Understanding and Visualizing Data Iteration in Machine Learning Fred Hohman , Georgia T ech, @fredhohman Kanit Wongsuphasawat , Apple, @kanitw Mary Beth Kery , Carnegie Mellon University, @mbkery Kayur Patel , Apple, @foil

slide-1

SLIDE 1

Fred Hohman, Georgia T ech, @fredhohman Kanit Wongsuphasawat, Apple, @kanitw Mary Beth Kery, Carnegie Mellon University, @mbkery Kayur Patel, Apple, @foil

Understanding and Visualizing Data Iteration in Machine Learning

slide-2

SLIDE 2

Test accuracy: 0.81

Convolutional Neural Network on MNIST

https://github.com/keras-team/keras/blob/master/examples/mnist_cnn.py

slide-3

SLIDE 3

How to improve performance? Convolutional Neural Network on MNIST

https://github.com/keras-team/keras/blob/master/examples/mnist_cnn.py

Test accuracy: 0.81

slide-4

SLIDE 4

A. Different architecture

How to improve performance? Convolutional Neural Network on MNIST

https://github.com/keras-team/keras/blob/master/examples/mnist_cnn.py

Test accuracy: 0.81

slide-5

SLIDE 5

A. Different architecture
B. Tweak hyperparameter

How to improve performance? Convolutional Neural Network on MNIST

https://github.com/keras-team/keras/blob/master/examples/mnist_cnn.py

Test accuracy: 0.81

slide-6

SLIDE 6

C. Adjust loss function
A. Different architecture
B. Tweak hyperparameter

How to improve performance? Convolutional Neural Network on MNIST

https://github.com/keras-team/keras/blob/master/examples/mnist_cnn.py

Test accuracy: 0.81

slide-7

SLIDE 7

C. Adjust loss function
A. Different architecture
B. Tweak hyperparameter
D. Get an ML PhD

How to improve performance? Convolutional Neural Network on MNIST

https://github.com/keras-team/keras/blob/master/examples/mnist_cnn.py

Test accuracy: 0.81

slide-8

SLIDE 8

C. Adjust loss function
A. Different architecture
B. Tweak hyperparameter
D. Get an ML PhD

Add more data!

How to improve performance? Convolutional Neural Network on MNIST

https://github.com/keras-team/keras/blob/master/examples/mnist_cnn.py

Test accuracy: 0.81

slide-9

SLIDE 9

https://github.com/keras-team/keras/blob/master/examples/mnist_cnn.py

Test accuracy: 0.81 Test accuracy: 0.99✓

Add 10x data

https://github.com/keras-team/keras/blob/master/examples/mnist_cnn.py

slide-10

SLIDE 10

6

https://twitter.com/karpathy/status/1231378194948706306

slide-11

SLIDE 11

7

“clean and grow the training set” “repeated this process until accuracy improved enough”

https://twitter.com/karpathy/status/1231378194948706306

slide-12

SLIDE 12

8

“clean and grow the training set” “repeated this process until accuracy improved enough”

https://twitter.com/karpathy/status/1231378194948706306

This is a data iteration!

slide-13

SLIDE 13

World Data Model Data Iteration Model Iteration

slide-14

SLIDE 14

World Data Model Data Iteration Model Iteration

slide-15

SLIDE 15

World Data Model Data Iteration Model Iteration

slide-16

SLIDE 16

Contributions

Identify common data iterations

and challenges through practitioner interviews at Apple

CHAMELEON: Interactive

visualization for data iteration

Case studies on real datasets

Understanding and Visualization Data Iteration

slide-17

SLIDE 17

Participant Information Interviews to Understand Data Iteration Practice

Semi-structured interviews with ML

researchers, engineers, and managers at Apple

23 practitioners across 13 teams

Domain Specialization # of people Computer vision Large-scale classification,

bject detection, video

analysis, visual search 8 Natural language processing Text classification, question answering, language understanding 8 Applied ML + Systems Platform and infrastructure, crowdsourcing, annotation, deployment 5 Senors Activity recognition 1

slide-18

SLIDE 18

“Most of the time, we improve performance more by adding additional data or cleaning data rather than changing the model [code].”

