Database System Architecture

Index Structures

Hector Garcia-Molina Stijn Vansummeren

Index structure

• Any data structure that takes as

input a search key and efficiently returns the collection of matching records

Sequential File 20 10 40 30 60 50 80 70 100 90

Sequential File 20 10 40 30 60 50 80 70 100 90 Dense Index

10 20 30 40 50 60 70 80 90 100 110 120

Sequential File 20 10 40 30 60 50 80 70 100 90 Sparse Index

10 30 50 70 90 110 130 150 170 190 210 230

Sequential File 20 10 40 30 60 50 80 70 100 90 Sparse 2nd level

10 30 50 70 90 110 130 150 170 190 210 230 10 90 170 250 330 410 490 570

Question:

• Can we build a dense, 2nd level

index for a dense index?

Sparse vs. Dense Tradeoff

• Sparse: Less index space per record

can keep more of index in memory

• Dense: Can tell if any record exists

without accessing file

(Later:

– sparse better for insertions – dense needed for secondary indexes)

Next:

• Duplicate keys
• Deletion/Insertion
• Secondary indexes

Duplicate keys

10 10 20 10 30 20 30 30 45 40

10 10 20 10 30 20 30 30 45 40

10 10 10 20 20 30 30 30

10 10 20 10 30 20 30 30 45 40

10 10 10 20 20 30 30 30

Dense index, one way to implement? Duplicate keys

10 10 20 10 30 20 30 30 45 40

10 20 30 40

Dense index, better way? Duplicate keys

10 10 20 10 30 20 30 30 45 40

10 10 20 30

Sparse index, one way? Duplicate keys

careful if looking for 20 or 30!

10 10 20 10 30 20 30 30 45 40

10 20 30 30

Sparse index, another way? Duplicate keys

place first new key from block

Deletion from sparse index

20 10 40 30 60 50 80 70

10 30 50 70 90 110 130 150

Deletion from sparse index

20 10 40 30 60 50 80 70

10 30 50 70 90 110 130 150

• delete record 40

Deletion from sparse index

20 10 40 30 60 50 80 70

10 30 50 70 90 110 130 150

• delete record 30

40 40

Deletion from sparse index

20 10 40 30 60 50 80 70

10 30 50 70 90 110 130 150

• delete records 30 & 40

50 70

Deletion from dense index

20 10 40 30 60 50 80 70

10 20 30 40 50 60 70 80

Deletion from dense index

20 10 40 30 60 50 80 70

10 20 30 40 50 60 70 80

• delete record 30

40 40

Insertion, sparse index case

20 10 30 50 40 60

10 30 40 60

Insertion, sparse index case

20 10 30 50 40 60

10 30 40 60

• insert record 34

34

• ur lucky day!

we have free space where we need it!

Insertion, sparse index case

20 10 30 50 40 60

10 30 40 60

• insert record 15

15 20 30 20

• Illustrated: Immediate

reorganization

• Variation:
• insert new block (chained file)
• update index

Insertion, sparse index case

20 10 30 50 40 60

10 30 40 60

• insert record 25

25

• verflow blocks

(reorganize later...)

Insertion, dense index case

• Similar
• Often more expensive . . .

Secondary indexes

Sequence field

50 30 70 20 40 80 10 100 60 90

Secondary indexes

Sequence field

50 30 70 20 40 80 10 100 60 90

• Sparse index

30 20 80 100 90 ...

does not make sense!

Secondary indexes

Sequence field

50 30 70 20 40 80 10 100 60 90

• Dense index

10 20 30 40 50 60 70 ... 10 50 90 ...

sparse high level

With secondary indexes:

• Lowest level is dense
• Other levels are sparse

Also: Pointers are record pointers

(not block pointers; not computed)

Duplicate values & secondary indexes

10 20 40 20 40 10 40 10 40 30

Duplicate values & secondary indexes

10 20 40 20 40 10 40 10 40 30

10 10 10 20 20 30 40 40 40 40 ...

• ne option...

Problem: excess overhead!

• disk space
• search time

Duplicate values & secondary indexes

10 20 40 20 40 10 40 10 40 30

10

another option...

40 30 20

Problem: variable size records in index!

