SLIDE 1
VOA in Delano, CA Between Visalia and Bakersfield, this 801 acre location houses
- ne of the last powerful
HF international broadcast stations.
Voice Of America Delano, Calif. VOA in Delano, CA Between Visalia - - PDF document
Voice Of America Delano, Calif. VOA in Delano, CA Between Visalia - - PDF document
Voice Of America Delano, Calif. VOA in Delano, CA Between Visalia and Bakersfield, this 801 acre location houses one of the last powerful HF international broadcast stations. Rhombic towers View from Melcher Road Dipole array towers
SLIDE 2
SLIDE 3
View from Melcher Road Dipole array towers Rhombic towers
SLIDE 4
Rhombic Antenna Tow ers
SLIDE 5
Dipole Array Tow ers These are 406 ft ‘skyhooks’
SLIDE 6
Delano Transmitting Station Compound and Antenna Field December 1998
Total of 6 reversible Rhombics Low band dipole curtains High band dipole curtains
VOA Delano, Calif.
SLIDE 7
Dipole Array Tow er (Side View ) The precision design and workmanship were extraordinary.
SLIDE 8
Immense Footings Can you imagine the forces exerted on each tower leg?’ Mark Carson painted the towers
SLIDE 9
Up close and ‘personal’ Notice the perfect, alternating white and red painting detail
SLIDE 10
Part of the dipole arrays strung betw een the tow ers Multiple transmission lines allowed for azimuthal and elevation angle slewing.
SLIDE 11
Maintenance at 200’
SLIDE 12
Balanced, open-w ire feedlines connected the antennas to the sw itch-bay on the right. Each of the lines could handle 250 kW.
SLIDE 13
Precise tensioning resulted in this w ire layout This was built in the early 1940’s and is still functional
SLIDE 14
Tensioning w eights Each of the 13 plates probably weighs well over 100 lbs Look how flat the terrain is!
SLIDE 15
HF Exciters The 1 Megawatt transmitter had already been disassembled
SLIDE 16
Delano Transmitter/Operating Schedule
SLIDE 17
Several of the higher power amplifier tubes Where does the pow er come from?
SLIDE 18
Forw ard and Reflected Pow er Meters 2 kW is considered a reasonable reflected power
SLIDE 19
Perfect for your new High Power 6m linear amplifier? They have probably all been thrown out by this time. They must have had 40 of these there. Jennings Vacuum Variables 25 – 650 pF 55 kV
SLIDE 20
Early View of VOA Control Room
SLIDE 21
2012 view of the control room after dismantling Much of the Electronics w ere in these cabinets An IBM “386-x” controlled all antennas and transmitters
SLIDE 22
VOA Satellite Interconnect System Delano connected by satellite the US, Indian and Pacific Ocean Regions
SLIDE 23
Satellite Interconnections Washington, DC provided the programming for overseas broadcasts
SLIDE 24
Largest Satellite System at VOA
