WATER SUPPLY SYSTEMS BASICS OF FILTRATION Substances to be removed * E.g. escherichia coli 0,1 1,5 m, b. Subtilis 0,3 m, legionella 0,5 1,5 m, anthrax spores 1 5 m ** Plant protection products, example for organic trace

slide-1
SLIDE 1

WATER SUPPLY SYSTEMS

slide-2
SLIDE 2

BASICS OF FILTRATION

2 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

* E.g. escherichia coli 0,1 – 1,5 µm,

  • b. Subtilis 0,3 µm,

legionella 0,5 – 1,5 µm, anthrax spores 1 – 5 µm ** Plant protection products, example for

  • rganic trace elements

*** Ions dissolved in the water

Substances to be removed

*** ** *

slide-3
SLIDE 3

BASICS OF FILTRATION

3 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

Filtration methods

slide-4
SLIDE 4

WATER TREATMENT

2

ULTRAFILTRATION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 4

slide-5
SLIDE 5

ULTRAFILTRATION

5 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

  • Retention of particles, bacteria and viruses by high filter fineness of

the UF membrane (Pore ​diameter = 0,02 µm): safe

  • Low pressure difference of up to 0.7 bar: energy efficient
  • Membrane structure allows a simple and reliable membrane

cleaning: easy

  • Fully automatic chemical-free cleaning of the membrane is

possible: self-cleaning

  • High yield of produced filtrate
slide-6
SLIDE 6

FUNCTION OF ULTRAFILTRATION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 6

slide-7
SLIDE 7

WTC 2500 UF, WTC 5000 UF

The energy efficient, modular system

slide-8
SLIDE 8

WTC 2500 UF, WTC 5000 UF THE ENERGY EFFICIENT, MODULAR SYSTEM

Reliable drinking water quality

  • Pre-filtration up to 200 µm (washable)
  • Pretreatment by flocculants (at very high

turbidity values)

  • Reliable UF-Membrane technology
  • Disinfection by Chlorination
  • Monitoring of:

Pressure, Operating hours, Drinking water yield Easy control and handling:

  • One-Man-Operation
  • Chemical-free water purification (except for

the addition of flocculants)

  • Set-up without tools

High yield

  • 5,000 liters of drinking water per hour on a

base area of one euro pallet

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 9

slide-9
SLIDE 9

WTC 2500 UF, WTC 5000 UF THE ENERGY EFFICIENT, MODULAR SYSTEM

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 10

1,33 m 0,8 m Membrane module 2 Main module Membrane module 1

slide-10
SLIDE 10

CUSTOMER REQUIREMENTS ON THE PRODUCT

11 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

  • WTC 2500 UF up to 2500 liters / per hour: up to 60.000 liters per day
  • WTC 5000 UF up to 5000 liters / per hour: up to 120.000 liters per day

How many people can be supplied with drinking water by WTC 5000 UF?

Water requirement for survival (per person) according to WHO* Minimum “survival” allocation Medium term allocation Drinking 4 liters per day 4 liters per day Food preparation, cleanup 3 liters per day 3 liters per day Personal hygiene

  • 7 liters per day

Laundry

  • 6 liters per day

*WHO (World Health Organization): „Technical Notes for Emergencies“, Technical Note No.9, Draft revised: 7.1.05

Total basic need 7 liters per day 20 liters per day Supply of Up to 17.142 persons Up to 6.000 persons

slide-11
SLIDE 11

WTC 2500 UF, WTC 5000 UF IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 12

Federal Agency for Technical Relief, flood in Balkans

slide-12
SLIDE 12

WTC 2500 UF, WTC 5000 UF IN ACTION

Federal Agency for Technical Relief, earthquake in Nepal

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 13

slide-13
SLIDE 13

WTC 2500 UF, WTC 5000 UF IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 14

Demonstration, Austrian Armed Forces, Korneuburg

slide-14
SLIDE 14

WTC 2500 UF, WTC 5000 UF IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 15

Navis and Björn-Steiger-Foundation, Sri Lanka

slide-15
SLIDE 15
  • Drinking water yield up to 2500 (WTC 2500 UF) or 5000 l/h (WTC 5000 UF)
  • Retention of particles, microbes und viruses
  • Energy efficient
  • Fully automatic and easy to operate
  • Minimum consumption of chemicals
  • Compact and easy to transport (4 persons at 4 corners)
  • Easy logistics – Euro pallet
  • Quickly operational
  • Simple maintenance and simply replaceable items
  • International certification of potable water bearing components (e.g. DVGW, WRA, FDA)

CUSTOMER BENEFITS AT A GLANCE !

