Visualization and Simulation Caio Brito Summary Local Illumination Graphical pipeline Illumination model Shader Global Illumination Ray Tracing Path tracing Physics based simulation Fluids Rigid

slide-1
SLIDE 1

Visualization and Simulation

Caio Brito

slide-2
SLIDE 2

Summary

  • Local Illumination

– Graphical pipeline – Illumination model – Shader

  • Global Illumination

– Ray Tracing – Path tracing

  • Physics based simulation

– Fluids – Rigid Body – Position-Based

slide-3
SLIDE 3

Local Illumination

slide-4
SLIDE 4

Local Illumination :: Graphical Pipeline

slide-5
SLIDE 5

Local Illumination :: Graphical Pipeline

slide-6
SLIDE 6

Local Illumination :: Illumination Model

slide-7
SLIDE 7

Local Illumination :: Illumination Model

  • Ambient

– Simple way of modeling indirect reflection. Ia: Ambient light intensity Ka: Ambient constant

slide-8
SLIDE 8

Local Illumination :: Illumination Model

  • Diffuse

– Ideal diffuse surface reflects light equally in all directions, according to Lambert's cosine law. – Lambert’s Cosine Law: amount of light energy that falls on surface and gets reflected is proportional to incidence angle.

slide-9
SLIDE 9

Local Illumination :: Illumination Model

  • Diffuse

– Smaller angle > Bigger cosine > More intensity.

slide-10
SLIDE 10

Local Illumination :: Illumination Model

  • Specular

– Simulates a highlight. – Reflection angle = incident angle.

slide-11
SLIDE 11

Local Illumination :: Illumination Model

slide-12
SLIDE 12

Local Illumination :: Illumination Model

  • Flat Shading

– Shades each polygon of an object based on the angle between the polygon's surface normal and the direction of the light source.

slide-13
SLIDE 13

Local Illumination :: Illumination Model

  • Gouraud Shading

– Calculates the surface normals for the polygons. – Lighting computations are then performed to produce intensities at vertices. – These intensities are interpolated along the edges of the polygons.

slide-14
SLIDE 14

Local Illumination :: Illumination Model

  • Phong Shading

– Calculate the surface normals at the vertices of polygons in a 3D computer model. – These normals are interpolated along the edges of the polygons. – Lighting computations are then performed.

slide-15
SLIDE 15

Local Illumination :: Illumination Model

Position-Normal Distributions for Efficient Rendering of Specular Microstructure

slide-16
SLIDE 16

Local Illumination :: Illumination Model

Physically-Accurate Fur Reflectance: Modeling, Measurement and Rendering

slide-17
SLIDE 17

Local Illumination :: Illumination Model

Discrete Stochastic Microfacet Models

slide-18
SLIDE 18

Local Illumination :: Shader

  • A Shader is a user-defined program designed to run
  • n some stage of a graphics processor.
  • Its purpose is to execute one of the programmable

stages of the rendering pipeline.

  • GLSL, HLSL, Cg, DirectX
  • Basic structure: Vertex Shader and Fragment Shader
  • http://antongerdelan.net/opengl/
  • https://learnopengl.com/
  • https://www.shadertoy.com/
slide-19
SLIDE 19

