HUAWEI OceanStor N8500 V200R001C10 Main Slide

2

Agenda

Trend & Challenges

1 2 3 4

Specifications & Features Stories Application Scenarios

3

Global Data Trend

The global data volume was 0.8 ZB in 2009 and will be up to 40 ZB in 2020. What does 40 ZB mean? 40 ZB ≈ 2 trillion Blu-ray Discs (BDs) (20 GB for a single BD) 40 ZB ≈ 5247 GB data for each person (about 7.6 billion population in 2020)

2009: 0.8 ZB

Source: IDC 2012

2020: 40 ZB 50X

4

Challenges Faced by Enterprise Customers

Low storage efficiency

Large investment

Excessive services

Heavy pressure on performance

Fast data growth

Difficult storage expansion

5

Agenda

Trend & Challenges

1 2 3 4

Specifications & Features Stories Application Scenarios

6

HUAWEI OceanStor N8500 Overview

• Excellent performance, 3 million OPS in the SPEC

benchmark test

• Up to 15 PB flexible storage space and PB-

level file storage, fitting for high-speed service growth

• Efficient data management, decreasing

the TCO by 60%

• Intelligent and converged storage,

simplifying the infrastructure

7

OceanStor N8500 Specifications

Item N8500 System architecture Multi-node active-active cluster architecture Number of nodes 2 to 24 Maximum system capacity 15 PB Cache per node Basic: 16 GB; Standard: 24 GB Enterprise: 48 GB; Enhanced: 96 GB (standard configuration) and scalable to 192 GB Ethernet GE and 10GE Protocol NFS, CIFS, FTP, HTTP, FCP, FCoE, iSCSI, NDMP LAN-Free Maximum capacity

• f a file system

256 TB Value-added software DST, LoadBalance, Snapshot, Mirror, Quota, Replication, WORM, SmartCache, HyperThin, HyperImage, HyperCopy, HyperClone, and HyperMirror Disk type SSD, SAS, NL-SAS, SATA, and intermixing of different disks

GE switch (optional) Cabinet (optional) Fibre Channel switch (optional) Engine Storage unit

8

OceanStor N8500 Architecture

Node 1 Node 2 Node 3 Node N

Separation of the control plane and data plane Fully redundant architecture Separation of file management and disk management Fully modular design

Service cache GE Service cache CPU 10GE FC CPU JBOD JBOD JBOD JBOD Service cache Service cache CPU CPU Service cache Service cache CPU CPU GE 10GE FC Service cache GE Service cache CPU 10GE FC CPU JBOD JBOD JBOD JBOD Service cache Service cache CPU CPU Service cache Service cache CPU CPU GE 10GE FC Service cache GE Service cache CPU 10GE FC CPU JBOD JBOD JBOD JBOD Service cache Service cache CPU CPU Service cache Service cache CPU CPU GE 10GE FC Service cache GE Service cache CPU 10GE FC CPU JBOD JBOD JBOD JBOD Service cache Service cache CPU CPU Service cache Service cache CPU CPU GE 10GE FC Data plane

NAS engine Storage unit

Control plane

9

• Oct. 2009
• Apr. 2011
• Oct. 2012

SPECsfs2008 nfs: 3,064,602 OPS

The Standard Performance Evaluation Corporation (SPEC) is a global authoritative third-party organization that tests application

• performance. Operation per second (OPS) refers to the number of supported concurrent requests per second.

10

… … … …

Excellent performance — Fully redundant clustered architecture

Server Network Storage

Traditional NAS architecture: non-cluster, non-redundant, limited concurrent processing capability

NAS engine A NAS engine B

Clustered NAD architecture: active-active, fully redundant, strong concurrent processing capability

NAS engine A NAS engine B

Storage pool

File system B File system A NAS engine C NAS engine D File system A File system B

a b a b c d

11

Cluster Parallel processing, improve the performance

CIFS NFS GAB LLT CFS CVM GLM

The standard file access protocol, wide compatibility

Private communication protocol, to ensure that the information transmission efficiency and consistency

The global lock management, to ensure the data consistency

CIFS NFS GAB LLT CFS CVM GLM CIFS NFS GAB LLT CFS CVM GLM

Cluster heartbeats Cluster heartbeats

12

Excellent performance — I/O paths with the same length and latency

Server Network Storage

NAS engine A NAS engine B

Clustered NAS architecture: data sharing, I/O paths with the same length and latency, stable performance

