Use of Intra‐Seasonal and Seasonal Forecasts to Reduce Risk in Regional Public Water Supply Management

Chris Martinez University of Florida

Agricultural and Biological Engineering

Overview

• Project Partners
• Project Background & Goals
• Methods
• Results
• Lessons Learned
• Relevance

Funded by NOAA’s Climate Program Office SARP-Water program

Agricultural and Biological Engineering

Background

• Current sources:
• Groundwater (13 wellfields)
• Tampa Bypass Canal/Hillsborough River
• Alafia River
• C.W. Bill Young off‐stream reservoir
• Desalination Plant

1998 2008 2012

Percentage of Water by Source

100% 61% 11% 28% 45.5% 45.5% 9%

Groundwater Permit

192 MGD 158 MGD 121 MGD 90 MGD Pre‐1998 1998 2002 2008

(12-month moving average)

Agricultural and Biological Engineering

Source Allocation Decisions

• Multiple decision scales:
• Water year plan (6‐months prior)
• Month to month adjustments
• Operational decisions (weekly)
• Multiple constraints:
• Permitted groundwater (12‐month moving average)
• Minimum streamflows
• Streamflow extraction ratio (maintain Fluoride limit)
• Costs of different sources

Agricultural and Biological Engineering

Project Goals

• Integrate forecast information into decision making

– Multiple temporal scales – Relevant spatial scales – Integrate forecasts into suite of models used by Tampa Bay Water

• System‐wide Decision Support

– What is the system‐wide benefit/risk of adopting forecast information? – What is the reliability of the current system? – Value judgments under different scenarios?

Agricultural and Biological Engineering

Links Between Climate/Hydrologic Information and Decisions by Tampa Bay Water

Decision Required Information Climate/Hydrology

Set Prices and monthly Source Allocation for water-year Update water-year Allocations

Time-Scale

18 months in advance Monthly,

• ut to 12

months Operational Allocations Weekly,

• ut to 4

weeks

• Estimate of initial reservoir volume
• Scenarios of historical conditions
• Demand forecasts
• Precipitation and Streamflow

forecasts

• Precipitation, Streamflow and

Demand forecasts

Agricultural and Biological Engineering

“Typical” Water Year

• Estimate of end of year reservoir level needed for plan for next water year

Oct --- Nov --- Dec --- Jan --- Feb --- Mar --- Apr --- May --- Jun --- Jul --- Aug --- Sep

Reservoir Max Using Reservoir Filling Reservoir Reservoir Min Max Groundwater use Max Direct Surface Water use

• Greater than expected groundwater pumping impacts next water year plan
• Seasonal forecasts can be used to determine expected

higher/lower groundwater pumping in winter months

Agricultural and Biological Engineering

Different Products for Different Time‐ Scales

• Operational – Ensemble Precipitation,

Streamflow and Demand forecasts derived from medium‐range forecast products

• Monthly/Seasonal – Probabilistic Precipitation

and Streamflow/Withdrawal Climate‐based Forecasts

• Water‐Year – Decision Support, taking into

account previous and next 12 months

Agricultural and Biological Engineering

Operational Time‐scale

Current Forecast Historical Forecast Analogs Historical Observations (Stations or NARR)

• Forecast analogs using

the ESRL/PSD GFS Retrospective forecast archive

• 1‐15 day
• 2.5° x 2.5°
• 1979‐present
• Analog selection can be

tailored to need

Ensemble of Hydrologic Forecasts

• +/‐ 30 day search window
• 100 analog forecasts

http://www.esrl.noaa.gov/psd/forecasts/ reforecast/

Agricultural and Biological Engineering

Precipitation Forecast Skill

‐0.05 0.05 0.1 0.15 0.2 0.25 0.3 0.35 J F M A M J J A S O N D CRPSS

24‐hr 48‐hr 72‐hr 5‐day week‐1 week‐2

‐0.05 0.05 0.1 0.15 0.2 0.25 0.3 0.35 J F M A M J J A S O N D CRPSS

Day 1 Day 2 Day 3 Day 5 Day 7 0.2 0.4 0.6 0.8 1 1 2 3 4 5 6 Forecast Observation

F(x) x

[ ] dx

(x) F F(x) CRPS

2

• ∫

∞ ∞ −

− =

CRPSS: Continuous Ranked Probability Skill Score

Ref Forecast

CRPS CRPS 1 CRPSS − =

Agricultural and Biological Engineering

Monthly/Seasonal Time‐scale

• Forecast analogs using CFS retrospective

forecast archive http://cfs.ncep.noaa.gov/

– Week 2 – Monthly – Seasonal

• Climate‐based probability of exceedance

streamflow forecasts

Agricultural and Biological Engineering

Probability of Exceedance Streamflow Forecasts

Posterior probability of streamflow conditioned on predictor Streamflow Forecast Streamflow Exceedance Probability (%) Season Lagged Niñ03.4

Correlation of Streamflow w/ ENSO

Agricultural and Biological Engineering

Decision Support + Scenarios

• Inputs:

– Forecasted Demand – Forecasted Withdrawal

• Outputs:

– Optimized source‐water allocations based on preferences/constraints – End of year reservoir volume

Agricultural and Biological Engineering

Lessons Learned

• There is a learning curve associated with using

weather/climate datasets!!! (for hydrologists/engineers, at least…)

• Limited number of forecasted variables

archived in retrospective archives may limit usefulness

Agricultural and Biological Engineering

Relevance

• Tools/approaches that can easily be replicated

in other regions

– Analog forecasts – Exceedance streamflow forecasts