Duplicate values & secondary indexes

10 20 40 20 40 10 40 10 40 30

10 20 30 40 50 60 ...

buckets

Why “bucket” idea is useful

Indexes Records Name: primary EMP(name,dept,floor,...) Dept: secondary Floor: secondary

Query: Get employees in (Toy Dept) ^ (2nd floor)

• Dept. index

EMP Floor index Toy 2nd

→ Intersect toy bucket and 2nd Floor bucket to get set of matching EMP’s

This idea used in text information retrieval

Document s

...the cat is fat ... ...was raining cats and dogs... ...Fido the dog ... Inverted lists cat dog

IR QUERIES

• Find articles with “cat” and “dog”
• Find articles with “cat” or “dog”
• Find articles with “cat” and not

“dog”

• Find articles with “cat” in title
• Find articles with “cat” and “dog”

within 5 words

Summary so far

• Conventional index

– Basic Ideas: sparse, dense, multi- level… – Duplicate Keys – Deletion/Insertion – Secondary indexes

– Buckets of Postings List

Outline/summary

• Conventional Indexes
• Sparse vs. dense
• Primary vs. secondary
• B trees
• -> Next
• B+trees vs. indexed sequential
• Hashing schemes

Conventional indexes

Advantage:

• Simple
• Index is sequential file

good for scans Disadvantage:

• Inserts expensive, and/or
• Lose sequentiality & balance

Example Index (sequential)

continuous free space 10 20 30 40 50 60 70 80 90 39 31 35 36 32 38 34 33

• verflow area

(not sequential)

• NEXT: Another type of index

– Give up on sequentiality of index – Try to get “balance”

Root

B+Tree Example n=3

100 120 150 180 30 3 5 11 30 35 100 101 110 120 130 150 156 179 180 200

Sample non-leaf

to keys to keys to keys to keys < 57 57≤ k<81 81≤k<95 ≥95 57 81 95

Sample leaf node:

From non-leaf node to next leaf in sequence 57 81 95

To record with key 57 To record with key 81 To record with key 85

In textbook’s notation n=3

Leaf: Non-leaf:

30 35 30 30 35 30

Lookup record(s) with key = 35 n=3

Root

100 120 150 180 30 3 5 11 30 35 100 101 110 120 130 150 156 179 180 200

Lookup record(s) with key = 40 n=3

Root

100 120 150 180 30 3 5 11 30 35 100 101 110 120 130 150 156 179 180 200

Range query: lookup record(s) with 35 <= key <= 150 n=3

Root

100 120 150 180 30 3 5 11 30 35 100 101 110 120 130 150 156 179 180 200

• The I/O cost of a lookup in a BTree is

equal to longest path of the root to a leaf

• Hence, the goal is to keep this longest

path as short as possible

• In particular: we want all leafs to be at

the same depth in the tree (and hence want a balanced tree)

Size of nodes: n+1 pointers n keys

(fixed)

Don’t want nodes to be too empty

• Use at least

Non-leaf: (n+1)/2 pointers Leaf : (n+1)/2 pointers to data

Full node min. node Non-leaf Leaf

n=3

120 150 180 30 3 5 11 30 35

counts even if null

B+tree rules tree of order d

(1) All leaves at same lowest level (balanced tree) (2) Pointers in leaves point to records except for “sequence pointer”

(3) Number of pointers/keys for B+tree

Non-leaf (non-root) n+1 n (n+1)/2 (n+1)/2- 1 Leaf (non-root) n+1 n Root n+1 n 2 1 Max Max Min Min ptrs keys ptrs→data keys (n+1)/2

(n+1)/2

Insert into B+tree

(a) simple case

– space available in leaf

(b) leaf overflow (c) non-leaf overflow (d) new root

(a) Insert key = 32

n=3

3 5 11 30 31 30 100 32

(a) Insert key = 7

n=3

3 5 11 30 31 30 100 3 5 7 7

(c) Insert key = 160

n=3

100 120 150 180 150 156 179 180 200 160 180 160 179

(d) New root, insert 45

n=3

10 20 30 1 2 3 10 12 20 25 30 32 40 40 45 40 30 new root

(a) Simple case - no example (b) Coalesce with neighbor (sibling) (c) Re-distribute keys (d) Cases (b) or (c) at non-leaf

Deletion from B+tree

(b) Coalesce with sibling

– Delete 50

10 40 100 10 20 30 40 50

n=4

40

(c) Redistribute keys

– Delete 50

10 40 100 10 20 30 35 40 50

n=4

35 35

40 45 30 37 25 26 20 22 10 14 1 3 10 20 30 40

(d) Non-leaf coalese

– Delete 37

n=4

40 30 25 25

new root

Outline/summary

• Conventional Indexes
• Sparse vs. dense
• Primary vs. secondary
• B trees
• B+trees vs. indexed sequential
• Hashing schemes
• -> Next