NAS engine C NAS engine D

HA HA

A C D B

NAS engine A NAS engine B NAS engine C NAS engine D

Traditional NAS architecture: data forwarding, I/O paths with different lengths and latencies

a b c d

A C D B A C D B A C D B

Virtual storage resource pool

a b c d

13

… …

High scalability — Flexible and Cost-effective Expansion Modes

… … … …

File system A File system A File system A

Server Network Storage

File system A File system A

Traditional mode: limited, restricted Modular mode: flexible, cost-effective

… … … … … …

NAS engine Storage unit

• Max. 24 nodes
• Max. 15 PB

14

Robust reliability — Max. N–1 node redundancy

Clients IP resource pool 192.168.1.10 192.168.1.11 192.168.1.12 192.168.1.13

Controller A Controller B Controller C Controller D

192.168.1.10 192.168.1.11 192.168.1.12 192.168.1.13

Controller A Controller B Controller C Controller D

192.168.1.10 192.168.1.11 192.168.1.12 192.168.1.13

Controller A Controller B Controller C Controller D

192.168.1.12 192.168.1.13 192.168.1.10 192.168.1.11

Controller A Controller B Controller C Controller D

192.168.1.12 192.168.1.13 192.168.1.10 192.168.1.11

Virtual storage resource pool

15

NAS engine A NAS engine B NAS engine C NAS engine D

192.168.1.10 192.168.1.11 192.168.1.12 192.168.1.13 10 clients 10 clients 10 clients 10 clients

Virtual storage resource pool

Load balancing

Built-in DNS domain name resolution N8500 node IP address Balance policy N8500.com N8500 domain name

40 clients

Virtual IP resource pool 192.168.1.10 192.168.1.11 192.168.1.12 192.168.1.13

NAS engine A NAS engine B NAS engine C NAS engine D

192.168.1.10 192.168.1.11 192.168.1.12 192.168.1.13 20 clients 10 clients 10 clients

Balance policy: round robin–based, CPU utilization, network bandwidth, number of client links

16

Load balancing

120 clients

Virtual IP resource pool 192.168.1.10 192.168.1.11 192.168.1.12 … 192.168.1.21

NAS engine A NAS engine B NAS engine C NAS engine D

192.168.1.10 192.168.1.11 192.168.1.12 192.168.1.13 192.168.1.14 192.168.1.15 192.168.1.16 192.168.1.17 192.168.1.18 192.168.1.19 192.168.1.20 192.168.1.21 30 clients 30 clients 30 clients 30 clients

Virtual storage resource pool

NAS engine A NAS engine B NAS engine C NAS engine D

192.168.1.10 192.168.1.13 192.168.1.14 192.168.1.15 192.168.1.11 192.168.1.16 192.168.1.17 192.168.1.18 192.168.1.12 192.168.1.19 192.168.1.20 192.168.1.21 40 clients 40 clients 40 clients

17

…

Intelligent migration, improving performance while reducing costs

Cold data Tier 1 SAS Tier 2 SATA Hotspot data

Server Network Storage

DST: Smart relocation of non-hotspot data reducing costs by 60% SmartCache: Accelerating hotspot data access by 10 times

Tier 0 SSD Tier 1 SAS

…

18

Multiple Features Ensuring Data Security

Preventing deletion by mistake Snapshot data used for test and verification

Incremental data–based asynchronous replication Fibre Channel or IP link Replication link compression

Local HA solution Device-level redundancy Service continuity protection

Snapshot File system mirroring Remote replication Administrators

Master System Storage

19

Storage Pool

Local High availability Local High availability & & Async Async Replication Replication

Mirror A Mirror B

Engine A Engine B Engine C Engine D Engine A Engine B

File System Mirror Storage Pool WAN

Async Replication (FC/IP)

Site A Site B

• 1. Local high availability .The

business will not interrupt if one storage failed.

• 2. Async data replication, to ensure

the data security if site A failed.

20

Multi-protocol Convergence—— Reducing Investment Costs

OceanStor N8500 storage system

NFS CIFS FTP HTTP Block-based

Management interface

Others FC iSCSI FCoE SMI-S SNMP Syslog NDMP NTP SSH File-based

21

Agenda

Trend & Challenges

1 2 3 4

Specifications & Features Stories Application Scenarios

22

Application Scenario— high performance file processing for M&E

Typical cases Requirements Advantages

 Editing & Production: low latency, high reliability,  Media asset storage system: scalable from 200 TB to several PB,

easy management

 Flexible expansion of both performance and capacity  Verified seamless compatibility with industrial ISV  Large bandwidth and high cost performance: proven 20% to

