slide-1
SLIDE 1

Transportation Management Plans Transportation Management Plans For Work Zones For Work Zones

Maryland State Highway Administration Maryland State Highway Administration Office of Traffic and Safety Office of Traffic and Safety Rummel, Klepper and Kahl, LLP Rummel, Klepper and Kahl, LLP Consulting Engineers Consulting Engineers

MdQI MdQI Conference Conference January 30, 2008 January 30, 2008

slide-2
SLIDE 2

2 2

Overview Overview

  • Part 1 –

Presentation

– Rule on Work Zone Safety and Mobility – Highlights of TMP Process

  • Significant Projects
  • Maintenance of Traffic Alternatives Analysis
  • Transportation Management Plans
  • Part 2 – Workshop

– Overview of Project Experience

  • MD 4/Suitland Parkway MOTAA
  • I‐695/Charles Street Interchange TMP

– Group Brainstorming

  • WZ Impact Management Strategies
slide-3
SLIDE 3

3 3

Rule on Work Rule on Work Zone Safety and Zone Safety and Mobility (23 CFR 630, Subpart J) Mobility (23 CFR 630, Subpart J)

  • Goals of the Rule

– Expand thinking beyond the actual WZ itself – Expand WZ management beyond just “traffic safety and traffic control” – Advocate innovative thinking in work zone planning, design and implementation

  • All current and future SHA projects should be in

compliance with the Rule

– Implementation Deadline was October 12, 2007

The Rule better reflects current needs for The Rule better reflects current needs for improved safety improved safety and and minimized traffic disruptions minimized traffic disruptions during the construction of highway projects during the construction of highway projects

slide-4
SLIDE 4

4 4

Overview Overview

  • Part 1 –

Presentation

– Rule on Work Zone Safety and Mobility – Highlights of TMP Process

  • Significant Projects
  • Maintenance of Traffic Alternatives Analysis
  • Transportation Management Plans
  • Part 2 – Workshop

– Overview of Project Experience

  • MD 4/Suitland Parkway MOTAA
  • I‐695/Charles Street Interchange TMP

– Group Brainstorming

  • WZ Impact Management Strategies
slide-5
SLIDE 5

5 5

Transportation Management Plans Transportation Management Plans (TMP) (TMP)

  • Which projects need a TMP?

– At SHA, all federal and non‐federal aid projects that are defined as “Significant Projects” – Non‐significant projects to the extent practical and feasible

  • What is a TMP?

– A TMP lays out a set of strategies and how these strategies will be implemented to manage work zone impacts

  • TMP strategies include:

– Temporary traffic control measures and devices (TCP) – Transportation operations (TO) strategies – Public information and outreach (PI&O) strategies

slide-6
SLIDE 6

6 6

TMP Process TMP Process

  • Planning, Preliminary Investigation and Design

Step 1 – Create TMP Team Step 2 – Compile Project Material Step 3 – Maintenance of Traffic Red Flag Summary Step 4 Step 4 – – Identify Significant Projects Identify Significant Projects Step 5 Step 5 – – Maintenance of Traffic Alternative Analysis Maintenance of Traffic Alternative Analysis (MOTAA) (MOTAA) Step 6 – Determine TMP Needs Step 7 – Identify Stakeholders and Revise TMP Team Step 8 Step 8 – – Preliminary Design (Draft TMP) Preliminary Design (Draft TMP) Step 9 Step 9 – – Detailed Design (Semi Detailed Design (Semi‐ ‐final, Final TMP) final, Final TMP)

slide-7
SLIDE 7

7 7

TMP Process TMP Process (cont.) (cont.)

  • Construction

Step 10 Step 10 – – Implement TMP Implement TMP Step 11 Step 11 – – Monitor TMP Monitor TMP Step 12 Step 12 – – Update/Revise TMP Update/Revise TMP

  • Performance Assessment

Step 13 ‐ Evaluation

slide-8
SLIDE 8

8 8

Significant Pr Significant Projects

  • jects
  • Why identify significant projects?

– Such that the appropriate resources (manpower and funding) can be allocated to projects with greater work zone impacts

  • When are significant projects identified?

– Project Scoping

  • Is my project “significant”?

