2013 Vehicle Powertrain Foundation Accessible to: Undergrads, Masters Students, and PhD Candidates On-campus and Distance Learning Degree Seeking and Non-Degree Seeking Certificates The Vehicle Development Process Through Coursework

SLIDE 1

2013

Accessible to: Undergrads, Masters Students, and PhD Candidates On-campus and Distance Learning Degree Seeking and Non-Degree Seeking Certificates

Vehicle Powertrain Foundation

SLIDE 2

The Vehicle Development Process Through Coursework Using State-of-the-Art Tools

Vehicle Modeling

(Simulink)

Powertrain Subsystems

(VeriStand & INERTIA)

Advanced Modeling

(Cruise & DynaCar)

Powertrain HIL Testing

(VeriStand & DynaCar)

Embedded Controls

(MotoHawk)

Vehicle Testing

(ADCS)

Systems Validation

(cRIO)

Foundational Courses Thermodynamics Energy Systems Combustion Dynamic Systems Controls Signal Processing NVH

SLIDE 3

Core Powertrain Courses

Intro and Advanced IC Engines Introduction to Motor Drives Distributed Embedded Control Systems Power Electronics + Lab Power Systems Operation Power Systems Protection + Lab Vehicle Battery Cells and Systems Advanced Electric Machines

Vehicle Integration Courses

Vehicle Dynamics Powertrain Instrumentation and Test Intro Prop Systems for Hybrid Electric Vehicles + Lab Adv Prop Systems for Hybrid Electric Vehicles + Lab

SLIDE 4

Michigan Tech Short Courses

Hands-On Short Course Title Duration (Days)

Experimental Studies in Hybrid Electric Vehicles 2-5 Modeling and Synthesis of Hybrid Electric Vehicles 2-3 Ground Vehicle Dynamics 2-3 Battery Engineering for Hybrid Electric Vehicles 2-3 Electric Machines 2-3 Power Electronics 2-3 SI Engine Fundamentals 2-5 SI Engine Management Systems and Torque Control 2-4 Diesel Engine Fundamentals 2-3 Introduction to Diesel Engine Control, Emissions, and Aftertreatment 2-3 Advanced Powertrain Instrumentation 2-3 Embedded Control System Design 2-3 Model Based Control System Design 2-3 Optimization of Control Systems Using Matlab / Simulink 2-3 Nonlinear Control System Analysis and Design 2-3 Smart Microgrid Systems 2-3 Digital Signal Processing and Dynamic Measurements 3-4 Many Engineering Courses in Thermo, Heat Transfer, Fluids, Energy Systems, HVAC, etc. 1-5 Custom Courses Available Upon Request 1-5

SLIDE 5

Example Short Course

Recent Short Course Set of HEV seminars were delivered during annual training week

Delivered via Mobile lab with virtual guests 563 participants

SLIDE 6

Regional & National STEM Outreach

Advanced Technology Vehicles, Microgrids, and Renewable Fuels & Energy

SLIDE 7

MISC EXTRA BACKUP Mobile STEM Outreach

Community Colleges

Bay de Noc Delta Grand Rapids Macomb Wayne

Great Lakes Region

Chicago Milwaukee Green Bay 3M - Minneapolis Kohler, WI

Western UP Math and Science Fair Michigan Tech Youth Programs MI High Schools

DAPCEP GRAPCEP Cass Tech Gear Up Wayne

TARDEC

Collaborating to connect with inner-city youth

USA Science and Engineering Festival

April 28-29, 2012 Washington, D.C.

Underrepresented Rural and Local K-12 Schools

SLIDE 8

Hands-On Outreach Activities

Classroom, Powertrain Testcells, & Multifunction Laboratory Benches

Portable Chassis Dyno Hybrid Vehicles Chevy Malibu BAS Saturn Vue MultiMode Chevy Volt EREV Interactive Microgrid

Features PHEV & 5kW controllable load 80kW generator PV array & wind turbine Wireless communication Interactive GUI

Configurable HEV

Education, Demonstration, & Research in Energy Surety

Aid in the development of smart microgrids Support the transformation of US military installations in safe, reliable power generation

Web Pages & Brochure

MTU.EDU HEV

SLIDE 9

Lecture & Configurable Outreach Space

TEST CELL 2 TEST CELL 1

Outreach Example: What is a Hybrid Vehicle?

Apply the Concepts: HIL testing with a Real Powertrain Apply the Concepts: with a Configurable HEV Apply the Concepts: Apply the Concepts: HEV Gaming - A virtual garage and drive route

Hands-On STEM Outreach Short Duration High Impact Experiences in Sustainable Transportation

How it Works: Electric Machines How it Works: Engines How it Works: Batteries Apply the Concepts: flow Apply the Concepts: Design for Energy Surety with a controllable renewable microgrid

MOBILE LAB PARTNERS: Mobile Laboratory:

A Unique Venue for Education, Outreach, and Research Toward Sustainable Transportation and Energy Surety

SLIDE 10

Uses

Hands-on Education: Courses, Short Courses, Seminars Outreach: schools, exhibits, conferences, community events Product & Technology Demonstrations Research partnerships

Audience

College & Pre-College Students Engineers Corporate Decision Makers Governmental Policy Makers Defense Personnel

Partnering with Government, Industry, & Nonprofit Organizations to Deliver Hands-On Education & Outreach Across the Nation