7Flexible expansion，cost-effective scale up and scale out configuration

 0% higher performance than other vendors  Verified compatibility with industrial ISVs such as AVID, Sobey,

Jetsen, and DAYANG

Sampling N8500

HD: 100 Mbit/s SD:50 Mbit/s Editing Special effects Composition

Editing & Production N8500

Process Transcoding Web

MAM

Catalog Inde x Tapes

Broadcast system

Broadcast service

N8500

Archive Delivery Index

Core Node Edge Node Edge Node Edge Node

Strea ming

…

Strea ming

NSP

23

Application Scenario —Massive file archiving

Typical cases Requirements Advantages

 A large number of scanned pictures need to be archived. The data

to be archived is rarely accessed, and some critical data will be backed up to a tape library using backup software.

 Good expansion  Block and file storage space  Data disaster recovery (DR) for critical data protection  Efficiency and performance: efficient management of massive

small files and powerful I/O processing

 Clustered architecture and flexible expansion: flexible expansion of

performance and capacity for economical and pragmatic solution configuration

 Unified storage feature: storage space for databases, reducing

device investment N8500 WAN DB server LAN

HA

Apps server FC－SAN NFS/CIFS N8500 IT service Backup server

Site A Site B

Tape/V TL

24

Application Scenario — Simplifying IT infrastructure

Typical cases Requirements Advantages

 Centralized storage  Good expansion  Block and file storage space  Data disaster recovery (DR) for critical data protection  lexible expansion of performance and capacity for economical and

pragmatic solution configuration

 Unified storage feature: storage space for databases, reducing

device investment

 High performance

N8500 WAN DB server LAN

HA

Apps server FC－SAN NFS/CIFS N8500 IT Service Backup server

Site A Site B

Tape/V TL IP-SAN

25

Agenda

Trend & Challenges

1 2 3 4

Specifications & Features Stories Application Scenarios

26

Product Application Across the Globe

WSU, South Africa Mackenzie Presbyterian University, Brazil Tennessee, US DataStore 365 Russia Dataline data center Spain Police Bureau Italy Fineco Bank ChungHwa Telecom IDC (Thailand) Turkey Research Institute Norway OBC People's Procuratorate of Shenzhen SINAP CCTV IMG Media Ministry of Communications and Transportation, Mexico Shaanxi Public Security Illumination Entertainment, France Brazil Telesp Phoenix TV China Petroleum

27

Packaging Island of CCTV

Customer requirements Solution Benefits

 Reduced computing time of rendering, improved package production efficiency, 3600 MB/s performance delivered by the 4-node 10GE network  Free of single points of failure, ensuring long-term stable running and data security  Compatible with all types of operating systems in the exiting IT environment, easy space and permission allocation, safeguarded data security brought by periodic snapshot It is the main channel for the national public to obtain information and is an important window for China and the world to understand each other. It has growing impacts on the world. The CCTV is relocated to a new site, requiring a new rendering system. CCTV is the predominant news agency in mainland China, one

• f the most competitive

mainstream media today.

10GE 30+ rendering clustered blades 40+ graphic workstations HUAWEI OceanStor N8500 10GE switch Physical type library NetBackup server

 More than 2.2 GB/s read/write throughput for 10 channels' package production  Space and permission management of production items  Scalable storage architecture meeting the increasing expansion requirements  Huawei media storage solution: one N8500 device with 100 TB capacity and good compatibility, and ISV Jetsen.  Components: N8500 clustered NAS system Snapshot and rapid data restoring (a maximum of 512 snapshot/file systems) Quota management and NetBackup

28

IMG MAM System

10GE HUAWEI OceanStor N8500 E6000 server 10GE switch E6000 server E6000 server E6000 server "What has really impressed us has been the quality of the technology, combined with the creative approach of the Huawei engineers. We spoke to other suppliers, who told us that what we wanted could not be done. Huawei did not seem to hit the same walls as others – they worked hard to understand the broadcast arena and find a solution which delivered on our needs." — IMG Media manager, Shane Warden International Medical Group (IMG) is the best worldwide sports and media company with more than 3000 staffs. Its customers, such as Sky-Sports, ESPN, and BBC, cover more than 30 countries. iNews-02 Ardom system iNews-01 EVS system

Customer requirements Solution Benefits

 Simplified network that can carrying multiple devices  Higher performance to support production expansion  Online and near-line shared storage  Huawei media asset storage solution  Components: E6000 blade cluster with high performance and density N8000 NAS system with high performance for production space and low-cost SATA disks with large capacity for near-line storage (file-based migration, accurate location, and flexible granularity)  Highly reliable E6000 blades simplify the network. Cluster virtualization reduces servers by 50%, saving more than 60% space.  The N8000 solution provides online and near-line shared storage, remarkably reducing storage expansion costs.  Provides customers with high-performance and cost-effectiveness as a tier-1 vendor.