– The lead office, or their consultant, will determine if a project is significant

  • What resources does SHA have for identifying

significant projects?

– “Guidance on Identifying Significant Projects” – Flow Charts

slide-9
SLIDE 9

9 9

Significant Pr Significant Projects

  • jects
  • What does SHA take into consideration when

identifying significant projects?

– Location (Freeway/Expressway, NHS, Principle Arterial) – Magnitude and extent of work zone impacts

  • Mobility Impacts (delays exceeding allowable mobility

thresholds)

  • Safety Impacts (worker and traveling public)

– Project characteristics

  • High level of public interest
  • Project duration/complexity
  • High accident intersections and segments
  • Unusual road work strategies
slide-10
SLIDE 10

10 10

Significant Pr Significant Projects

  • jects ‐

‐ Exceptions Exceptions

  • What if my project is considered significant

based on the “three day lane closure” rule*, but is not anticipated to have significant impacts?

– Submit a written request for an exception to the FHWA Maryland Division Office – SHA anticipates obtaining “blanket exceptions” for certain categories of projects

  • Maintenance projects, such as litter pickup, guardrail

repairs, and bridge cleaning * All Interstate system projects within the boundaries of a designated Transportation Management Area (TMA) that occupy a location for more than three days with either intermittent or continuous lane closures are considered significant projects.

slide-11
SLIDE 11

11 11

Maintenance of Traffic Alternatives Maintenance of Traffic Alternatives Analysis (MOTAA) Analysis (MOTAA)

  • What is the purpose of the MOTAA?

– To compare work zone options, including staging/ phasing options as well as temporary traffic control

  • ptions, and to document maintenance of traffic

constraints for each option. – – Most important part: Most important part: Identify the impacts early enough in the project development process to make the changes necessary (right‐of‐way, bridge, environmental, etc.)

  • Which projects require a MOTAA?

– All significant projects

  • When should the MOTAA be conducted?

– Concept MOTAA during Project Planning (OPPE) – Detailed MOTAA during Preliminary Design

slide-12
SLIDE 12

12 12

Concept MOTAA Concept MOTAA

  • Occurs during project planning (construction

could be 10+ years away)

  • Investigate potential major maintenance of traffic

issues for each alternate retained for detailed study, such as:

– Constructability – Right‐of‐way, utility, and environmental impacts – Construction duration and cost – Mobility impacts (qualitative assessment of impacts on vehicular, pedestrian and bicycle traffic; access; emergency services; etc.)

  • Detailed traffic analysis is not required
slide-13
SLIDE 13

13 13

Detailed MOTAA Detailed MOTAA

  • Occurs during preliminary design, after the

preferred design alternate has been selected (ideally, prior to PI – 30%)

  • Investigate in more detail temporary traffic

control options for the selected design alternate

– Discuss work zone options with the Design Office and District Traffic prior to developing scope of work – Work Zone options may include:

– Full closure – Part‐width construction – Lane shifts or closures – Reversible lanes – Temporary structures – One‐lane, two‐way

  • perations

– Widening – Temporary crossover – Use of shoulder or median

slide-14
SLIDE 14

14 14

Detailed MOTAA Detailed MOTAA

  • Identify work zone constraints and report impacts
  • n any of the following:
  • MOTAA is more than just traffic analysis!

– Ability to comply with thresholds in Lane Closure Guidelines – Ability to maintain access (businesses, communities, etc.) – Ability to provide required ramp merge distances – Ramp capacity – Impacts on pedestrian and bicycle facilities – Impacts on emergency services – Public Safety – Ability to maintain existing drainage, utility and lighting systems – Right‐of‐way impacts – Environmental impacts – Bridge widths – Impacts to earthwork, pier clearances, retaining walls, profile differences, etc. – Constructability – Construction equipment access – Impacts on construction duration – Construction and MOT costs

slide-15
SLIDE 15

15 15

Detailed MOTAA Detailed MOTAA

  • Also consider at this time:

– Preliminary work zone impact management strategies – Preliminary cost estimates for strategy implementation (when available) – Information from other projects in the corridor to evaluate the combined or cumulative impact of the projects

slide-16
SLIDE 16

16 16

Documenting the MOTAA Documenting the MOTAA

  • “Guidance on Maintenance of Traffic Alternatives

Analysis” provides a suggested method of documentation

  • Office of Bridge Design has used a Kepner

– Tregoe Analysis

– Incorporates MOT into the decision on which project alternate moves forward for design

  • Bottom line – format is not important (for

Concept MOTAA or Detailed MOTAA) as long as all of the potential impacts have been considered

slide-17
SLIDE 17

17 17

After the MOTAA After the MOTAA

  • Re‐evaluate the significant project status

– Did the MOTAA identify an option that eliminates work zone impacts?

  • Consider a corridor/regional TMP

– If there are multiple or consecutive projects that are within the same general corridor, coordination amongst these projects will minimize the impacts

  • Review the budget

– Include funds in the CTP estimate for TMP development and implementation – Don’t forget to include funds for PI&O, Work Zone ITS, etc.

slide-18
SLIDE 18

18 18

Onto the TMP Onto the TMP

  • When should development of the TMP begin?

– All of the work done up to this point is a part of the TMP process – Ideally, first draft at PI – Realistically, first draft at Semi‐Final

  • Who’s responsible for developing the TMP?

– The TMP Coordinator, in consultation with the TMP Team

  • TMP Coordinator = Project Manager (or consultant)
  • TMP Team = appropriate representatives from SHA and
  • ther stakeholders
slide-19
SLIDE 19

19 19

TMP Development During Design TMP Development During Design

  • As design progresses, refine Traffic Control Plan

(TCP) and elements that were initially identified in the MOTAA

  • The TMP Team should work with technical

specialists to jointly identify/confirm:

– The work zone impacts that need to be addressed – The proposed work zone impact management strategies

  • Identify any TMP elements that:

– Require long lead times – Need to be established prior to the start of construction – Require improvements to be completed prior to the start

  • f construction (e.g., alternate route improvements)
slide-20
SLIDE 20

20 20

Fine Tuning Fine Tuning Temporary Traffic Temporary Traffic Control (TTC) Strategies Control (TTC) Strategies

  • Traffic control strategies

– Phasing/staging, full closure, lane shifts and closures, crossovers, detours, etc.

  • Project timing

– Night work, weekend work, special events, seasonal traffic, environmental time restrictions, etc.

  • Traffic control devices

– Signing, striping, signals

  • Products: Temporary traffic control plans and

specifications

  • District Traffic must approve TCP
slide-21
SLIDE 21

21 21

Selecting Transportation Selecting Transportation Operations (TO) Strategies Operations (TO) Strategies

  • So many to choose from!

– Work Zone ITS

  • Dynamic late lane merge, speed ahead, travel time, etc.

– Demand Management

  • Transit improvements, carpool incentives, etc.

– Corridor Network Management

  • Signal timing, reversible lanes, parking restrictions, etc.

– Safety Management

  • Speed limit reduction, moveable barrier systems, rumble

strips, etc.

– Incident Management

  • Standby towing, pull‐off areas, planned detours, etc.

– Enforcement

  • Cooperative police enforcement, drone radar, etc.
  • District Traffic must approve TO Strategies
slide-22
SLIDE 22

22 22

Selecting Public Selecting Public Information and Outreach Information and Outreach (PI&O) Strategies (PI&O) Strategies

  • Public Awareness

– Newsletters, brochures, etc. – Press releases – Mass Media (earned and/or paid) – Project website (project information, construction progress, traffic cameras) – Public meetings, workshops, community events

  • Motorist Information

– Radio traffic news – Changeable message signs – Email alerts – Highway Advisory Radio

  • Office of Communications must approve PI&O Strategies
slide-23
SLIDE 23

23 23

Draft TMP Draft TMP

  • What should be included in the Draft TMP?

– Project summary, goals and objectives – Anticipated work zone impacts – Stakeholders and others impacted by the project – SHA and other projects in the vicinity that may require coordination – Narrative of the recommended construction phasing/staging strategies – Traffic analysis and results – Proposed work zone impact management strategies (TO and PI&O) and associated costs – Preliminary TCP showing construction phasing/staging

  • What resources does SHA have to help me develop the TMP?

