▪ Overview of Mobile Industrial Robots ▪ Future Steps for Mobile Industrial Robots ▪ Products ▪ Safety & Certifications ▪ Questions and Comments

Overview

▪ MIR is a leading manufacturer of collaborative mobile robots ▪ MiR develops, manufactures and sells mobile robots for the professional market ▪ The purpose of the MiR robots is to automate in-house transportation ▪ The present markets are:

▪ Industry ▪ Healthcare

Market Demands

Flexibility Price & ROI Quality Ownership (saves on external and expensive support) User-friendly

The History of MiR

▪ First construction idea was made of LEGO bricks start 2011. ▪ The ”Alfa-version” was developed by the founder and co-owner Niels Jul Jacobsen in April 2012. ▪ Mobile Industrial Robots was established in May 2013 and commercial-wise the company started in October 2014. ▪ Thomas Visti entered the company as co-owner and holds the position as CEO from October 2014.

The Company Today

▪ We have installed robots in the manufacturing industry and healthcare sector. ▪ We have established partners all over the world. ▪ 40 employees – 17 recruited in 2016. ▪ Winner of several International Awards

Born Global

2015 - Denmark 2016 - USA 2017 - China, Germany, Spain, Singapore

Odense Dortmund Barcelona New York Shanghai Singapore

Distributors

95 distributors in 34 countries

References

Future Steps for Mobile Industrial Robots

Growth 2015-2018

€ - € 5.000,00 € 10.000,00 € 15.000,00 € 20.000,00 € 25.000,00 2015 2016 2017 2018

Turnover EUR (K)

20.000 10.000 3.400 670

(K)

Products

Tech Specs

▪ Payload: 100 kg – 220 lbs. ▪ Towing capacity (with MiRHook 200): 300 kg – 660 lbs. ▪ Precision: +/-50 mm - +/- 2” of position +/- 10 mm - +/- 0.4” to docking marker ▪ Max speed forwards: 1.5 m/s – 5.4 ft./s ▪ Max speed backwards: 0.3 m/s – 1 ft/s ▪ Battery run time: 10 hours or 20 km – 12.5 mi ▪ Weight: 62.5 kg – 138 lbs. ▪ Battery charging: 0-80%: 2 hours ▪ Communication: Wi-Fi, Bluetooth, Ethernet and PLC ▪ Safety: Complies with EN1525 safety regulations, SICK safety lasers, PLd cat. 3 ▪ CE certified: Yes

Tech Specs

▪ Payload: 200 kg – 440 lbs. ▪ Towing capacity (with MiRHook 200): 500 kg – 1102 lbs. ▪ Precision: +/-50 mm - +/- 2” from reference point +/- 10 mm - +/- 0.4” to docking marker ▪ Max speed forwards: 1.1 m/s – 3.6 ft./s ▪ Max speed backwards: 0.3 m/s – 1ft/s ▪ Battery run time: 10 hours or 15 km – 12.5 mi ▪ Weight: 62.5 kg – 138 lbs. ▪ Battery charging: 0-80%: 2 hours ▪ Communication: Wi-Fi, Bluetooth, Ethernet and PLC ▪ Safety: Complies with EN1525 safety regulations, SICK safety lasers, PLd cat. 3 ▪ ESD approved: Yes ▪ CE certified: Yes ▪ Clean Room certified: Yes

Benefits of MiR Robots

Very flexible: Easily re-mapped and taught new destinations and tasks Redeploy workers from pushing a cart to higher-value activities Fast ROI: Do not require any expensive installation and pay themselves off in less than a year Safe operation: Maneuver safely around people and obstacles, even in very dynamic environments

Increase productivity: go around obstacles and find the best path according to their internal map ensuring the material flow Support changing business needs: Redeploy easily to different processes or facility layouts Very user-friendly: Easy to control via a simple web interface that requires no prior programming experience Many applications: Can be redeployed for different tasks with various top modules

AMR vs. AGV

AMR AGV

Trackless, autonomous navigation Requires ”tracks” – e.g. magnetic stripes in the floor or wires Travels safely around people and obstacles Stops at any obstacle without possibility to change route Easy to expand/change work area Expensive and time consuming to expand/change work area Navigates dynamically using a map, allowing it to plan it’s own path Restricted to fixed routes

AMR – Autonomous (collaborative) Mobile Robot AGV – Automated Guided Vehicle

▪ Includes a VL Marker for accurate docking ▪ Laser guided into position

▪ Automated in-house transport solutions ▪ Automatic pick-up and drop-off of carts ▪ Towing Capacity of MiRHook 100: 300 kg – 661 lbs. ▪ Towing Capacity of MiRHook 200: 500 kg – 1100 lbs.

▪ Fleet Management for optimized robot traffic ▪ Automatic prioritization and selection of the robot best suited for a job, based on position and availability ▪ Planning of the use of different top modules ▪ Text message or e-mail notifications if obstacles prevent the robots from completing planned jobs

An Open Interface

Conveyor bands Customize your own top module Shelf lift ERP Integration Hook for towing carts Robot arms Safety units Your solution

A World of Opportunities

Click on the icons for application videos

Safety & Certifications

▪ SICK safety scanners S300

• ISO/EN 13849
• Category 3, Performance Level D

▪ 2 Scanners (S300) - 360 degrees coverage ▪ Dual channel encoders on each wheel

• Speed measurement
• Feedback to S300

▪ SICK Safety PLC and relays

• Cuts power to motors

▪ Conform to the EU Standard EN1525

MiR Safety System

CE Certified

Signed Declaration of Conformity (CE Certification) delivered with each robot

Sensory Input

Accelerometer and Gyroscope 4 Ultrasonic Sensors

Planning Algorithm

3D Camera 2 SICK S300 Scanners Dual Channel Encoders on each Wheel

Mechanical and Technical Components

Customized lighting colors and patterns Used for communicating actions to people

Light:

▪ Beep ▪ Horn ▪ MP3/WAV files

Sound:
