Visu isualizin ing Scie ientifi fic Con

• ncepts in

in Nanoelectronics(SPMSjr0 r01)

Cao Yixuan Ying Yunqian Dunman High School Wang Xiao, Renshaw (Asst Prof) Nanyang Technological University

Content

• Introduction
• Aims/Objectives
• Literature Review
• Work Accomplished
• Methodology
• Results
• Conclusion
• Acknowledgements

What is nanoelectronics?

The term nanoelectronics refers to the use of nanotechnology in electronic components. These components are often only a few nanometers in size. Applications of such technology are usually found in transistors for carbon nanotubes, flexible electronic circuits, creating data storage chips, e-textiles and solar energy cells etc.

Previous works:

• Content-based
• Diagrams are 2D→might be

incomprehensive for the public and new investigators For this project:

• 3D diagrams →clear

image of the electric models can be presented to the public.

• Different types of

perovskite materials

Introduction

Introduction

Scope

• 3D

computing graphics software Blender to study the physical properties of ultra thin metal oxides. Assumption

• Schematics and working

principles of nanoelectronics can be represented using 3D diagrams.

Introduction

• Constraints in the software’s

modelling techniques and for aesthetics needs.

• Simulations and graphical

depictions of ultra thin metal

• xides may differ slightly from

actual physical property (colour, shape, orientation and position of particles).

AIMS/OBJECTIVES

Visualize complex scientific concepts in nanoelectronics by designing 3-dimensional (3D) images.

Literature Review

Electronic Phase Separation at the LaAlO3 /SrTiO3 Interface

• Emerged as one of the most scientifically and technologically

interesting material systems.

• Perovskites display “a broad range of physical manifestations,

including charge-ordered insulator, double-exchange ferromagnet and high-temperature superconductor”.

Work Accomplished

Figure 1.1 Two-dimensional figure of LaAlO3 Figure 1.2 Three-dimensional modelled figure of LaAIO3

Graphical simulations of cubic lanthanum aluminate (LaAlO3) with moisture air.

Figure 2.1 Two-dimensional figure of SrTiO3 Figure 2.2 Three-dimensional modelled figure of SrTiO3

Graphical simulations of cubic strontium titanate (SrTiO3) with moisture air.

Figure 3.2 Three-dimensional modelled figure of SrTiO3 Figure 3.1 Two-dimensional figure of SrTiO3

Graphical simulations of elongated strontium titanate (SrTiO3) with wave-like amorphous SAO and moisture air.

Figure 4.1 Two-dimensional figure of SrTiO3 Figure 4.2 Three-dimensional modelled figure of SrTiO3

Graphical simulations of elongated strontium titanate (SrTiO3) with abundant amount of oxygen vacancy.

Figure 5.1 Two-dimensional figure of SrTiO3 circuit Figure 5.2 Three-dimensionally modelled figure of SrTiO3 circuit

Graphical simulations of elongated strontium titanate (SrTiO3) with wave-like amorphous SAO, external circuit and electrode.

Figure 5.1 Two-dimensional figure of SrTiO3 circuit Figure 5.3 Three-dimensionally modelled figure of SrTiO3 circuit (without wiring, grounding and electrodes)

Graphical simulations of elongated strontium titanate (SrTiO3) with wave-like amorphous SAO, excluding external circuit and electrode.

Methodology

Methodology

• Possible graphic softwares: Blender, autoCAD, Cinema 4D
• Use the software skillfully, before moving on to create 3D graphic

models for perovskite materials.

• Tutorial lessons on Blender online or YouTube → more direct and

comprehensive operations.

• Scaling, rotating, shifting and editing meshes.
• Memorise and make use of the shortcut keys to improve working

efficiency.

Methodology

• Add grid mesh and enter edit

mode.

• Basic
• perations

such as dragging, rotating and scaling vertices or faces of the mesh is needed to produce a more accurate and aesthetic structure.

Methodology

• Diverse shapes and size in
• rder to accurately present

the material’s physical property.

Results

Results

• Products using Nanoelectronics

are made of tiny molecules in 3D, sometimes with many water molecules attached with it.

