø ÷-TenCalb æ è ç ö ø ÷xCalb.Length1 xSt.Coeff æ è ç ö ø ÷ Thermal.Corr = Surf.Temp+ BHT 2 æ è ç ö ø ÷-TempCalb æ è ç ö ø ÷xCalb.Length xTh.Coeff æ è ç ö ø ÷

? !

slide-22
SLIDE 22

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

Elastic Stretch Correction Per Station

22

slide-23
SLIDE 23

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

Driller’s Depth Way-point Correction

23

Key concept is depth is POOH determined

  • Way-point used in driller’s depth
  • Same model for driller’s and wireline
  • Corrected depth for LWD
  • LWD and wireline depths are compatible
  • Understandable parameters
  • Calculable uncertainty
  • Driller’s True Along-hole Depth

correction % of calibrated along-hole depth low uncertainty moderate uncertainty high uncertainty highest uncertainty

slide-24
SLIDE 24

45th General Meeting March 17th, 2017 The Hague, The Netherlands Wellbore Positioning Technical Section

24

  • Consistency of along-hole depth measurement
  • Coherency of measurement methodology
  • Correction method for both wireline and drill pipe
  • Compliance with (proposed) API RP-78

Conclusion

What Depth ? presented by Harald Bolt
