UNITHAI SHIPYARD PRESENTATION Introduction: The Unithai Group represents the Thai arm of the IMC Pan Asia Alliance Group, a regional organization with primary business interests in shipping, distribution, logistics, engineering and

slide-1
SLIDE 1

UNITHAI SHIPYARD PRESENTATION

slide-2
SLIDE 2

Introduction:

2

  • The Unithai Group represents the Thai arm of the IMC Pan Asia Alliance

Group, a regional organization with primary business interests in shipping, distribution, logistics, engineering and infrastructure development.

  • Unithai’s operations in Thailand include shipping services, a container

terminal, a logistics based distribution centre and the largest shipyard in Thailand (UTSE).

  • UTSE Incorporated in 1990 as a PLC and started operations in 1993
  • 3 main activities, supported by a centralized supporting function:

Shipyard Business Division (SBD) Marine Onshore & Offshore Service Division (MOS) Offshore Fabrication Division (OFD)

  • Our corporate mission is to create sustainability as the shipyard partner
  • f choice
  • UTSE exists to provide quality shiprepair, conversion, newbuilding,

services and onshore/offshore fabrications to customers worldwide. We work closely and in partnership with customers to determine their needs and to satisfy their requirements on time and at competitive costs

slide-3
SLIDE 3

UTSE Qualification:

3

slide-4
SLIDE 4

UTSE LOCATIONS:

4

Songkhla Leam Chabang

Operate in 2 Strategic Locations

  • Laem Chabang Yard
  • Workshop
  • Bonded Warehouse
  • Fabrication area
  • Load out jetty

Songkhla Yard

  • Warehouse
  • Workshop
  • Offshore tool / equipment
  • Supply base
  • Jetty
slide-5
SLIDE 5

UTSE Key Facilities:

5

Fabrication Area / Assemble Area

Total yard area 693,000 m2

1 2 3

Ship repair and conversion

Unithai JV Business (CUEL) Special Project Unithai Fabrication Business Marine Business

slide-6
SLIDE 6

SBD Key Facilities:

6 Repair Jetty 190 m. Workshop

Developing Quay 315 m. Depth 14 mtr Shore crane 30T

Floating Dock 2 13,500T Lifting Repair Quay 390 m. Floating Dock 3 48,000T Lifting

slide-7
SLIDE 7

SBD Key Facilities:

7

  • 2 Floating docks
  • 390 meters quay with 45 tonnes shore crane
  • Extension quaywall 315 mtr (under process)
  • 190 meters jetty/quay
  • 6-7 meters (MSL) water depth.
  • 100 tonnes floating crane
  • Painting booth for steel work
  • 7,500 sqm of covered workshops
  • 3,750 sqm mechanical, electrical
  • 3,750 sqm steelwork pre- fabrication

shop, equipped with optical plate profilers, overhead cranes (up to 32 tonnes), break press, bending rolls, automatic pipe benders & thin plating equipment Unithai 3 Unithai 2 Suphannica Chompoophukha Lifting cap. (tons) 48,000 13,500 LOA (m) 300 190 Breadth (m) 52 34.4 Docking Draft (m) 7.0 5.5

Repair Facilities

slide-8
SLIDE 8

SBD Activities:

8 Vessels

  • Container / Bulker / Tanker
  • Car carrier / Reefer
  • Cruise ship
  • Royal Thai Navy / US Navy
  • LPG
  • Dredger
  • Derrick Lay Barge
  • Air Craft carrier
  • Offshore Tender barge
  • Offshore tug

Services

  • Steel repair / Modification
  • Accommodation work
  • Tank coating / Hull coating
  • Machinery / piping / valves
  • Tail shaft work / CPP work
  • Engine overhaul
  • Cargo gear repairs and testing
  • Automation / Motor/ generator repair
  • Pneumatics / hydraulic / electronic.
  • Afloat Repair

Value

  • Reliable / Experience
  • Commitment / On time
  • Price competitive
  • Customer oriented
  • Available spare part
slide-9
SLIDE 9

SBD Activities:

9

  • Steel Repair/Renew
  • Full blasting and Silicon coating
  • Propulsion System Services
  • Main Engine Repair & Overhaul
  • Reconditioning Services
  • E & I, Navigation and Communication

Services

  • Boiler Services
  • Dynamic Balancing all parts
slide-10
SLIDE 10

SBD Activities: Ballast Water Management System (BWMS)