Figure 2.2 Three-dimensional modelled figure of SrTiO3 Figure 2.1 Two-dimensional figure of SrTiO3

Results

• Although they are too small for

human to see, we can use computing to represent its minor structure for further studies and investigations.

Figure 2.2 Three-dimensional modelled figure of SrTiO3 Figure 2.1 Two-dimensional figure of SrTiO3

Limitations

Limitations

• 2D images→only depicts front view;
• 3D models→both front and the side view of the material, for which the

latter is unknown.

Figure 2.2 Three-dimensional modelled figure of SrTiO3 Figure 2.1 Two-dimensional figure of SrTiO3

Limitations

• Could only simulate the side view similarly

as they did for the front view: ○ May involve inaccurate depiction of the actual metal oxide.

• For moisture air:

○ Quantity of water molecules present in the actual metal oxide is indeterminate.

Figure 2.2 Three-dimensional modelled figure of SrTiO3 Figure 2.1 Two-dimensional figure of SrTiO3

Conclusion

Conclusion

• Simple methodology of nanoelectronics can be represented using 3D

softwares.

• Only the front view diagram was given for each model.
• Affect the accurate visual depiction of the material.
• Require further investigation and research if people would like to

know more about this technology.

Acknowledgements

Supervisor : Professor Wang Xiao Assistant supervisor: Professor Han Kun Teacher mentor: Mr Lee Wei Keong

References

1. Wang Xiao, Renshaw (Asst Prof) ( 2018) NRPjr project synopses 2018. Retrieved from http://www.ntu.edu.sg/TalentOutreach/NRP/Documents/NRP%20Jr%202018%20Project%20Synopses.pdf 1.

• P. Reith, X. Renshaw Wang, and H.Hilgenkamp (2017) Analysing magnetism using scanning SQUID microscopy. Retrieved from

https://aip.scitation.org/doi/10.1063/1.5001390 1.

• X. Wang, G. Baskaran, Z. Q. Liu, J. Huijben, J. B. Yi, A. Annadi, A. Roy Barman, A. Rusydi, S. Dhar, Y. P. Feng, J. Ding, H. Hilgenkamp & T.
• Venkatesan. (2018) Electronic Phase Separation at the LaAlO3/SrTiO3 Interface. Retrieved from

https://www.nature.com/articles/ncomms1192 2. No author given (2018) Perovskite introduction. Retrieved from https://www.perovskite-info.com/perovskite-introduction 3. CG Geek, How to use Blender : Beginner Tutorial, 2017. Accessed on: June. 6, 2018. [Streaming Video]. Available: Youtube. 4. Blender Guru, Blender Beginner Tutorial - Part 1: User Interface, 2016. Accessed on :June. 6, 2018. [Streaming Video]. Available: Youtube.

References

1. Blender Guru, Blender Beginner Tutorial - Part 2: Moving, Rotating, Scaling, 2016. Accessed on : June. 6, 2018. [Streaming Video]. Available: Youtube. 2. Blender Guru, Blender Beginner Tutorial - Part 3 :Edit Mode, 2016. Accessed on : June. 6, 2018. [Streaming Video]. Available: Youtube. 3. Blender Guru, Blender Beginner Tutorial - Part 4: Material Nodes , 2016. Accessed on :June. 6 , 2018. [Streaming Video]. Available: Youtube. 4. BornCG, Blender 2.6 Tutorial 08 - Adding Color & Material(s), 2011. Accessed on: June. 6 , 2018. [Streaming Video]. Available: Youtube. 5. Blender Guru, Blender Beginner Tutorial - Part 6: Texturing, 2016. Accessed on : June. 6 , 2018. [Streaming Video]. Available: Youtube. 6. Blender Guru, Blender Beginner Tutorial - Part 8: Lighting, 2016. Accessed on : June. 6 , 2018. [Streaming Video]. Available: Youtube. 7. Blender Guru, Blender Beginner Tutorial - Part 9: Rendering and Compositing, 2016. Accessed on : June. 6 , 2018. [Streaming Video]. Available: Youtube. 8. WeShareB Knowledge, How to add text on blender, 2017. Accessed on : June. 6, 2018. [Streaming Video]. Available: Youtube.
