Version Control Systems: SVN and GIT How do VCS support SW development teams?

CS 435/535

The College of William and Mary

Chapter 3 Agile software development

Agile manifesto

We are uncovering better ways of developing software by doing it and helping others do it. Through this work we have come to value:

• Individuals and interactions over processes and tools

Working software over comprehensive documentation Customer collaboration over contract negotiation Responding to change over following a plan

That is, while there is value in the items on the right, we value the items on the left more.

2

What is needed?

Chapter 3 Agile software development

Plan-driven and agile specification

Requirements specification Requirements engineering Design and implementation Requirements change requests Plan-based development Agile development Requirements engineering Design and implementation

3

Chapter 3 Agile software development

The extreme programming release cycle

Break down stories to tasks Select user stories for this release Plan release Release software Evaluate system Develop/integrate/ test software

4

Chapter 3 Agile software development

The Scrum process

Outline planning and architectural design Project closure Assess Select Review Develop Sprint cycle

5

Chapter 3 Agile software development

Scrum benefits The product is broken down into a set of manageable and understandable chunks. Unstable requirements do not hold up progress. The whole team have visibility of everything and consequently team communication is improved. Customers see on-time delivery of increments and gain feedback on how the product works. Trust between customers and developers is established and a positive culture is created in which everyone expects the project to succeed.

6

Software Engineering is Team Work

• Enabling technology for productivity
• must support parallelization
• must support communication
• Documentation as preserved communication
• must support management of tasks & people
• What needs to be done? When? By whom?
• What has been done? By whom?

Remember SVN from CS 301? What does it support?

Version Control Systems

Centralized

• CVS – 1990
• SVN - 2000

Distributed

• Bitkeeper - 1997
• Git – 2005
• Bazaar – 2005
• Mercurial - 2005

*More VCS at http://en.wikipedia.org/wiki/Comparison_of_revision_control_software

Version Control Systems

• Version control system
• supports concurrent software development on shared code base
• keeps track of changes,
• integrates versions / recognizes conflicts,
• allows for recovery, documentation of changes
• Common set up:
• IDE as front end, VCS as back end (shared, persistent storage)

Subclipse: eclipse plugin for SVN

Subclipse: eclipse plugin for SVN

http://subclipse.tigris.org/update_1.8.x

EGit: eclipse plugin for Git

EGit: eclipse plugin for Git

http://download.eclipse.org/egit/updates

EGit: eclipse plugin for Git http://eclipsesource.com/blogs/tutorials/egit-tutorial/ http://wiki.eclipse.org/EGit/User_Guide#Overview

Centralized vs Distributed Version Control Systems

Image from http://git-scm.com/book/en/Getting-Started-About-Version-Control

Centralized Architecture:

Distributed Version Control Systems

Image from http://git-scm.com/book/en/Getting-Started-About-Version-Control

Distributed Architecture:

Centralized vs Distributed VCS

• What are the pros & cons?
• Software engineering is much about scalability:
• Project size in # of developers
• about 10
• up to 100
• more than 100

Workflows: Centralized

Image from http://git-scm.com/book/en/Distributed-Git-Distributed-Workflows

• Small teams
• Typical workflow for SVN

and CVS

• Repository is a single point
• f failure

Workflows: Integration - Manager

Image from http://git-scm.com/book/en/Distributed-Git-Distributed-Workflows

• Supported by CVS and

SVN using branches

• More easily supported by

distributed version control systems

Workflows: Director and Lieutenants

Image from http://git-scm.com/book/en/Distributed-Git-Distributed-Workflows

• Supported by CVS and

SVN using branches

• More easily supported by

distributed version control systems

• Generally used by huge

projects (e.g., Linux kernel)

Versions, Revisions, and Snapshots

• CVS: each commit generates a new version

for each file modified

• SVN: each commit generates new state of

the file system tree, called a revision

• GIT: same than SVN; keeps a snapshot of

the system but instead of saving the deltas it saves the changed files and references to the unchanged ones

Git follows idea of a file system with snapshots

SVN et al:

1.4: Other systems tend to store data as changes to a base version of each file.