10

Ballast Water Management system

Makers in cooperation with Unithai

Maker BWMS Name Country Process Cappacity of approval Substance IMO Basic Approval Substance IMO Final Approval Approval of BWMS G8 (MEPC174(58)) Approval given by the Administration Alfa-Laval AB PureBallast Sweden Filtration + UV/T 250 - 3,000㎥/h Approved Approved Approved Optimarin AS Optimarin Ballast System Norway Filtration + UV 21 - 5,400㎥/h N/A N/A Approved JFE Engineering Corporation JFE BallastAce Japan Filtration + Chlorination + Cavitation 17.5 - 4,500㎥/h Approved Approved Approved TECHCROSS INC Electro-Cleen System Korea Electrolysis/Electroc hlorination 300㎥/h Approved Approved Approved Kuraray Co., Ltd. MICROFADE Japan Filter + Calcium hypochlorite 125 - 4,000㎥/h Approved Approved Approved MIURA Co., Ltd. Miura BWMS Japan Filter＋UV 200 - 6000 ㎥/h N/A N/A Approved SUNRUI BalClor China Filtration/Electrolysis 170 , 8,500 ㎥/h Approved

slide-11
SLIDE 11

Ship Repair Customer:

11

slide-12
SLIDE 12

MOS: Facilities and Service Activities

12 Range of Services

  • Engineering Services / 3D Scan camera
  • Brownfield Maintenance Project
  • Brownfield Modification / Upgrading Project
  • Manpower Supply
  • Equipment Supply
  • NDT
  • Scaffolding
  • ASME Tank repair (U, U2, R stamp)
  • Supply Base / Warehouse
  • Services

Songkhla’s Yard Facilities

  • Total area 6,666 M2
  • Jetty 1 length 60 m
  • Jetty 2 length 30 m
  • Water dept4.5 m
  • Docking area2,900 m2
  • Accommodate 12 vessel/ time
  • Warehouse800 m2
  • Storage area 900 m2
  • Work shop 350 m2
slide-13
SLIDE 13

MOS: Facilities and Service Activities

13

slide-14
SLIDE 14

MOS: Selected Service Record

14

Project : Produced Water Debottlenecking Location : Bualuang Field Platform : “A” & “B” PW DBN Owner: OPHIR Work Scope: epC

  • New equipment installation
  • Pipe
  • Electrical & Instrument
  • Scaffolding

Name : FPSO Rubicon Vantage Built : 1987 LOA - 230.18m LBP - 223.00m Breadth - 32.40m GRT - 45,150 Tons Refurbishment Oct 2014 - Mar 2015 Refurbishment Oct 2014 - Mar 2015 Works Scope

  • Major Refurbishment works

– hull structures, – machinery, – Electrical – navigational eqpt., – surface treatment, – etc.

  • Bow & Forecastle Deck

modifications

  • Metering Skid Installation &

Integration works

slide-15
SLIDE 15

MOS: Selected Service Record

15

US Navy Project : Voyarge Service (VR) period for Maintenance and Service Esso Refinery Tank Repair & Maintenance Pipe Valve and Structure Repair & Maintenance

slide-16
SLIDE 16

OFD Business:

16 OFD Capabilities

  • Engineering / Procurement
  • Construction /Quality control
  • Pre-Commissioning
  • Manpower up to 8 million manhr per annum
  • 20,000 Tons per annum

OFD Business includes

  • PAR / PAU
  • Skids Modules
  • Offshore Structure
  • Wind Farm Structure
  • Prefabrication Work
  • Cryogenic/LNG Tank

OFD, specializes in the fabrication of steelwork for a wide range of markets and applications. Serving customers on the worldwide basis, activities undertaken include engineering, shop drawing, material supply, fabrication, painting and erection (where required) of steel structures for infrastructure development, power generation, industrial buildings, and offshore structures

slide-17
SLIDE 17

OFD: Facilities

17

slide-18
SLIDE 18

OFD: Facilities

18 Workshop 1 Workshop 2 Workshop 3 Workshop 4

slide-19
SLIDE 19

OFD: Products:

19 PAR / PAU Offshore Construction Windfarm Structure Prefabrication Work Cryogenic/LNG Tank

slide-20
SLIDE 20

OFD: Load out Capacity

20

  • Load – out Jetty no.1: 30 m wide for 4,500 T integrated components.
  • Load – out Jetty no.2: 30 m wide for 7,500 T integrated components.
  • Load – out Jetty no.3: Vessel LOA 100 m – 300 m.
  • Ground Load:

10 Ton / Sq.m. (Tested up to 30 T / Sq.m.)

  • Water Depth:

Minimum water at low tide is 5.5 – 6.0 m. and normal tide variation is 2.32 m.

  • SPMT:

Maximum Wheel load of SPMT is 36 T / 2.4 m. = 14 T / m Bulk head jetty design capacity is 18.2 T / m
