Video and Audio Convergence Solution

International Product and Solution Center

Contents

Solution Introduction

Requirement Analysis

Product List

Background

Background

Background

Current situation

• CCTV systems focus on evidence recording, data security and evidence searching.
• Alarm systems focus on high accuracy, multiple perception modes and standardized procedure.
• But even with the most accuracy systems, the treasure lost and criminal still happens.

Trend

• Intelligent detection and immediate action is the future trend for security system, aiming to improve pre-caution and

immediate processing, to prevent loss.

Current situation

• Video evidences are recorded and kept by CCTV system, while audio evidences are recorded and kept by Public

Announcement (PA) system.

• Obviously it is not convenient to check evidences on two divided systems.
• Configuration on two separate systems is complicated. Operators need much cyber knowledge.

Trend

• To record and converge video and audio evidence is the future trend of security system.
• One system to contain both CCTV and PA parts, will be more friendly for users.

Real-time Deterrent Video and Audio

Requirement Analysis

Perimeters

• When intrusion happens, though cameras can record everything, the

intruder may not be aware of this, and would keep on intruding. Operators can only do afterwards checking.

• Operators can only check the intrusion via video clips, no immediate

actions can be taken to avoid further lost.

• Requiring intelligent detection and automatically trigger alarm via

CCTV system, then send alarm to surveillance center.

• Requiring audio warning upon detected intrusion, to fend off further

intrusion.

NVR Switch HikCentral

Perimeter Intrusion Recorded by CCTV system Theft been perceived Check video

Pain Points Requirements

Thermal camera Thermal camera IP camera

• With CCTV system alone, no immediate action can be taken

when non-business hour intrusion happens.

• With CCTV system alone, no immediate action can be taken

when limited district been intruded, e.g. petrol storage area.

• In unmanned petrol station, if people forget to pay after fueling,
• perators cannot give any remote reminding.
• Petrol station require intelligent detection function, triggering

alarm once intrusion been detect.

• Requiring audio warning been sent out automatically, warning the

intruders to give up intrusion.

• Requiring information broadcasting in emergency situation.
• Requiring remote audio reminding when people forget to pay.

NVR Switch HikCentral

Limited district Intrusion Recorded by CCTV system May cause serious damage

Petrol Station

Pain Points Requirements

IP camera Explosion-proof camera

• People flow is extremely high at metro/railway stations. It

is dangerous for passengers wandering near the edge of

• platforms. Station managers are not able to remotely

eliminate these risks.

• Station managers can check the live status of metro/railway

station, and for emergency or dangerous situation, broadcast audio warning remotely.

• Set time schedule to play train approaching information.
• Broadcasting information in case of emergency.

Theft Recorded by CCTV system Check video

Metro/Railway Station

Waiting near the edge

NVR Switch HikCentral

Loss and Damage happens

Pain Points Requirements

IP camera IP camera

• For current access control system, it can record illegal swiping

cards or break-in actions, but no immediate action can be taken to avoid further lost.

• In key areas, if doors remain open, managers have to arrange

people to close them. During this time, potential trespass may happen.

• Requiring alarm signal been triggered and sent to control

center once illegal swiping cards or break in happens.

• Requiring remote audio warning automatically or manually,

warning the breaker to stop.

• In key areas, if doors are forgot to be closed. Remote audio

reminding is required to ask people nearby to close the door.

• Requiring information broadcasting in case of emergency.

NVR Switch HikCentral

Illegal swiping cards or break in Monitor from security center Send guards Forget close the door

Office and Building

Pain Points Requirements

IP camera Access reader

• In school, once any disciplinary breaches are detected, (e.g.

smoking) school authorities cannot take any immediate action except for sending someone on site.

• When intrusion on school perimeters happens, security

authorities can only do live view or afterwards checking. No immediate actions can be taken to stop the intruder.

• Requiring remote audio to warn disciplinary students

immediately.

• Requiring audio warning been sent out once intrusion is

detected, warning the intruder to give up intrusion.

• Requiring information broadcasting in emergency situation.
• Set time schedule to play music in break time.

NVR Switch HikCentral Smoke Recorded by CCTV system Send people to handle Disciplinary breaches

School

Pain Points Requirements

IP camera IP camera IP camera

Requirement Analysis

After analyzing the scenarios above, it is not difficult to see that existing CCTV system is not capable enough to handle all these pain points. More should be done to enhance the whole security system.

• CCTV system automatically detects the triggers,

and alarms are sent to control center, and simultaneously trigger audio warning via IP speaker.