Versions, Revisions, and Snapshots

Image from http://svnbook.red-bean.com/en/1.7/svn.basic.in-action.html

SVN and Git use global revision numbers

Operations and states (CVS and SVN)

Workspace Repository

Checkout Commit

Operations and states (Git)

Workspace Repository

Checkout Commit

Staging area (Index)

Stage

Operations and commands - Git

http://osteele.com/posts/2008/05/commit-policies

Workflows: Integration - Manager

Image from http://git-scm.com/book/en/Distributed-Git-Distributed-Workflows

• Supported by CVS and

SVN using branches

• More easily supported by

distributed version control systems

Operations and commands

Operation CVS SVN Git Init init create init Import import import commit Checkout checkout checkout clone Checkout branch checkout checkout checkout Commit/Checkin commit commit commit, push Update update update fetch, pull

Operations and commands - SVN+Eclipse

Operations and commands - SVN+Eclipse

Operations and commands - SVN+Eclipse

Operations and commands - SVN+Eclipse

Operations and commands - SVN+Eclipse

Operations and commands - SVN+Eclipse

Workflows and issues

• Workflow: 1) get code base 2) make changes 3) deliver changes
• Issue: Read/write access to remote repository
• Protected: User authentication, registration, account/pw necessary in communication, IDE

stores/uses account/pw for convenience

• Issue: Conflicts
• Changes do not fit together, automatically recognized at some level of granularity (same file,

same method, same line of code)

• Automatically recognized, manually fixed
• Issue: Documentation / Communication
• What changed, how trustworthy are the changes, what needs to be changed as an effect
• Finding the right historical version to undo some changes

Tagging

• Useful for marking specific points in history, in particular: Releases
• Two types: lightweight vs annotated
• annotated: full objects in Git DB, check summed, contain tagger

name, email, date, tagging message, can be signed & verified

$ git show v1.4 tag v1.4 Tagger: Scott Chacon <schacon@gee-mail.com> Date: Mon Feb 9 14:45:11 2009 -0800 my version 1.4 commit 15027957951b64cf874c3557a0f3547bd83b3ff6 Merge: 4a447f7... a6b4c97... Author: Scott Chacon <schacon@gee-mail.com> Date: Sun Feb 8 19:02:46 2009 -0800 Merge branch ’experiment’

• $ git tag -a v1.4 -m ’my version 1.4’

Branching

• CVS: simple process for creating branches
• n the repository
• SVN: has no internal concept of a branch;

branches are managed as copies of a directory.

• GIT: very simple process for creating local

and remote branches

Merging

1 2 3 5 6 4

Branch

1 2 3 5 6 4

Branch

7

Merge

Branching in SVN

Branching in SVN

Branching in SVN

Branching in SVN

Branching in SVN

Branching in SVN

Branching in SVN

Branching in Git

• Branches are lightweight movable pointers to

commits

• The default branch is the MASTER (trunk)

Images from http://git-scm.com/book/en/Git-Branching-Basic-Branching-and-Merging

Branching in Git Initial layout for three commits New branch pointer (iss53)

Images from http://git-scm.com/book/en/Git-Branching-Basic-Branching-and-Merging

Branching in Git New commit on the branch Hot fix branch on master

Images from http://git-scm.com/book/en/Git-Branching-Basic-Branching-and-Merging

Merging in Git

Images from http://git-scm.com/book/en/Git-Branching-Basic-Branching-and-Merging

Merging in Git

Images from http://git-scm.com/book/en/Git-Branching-Basic-Branching-and-Merging

Branching & Merging in Git

• Key concept, well supported
• Local workflow
• people create branches for any issue / task /assignment they deal with,

sometimes called “topic” branch

• optional: rebase instead of merge to obtain a linear history
• only recommended for local repository
• Remote repository: merge with master
• For integration manager with blessed repository: pull request

What is missing so far?

• Documentation of problems, bug reports
• Work assignments, who does what and till when

Issue tracking

Github Issue Tracker

• Filter by open and closed issues, assignees, labels, and milestones.
• Sort by issue age, number of comments, and update time.
• Milestones / labels

Github Workflow: Code review & Pull request

• Pull request starts conversation around proposed changes. Additional commits may add to branch

before merging into master.

• Pull Request = Code + Issue + Code Comments

Software Engineering is Team Work

• Enabling technology for productivity
• must support parallelization
• must support communication
• Documentation as preserved communication
• must support management of tasks & people
• What needs to be done? When? By whom?
• What has been done? By whom?
