We measure temperature accurately even in extreme conditions APPLICATION INDUSTRY Steel Cement Glass Aluminium STEEL INDUSTRY APPLICATIONS Blast Furnace Sinter Plant Coke Plant Pre-heated Ladle Torpedo Car

slide-1
SLIDE 1

We measure temperature accurately even in extreme conditions

slide-2
SLIDE 2

APPLICATION INDUSTRY

Steel Cement Glass Aluminium

slide-3
SLIDE 3
slide-4
SLIDE 4

STEEL INDUSTRY APPLICATIONS

 Blast Furnace  Sinter Plant  Coke Plant  Pre-heated Ladle  Torpedo Car  Ladle Pouring  Continuous Casting  Hot Rolling  Wire & Rod Mill  Galvanizing / Rolled Steel  Forging

slide-5
SLIDE 5

BLAST FURNACE

AST A450 C

MOLTEN METAL Two colour technology ensure accurate and repeatable measurement irrespective of the low and variable emissivity. Small spot size helps to install the sensor at long distance from object. Laser pilot light or through lens sighting for precise targeting

slide-6
SLIDE 6

MOLTEN METAL AST A450 C

slide-7
SLIDE 7

SINTER PLANT

AST 450 C FO

SPECIALITY Two colour pyrometer with fiber optic cable help the pyrometer to install away from the hot area without need of water cooling. Wide angle optical head ensures measurement of large area of the grate.

slide-8
SLIDE 8

COKE PLANT

SPECIALITY Heavy duty fiber optic cable help the pyrometer to install away from the hot area without need of water

  • cooling. Optical heads with variety of D:S ratio are

available

AST 450 FO

slide-9
SLIDE 9

PRE-HEATED LADLE

Ladle temperature before hot metal pouring SPECIALITY AST Software and the Peak picker facility enable to record temperature of each ladle. Variety of accessories like Large display (up to 12”)temperature indicator cooling and mounting accessories etc.

AST 450 FOPL AST A450

slide-10
SLIDE 10

TORPEDO CAR

SPECIALITY On line thermal imaging

ThermEye 384L

slide-11
SLIDE 11

LADLE POURING

SPECIALITY Ratio/multi wavelength technology ensure accurate and repeatable measurement irrespective of the low and variable emissivity. Small spot size helps to install the sensor at long distance from object

AST 450 C S 3000

slide-12
SLIDE 12

CONTINUOUS CASTING

APPLICATION Spray Chamber SPECIALITY

  • Ratio pyrometer with fibre optic

cable

  • Rugged accessories like sighting

tube, air cooling jacket etc.

AST CONCAST

slide-13
SLIDE 13

HOT ROLLING

SPECIALITY Pyrometer with peak picker and software for continuous data storage. Small spot size help to find the hottest spot and to measure the real hot surface temperature instead of oxidation scaling.

AST 450

slide-14
SLIDE 14

WIRE & ROD MILL

AST 450C FO/PL

SPECIALITY

  • Two colour pyrometer with fiber optic cable

help the pyrometer to install away from the hot area without need of water cooling.

  • Very small spot size( down to 0.5mm) and the

fast response time (2ms) enable to record temperature accurately.

slide-15
SLIDE 15

STEEL BARS

AST A450

SPECIALITY

  • Fast response time of 2ms, small spot size 2.5mm from a

distance of 500mm suitable for smallest bars.

  • USB output for easy parameter setting, continuous laser

targeting light for precise focusing.

slide-16
SLIDE 16

ANNEALING FURNACES

AST 250

SPECIALITY Single colour pyrometer with rugged cooling jacket with quartz protection window.

slide-17
SLIDE 17

GALAVANIZING / ROLLED STEEL

Special multi wavelength pyrometers for low emissivity and fluctuating emissivity surfaces Features

  • Measure temperature accurately even in very

low emissivity surfaces

  • Compensate emissivity variation due to

surface condition, shape, intermediate disturbances

  • Calculate emissivity based on brightness

temperature at different wavelength.

  • Scanner for oscillating objects

P 3000

slide-18
SLIDE 18

INDUCTION HEATING

AST 250FO/PL

SPECIALITY

  • Fiber
  • ptic

version help to keep the electronic away from the high electromagnetic field.

