Week 11 - Monday

 What did we talk about last time?  Project 2 work day  Before that: environment mapping

• Blinn and Newell's method
• Sphere mapping
• Cubic environmental mapping
• Environment mapping in MonoGame

 The reflectance equation we have been

studying is:

 The full rendering equation is:  The difference is the Lo(r(p,l),-l) term

which means that the incoming light to

• ur point is the outgoing light from some
• ther point

 Unfortunately, this is all recursive (and

can go on nearly forever)

i i

• ω

d θ r L f L

∫

− ⊗ =

Ω

cos ) ), , ( ( ) , ( ) , ( l l p v l v p

i i i

• ω

d θ L f L

∫

⊗ =

Ω

cos ) , ( ) , ( ) , ( l p v l v p

 Real-time rendering uses local (non-recursive) lighting

whenever possible

 Global illumination causes all of our problems (unbounded

• bject-object interaction)
• Transparency
• Reflections
• Shadows

 We can describe a path that light L makes to the eye E using

the following notation

Operator Description Example Explanation * Zero or more

S*

Zero or more specular bounces + One or more

D+

One or more diffuse bounces ? Zero or one

S?

Zero or one specular bounces | Either/or

D|SS

Either a diffuse or two specular bounces () Group

(D|S)*

Zero or more of diffuse or specular

 Shadow terminology:

• Occluder: object that blocks the light
• Receiver: object the shadow is cast
• nto

 Point lights cast hard shadows

(regions are completely shadows or not)

 Area lights cast soft shadows

• Umbra is the fully shadowed part
• Penumbra is the partially shadowed part

 A planar shadow occurs when an object casts a shadow on a flat surface  Projection shadows are a technique for making planar shadows:

• Render the object normally
• Project the entire object onto the surface
• Render the object a second time with all its polygons set to black

 The book gives the projection matrix for arbitrary planes

 We need to bias (offset) the plane just

a little bit

• Otherwise, we get z fighting and the

shadows can be below the surface

 Shadows can be draw larger than the

plane

• The stencil buffer can be used to fix this

 Only opaque shadows work

• Partially transparent shadows will make

some parts too dark

• Z-buffer and stencil buffer tricks can

help with this too

Hard to see example from Shogo: MAD

 Another fix for projection shadows is rendering them to a

texture, then rendering the texture

• Effects like blurring the texture can soften shadow

 If the light source is between the occluder and the receiver, an

antishadow is generated

 True soft shadows occur due to area lights  We can simulate area lights with a number of point lights

• For each point light, we draw a shadow in an accumulation buffer
• We use the accumulation buffer as a texture drawn on the surface

 Alternatively, we can move the receiver up and down slightly and average those results  Both methods can require many passes to get good results

 You can also blur based on the amount of distance from the

• ccluder to the receiver
• It doesn't always look right if the occluder touches the receiver

 Haines's method is to paint the silhouette of the hard shadow with

gradients

• The width is proportional to the height of the silhouette edge casting the

shadow

 All you need is the appropriate matrix to flatten all the geometry

• f your model onto a plane

 In this case, the shadow is cast from a light vector that's in positive

y onto a plane with a normal that's also positive y, 100 units below the origin

 All that's needed is to update the world matrix:  Then draw the model with lighting off and a black color Matrix shadow = Matrix.CreateShadow(Vector3.UnitY, new Plane(Vector3.UnitY, 100)); world = world * shadow

 More on shadows

• Shadow volumes
• Shadow mapping

 Ambient occlusion

 Start Assignment 4  Start Project 3  Keep reading Chapter 9