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 16

slide-16
SLIDE 16

WATER TREATMENT

3

REVERSE OSMOSIS

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 17

slide-17
SLIDE 17

FUNCTION OF REVERSE OSMOSIS

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 18

slide-18
SLIDE 18

WTC 500

The compact all-rounder

slide-19
SLIDE 19

WTC 500 THE COMPACT ALL-ROUNDER

Reliable drinking water quality

  • Pre-filter 5 µm nominal
  • Reliable RO-Membrane technology
  • Disinfection by Chlorination and UV lamp
  • Monitoring of:

Conductivity, Temperature, Pressure level, Operating hours, Drinking water yield

  • Options: Double Pass, Anti-scalant

Easy handling:

  • Robust and manual operation
  • Chemical-free water purification

High yield:

  • 550 liters of drinking water per hour on a

base area of one euro pallet

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 20

slide-20
SLIDE 20

WTC 500 THE COMPACT ALL-ROUNDER

21 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

Easy logistics, easy handling:

  • Compact: 1185 x 785 x 585 mm

(equals one euro pallet)

  • Weight: 197 kg
  • Highly mobile
  • Robust
  • Steel frame
  • Stackable
slide-21
SLIDE 21

WTC 500 IN ACTION

Flood after tsunami, Maldives

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 22

slide-22
SLIDE 22

WTC 500 IN ACTION

Disaster mission, NAVIS Help Organization, Haiti

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 23

slide-23
SLIDE 23

WTC 500 IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 24

System test, New Zealand Army

slide-24
SLIDE 24

WTC 500 GT THE COMPACT ALL-ROUNDER

Independent:

  • Integrated electric power generator
  • Multi-Fuel-Approach

Easy logistics, easy handling:

  • All required components are loadable on a

trailer (4400 x 4280 x 2070 mm)

  • Robust
  • Highly mobile
  • Low weight (1700 kg)
  • Off-road single axle trailer
  • Weatherproof cover

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 25

slide-25
SLIDE 25

WTC 500 GT IN ACTION

System test, Namibia System test, Singapore

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 26

System test, Chile

slide-26
SLIDE 26

WTC 500 GT IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 27

Demonstration, Philippines

slide-27
SLIDE 27

DISPLAY IMAGE

Produktmanagement Wasser FFM-P/Brockmann bkm | WTC 500 RO plus Vertriebsmeeting | 08.03.2016 28

slide-28
SLIDE 28

Characteristic WTC 500 RO 2 | WTC 700 RO 2 Output (2 Versions) up to 500 l/h 2 membranes, up to 700 l/h 3 membranes Dimensions (LxWxH) 1200x800x approx. 900 mm (Euro-pallet dimensions) Weight

  • approx. 160 | 175 kg

Power supply 400 V, 3-phase, 50 Hz (60Hz is also possible, if another raw water pump is used) Power consumption

  • approx. 8,5 kW (raw water pump included, similar to the old

version)

TECHNICAL DATA

Produktmanagement Wasser FFM-P/Brockmann bkm | WTC 500 RO plus Vertriebsmeeting | 08.03.2016 29

slide-29
SLIDE 29

DIFFERENCES TO THE OLD WTC 500 RO (1/2)

  • Integrated prefilter
  • 6 detachable handles
  • significantly clearer control panel
  • cheaper (approx. 5-10% sales price)
  • significantly higher reliability
  • high-pressure pump in stainless steel

instead of brass

  • materials: stainless steel or plastic
  • no plastic in external lines
  • no fragile parts like cutting rings or

solenoid valves

Produktmanagement Wasser FFM-P/Brockmann bkm | WTC 500 RO plus Vertriebsmeeting | 08.03.2016 30

slide-30
SLIDE 30

DIFFERENCES TO THE OLD WTC 500 RO (2/2)

