VIADUCT LOCATION STUDY October 19, 2009 Background Information Traffic Study Alternative Evaluation Public Involvement Preferred Concept Next Steps Evaluate alternatives for the location of a viaduct to serve central

slide-1
SLIDE 1

VIADUCT LOCATION STUDY

October 19, 2009

slide-2
SLIDE 2
  • Background Information
  • Traffic Study
  • Alternative Evaluation
  • Public Involvement
  • Preferred Concept
  • Next Steps
slide-3
SLIDE 3
  • Evaluate alternatives for the location of a

viaduct to serve central and eastern Waverly spanning U.S. Highway 6 and the BNSF Railway

slide-4
SLIDE 4

Waverly Rd. Oldfield St. Bluff Road Amberly Road

  • N. 148th St.
  • N. 162nd St.

Waverly High School Waverly Middle School Waverly (Hamlow) Elem. School Study Area

Legend

Waverly Intermediate School

  • N. 141st St.
slide-5
SLIDE 5

North

slide-6
SLIDE 6
  • Conduct Grade Separation Study
  • A minimum exposure factor of 50,000 for a

single crossing shall be required for identification as a potential location. (Exposure factor = # trains/day x # cars/day)

  • A new grade separation project will require

closing a minimum of two public at-grade crossings.

slide-7
SLIDE 7
  • Train Data
  • Vehicle Data
  • Accident History
  • Nearby Development
  • Adjacent RR crossings
  • Sight Distance
  • School Locations/Bus Routes
  • Hospital Locations
  • Fire Station Locations
  • Project Location
  • Cost-Benefit Analysis
  • Pedestrian Traffic
  • Right-of-Way/Relocation
  • Impact on Community
  • Local Support & Funding
  • Railroad Support & Funding
slide-8
SLIDE 8
  • Existing Traffic
  • Pedestrians
  • Operations
  • Safety
  • Train Volumes
  • Exposure Factors
  • Alternatives / Impacts
  • Future Growth Scenarios
  • Development Impacts
  • Schools & Bus Routes
  • Emergency Vehicles
slide-9
SLIDE 9
  • Data Collection
  • Counts
  • Field Review
  • Analysis
  • Operations
  • Crash History
  • Exposure Factors
  • Trains vs. Vehicles
  • Traffic Modeling
  • Current Land Use
  • Travel Patterns
slide-10
SLIDE 10
slide-11
SLIDE 11
slide-12
SLIDE 12
  • 141st Street and BNSF Crossing
  • 2 Train / Vehicle Crashes: PDO
  • 148th Street and BNSF Crossing
  • 1 Train / Vehicle Crash: PDO
  • 162nd Street and BNSF Crossing
  • 3 Train / Vehicle Crashes: 1 PDO, 1 injury, 1 fatality

Intersection Angle Rear-End Sideswipe Other Total Same Opposite US 6 & Amberly Rd 12 1 2 3 18 US 6 & N 141st St 5 2 1 1 1 10 US 6 & N 148th St 3 2 2 5 12 US 6 & N 140th St 5 4 1 10

Intersection Crash Data Crossing Location Crash Data

slide-13
SLIDE 13

Yearly train counts through Waverly, NE (2009 - 2034 growth, using 2008 as base and increasing 2.43% per year) 40 50 60 70 80 90 100 110 120 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027 2028 2029 2030 2031 2032 2033 2034 Average day Peak day

slide-14
SLIDE 14
  • Exposure Factor of 50,000 Warrants a Viaduct
  • Existing Factor is More Than 5 Times Greater

Exposure Factor Calculations Exposure Factor Calculations

slide-15
SLIDE 15
slide-16
SLIDE 16
slide-17
SLIDE 17

Average Train Delay at Crossings = 2:45

slide-18
SLIDE 18
slide-19
SLIDE 19
  • Ability to eliminate crossing hazard and improve

safety

  • Cost
  • Connectivity to existing/future roadway network
  • Impact to private property, including access
  • Public support
  • Ability to accommodate truck and farm machinery

traffic

  • Environmental impacts
  • Utility impacts
  • Benefits (how much traffic is served)
slide-20
SLIDE 20

Jamestown St. Heywood St.

