Turbocharge your MySQL analytics with ElasticSearch

Guillaume Lefranc Data & Infrastructure Architect, Productsup GmbH Percona Live Europe 2017

About the Speaker Guillaume Lefranc

• Data Architect at Productsup
• Replication Manager for MySQL and

MariaDB - Lead Architect

• DBA Manager at MariaDB Corporation
• Infrastructure Consultant at Coinigy
• DB Architect at dailymotion.com

Takeaways In this presentation, we will speak about:

• How Elasticsearch works as a document and column store
• What are its strengths and weaknesses when it comes to analytics
• How to sync data with MySQL
• How to build aggregations

Case study Disclaimer: This case study is about medium data, not big data

Case study Disclaimer: This case study is about medium data, not big data What is medium data?

Case study Disclaimer: This case study is about medium data, not big data What is medium data? Answer: from 100GB to a few TBs

Case study Disclaimer: This case study is about medium data, not big data What is medium data? Answer: from 100GB to a few TBs Types of data:

• User activity (Clicks)

Case study Disclaimer: This case study is about medium data, not big data What is medium data? Answer: from 100GB to a few TBs Types of data:

• User activity (Clicks)
• Market Data

Case study Disclaimer: This case study is about medium data, not big data What is medium data? Answer: from 100GB to a few TBs Types of data:

• User activity (Clicks)
• Market Data
• Trips

Use Cases Business cases:

• A ride-sharing app

Example dataset: NYC Taxi Data (6 months: 78 million trips)

Use Cases Business cases:

• A ride-sharing app

Example dataset: NYC Taxi Data (6 months: 78 million trips)

• Cryptocurrency market data

200 million documents per month - Courtesy of coinigy.com

MySQL and Medium Data

• Medium data can scale well in MySQL (SELECT … WHERE id = ?)

MySQL and Medium Data

• Medium data can scale well in MySQL (SELECT … WHERE id = ?)
• … not with Analytics

MySQL and Medium Data

• Medium data can scale well in MySQL (SELECT … WHERE id = ?)
• … not with Analytics
• Every case cannot be covered by an index

MySQL and Medium Data

• Medium data can scale well in MySQL (SELECT … WHERE id = ?)
• … not with Analytics
• Every case cannot be covered by an index
• Aggregations can be slow, especially if doing table scans

Elasticsearch - What?

• “You know, for Search” -> Inverted Index

Elasticsearch - What?

• “You know, for Search” -> Inverted Index
• Document Store

Elasticsearch - What?

• “You know, for Search” -> Inverted Index
• Document Store
• REST API

○ POST /market_data -d ‘{ "market": "BTC/USD", value: “3418.03953” }

Elasticsearch - What?

• “You know, for Search” -> Inverted Index
• Document Store
• REST API

○ POST /market_data -d ‘{ "market": "BTC/USD", value: “3418.03953” }

• JSON Native

Elasticsearch - Anatomy of a Document

{ "_index" : "raw-2016-07", "_type" : "market_raw", "_id" : "108051174765", "_score" : 7.455347, "_source" : { "quantity" : 0.64130859, "time_local" : "2016-07-12 06:45:34", "type" : "SELL", "market" : "USD/BTC", "total" : 414.52263332, "@timestamp" : "2016-07-12T06:45:34.000Z", "price" : 646.37, "exchange" : "BITS", "id" : 108051174765, "tradeid" : "11649948" }

Elasticsearch - Why?

• Distributed

Elasticsearch - Why?

• Distributed
• Fault Tolerant

Elasticsearch - Why?

• Distributed
• Fault Tolerant
• Scales Horizontally

Elasticsearch - Why?

