SLIDE 1
UNIVERSAL ROBOTS RUC 2018
Universal Robots - Evolving the future
UNIVERSAL ROBOTS SET THE STANDARD…
Ø Fast Set-up Ø Flexible Deployment Ø Easy Programming Ø Safe
UNIVERSAL ROBOTS RUC 2018 Universal Robots - Evolving the future - - PowerPoint PPT Presentation
UNIVERSAL ROBOTS RUC 2018 Universal Robots - Evolving the future - - PowerPoint PPT Presentation
UNIVERSAL ROBOTS RUC 2018 Universal Robots - Evolving the future UNIVERSAL ROBOTS SET THE STANDARD Fast Set-up Flexible Deployment Easy Programming Safe UNIVERSAL ROBOTS SET THE STANDARD Fast setup Fast Set-up Flexible
SLIDE 2
SLIDE 3
Collaborative
Fast setup Flexible Easy to Program Safe
UNIVERSAL ROBOTS SET THE STANDARD…
Fast Set-up Flexible Deployment Easy Programming Safe
SLIDE 4
Collaborative
Fast setup Flexible Easy to Program Safe
…NOW WE’RE RAISING IT WITH e-SERIES
Faster Set-up More Flexible Deployment Easier Programming Safer
SLIDE 5
INTRODUCTING THE e-SERIES PLATFORM
A technologically advanced, modern hardware platform delivering collaborative innovations across a breadth of applications for years to come
SLIDE 6
SLIDE 7
THE FUTURE IS…
THE PLATFORM
SLIDE 8
e-Series PLATFORM TECHNOLOGY HIGHLIGHTS
- Force-Torque Sensor with
technology
- High-speed System Bus
- Modern Processors
- Advanced Tool Interface
- Full Cat. 3 Safety Architecture
SLIDE 9
IMPROVED TOOL CONNECTIVITY EASY-REPLACEABLE JOINTS NEW SCB WITH 20 DI, 16 DO ALL SW UPDATED VIA .URUP
e-Series AT A GLANCE
Serial comm. (UART RS-485) + 2A peak current Embedded motherboard 2-6 min to replace joints PolyScope, joints, screenboard, SCB
e-Series
Collaborative Fast setup Flexible Easy Program- ming
SLIDE 10
IMPROVED SENSITIVITY
e-Series
500Hz SYSTEM BUS
4x faster than CB3 Built-in F/T sensor Utilizing technology
Collaborative Fast setup Flexible Easy Program- ming
IMPROVED REPEATABILITY
+/- 0.03mm UR3e/UR5e +/- 0.05mm UR10e
REDUCED NOISE
10dBA reduction in audible noise
e-Series AT A GLANCE
SLIDE 11
HIGHER FLEXIBILITY FULL ISO 10218-1 Compliant ISO 13849-1, Cat. 3 PLd NEW UNIFORM BASE DESIGN 2 NEW SAFETY FUNCTIONS
Stopping time, stopping distance Certified by TÜV Nord Increases clearance from potential pinching hazards Wrist 2 extension
e-Series
NEW ELBOW SAFETY FUNCTIONS
Elbow force limiting, safety plane monitoring
TOOL SPHERE MONITORING
User defined tool spheres
e-Series AT A GLANCE
Collaborative Fast setup Flexible Easy Program- ming
SLIDE 12
NEW TEACH PENDANT OPTIMIZED PROGRAMMING FLOW
Easier navigation, fewer clicks Capacitive touch, wide screen 1200x800, low weight
e-Series
Collaborative Fast setup Flexible Easy Program- ming
e-Series AT A GLANCE
SLIDE 13
e-Series POLYSCOPE
New design with updated look and feel Improved programming flow Payload and CoG estimation wizard Feature plane teach-in wizard Elbow safety (force, speed, boundary restriction)
Key features
SLIDE 14
e-Series POLYSCOPE
New design with updated look and feel Improved programming flow Payload and CoG estimation wizard Feature plane teach-in wizard Elbow safety (force, speed, boundary restriction)
Key features
SLIDE 15
e-Series POLYSCOPE
New design with updated look and feel Improved programming flow Payload and CoG estimation wizard Feature plane teach-in wizard Elbow safety (force, speed, boundary restriction)
Key features
SLIDE 16
e-Series POLYSCOPE
New design with updated look and feel Improved programming flow Payload and CoG estimation wizard Feature plane teach-in wizard Elbow safety (force, speed, boundary restriction)
Key features
SLIDE 17
e-Series POLYSCOPE
New design with updated look and feel Improved programming flow Payload and CoG estimation wizard Feature plane teach-in wizard Elbow safety (force, speed, boundary restriction)
Key features
SLIDE 18
IMPROVED TOOL CONNECTIVITY HIGHER FLEXIBILITY IMPROVED SENSITIVITY
e-Series
FULL ISO 10218-1 Compliant ISO 13849-1, Cat. 3 PLd NEW UNIFORM BASE DESIGN EASY-REPLACEABLE JOINTS NEW TEACH PENDANT NEW SCB WITH 20 DI, 16 DO 2 NEW SAFETY FUNCTIONS 500Hz SYSTEM BUS OPTIMIZED PROGRAMMING FLOW ALL SW UPDATED VIA .URUP
e-SeriesAT A GLANCE
Stopping time, stopping distance Certified by TÜV 4x faster than CB3 Serial comm. (UART RS-485) + 2A peak current Built-in F/T sensor Utilizing technology Increases clearance from potential pinching hazards Wrist 2 extension Embedded motherboard 2-6 min to replace joints Easier navigation, fewer clicks Capacitive touch, wide screen 1200x800, low weight PolyScope, joints, screenboard, SCB
SLIDE 19
- Access more automation opportunities
- Force/torque sensor for finishing applications
and light-assembly applications
- Standardized technology platform completely
upgradeable via SW
- Challenging process and handling applications
that benefit from best-in-class repeatability
Kick down more doors with e-Series
SLIDE 20
- Eliminate Safety related objections
- Strictly compliant safety architecture
- Programmable robot stopping time and
stopping distance tools to
- Enhanced safety performance with elbow
joint monitoring and tool sphere monitoring
Kick down more doors with e-Series
SLIDE 21
- Simplify the bill of material and
eliminate time consuming end-of-arm tool cable routing
- Wrist joint tool serial interface and tool
power supply
- Standardize solutions across all three e-
Series models
- Uniform base height on UR3e / UR5e /
UR10e
Accelerate Integrations with e-Series
SLIDE 22
- Reduce time spent programming the
robot and performing risk assessments
- Streamlined programming flow
- Automatic payload configuration
Accelerate Integrations with e-Series
SLIDE 23
Transform ambitions into results by changing the way things are made
The e-Series PLATFORM
SLIDE 24