  • no fluid level sensor in the chlorine tank (was

prone to failures)

  • consistent drinking water certificates (DVGW,

FDA, ACS)

  • no fragile UV lamp (not necessary due to the

already present double security)

  • no cartridge filter (not necessary, relict)
  • no maintenance pump needed
  • significantly bigger chlorine tank
  • WTC 500 RO 2 and WTC 700 RO 2
  • raw water pump and prefilter in part no.
  • ptional accessory case for transportation

Produktmanagement Wasser FFM-P/Brockmann bkm | WTC 500 RO plus Vertriebsmeeting | 08.03.2016 31

slide-31
SLIDE 31

CLEARER STRUCTURE DESPITE THE INTEGRATED FILTER

WTC 500 RO WTC 500 RO 2

Produktmanagement Wasser FFM-P/Brockmann bkm | WTC 500 RO plus Vertriebsmeeting | 08.03.2016 32

slide-32
SLIDE 32

extremely reliable & easy to operate

  • Up to 500 | 700 l/h of salt water (maximum output with fresh water)
  • Retention of particles, microorganisms and viruses
  • Additonally removes salts and chemicals
  • Extremely robust and reliable (even more than its predecessor)
  • Extremely easy to operate (even easier than its predecessor)
  • Minimal chemical use
  • Compact and easily transportable (all inclusive and easier to transport than its predecessor)
  • Quickly deployed

BENEFITS

Produktmanagement Wasser FFM-P/Brockmann bkm | WTC 500 RO plus Vertriebsmeeting | 08.03.2016 33

slide-33
SLIDE 33
  • Drinking water yield up to 550 l/h
  • Retention of particles, microbes und viruses
  • Additional removal of salts und chemicals
  • Extremely robust and reliable
  • Easy handling
  • Minimum chemical consumption
  • Compact and easy to transport
  • Quickly operational

CUSTOMER BENEFITS AT A GLANCE !

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 34

slide-34
SLIDE 34

WTC 1600, WTC 3000

The fully automatic all- rounder

slide-35
SLIDE 35

WTC 1600, WTC 3000 THE FULLY AUTOMATIC ALL-ROUNDER

Reliable drinking water quality

  • Pre-filter up to 5 µm nominal
  • Pretreatment by Anti-scalant (WTC 3000)
  • Reliable RO-Membrane technology
  • Disinfection by Chlorination
  • Monitoring of:

Conductivity, Temperature, Pressure level, Operating hours, Drinking water yield

  • Options: UV lamp, Double pass, Anti-scalant

dosage (WTC 1600) Easy handling:

  • Two-Button-System
  • Fully automatic control and operation (PLC)
  • One-Man-Operation
  • Chemical-free water purification

High yield:

  • Produces up to 1600 liters or 3000 liters of

drinking water per hour

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 36

slide-36
SLIDE 36

WTC 1600, WTC 3000 THE FULLY AUTOMATIC ALL-ROUNDER

37 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

Easy logistics, easy handling:

  • All required components are loadable on a steel frame

(1900 x 1600 x 1050 mm)

  • Weight: 1000 kg or 1100 kg
  • Fork-lift pockets
  • Mobile
  • Robust
slide-37
SLIDE 37

WTC 1600 G, WTC 3000 G THE FULLY AUTOMATIC ALL-ROUNDER

38 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

Independent:

  • Integrated electric power generator
  • Multi-Fuel-Approach

Easy logistics, easy handling:

  • All required components are loadable on one steel frame

(2800 x 1600 x 1050 mm)

  • Weight : 1700 kg or 1800 kg
  • Fork-lift pockets
  • Mobile
  • Robust
slide-38
SLIDE 38

WTC 1600 G IN ACTION

Flood catastrophe, Brazil

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 39

slide-39
SLIDE 39

WTC 1600 G IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 40

Operation Australian Army, Australia Aid mission after tsunami, Sri Lanka

slide-40
SLIDE 40

WTC 3000 G IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 41

Water supply for a field camp of Russian Army, Russia

slide-41
SLIDE 41

WTC 1600 GT, WTC 3000 GT THE FULLY AUTOMATIC ALL-ROUNDER

42 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

Independent:

  • Integrated electric power generator
  • Multi-Fuel-Approach

Easy logistics, easy handling:

  • All required components are loadable on one trailer

(5460 x 2170 x 2490 mm)

  • Weight: max. 3500 kg
  • Highly mobile
  • Robust
  • Off-road single axle trailer
  • Weatherproof cover
slide-42
SLIDE 42

WTC 1600 GT IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 43

Product Training in Tampere, Finland WBP 700 / WTC 1600 GT demo in USA, NATO-Headquarters in Norfolk Virginia

slide-43
SLIDE 43

WTC 1600 GT IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 44

Training WTC 1600 GT, Argentina Schwäbisch Hall, Germany

slide-44
SLIDE 44

WTC 3000 GT IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 45

UN blue helmet mission in Mogadishu, Somalia

slide-45
SLIDE 45

WTC 1600, WTC 3000 REVIEW

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 46

  • WTC 1600

WTC 3000 WTC 1600 G WTC 3000 G WTC 1600 GT WTC 3000 GT Dimensions [mm] 1900 x 1600 x 1050 2800 x 1600 x 1050 5460 x 2170 x 2490 Weight [kg] 1000 1100 1700 1800

  • Max. 3500

Features Robust Highly mobile Fork-lift pockets Robust Highly mobile Fork-lift pockets Robust Highly mobile Weatherproof cover Generator Integrated electric power generator Multi-Fuel-Approach Integrated electric power generator Multi-Fuel-Approach Trailer Off-road single axle trailer

slide-46
SLIDE 46
  • Drinking water yield up to 1600 or 3000 l/h
  • Retention of particles, microbes und viruses
  • Additional removal of salts und chemicals
  • Fully automatic and easy to operate
  • Robust and off-road trailer
  • Autarkic by integrated electric power generator
  • Quickly operational

CUSTOMER BENEFITS AT A GLANCE !

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 47

slide-47
SLIDE 47

WTC 8000/ 15000 RO/UF C

The adjustable hybrid

slide-48
SLIDE 48

WTC 8000/15000 RO/UF C THE ADJUSTABLE HYBRID

Reliable drinking water quality

  • Pre-filter
  • Dechlorination and pretreatment with

flocculants

  • Reliable UF- and RO-Membrane technology
  • Chlorination and Remineralization
  • Monitoring of:

Conductivity, Temperature, Pressure level, Operating hours, Drinking water yield

  • Separation of technical and operational room
  • Options: UV lamp, Double pass, Anti-scalant

Easy handling:

  • Touchscreen
  • Fully automatic control and operation (PLC)
  • One-Man-Operation
  • Low demand on chemicals

High yield:

  • Produces up to 8000 l/h (RO / UF/RO)
  • Produces up to 15000 l/h (UF)
  • Treatment of salt water with up to 55 g salt

per liter

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 49

slide-49
SLIDE 49

WTC 8000/15000 RO/UF C THE ADJUSTABLE HYBRID

50 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

Flexible:

  • Modular construction
  • Container is customizable
  • Lots of options selectable by the customer
  • Available with 50 Hz as well as 60 Hz

Easy logistics, easy handling:

  • All necessary components lorried in a 20‘ Container
  • Purification modules come with standardized interface
  • Mobile
  • Robust
slide-50
SLIDE 50
  • 8000 l/h with salt water / 15000 l/h with fresh water
  • Retention of particles, microbes and viruses
  • Additional removal of salts and chemicals
  • Fully automatic and easy to operate
  • Adaptable to the raw water quality
  • Energy efficient
  • Easy Logistics – 20’ Container
  • Separation of technical and operational room
  • Double-Pass (Option) allows purification according to STANAG 2136

CUSTOMER BENEFITS AT A GLANCE !