29

Phoenix Television Multi-service Platform

 High bandwidth, providing high throughput and low latency for video editing  High reliability and zero-failure, preventing service interruption  Integrated solution, supporting video editing, VDI individual web disk, and office automation (OA) systems simultaneously and implementing unified management

10GE OA system HUAWEI OceanStor N8500 Switch 10GE GE GE Since the debut of its Phoenix Chinese Channel

• n March 31, 1996, Phoenix Television has been

adhering to its purpose of "Bringing Global Chinese Closer" and providing Chinese people across the world with high-quality Chinese television programs. Today, Phoenix Television has grown into a multi-national media enterprise with a global reputation and worldwide brand recognition. Through years of dedication, Phoenix TV has established a highly valued media brand and listed on the Growth Enterprise Market (GEM) on Jun 30, 2000. Individual web disk system Video editing system

Customer requirements Solution Benefits

 Deploy 2-node standard N8500 in the UK data center, implementing online dynamic bandwidth allocation and load sharing.  Components: N8500 clustered NAS system with a maximum of 24 nodes 72 TB capacity 10GE and GE ports  Reduces the video service processing time. Throughput of a single node exceeds 1 GB/s, and that of the system exceeds 2 GB/s.  Makes system run properly with full redundancy, and keeps data safe.  Compatible with all devices and operating systems in complex service

• environments. Multiple service platforms improve the overall efficiency.

 Space and permission allocation is quick and simple. Periodic snapshot ensures data security.

30

Ottoman Archives of Turkey National Archives

 File servers are used on the live network to provide services for external

• applications. A file is restricted to 10 TB. LUNs of over 10 TB cannot be provided.

Performance and capacity are restricted and no remote data protection solution is provided.  The current system data needs to be migrated to implement NAS storage of unstructured data. A NAS system needs to be deployed at two sites respectively to implement bidirectional remote replication between the two sites.  Use the N8500 clustered NAS storage system to save unstructured data and provide the CIFS sharing service.  Configure remote replication for two NAS systems to implement remote protection of local data.  High security and reliability: Bidirectional remote replication enables backup protection of data at two sites. Physical hardware cooperation and end-to-end link redundancy ensure service continuity and data reliability.  Flexible expansion: I/O modules support flexible configuration, meeting service development requirements in the next five years.  Convergence and easy to use: Graphical management interface enables unified management of two NAS devices, improving O&M efficiency.

IP cable N8500 Remote replication IP-SAN NFS/CIFS Database LAN Application server N8500 WAN Ankara Istanbul

Customer requirements Solution Benefits

Ottoman archive center of Turkey National Archives saves a large amount

• f historical document data that is important materials for researching

Ottoman history. The HQ is located in Ankara, the capital city of Turkey. A branch is located in Istanbul. The archive center saves archive files of Turkey after 1920 and historical documents related to Muslim countries during the Ottoman Empire period.

31

Online Backup Company

Online Backup Company is Norwegian's largest online cloud backup and DR solution provider, servicing 40,000 global clients. As the main solution for OBC's new services and Europe expansion plans, Asigra and HUAWEI OceanStor N8000 series meet our specific requirements on storage. They can easily cope with backup, recovery, daily and weekly task management, and 32 self-healing processes." — OBC CTO Kent Vilhelmsen

WAN Large-sized enterprise customer Enterprise customer SMB customer N8000: back-end storage of the cloud backup system DC

Customer requirements Benefits

 A full solution to software and hardware for a new generation online backup and disaster recovery system  Centralized storage system with good security and feasibility  The back-end storage of a cloud backup system being able to provide high- performance processing, and expand with the rapid growth of services

Solution

 Centralized cloud backup storage solution in a DC, 1PB data capacity  Components: Combination of N8000 clustered NAS storage and cloud backup software Asigra NAS engines can be flexibly added, and back-end storage can be expanded with the growth of services. DST (file-based, fine granularity, accurate hotspot location)  Provides high-performance NAS solution, meeting concurrent access requirements.  The capacity is up to 15 PB, meeting long-term service growth and system expansion requirements (the system has been expanded for two times).  The centralized management improves the IT operating efficiency and reduces the investment.
