Viper

A Verification Infrastructure for Permission based Reasoning

Peter Müller, ETH Zurich

Joint work with Pietro Ferrara, Uri Juhasz, Ioannis Kassios, Milos Novacek, Malte Schwerhoff, and Alex Summers

2

Automatic Program Verification

• Most automatic deductive

verifiers use solvers for first

• rder logic (Z3, CVC4)
• Verification conditions are

computed via translation to intermediate verification language (Boogie, Why)

• Many success stories: Corral,

Dafny, Frama-C, Spec#, VCC

Peter Müller – Dagstuhl, May 04, 2015

Intermediate verification language Verification condition generator Prover Front-end Programming & specification language Front-end Programming & specification language Front-end Programming & specification language

3

Verifiers for Permission Logics

• Separation Logic (and other

permission logics) use custom logics to reason about heap- manipulating programs

• Custom verification engines

(jStar, Smallfoot, VeriFast)

• Custom decision procedures

(GRASShopper) or complex encodings (Chalice)

Peter Müller – Dagstuhl, May 04, 2015

Symbolic execution Prover Programming & specification language Symbolic execution Programming & specification language Symbolic execution Programming & specification language

4

Viper Viper Infrastructure

Peter Müller – Dagstuhl, May 04, 2015

Silver

Intermediate Language

Carbon

Boogie Encoding

Silicon

Symbolic Execution

Sample

Specification Inference

Boogie

VC Generation (Microsoft Research)

Z3

SMT solver (Microsoft Research)

Frontend Frontend Frontend

5

Language Overview of Silver

• Top-level declarations
• Fields
• Methods
• Heap-dependent

functions

• Predicates
• Domains

(uninterpreted functions and quantified axioms)

• Statements
• Assignments, calls,

conditionals, loops

• inhale, exhale
• fold, unfold
• Types
• Int, Bool, Ref, Perm
• Set[T], Seq[T]
• Types declared in

domains

Peter Müller – Dagstuhl, May 04, 2015

6

Example: Modeling Locks

Peter Müller – Dagstuhl, May 04, 2015

class C { int[ ] data; monitor invariant data_; void Foo( ) { acquire this; int i = data.length; while( 0 < i ) invariant data_; invariant holds( this ); { …; i = i – 1; } release this; } }

7

Example: Leak Check

Peter Müller – Dagstuhl, May 04, 2015

class C { int[ ] data; monitor invariant data_; void Foo( ) { acquire this; int i = data.length; while( 0 < i ) invariant data_; invariant holds( this ); { …; i = i – 1; } release this; } }

8

Example: Finite Blocking

Peter Müller – Dagstuhl, May 04, 2015

class C { int[ ] data; monitor invariant data_; void Foo( ) { acquire this; int i = data.length; while( 0 < i ) invariant data_; invariant holds( this, i ); { …; i = i – 1; } release this; } }

9

Viper Viper – Frontends

Peter Müller – Dagstuhl, May 04, 2015

Silver

Intermediate Language

OpenCL

Frontend (University of Twente)

Java

Frontend (University of Twente)

Scala

Frontend

Chalice

Frontend

Carbon

Boogie Encoding

Silicon

Symbolic Execution

Sample

Specification Inference

Boogie

VC Generation (Microsoft Research)

Z3

SMT solver (Microsoft Research)

10

Conclusion

• Viper is useful to
• Develop verifiers based on permission-logics
• Prototype new verification techniques
• Experiment with and integrate different back-ends
• Next-Generation Concurrency
• We have encoded message-passing and verified

certain liveness properties (via ranking functions)

• We have not yet experimented with racy programs,

weak memory models, higher-order idioms

Peter Müller – Dagstuhl, May 04, 2015