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 51

slide-51
SLIDE 51

CHLORINE PRODUCTION IN THE FIELD

4

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 52

slide-52
SLIDE 52

ADVANTAGES OF CHLORINE PRODUCTION IN THE FIELD

  • Table salt (NaCl) is available worldwide and relatively easy to obtain

 almost independent of a complex supply chain

  • no storage and no handling with a hazardous good

 easy of handling and application

  • significantly reduced operating costs, because only table salt and very

little power is needed

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 53

slide-53
SLIDE 53

PROCESS SCHEME OF CHLORINE PRODUCTION IN THE FIELD

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 54

Buffer bucket

Chlorine Demineralized water Salt Electrolysis

Fresh water bucket Fresh water

Cl- Cl- Cl2 H2 H+ H+

Degassing hydrogen Electrolysis cell Sole Salt Active chlorine concentrate (to external dosing pump)

slide-54
SLIDE 54

E-CHLORINATOR THE LOCAL CHLORINE PRODUCER

High yield:

  • Produces up to 1455 mg activated chlorine per hour
  • Disinfection of up to 6000 l/h (cCl2=0,24 mg/l)

Safety:

  • No longer transport of hazardous material
  • No handling of hazardous material necessary
  • Only table salt is required
  • Addition of chlorine protects drinking water against recontamination

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 55

slide-55
SLIDE 55

E-CHLORINATOR THE LOCAL CHLORINE PRODUCER

Easy logistics, easy handling:

  • All required components are loadable on one stainless steel frame

(604 x 470 x 797 mm)

  • Weight: 35 kg
  • Robust
  • Free from hazardous material
  • Use as a stand-alone-system or in combination with WTC UF possible

(requires softened water)

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 56

slide-56
SLIDE 56
  • Chlorination for up to 6000 l/h drinking water
  • Autarkic by local chlorine production
  • Significant reduction of transport risk
  • Minimal operating costs
  • Operating materials local available
  • Up to 1455 mg/h activated chlorine
  • Compact, frame or wall installation possible
  • Simple, intuitive operation

CUSTOMER BENEFITS AT A GLANCE !

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 57

slide-57
SLIDE 57

WATER STORAGE AND ADDITIONAL ACCESSORIES

5

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 58

slide-58
SLIDE 58

ACCESSORIES WATER STORAGE AND DRINKING WATER DISTRIBUTION STATION

59 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

  • Raw / Drinking Water Tanks

– Closed pillow tanks – Open, self-erecting tanks – Open storage tanks with steel support frame – Inliner tank

  • Distribution Station

– Efficient in a very confined space, easy water delivery, fast and safe

slide-59
SLIDE 59

DRINKING WATER FILLING

6

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 60

slide-60
SLIDE 60

Years of experience with mobile operations have shown:

  • Taste neutrality and optical clearness must be provided
  • Psychological barriers:

– Large drinking water storage tanks are hardly accepted – Drinking water provided in small packages is more convenient and accepted

  • Distribution to individuals is only possible in small packages
  • In areas with an increased level of threat, water transport is often:

– Time-consuming – Cost-intensive – Resource-consuming (Personnel / Vehicles / Fuel)

CUSTOMER REQUIREMENTS ON THE PRODUCT

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 61

slide-61
SLIDE 61

WATER PACKAGING ON SITE

62 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

Advantages of water packaging in crisis and disaster areas:

  • High savings on logistical costs by:

– Reducing the volume about min. 90% – Reducing the weight about min. 95%  High reduction of dependency on the supply chain

  • Higher security through full control over the packaging

process from source to consumption

slide-62
SLIDE 62

CUSTOMER REQUIREMENTS ON THE PRODUCT

63 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

Requirements specification for a mobile purification system from customer view:

  • High hygiene standard
  • Logistically easy to handle / transport
  • Robust and sturdy construction
  • High flexibility
  • Easy to operate
  • High yield
slide-63
SLIDE 63

SAFE WATER PURIFICATION CONCEPT

MOBILE SOLUTION REQUIREMENTS FOR HYGIENIC DRINKING WATER FILLING Highly mobile applications (e.g. special forces, rapid emergency aid) Semi-mobile applications (e.g. large field camps, long-term emergency aid)

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 64

Water Bottling Plant (WBP) Water Packaging System (WPS)

slide-64
SLIDE 64

WPS 1600 GT

The flexible filling system

slide-65
SLIDE 65

WPS 1600 GT THE FLEXIBLE FILLING SYSTEM

66 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

High yield:

  • Produces 1600 water-filled sachets per hour
  • Flexible filling quantity

– Quantity adjustment during usage (250 – 500 – 1000 ml) Safety:

  • Highest hygiene requirements under field conditions

– Sterile filters (Incoming water) – HEPA filtered air – UV-disinfection (Foil material) Independent:

  • Integrated power generator
slide-66
SLIDE 66

WPS 1600 GT THE FLEXIBLE FILLING SYSTEM

67 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

Easy logistics, easy handling:

  • Mounted on a single-axle (6000 x 2300 x 2500 mm)
  • Weight: 3500 kg
  • Highly mobile
  • All-terrain mobile single axle trailer
  • Reduced transport volume / weight
  • Significantly reduced logistics costs

Easy handling through:

  • Fully automatic operation
  • Low personnel expenditure (1 person)
slide-67
SLIDE 67

WPS 1600 GT + WTC 3000 GT IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 68

Setup test water filling system (WPS 1600 GT + WTC 3000 GT), Senegalese Army

slide-68
SLIDE 68

WPS 1600 GT IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 69

System test combination of WTC 1600 GT and WPS 1600 GT, Luxembourgian Army, Luxemburg

slide-69
SLIDE 69

WPS 1600 GT IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 70

South African National Defence Force (SANDF), Project ’Blesbok’, Housed in a extendable 20‘ container, South Africa

slide-70
SLIDE 70
  • Up to 1600 sachets per hour
  • Significant reduction of logistics costs
  • Significant reduction of transport costs
  • Fully automatic and easy to operate
  • Quickly operational
  • Flexible adjustable bag size
  • Highest hygiene under field conditions

CUSTOMER BENEFITS AT A GLANCE !

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 71

slide-71
SLIDE 71

WBP 1300

The solution for reduction of logistic costs

slide-72
SLIDE 72

WBP 1300 THE SOLUTION FOR REDUCTION OF LOGISTIC COSTS

73 FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems

High yield:

  • 1300 bottles (1 L) in a standard 20‘ container

Safety:

  • Highest hygiene requirements under field conditions

– Sterile filters (Drinking water & pressurized air) – Excess pressure in the system – HEPA filtered air (Filling & capping area) – Integrated Cleaning-In-Place (CIP) / Sterilization-In-Place (SIP) Processes

  • Fully automated control and function
slide-73
SLIDE 73

WBP 1300 THE SOLUTION FOR REDUCTION OF LOGISTIC COSTS

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 74

slide-74
SLIDE 74

Easy logistics, easy handling:

  • All components stored in a 20 feet ISO container
  • Weight (approx. 8900 kg)
  • Mobil und robust
  • Reduction of transport volume / weight by approx. 90% / 95%
  • Significantly reduced logistics costs

Easy operation:

  • Fully automatic operation
  • Kärcher Futuretech operating system (PLC)
  • Low personnel expenditure (max. 3 persons)

WBP 1300 THE SOLUTION FOR REDUCTION OF LOGISTIC COSTS

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 75

slide-75
SLIDE 75

WBP 1300 IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 76

South African National Defence Force (SANDF), Project ‘Blesbok‘, Housed in tent

slide-76
SLIDE 76

WBP 1300 IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 77

Project “TWAA“, Housed in lightweight building construction 1 2 3 WBP 1300 Lightweight building construction Base panel 1 2 3

slide-77
SLIDE 77

WBP 700 IN AFGHANISTAN

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 78

72,5 11,7 19,14 11,81 3,27

Customer Location Production Time Period Number of Systems UK Army Camp Bastion

  • Feb. 2008 – Jun. 2014

4 German Armed Forces Camp Marmal

  • Feb. 2008 – Jun. 2013

1 US Army Camp Dwyer

  • Aug. 2010 – Sep. 2013

2-5 US Army Camp Leatherneck

  • Oct. 2012 – Sep. 2013

2-5 US Army FOB Delaram II

  • Nov. 2010 – May 2012

2

Amount

  • f

bottles in Mio.

slide-78
SLIDE 78

WBP 700 PROVEN ACCEPTANCE

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 79

slide-79
SLIDE 79
  • PET bottles from Kärcher Futuretech can be stored under field conditions

without chlorine in the filled bottles (taste!)