  • N. 162nd St.
  • N. 141st St.
slide-21
SLIDE 21

Concept #1: Viaduct at 148th Street (Alternate 1)

  • Estimated construction cost: $ 8.2 Million
  • Grade-separated pedestrian crossing at 141st Street:

$2.3 Million

  • Projected traffic: 4,400 vehicles per day

Reasons for Consideration

  • Relative close proximity to downtown
  • Reduces area required for right-of-way acquisition
  • Accommodates largest volume of traffic, including

truck traffic

  • Sidewalk/trail along this alignment would best

accommodate future residential development and present school locations

  • Continuity to existing road network

Disadvantages

  • Impacts to Millard Lumber employee parking
  • Impacts to agricultural property
  • Lengthy access/frontage roads required
slide-22
SLIDE 22

Concept #2: Viaduct at 148th Street (Alternate 2)

  • Estimated construction cost: $8.4 Million
  • Grade-separated pedestrian crossing at 141st Street:

$2.3 Million

  • Projected traffic: 4,400 vehicles per day

Reasons for Consideration

  • Relative close proximity to downtown
  • Reduces area required for right-of-way acquisition
  • Accommodates largest volume of traffic, including

truck traffic

  • Sidewalk/trail along this alignment would best

accommodate future residential development and present school locations

  • Continuity to existing road network
  • More direct connection to US-6

Disadvantages

  • Impacts to future development west of 148th Street
  • Impacts to agricultural property
  • Impacts to commercial property
slide-23
SLIDE 23

Concept #3A: Viaduct at 148th Street (Alternate 3A)

  • Estimated construction cost: $7.7 Million
  • Grade-separated pedestrian crossing at 141st Street:

$2.3 Million

  • Projected traffic: 4,300 vehicles per day

Reasons for Consideration

  • Relative close proximity to downtown
  • Reduces area required for right-of-way acquisition
  • Accommodates largest volume of traffic, including

truck traffic

  • Sidewalk/trail along this alignment would best

accommodate future residential development and present school locations

  • Existing 148th Street is maintained as the primary

alignment including connection to Highway 6

  • Continuity to existing road network

Disadvantages

  • Impacts to future development west of 148th Street
  • Impacts to agricultural property
slide-24
SLIDE 24

Concept #3B: Viaduct at 148th Street (Alternate 3B)

  • Estimated construction cost: $10.0 Million
  • Grade-separated pedestrian crossing at 141st Street:

$2.3 Million

  • Projected traffic: 4,300 vehicles per day

Reasons for Consideration

  • Relative close proximity to downtown
  • Access to downtown
  • Reduces area required for right-of-way acquisition
  • Accommodates largest volume of traffic, including

truck traffic

  • Sidewalk/trail along this alignment would best

accommodate future residential development and present school locations

  • Existing 148th Street is maintained as the primary

alignment including connection to Highway 6

  • Continuity to existing road network

Disadvantages

  • Impacts to future commercial development
  • Impacts to commercial property
  • Impacts to agricultural property
slide-25
SLIDE 25

Concept #4: Viaduct at 152nd Street (Eliminated)

  • Estimated construction cost: $7.4 Million
  • Grade-separated pedestrian crossing at 141st Street:

$2.3 Million

  • Projected traffic: 2,900 vehicles per day

Reasons for Elimination

  • Distance from central Waverly:
  • Increased vehicle travel distance/times
  • Too remote to provide pedestrian access

across BNSF Railway and U.S. Highway 6

  • Increased emergency response times
  • Lower traffic utilization
  • No direct access to downtown
  • Property impacts

Reasons for Initial Consideration

  • Provided an alternate viaduct location to 148th

Street

  • Viaduct constructed near eastern edge of future land

use plan

slide-26
SLIDE 26

Concept #5: Viaduct at 162nd Street (Eliminated)

  • Estimated construction cost: $5.0 Million
  • Grade-separated pedestrian crossing at 141st Street:

$2.3 Million

  • Projected traffic: 300 vehicles per day

Reasons for Elimination

  • Distance from central Waverly:
  • Increased vehicle travel distance/times
  • Too remote to provide pedestrian access across