Camera IP speaker Network Control Center NVR

• Operators can talk via IP speaker, giving audio

warnings.

• Operators can set specific audio plans for IP

speakers to play audio on schedule.

Linkage between Event and Audio One-way Audio Audio Plan

Video and Audio Convergence Solution

• Broadcasting information to multiple IP Speakers

Broadcast

Access Control Alarm

Solution Introduction

Small and One-site Scenario Big and Multi-sites Scenario

Linkage between Event and Audio One-way Audio Audio Plan

System Structure

Small and One-site Scenario

• One-site system;
• Simple, easy to deploy;
• Control and management on NVR;
• Limited functions;

Big and Multi-sites Scenario

• Multi-sites system；
• Connected via IP;
• Centralized managed by HikCentral;

NVR Switch HikCentral Perimeter Intrusion Auto detection Trigger audio warning Flee

Performance

• Cameras deployed at perimeters for daily monitoring. With smart

detection (e.g. line crossing, intrusion detection), cameras can automatically detect and trigger alarm.

• No need for the guards to stay and stare at various videos for low-

effective monitoring.

• Alarm videos will come and pop up automatically.
• IP speakers are linked with correspond cameras. When alarm been

triggered, IP Speaker will automatically send audio warning.

• IP speakers can link with multiple types cameras, e.g. optical

cameras, thermal cameras.

• Intruders will be surprised and alarmed, in subconscious, giving up

and fleeing.

• Lost and damage been avoided.

7*24 Pre-Caution system Advanced Central Guarding System Automatic Audio Warning Protection for Treasury

Petrol Station School Thermal camera IP camera IP speaker Thermal camera

NVR Switch HikCentral Illegal swapping cards or break in Monitor from security center Remote Warning Forget close the door Flee Broadcasting

• Hikvision access control system can build linkage with CCTV system.

If events been detected at access control system, linked cameras will start recording and sending video to the security center.

• IP Speakers are linked with correspond cameras. When alarm is

triggered, IP Speaker will automatically send audio warning.

• Guards can monitor live video from security center, and start audio

warning via IP Speaker.

• Administrators can set schedule for IP Speakers to spread

information.

CCTV and Access Control Linkage Automatic Audio Warning Active Audio Warning Schedule Audio Plan

Performance

Metro/Railway Station School IP camera Access reader IP speaker

• Step1: Use NAManager software to search and link IP speaker with NVR via IP address.
• Step2: Use IP Speaker Tool to upload video files into NVR.
• Step3: Set alarm Settings on NVR’s local menu to trigger IP speaker.

Linkage between Event and Audio Function Overview

Note: 1. On each NVR, Maximum 4 IP speakers can be linked;

• 2. Uploaded video files should be MP3 format, within 10 M;
• 3. Recommend to set Volume as 70 or above;

• Set Event on HikCentral web page, choose Link IP Speaker to select event triggered Speaker.
• Audio alarm can be linked with events, triggered by CCTV system, access control system, alarm system, etc.

Linkage between Event and Audio DEMO Video Function Overview

• Option1: Enable One-way Audio on Control client dashboard.
• Option2: Enable One-way Audio on E-MAP
• Option3: Enable One-way Audio on Live view.

One-way Audio

Note: 1. One client can have one-way audio on several IP Speakers;

Function Overview

Broadcast

• Step1: Go to Control client Broadcast.
• Step2: Select Area and IP Speakers.
• Step3: Select audio files to start broadcasting.

Note: 1. Cannot do broadcasting for offline IP Speaker;

• 2. IP Speaker status refresh time is 3 minutes;

Function Overview

On HikCentral > Logical View, users can set flexible audio plan and audio task.

Audio Plan

Function Overview

Note: 1. Priority level: One-way Audio > event triggered Audio > Audio Plan;

• 2. Up to 32 audio plans, up to 8 audio tasks on each plan;

Product List

• Support PoE 802.3af
• Suitable for Indoor and Outdoor
• Aluminum
• Temperature: 0-55 °C
• On-site management
• Can work independently when

remote center is offline

• Converge video and audio

stream

• IoT, linkage between CCTV,

alarm, access control

• Centralized management
• Support linkage between

event and audio, one-way audio and audio plan

• All-in-One solution,

combining multiple subsystems together.

I series NVR HikCentral Professional DS-PA0103-A Product List IP cameras Access Control Alarm

• Intelligent detection by IP

cameras

• Visual access control system,

linked with CCTV system

• Alarm system send emergency

alarm to the center

• All subsystems above can be

linked with IP Speaker

DS-PA0103-B