  • Very small spot size ( down to 0.5mm) and the fast response time (2ms) enable to

measure temperature accurately even through the gap of the coils.

slide-19
SLIDE 19

FORGING

AST 450;AST450C

SPECIALITY Fast pyrometer with rugged housing . Online data storage. Laser pilot light

  • r Through the lens sighting for

precise targeting. Small spot size

slide-20
SLIDE 20

CEMENT INDUSTRY

slide-21
SLIDE 21

CEMENT INDUSTRY APPLICATIONS

 KILN Burning Zone  KILN Inlet & Secondary Air  Clinker in the conveyor  KILN Shell

slide-22
SLIDE 22

KILN BURNING ZONE

SPECIALITY

  • Two

colour pyrometer ensure trouble free temperature measurement even in dusty atmosphere.

  • Rugged

water cooling jacket and air purge with quartz protection window make the system suitable for harsh environment application.

  • Fibre optic version help to

keep the electronic part away from hot area thus to eliminate water cooling. AST450C FO AST 450C

slide-23
SLIDE 23

KILN INLET &SECONDARY AIR

SPECIALITY

  • Two colour pyrometer ensure trouble free

temperature measurement even in dusty atmosphere.

  • Fibre optic version with sighting tube help to

keep the electronic part away from hot area thus to eliminate water cooling.

AST450C FO AST 450C

slide-24
SLIDE 24

CLINKER IN THE CONVEYOR

AST L10

slide-25
SLIDE 25

KILN SHELL

For Temperature profiling of large area to find Hot / cold spot Thermal imager

  • Temp. 0…..400ºC

ThermEye 160 /160 H

slide-26
SLIDE 26

AlUMINIUM INDUSTRY

slide-27
SLIDE 27

ALUMINIUM INDUSTRY APPLICATIONS

 EXTRUSION  ROLLING  CONTINUOS CASTING  FORGING

slide-28
SLIDE 28

ALUMINIUM EXTRUSION

slide-29
SLIDE 29

AST AE3000 ALUMINIUM PROFILE AT THE DIE EXIT

Features:

  • Simple to use - no calibrations

required

  • High accuracy - (1%) in real site

conditions

  • Capable of measuring targets with

variable emissivity

  • Measures, through smoke, dust,

water vapor etc.

  • Temperature range: 350-650°C

ALUMINIUM EXTRUSION

slide-30
SLIDE 30

AB3000 FOR AlUMINIUM BILLET

slide-31
SLIDE 31

Hot Rolling

Features:

  • High accuracy in real world

conditions

  • Capable of measuring targets with

variable emissivity

  • Temperature range: 100-600°C
  • Rugged design
  • Full range of accessories
  • Wide range of built-in functions

Pointing laser source

AST FR 3000

ALUMINIUM HOT ROLLING

slide-32
SLIDE 32

ALUMINIUM FORGING

AST P3000;PS3000;FR3000

slide-33
SLIDE 33

ALUMINIUM CONTINUOUS CASTING

AST AC3000;P3000;PS3000

slide-34
SLIDE 34

OTHER CASTING APPLICATIONS

slide-35
SLIDE 35

ALUMINIUM HOT ROLLING MILL

ASTAC3000;P3000;PS3000

slide-36
SLIDE 36

COLD ROLLING

AST FR 3000

slide-37
SLIDE 37
slide-38
SLIDE 38

ROD COILING

AST FR 3000

slide-39
SLIDE 39

MOLTEN ALUMINIUM

AST AM 3000

  • Simple to use
  • High accuracy - (1%) in

real site conditions

  • Capable of measuring

targets with variable emissivity

  • Measures, through smoke,

dust, water vapor etc.

  • Temperature range: 450-

900°C

  • Rugged design
slide-40
SLIDE 40

GLASS INDUSTRY

slide-41
SLIDE 41

GLASS INDUSTRY APPLICATIONS

 FURNACE CROWN  FURNACE SIDE WALL  FORE HEARTH  FEEDER  WORKING END  GLASS MOULD  GLASS GOB  FLOAT GLASS

slide-42
SLIDE 42

APPLICATIONS

  • Furnace Crown
  • Furnace sidewall
  • Fore hearth
  • Feeder
  • Working end

AST 450 G2

slide-43
SLIDE 43

GLASS GOB

SPECIALITY Fast ratio pyrometer for dusty, oily, moisture atmosphere with peak picker and software for continuous data

  • storage. Small spot size help to find

the hottest spot. Selected wavelength measure gob inside temperature.

AST A450 C

slide-44
SLIDE 44

AST A250 GLASS MOULD

SPECIALITY Fast pyrometer with peak picker and software for continuous data storage. Small spot size

slide-45
SLIDE 45

FLOAT GLASS

AST A 514

slide-46
SLIDE 46

THANK YOU