• Distributed
• Fault Tolerant
• Scales Horizontally

Elasticsearch - Column Store

• All fields are indexed by default

Elasticsearch - Column Store

• All fields are indexed by default
• Query is (almost) always an index scan

Elasticsearch - Column Store

• All fields are indexed by default
• Query is (almost) always an index scan
• Doc values

○ Field values serialized on disk ○ Not stored in the JVM Heap: OS cache reliant ○ Compression ○ By default: all numerics, geo_points, dates, IPs and not_analyzed strings (keywords)

Elasticsearch - Column Store

• All fields are indexed by default
• Query is (almost) always an index scan
• Doc values

○ Field values serialized on disk ○ Not stored in the JVM Heap: OS cache reliant ○ Compression ○ By default: all numerics, geo_points, dates, IPs and not_analyzed strings (keywords)

• Not a general purpose column-store replacement

Elasticsearch - Column Store

• All fields are indexed by default
• Query is (almost) always an index scan
• Doc values

○ Field values serialized on disk ○ Not stored in the JVM Heap: OS cache reliant ○ Compression ○ By default: all numerics, geo_points, dates, IPs and not_analyzed strings (keywords)

• Not a general purpose column-store replacement
• Not exactly fast as a document DB

Bibliography:

• https://www.elastic.co/blog/elasticsearch-as-a-column-store
• https://www.elastic.co/guide/en/elasticsearch/guide/current/_deep_dive_on_doc_values.html

Alternatives (Open Source)

• MariaDB Columnstore
• Yandex Clickhouse
• Apache Spark

Bibliography: https://www.percona.com/blog/2017/03/17/column-store-database-benchmarks-mariadb-columnstore-vs

• clickhouse-vs-apache-spark/

MySQL Analytics: Performance Fast if data is in the index Very slow if linear scans have to be used Example: SELECT DATE(pickup_datetime) AS date, SUM(total_amount) AS earnings FROM trips WHERE driver_id=102 GROUP BY date ORDER BY pickup_datetime DESC;

• > returns in milliseconds

SELECT DATE(pickup_datetime) AS date, SUM(total_amount) AS earnings FROM trips GROUP BY date ORDER BY pickup_datetime DESC;

• > 4 minutes

Importing data: Logstash

• Logstash is an open source data collection engine with real-time pipelining capabilities.
• The L in ELK Stack
• ETL for ElasticSearch
• Pipeline model (input -> filter -> output)

Importing data - Input

input { jdbc { jdbc_driver_library => "/usr/share/java/mysql-connector-java.jar" jdbc_driver_class => "com.mysql.jdbc.Driver" jdbc_connection_string => "jdbc:mysql://db1:3306/taxi_platform?useCursorFetch=true" jdbc_user => "root" jdbc_password => "admin" jdbc_fetch_size => 100000 statement => "SELECT id, driver_id, passenger_id, pickup_datetime, dropoff_datetime, CONCAT(pickup_latitude, ',', pickup_longitude) AS pickup_location, CONCAT(dropoff_latitude,',', dropoff_longitude) AS dropoff_location, payment_type, total_amount from trips WHERE id > :sql_last_value" use_column_value => true tracking_column => id #schedule => "*/5 * * * *" }

Importing data - Input

• Dealing with large result sets

jdbc_connection_string => "jdbc:mysql://db1:3306/taxi_platform?useCursorFetch=true" jdbc_fetch_size => 10000

• SQL Last Value

use_column_value => true tracking_column => id statement => "SELECT … WHERE id > :sql_last_value"

• Scheduler

schedule => "*/5 * * * *"

Reference: https://www.elastic.co/guide/en/logstash/current/plugins-inputs-jdbc.html

Importing Data - Filters Filters (Input Transformation) filter { mutate { convert => [ "pickup_datetime", "string" ] } date { match => [ "pickup_datetime", "ISO8601" ] } }

• Date field is used by partitioning, if there is no suitable field, Elasticsearch will use the current date and

time

Importing Data - Output

• utput {

elasticsearch { hosts => [ "es1:9200" ] user => "elastic" password => "elasticpassword" index => "taxi-%{+YYYY-MM}" document_type => "trips" document_id => "%{id}" } }

Importing Data - Output

• Document partitioning

index => "taxi-%{+YYYY-MM}"

• Matching ID with MySQL

document_id => "%{id}"

Schema Design - Indexes

• Document Partitioning
• ElasticSearch Types
• Number of Indices
• Number of Shards
• Replication Factor

Schema Design - Indexes

PUT /taxi { "settings" : { "index" : { "number_of_shards" : 5, "number_of_replicas" : 1 } } } PUT _template/template1 { “template”: “taxi*”, “settings”: {

