Preventing & Identifying Failures of Dead Break Elbows Wind Farm Applications 1 Introduction Brian Peyres, Senior High Voltage Reliability Engineer, EDP Renewables. Level 2 Thermographer with 20 Years in the generating and utility

slide-1
SLIDE 1

Preventing & Identifying Failures

  • f Dead Break Elbows

Wind Farm Applications

1

slide-2
SLIDE 2

Introduction

2

  • Brian Peyres,

Senior High Voltage Reliability Engineer, EDP Renewables.

  • Level 2 Thermographer with 20 Years in

the generating and utility industry.

slide-3
SLIDE 3

Introduction

3

  • Dead break elbows are commonly used by

utilities and wind energy generators.

slide-4
SLIDE 4

Introduction

4

  • Dead break style connections are a

reliable connection if installed and maintained correctly.

  • This presentation will highlight nearly 6

years of work investigating failures and developing preventative maintenance plans to eliminate termination failures.

slide-5
SLIDE 5

Wind Farm Collection Systems

5

  • 10-17 turbines with a generating capacity

up to 28 MW per circuit are typical.

slide-6
SLIDE 6

Wind Farm Collection Systems

6

  • Up to 165 high voltage terminations per

circuit.

slide-7
SLIDE 7

Wind Farm Collection Systems

7

  • Average of 1300 high voltage terminations

per 200MW wind farm.

slide-8
SLIDE 8

Faults

8

slide-9
SLIDE 9

Faults

9

slide-10
SLIDE 10

Faults

10

slide-11
SLIDE 11

Faults

11

slide-12
SLIDE 12

Faults

12

slide-13
SLIDE 13

Faults

13

slide-14
SLIDE 14

Faults

14

slide-15
SLIDE 15

Faults

15

  • At our peek we were losing on average

2% of our assets due to termination failures.

  • This means roughly 35 circuit failures per

year.

  • Considering generation losses, damaged

equipment and labor each circuit failure could result in nearly $ 80,000 in total losses.

slide-16
SLIDE 16

Maintenance

16

  • In early 2010 we began an aggressive

Infra-Red inspection approach.

  • The results of the IR scans were quite

alarming.

slide-17
SLIDE 17

The finds over the years

17

slide-18
SLIDE 18

The finds over the years

18

Damaged Stud and surface pitting

slide-19
SLIDE 19

The finds over the years

19

slide-20
SLIDE 20

The finds over the years

20

slide-21
SLIDE 21

The finds over the years

21

slide-22
SLIDE 22

The finds over the years

22

Screwdriver used during construction to twist and form cable termination into position.

slide-23
SLIDE 23

The finds over the years

23

Cross threaded stud resulting in metal shavings and poor connection.

slide-24
SLIDE 24

The finds over the years

24

End cap could be removed by hand when this unit was repaired.

slide-25
SLIDE 25

The finds over the years

25

slide-26
SLIDE 26

The finds over the years

26

slide-27
SLIDE 27

The finds over the years

27

Notice the anomaly at the back of the T body? Loose connection was found internal to the transformer under oil.

slide-28
SLIDE 28

Why?

28

  • 1. Connection not properly tightened.
  • a. Ensure termination is free of defects and

mating surfaces are parallel to each other.

  • b. Tighten the end plug as much as possible by

hand.

  • c. Tighten to 55 ft-lbs.
  • d. Check fitting by moving T-body front to back.
  • e. Torque again to 55 ft-lbs.
slide-29
SLIDE 29

Why?

29

  • 2. Contamination
  • a. Watch for metal shavings, caused by

the termination resting on the stud as it is placed into position.

slide-30
SLIDE 30

Why?

30

Metal shavings resulting in poor contact and damaged threads.

slide-31
SLIDE 31

Why?

31

  • 3. Environmental Stresses
  • a. Water collecting in the lower end of the

vault can freeze and add weight to the cable.

  • b. Thermal cycling is common on wind

farm equipment. This continuous thermal movement could have effects

  • n termination reliability.
slide-32
SLIDE 32

Why?

32

Support bar and cable clamps added to help mitigate movement and support weight.

slide-33
SLIDE 33

Why?

33

  • 4. Studs !

Watch out for imitations !

Studs supplied by transformer manufacturer.

Not uniform, various lengths and poorly machined.

Studs supplied by T-Body manufacturer.

Uniform in shape, same length.

slide-34
SLIDE 34

Why?

34

Shown here is a stud from the T-Body manufacturer

slide-35
SLIDE 35

Why?

35

A B C D E

Overall Flange Threads Origin "E" Diameter "A" Length "B" Length Depth "C" Bottom "D" Top T-Body Manf. 15.25 61 14.3 1.25 23.5 23.5 T-Body Manf. 15.25 61 14.3 1.25 23.5 23.5 T-Body Manf. 15.25 61 14.3 1.25 23.5 23.5 T-Body Manf. 15.25 61 14.3 1.25 23.5 23.5 Tranformer Manf. 15.5 63 10.25 1 26 26.75 Tranformer Manf. 15.25 63.5 10.5 1.25 26.5 26 Tranformer Manf. 16 65 10.25 1 28 26.75 Tranformer Manf. 15.25 63 10 1 26 27 Tranformer Manf. 15.25 66 9.75 1.5 29 26.5 Tranformer Manf. 15.5 63 8 1.25 29 26 Tranformer Manf. 15.5 63 9.5 1.5 27.5 26 Tranformer Manf. 16 62.5 10.5 0.9 25 27 Tranformer Manf. 16 63 10 1.5 27 26

Not a single stud supplied by the transformer manufacturer were machined to the same dimensions as the T-Body manufacturer.

slide-36
SLIDE 36

Why?

36

End of the stud at a wider diameter than the inner. Damaged or poorly machined studs will not fully seat, this will result in a false positive torque.

slide-37
SLIDE 37

What it should look like

37

slide-38
SLIDE 38

What it should look like

38

This area must be free

  • f debris, secure and

tight.

slide-39
SLIDE 39

Experiment Time!

39

15 minutes into 100amp test. Bare connector 44.2°C Shielded boot 26.9°C ΔT 17.3°C

This area must be free

  • f debris and secure

and tight.

slide-40
SLIDE 40

Experiment Time!

40

This area must be free

  • f debris and secure

and tight.

45 minutes into 100amp test. Bare connector 69.6°C Shielded boot 35.7°C ΔT 33.9°C

slide-41
SLIDE 41

Experiment Time!

41

This area must be free

  • f debris and secure

and tight.

75 minutes into 100amp test. Bare connector 72.3°C Shielded boot 40.9°C ΔT 38.4°C

slide-42
SLIDE 42

Experiment Time!

42

This area must be free

  • f debris and secure

and tight.

75 minutes into 100amp test. Bare connector 72.3°C Shielded boot 40.9°C ΔT 38.4°C Good rule of thumb, add a multiple of 1.8 to what you read outside to estimate what your generating inside.

slide-43
SLIDE 43

Why?

43

  • False positive torque or poor

craftsmanship =

slide-44
SLIDE 44

Questions?

44