— Applied ML practitioner in computer vision

slide-19

SLIDE 19

Findings Summary Interviews to Understand Data Iteration Practice

Entangled Iterations

Separate model and data

iterations to ensure fair comparisons Data Iteration Frequency

Models: monthly → daily
Data: monthly → per minute

Why do Data Iteration?

Data improves performance
Data boostraps modeling
The world changes, so must

your data

slide-20

SLIDE 20

Common Data Iterations Interviews to Understand Data Iteration Practice

Gather more data randomly sampled from population

+ Add sampled instances

Gather more data randomly sampled from population

+ Add specific instances

Gather more data intentionally for specific label or feature range

+ Add synthetic instances

Gather more data by creating synthetic data or augmenting existing data

+ Add labels

Add and enrich instance annotations

Remove instances

Remove noisy and erroneous outliers

~ Modify features, labels

Clean, edit, or fix data

slide-21

SLIDE 21

Challenges of Data Iteration Interviews to Understand Data Iteration Practice

Tracking experimental and iteration history
Manual failure case analysis
Building data blacklists
When to “unfreeze” data versions
When to stop collecting data

slide-22

SLIDE 22

CHAMELEON

Retroactively track and

explore data iterations and metrics over versions

Attribute model metric

change to data iterations

Understand model sensitivity
ver data versions

Understanding and Visualization Data Iteration

slide-23

SLIDE 23

CHAMELEON

Compare feature distributions by:

Training and testing splits
Performance (e.g., correct v.

incorrect predictions)

Data versions

Understanding and Visualization Data Iteration

Count Binned feature Incorrect Correct

“Overlaid diverging histogram” per feature

slide-24

SLIDE 24

CHAMELEON Visualizations

correct instances: incorrect instances: total instances: accuracy: 154 60 214 0.720

Aggregated Embedding Prediction Change Matrix Sensitivity Histogram

slide-25

SLIDE 25

Demo

slide-26

SLIDE 26

Demo

slide-27

SLIDE 27

Case Study I

Visualization challenges prior data collection beliefs
Finding failure cases
Interface utility

400 2,000 4,000 2,000 ,000 ,000 0,000 ,000 200

1.1 1.5 1.9 1.13 1.18

A feature’s long-tailed, multi-modal distribution shape solidifies over collection time: 1,442 → 64,205 instances

64,502 instances
Collected over 2 months
20 features

Sensor Prediction

slide-28

SLIDE 28

Learning from Logs Case Study II

Inspecting performance across features
Capturing data processing changes
Encouraging instance-level analysis

Filter Filter

correct instances: incorrect instances: total instances: accuracy: 125 12 137 0.912

48,000 instances
Collected over 6 months
34 features

Filtering across features quickly finds data subsets to compare against global distributions

slide-29

SLIDE 29

Opportunities for Future ML Iteration Tools

slide-30

SLIDE 30

Opportunities for Future ML Iteration Tools

Interfaces for both data and model iteration

slide-31

SLIDE 31

Opportunities for Future ML Iteration Tools

Interfaces for both data and model iteration
Data iteration tooling to help experimental handoff

slide-32

SLIDE 32

Opportunities for Future ML Iteration Tools

Interfaces for both data and model iteration
Data iteration tooling to help experimental handoff
Data as a shared connection across user expertise

slide-33

SLIDE 33

Opportunities for Future ML Iteration Tools

Interfaces for both data and model iteration
Data iteration tooling to help experimental handoff
Data as a shared connection across user expertise
Visualizing probabilistic labels from data programming

slide-34

SLIDE 34

Opportunities for Future ML Iteration Tools

Interfaces for both data and model iteration
Data iteration tooling to help experimental handoff
Data as a shared connection across user expertise
Visualizing probabilistic labels from data programming
Visualizations for other data types

slide-35

SLIDE 35

Fred Hohman, Georgia T ech, @fredhohman Kanit Wongsuphasawat, Apple, @kanitw Mary Beth Kery, Carnegie Mellon University, @mbkery Kayur Patel, Apple, @foil

Understanding and Visualizing Data Iteration in Machine Learning

fredhohman.com/papers/chameleon