BNSF Railway and U.S. Highway 6

  • Increased emergency response times
  • Lowest traffic utilization
  • No direct access to downtown

Reasons for Initial Consideration

  • Lower construction cost
  • Fewer property impacts
  • Better accommodate future growth in far eastern

reaches of future city limits

slide-27
SLIDE 27

Concept #6: Viaduct at 141st Street (Eliminated)

  • Estimated construction cost: $7.0 Million
  • Grade-separated pedestrian crossing at 148th

Street: $2.3 Million

  • Projected traffic: 5,800 vehicles per day

Reasons for Elimination

  • Property impacts:
  • Home relocations
  • Residential and commercial driveway and

access closures/reconfiguration

  • Retaining wall in close proximity to homes
  • Intersecting street closures necessary
  • Increased traffic volumes on residential streets
  • Difficult turning movements for viaduct truck

traffic

  • Does not accommodate farm machinery

Reasons for Initial Consideration

  • Provides direct access to north and south of

U.S. Highway 6 near center of Waverly

  • Along same alignment as existing 141st Street
slide-28
SLIDE 28

Concept #7: Underpass at 141st Street (Eliminated)

  • Estimated construction cost: Not Calculated For This

Concept

  • Grade-separated pedestrian crossing at 148th

Street: $2.3 M

  • Projected traffic: 5,800 vehicles per day

Reasons for Elimination

  • Property impacts:
  • Residential and commercial driveway and

access closures/reconfiguration

  • Retaining wall in close proximity to homes
  • Increased traffic volumes on residential streets
  • Difficult turning movements for viaduct truck

traffic

  • Does not meet Nebraska Minimum Design

Standards- steep grades

  • Does not accommodate farm machinery
  • Long term maintenance and operational costs

Reasons for Initial Consideration

  • Provides direct access to north and south of

U.S. Highway 6 near center of Waverly

  • Along same alignment as existing 141st Street
slide-29
SLIDE 29
  • Public Meetings (2)
  • June 24, 2008
  • September 9, 2008
  • One-on-one / stakeholder meetings (9)
slide-30
SLIDE 30

Public Meeting #1

  • 36 comments received
  • 20 residents
  • 13 business owners
  • 3 unknown
  • 7 – support
  • 19 – oppose
  • 4 – support & oppose
  • 6 – undecided
slide-31
SLIDE 31
  • Reasons for supporting the project
  • Safety concerns with existing crossings
  • Existing vehicle delays at crossings
  • Existing train horn noise
  • Reasons for opposing the project
  • Concern for closing 141st Street crossing
  • Division of town
  • Loss of business
  • Increased travel times/distances
slide-32
SLIDE 32

Public Meeting #2 – Comments Received

  • Concern for closing 141st Street crossing
  • Increased travel times
  • Impacts to businesses
  • Any new structure must accommodate farm machinery
  • Any new structure must accommodate pedestrians
  • Provide direct access to U.S. Hwy 6
  • Provide direct access to downtown Waverly
  • Noise
slide-33
SLIDE 33
  • “Hybrid” of Concepts 2 & 4
  • Most direct connection to

Hwy 6

  • Most direct connection to

downtown

  • Decreased travel times
  • Best responds to public

comments

slide-34
SLIDE 34
slide-35
SLIDE 35
  • Federal – 80%
  • Railroad – 5%

ITEM COST 148th Street Viaduct 141st Pedestrian Overpass Viaduct/Roadway Construction $9,150,000 $2,300,000 Utilities $200,600 $0 Right-of-Way $266,000 $50,000 Design Engineering & Environmental Review $1,153,990 $282,000 Construction Engineering $961,660 $235,000 TOTAL PROJECT COST $11,732,250 $2,867,000 Combined: $14,599,250

  • State (TMT) – 10%
  • Local – 5%
slide-36
SLIDE 36
  • Public Comment
  • Council vote on approving report recommendations
  • If/when moved to design/construction
  • NDOR Study Review/Approval
  • Preliminary Design
  • Environmental Documentation and Federal

Approval

  • Funding Approval
  • Right-of-Way Acquisitions
  • Final Design
  • Construction