Schema Design - Mapping

• Indexing with the optimal type
• Avoiding Full Text Search indexing (aka text or “analyzed”)
• Type overview

○ keyword ○ long ○ byte ○ date ○ geo_point ○ scaled_float

Schema Design - Mapping

{ "mappings": { "trips": { "properties": { "id": { "type": "long" }, "driver_id": { "type": "long" }, "passenger_id": { "type": "long" }, "pickup_datetime": { "type": "date" }, "dropoff_datetime": { "type": "date" }, "passenger_count": { "type": "byte" }, "pickup_location": { "type": "geo_point" }, "dropoff_location": { "type": "geo_point" }, "payment_type": { "type" : "byte" }, "total_amount": { "type": "scaled_float", "scaling_factor": 100 } } } } }

Query Design - Aggregation High Level concepts:

• Buckets

○ driver name, passenger name, location ○ currency exchange (bitstamp, coinbase, etc) ○ Can be nested

• Metrics

○ count ○ pricing sum, avg, max, min, etc SELECT metric FROM index GROUP BY bucket

Building an aggregation, step by step Drivers’ average earning per day with customers using Credit Cards as a filter

• Search component: payment_type:1
• Bucket terms aggregation (driver name or id)
• Bucket date histogram aggregation (per day, month, specific interval, etc)
• Metric average aggregation

Query design - The search component

• Aggregations can be filtered by search
• Multiple indexes can be hit using regular expressions

GET /taxi-*/_search?q=payment_type:1

• Up to complex searches

GET /taxi-2016-01/_search?q=+pickup_datetime:2016-01-09 +total_amount:>60&size=10000'

Query Design - The Terms bucket The Terms bucket { "size": 0, <- do not return documents "aggs": { <- define aggregation "drivers": { <- canonical agg name "terms": { <- agg type "field": "driver_id" <- agg argument (and options) } } } }

Query Design - The date histogram bucket "aggs": { "drivers": { "terms": { "field": "driver_id" }, "aggs": { "by_day": { "date_histogram": { "field": "pickup_datetime", "interval": "day" },

Query design - Metric aggregation "aggs": { "by_day": { "date_histogram": { "field": "pickup_datetime", "interval": "day" }, "aggs": { "avg_earning": { "avg": { "field": "total_amount" } } } }

Query Results Obviously too long to show here! General info comes first: { "took" : 1804, <- 1804ms execution time "timed_out" : false, "_shards" : { "total" : 30, <- number of shards parsed "successful" : 30, "failed" : 0 }, "hits" : { "total" : 46066859 <- number of parsed documents }

Query Results - Example aggregation result { "key" : "Shay Banon", "doc_count" : 5476, "by_day" : { "buckets" : [ { "key_as_string" : "2017-01-01 00:00:00", "doc_count" : 152, "avg_earning" : { "value" : 11.11 } },

Query filtering - Filtering by location "filter": { "geo_polygon": { "pickup_location": { "points": [ {"lat": -74.04, "lon": 40.56}, {"lat": -74.04, "lon": 40.74}, {"lat": -73.83, "lon": 40.74}, {"lat": -73.83, "lon": 40.57} ] } } }

Going further - Bucket aggregations

Adjacency Matrix Aggregation Children Aggregation Date Histogram Aggregation Date Range Aggregation Diversified Sampler Aggregation Filter Aggregation Filters Aggregation Geo Distance Aggregation GeoHash grid Aggregation Global Aggregation Histogram Aggregation IP Range Aggregation Missing Aggregation Nested Aggregation Range Aggregation Reverse nested Aggregation Sampler Aggregation Significant Terms Aggregation Terms Aggregation

Going Further - Metric Aggregations

Avg Aggregation Cardinality Aggregation Extended Stats Aggregation Geo Bounds Aggregation Geo Centroid Aggregation Max Aggregation Min Aggregation Percentiles Aggregation Percentile Ranks Aggregation Scripted Metric Aggregation Stats Aggregation Sum Aggregation Top hits Aggregation Value Count Aggregation

Going Further - Kibana Build cool dashboards with your aggregations