  • The bottled drinking water enjoys a high acceptance within the consumers
  • Storage of drinking water (without addition of chlorine) according to the

British Ministry of Defense and US-CHPPM (now PHC) up to 730 days

  • Over 120 million bottles have been produces worldwide with WBP / EWPS

systems so far

  • No single stored bottle had suffered from microbiological contamination

WATER BOTTLING PLANTS BY KÄRCHER FUTURETECH A SUCCESS STORY

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 80

slide-80
SLIDE 80
  • Up to 1300 bottles (1 L) per hour
  • Significant reduction of logistics costs
  • Significant reduction of transport risk
  • Fully automatic and easy to operate
  • Highest hygiene under field conditions
  • Simple logistics – 20‘ Container
  • Separation of operational and technical room

CUSTOMER BENEFITS AT A GLANCE !

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 81

slide-81
SLIDE 81

REFERENCE PROJECTS

7

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 82

slide-82
SLIDE 82

WATER- UNIMOG

Safe drinking water for inaccessible area

slide-83
SLIDE 83
  • Transport possibilities are a critical factor for the success in

disaster situations

  • Compact water purification systems of Kärcher Futuretech can

produce a large amount of drinking water at a low electricity demand

  • UNIMOG truck even reaches nearly inaccessible terrain

 UNIMOG truck represents with its Kärcher Futuretech systems an ideal symbiosis for answering application related challenges

WATER-UNIMOG SAFE DRINKING WATER FOR INACCESSIBLE AREA

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 84

slide-84
SLIDE 84

WATER-UNIMOG SAFE DRINKING WATER FOR INACCESSIBLE AREA

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 86

Transport Output Distribution Setup Production

slide-85
SLIDE 85

UNIMOG SAFE DRINKING WATER FOR INACCESSIBLE AREA

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 87

slide-86
SLIDE 86

WAA DEKON

slide-87
SLIDE 87

In 2011 the German Armed Forces have demanded for a specific system to prepare high CBRN-contaminated raw water for decontamination purposes  Filling of drinking water storage tanks of decontamination systems (for example TEP 90, MEP, leDA)

PROJECT INFORMATION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 89

Contract awarding

  • f prototype system

Summer test

hot climatic conditions

Winter test

cold climatic conditions

Transportation test

(Shock and vibration)

Contract awarding for serial production

  • f 9 systems in total
slide-88
SLIDE 88

SUMMER TEST IN SARDINIA

Accessories container (incl. electricity supply, drinking water storage and distribution) Water purification container

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 90

TEP 90 incl. drinking water storage Drinking water transport trailer Filling of the drinking water transport trailer

slide-89
SLIDE 89

MAIN REQUIREMENTS OF TENDER SPECIFICATIONS

  • Safe production of drinking water based on STANAG 2136 and FINABEL* test conditions
  • Production of up to 6 m³/h (approx. 1,600 gal) of drinking water in Double-Pass-Mode
  • System based on two 20‘-ISO 1C container
  • Operation mounted on vehicle and unloaded
  • Made for harsh conditions of military applications
  • Operation temperature zone from -32 °C to +49 °C (A1 to C1 in acc. to STANAG** 4370)
  • Autonomous and autarkic operation
  • Protection of operator during drinking water production is of highest interest

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 91

*FINABEL: Organization promoting cooperation and interoperability between the national armies of the member states of the European Union (source: www.wikipedia.com)

slide-90
SLIDE 90

PRODUCTION OF SAFE DRINKING WATER

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 92

Switch cabinet Dosing stations Waste water tank Separate engineering room UV treatment CIP tank Water for flushing Submersible Pump Bag filters Separate operator room RO membranes High pressure pumps

slide-91
SLIDE 91

PRODUCTION OF SAFE DRINKING WATER

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 93

Air conditioning Storage rack accessories Switch cabinet Energy distribution Drinking water distribution Water storage tank Power generator Storage rack for heated hoses (back side)

slide-92
SLIDE 92

WAA DEKON IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 94

Winter Test, Finland

slide-93
SLIDE 93

WAA DEKON IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 95

Testing WAA Dekon, Germany

slide-94
SLIDE 94

WAA DEKON IN ACTION

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 96

Testing WAA Dekon, Germany

slide-95
SLIDE 95

Successfully used all over the world

MAKE A DIFFERENCE THANK YOU

FTS / 26.08.2016 / 2016-08-26 Presentation (EN) Water Supply Systems 97