Local Illumination :: Shader

  • Vertex Shader
slide-20
SLIDE 20

Local Illumination :: Shader

  • Fragment Shader
slide-21
SLIDE 21

Local Illumination :: Shader

  • Fragment Shader
slide-22
SLIDE 22

Local Illumination

slide-23
SLIDE 23

Global Illumination

slide-24
SLIDE 24

Global Illumination

  • Local Illumination
  • Global Illumination
slide-25
SLIDE 25

Global Illumination :: Ray Tracing

slide-26
SLIDE 26

Global Illumination :: Ray Tracing

slide-27
SLIDE 27

Global Illumination :: Ray Tracing

slide-28
SLIDE 28

Global Illumination :: Ray Tracing

slide-29
SLIDE 29

Global Illumination :: Ray Tracing

slide-30
SLIDE 30

Global Illumination :: Ray Tracing

slide-31
SLIDE 31

Global Illumination :: Ray Tracing

slide-32
SLIDE 32

Global Illumination :: Ray Tracing

slide-33
SLIDE 33

Global Illumination :: Ray Tracing

slide-34
SLIDE 34

Global Illumination :: Ray Tracing

slide-35
SLIDE 35

Global Illumination :: Ray Tracing

slide-36
SLIDE 36

Global Illumination :: Ray Tracing

  • Primary Rays

– Primary rays are rays from the viewpoint to the nearest intersection point. – Local illumination is computed:

slide-37
SLIDE 37

Global Illumination :: Ray Tracing

  • Secondary Rays

– Reflection Ray

slide-38
SLIDE 38

Global Illumination :: Ray Tracing

  • Secondary Rays

– Refraction Ray

slide-39
SLIDE 39

Global Illumination :: Ray Tracing

slide-40
SLIDE 40

Global Illumination :: Ray Tracing

  • Limitation
slide-41
SLIDE 41

Global Illumination :: Ray Tracing

  • Limitation
slide-42
SLIDE 42

Global Illumination :: Path Tracing

  • Trace multiple rays from a single pixel
slide-43
SLIDE 43

Global Illumination :: Path Tracing

  • How to choose a secondary ray?
  • Each material have a Kd, Ks and Kt

– Let Ktot = Kd + Ks + Kt – Choose a random number R in the interval (0,Ktot)

  • If (R < Ks), trace a diffuse ray
  • else if (R < Kd + Ks), trace a specular ray
  • else, trace a refraction ray
slide-44
SLIDE 44

Global Illumination :: Path Tracing

slide-45
SLIDE 45

Global Illumination :: Path Tracing

slide-46
SLIDE 46

Global Illumination :: Path Tracing

slide-47
SLIDE 47

Which Realism?

  • Photorealism

– image produces the same visual response as the scene

  • Functional realism

– Image provides the same visual information as the scene

slide-48
SLIDE 48

Which Realism?

  • Photorealism
slide-49
SLIDE 49

Which Realism?

  • Functional realism
slide-50
SLIDE 50

Physics Based Simulation

slide-51
SLIDE 51

Physics Based Simulation :: Fluid Simulation

  • Smoothed Particle Hydrodynamics

– Solve Navier-Stokes equation – Finite number of particles

  • Position, velocity, mass, density, viscosity and influence radius
slide-52
SLIDE 52

Physics Based Simulation :: Fluid Simulation

  • Smoothed Particle Hydrodynamics
slide-53
SLIDE 53

Physics Based Simulation :: Fluid Simulation

  • Smoothed Particle Hydrodynamics
slide-54
SLIDE 54

Physics Based Simulation :: Fluid Simulation

  • Smoothed Particle Hydrodynamics
slide-55
SLIDE 55

Physics Based Simulation :: Fluid Simulation

  • Smoothed Particle Hydrodynamics
slide-56
SLIDE 56

Physics Based Simulation :: Rigid Body Dynamics

  • Rigid bodies have a position and orientation
  • No deformation
  • The motion be represented by 2 parameters

– Center of mass – Orientation

  • Force and Torque are computed
slide-57
SLIDE 57

Physics Based Simulation :: Rigid Body Dynamics

slide-58
SLIDE 58

Physics Based Simulation :: Position-Based Dynamics

  • Particles everywhere

– Position, velocity, mass, phase

  • Uses different constraints for each kind of

simulation

– Distance (clothing) – Shape (rigids, plastics) – Density (fluids) – Volume (inflatables) – Contact (non-penetration, friction)

slide-59
SLIDE 59

Physics Based Simulation :: Position-Based Dynamics

slide-60
SLIDE 60

Physics Based Simulation

slide-61
SLIDE 61

Visualization and Simulation

Caio Brito