– Refer to SHA’s “Transportation Management Plans: Guidelines for Development, Implementation and Assessment”

slide-24
SLIDE 24

24 24

Final TMP Final TMP

  • Traffic Control Plans

– Address any comments from previous submissions – Develop plans in more detail to show temporary signing, striping, signals, etc.

  • TMP Document

– Address any comments on draft TMP – Modify and fine tune TO and PI&O strategies TMP as project evolves

  • Develop any non‐standard special provisions
  • Incorporate TMP implementation costs in project

estimate

slide-25
SLIDE 25

25 25

Implement TMP Implement TMP

  • Rule Requirement:

– SHA and the Contractor must designate a trained person at the project level to implement the TMP and

  • ther safety and mobility aspects of the project.
  • SHA – On‐site Project Engineer
  • Contractor –

Traffic Manager

  • Responsibilities include:

– Efficiently and appropriately implementing the TMP – Reviewing traffic operations throughout the project limits, including the condition of all traffic control devices, on a regular basis.

slide-26
SLIDE 26

26 26

Monitor TMP Monitor TMP

  • General

– Assure that media tools (CMS, HAR, etc.) provide accurate and timely information – Ensure contractor compliance with lane closure pickup times.

  • TMP Specific

– Implement monitoring requirements as specified in contract documents (monitoring queue lengths, documentation requirements, etc.) – Discuss TMP implementation and monitoring at monthly partnering meetings (as needed) – Determine if additional TMP elements are needed or if particular elements need refinement

slide-27
SLIDE 27

27 27

TMP Updates & Revisions TMP Updates & Revisions

  • SHA on‐site PE and Traffic Manager are

responsible for maintaining current documentation regarding:

– Deficiencies identified during TMP implementation – How and when these deficiencies were corrected

  • The Contractor shall submit any major TMP

changes to the District for review and approval

  • Changes may include:

– Changes to work activities that alter traffic control requirements – Changes to any work zone impact strategies

slide-28
SLIDE 28

28 28

More TMP F More TMP FAQS AQS

  • Contractors often change the TCP. How am I

supposed to know how the contractor will build the project?

  • Can a contractor make changes to the TMP?
  • Are we exposed to more legal liability by

providing a TMP at such a detailed level?

  • Doesn’t a comprehensive TMP add more to the

project cost?

  • How long should the TMP document be?
slide-29
SLIDE 29

29 29

Additional TMP R Additional TMP Resources esources

  • Work Zone Safety Toolbox
  • Work Zone Design Checklist
  • Lane Closure Analysis Guidelines
  • Work Zone Analysis Guide (forthcoming)
  • Temporary Traffic Barrier Policy

– Updated September 2007 to reflect requirements of Senate Bill 699

More Info: More Info:

http://www.marylandroads.com/Safety/oots/ trafficsignalsandlaws/otr_workzone.asp

slide-30
SLIDE 30

30 30

Overview Overview

  • Part 1 –

Presentation

– Rule on Work Zone Safety and Mobility – Highlights of TMP Process

  • Significant Projects
  • Maintenance of Traffic Alternatives Analysis
  • Transportation Management Plans
  • Part 2 – Workshop

– Overview of Project Experience

  • MD 4/Suitland Parkway MOTAA
  • I‐695/Charles Street Interchange TMP

– Group Brainstorming

  • WZ Impact Management Strategies
slide-31
SLIDE 31

31 31

MD 4/Suitland Parkway Interchange MD 4/Suitland Parkway Interchange

4

slide-32
SLIDE 32

32 32

Project Limits Project Limits

  • MD 4
  • From Westphalia Road to Dowerhouse Road
  • Suitland Parkway
  • Andrews Air Force Base to Presidential Parkway

INTERCHANGE LOCATION INTERCHANGE LOCATION

slide-33
SLIDE 33

33 33

Project Ob Project Objectives jectives

  • Construct New Interchange
  • Accommodate Existing/Future Traffic Volumes
slide-34
SLIDE 34

34 34

slide-35
SLIDE 35

35 35

Key Notes Key Notes – – MOTAA MOTAA

  • Project at PI stage when TMP Process was

initiated

– Still early enough to complete the MOTAA

  • In developing MOT Options, the following were

considered:

– Construction phasing – Traffic operations – Constructability – Access – Cost

slide-36
SLIDE 36

36 36

Key Notes Key Notes – – MOTAA MOTAA

  • Investigated MOT Options in detail

– Synchro analysis identified magnitude and duration of mobility impacts – 10 Options Evaluated

  • Modified MOT Design & Operations

– Detour to eliminate traffic movements – Barrier to prevent weaving – Modified intersection operations

slide-37
SLIDE 37

37 37

MOTAA Summary MOTAA Summary

slide-38
SLIDE 38

38 38

Key Notes Key Notes – – MOTAA MOTAA

  • Results of the MOTAA

– Full Roadway Closures (Presidential Parkway & MD 4) – Lane Shifts – Construction of Temporary Roadway – Long‐term Detour – Modified Operation of MD 4/ Dowerhouse Intersection

slide-39
SLIDE 39

39 39

MOT Pha MOT Phasing sing

Phase 1

  • Relocate utilities and Service Road east of MD 4
  • Widen EB Suitland Parkway Bridge over AAFB

ramps

Phase 2

  • Construct temporary roadway for MD 4 traffic along

alignment of Ramps G and C, with temporary signal

  • Construct Suitland Parkway detour to the north of

existing alignment

  • Construct AAFB ramps

Phase 3

  • Construct MD 4 and related ramps south of Suitland

Parkway

  • Construct Suitland Parkway and the outbound

AAFB ramp from AAFB to Presidential Parkway

Phase 4

  • Completion of MD 4 and related ramps and bridges
slide-40
SLIDE 40

40 40

Work Zone Impacts and Concerns Work Zone Impacts and Concerns

  • Issues to be addressed in the TMP:

– Worker Exposure along MD 4 – AAFB Access and Operations – Access and Staging Areas (construction, incident management) – Public Outreach – ITS Strategies – Transit Service

slide-41
SLIDE 41

41 41

Overview Overview

  • Part 1 –

Presentation

– Rule on Work Zone Safety and Mobility – Highlights of TMP Process

  • Significant Projects
  • Maintenance of Traffic Alternatives Analysis
  • Transportation Management Plans
  • Part 2 – Workshop

– Overview of Project Experience

  • MD 4/Suitland Parkway MOTAA
  • I‐695/Charles Street Interchange TMP

– Group Brainstorming

  • WZ Impact Management Strategies
slide-42
SLIDE 42

42 42

Charles Street Interchange Charles Street Interchange

slide-43
SLIDE 43

43 43

Project Limits Project Limits

  • I‐695
  • From I‐83 to West of York Road
  • Charles Street / Bellona Avenue
  • From Kenilworth Drive to Othoridge

Road

INTERCHANGE LOCATION INTERCHANGE LOCATION

slide-44
SLIDE 44

44 44

Project Ob Project Objectives jectives

  • Replace Charles Street Bridge –

Priority 1

  • Improve Traffic Flow
  • Improve Pedestrian Access and Safety
slide-45
SLIDE 45

45 45

Key Notes Key Notes – – Informal TMP Process Informal TMP Process

  • Project at Semi‐Final Design level when TMP

Process was implemented by SHA

  • Informal MOT alternatives analysis

– Constructability review of design alternates – Identification of number of lanes and turning movements to be maintained; lane continuity – Public outreach via community meetings – Identification of constraints

  • Minimize impacts to historic stone wall along Bellona
  • Existing bridge median not traffic bearing
  • Maintain roundabout until new signal is constructed
slide-46
SLIDE 46

46 46

Key Notes Key Notes – – Formal TMP Process Formal TMP Process

  • Formal traffic analysis of all MOT phases to

identify problem areas

  • Continued coordination with community
  • Addition I‐695 bridge redecking
  • ver the light

rail to the contract

– Made sense to include projects in the same contract due to their close proximity

  • TMP Team meetings

– Brought varying disciplines together to discuss MOT – Coordination with the District 4 Community Liaison and Office of Communications to identify public

  • utreach strategies
slide-47
SLIDE 47

47 47

Construction Phasing Construction Phasing

Phase 1

  • Remove Charles St. medians
  • Construct temporary pavement for ramps 3&5

Phase 2

  • Demo west side of Charles St. Bridge (traffic

shifted to east side)

  • Shift I‐695 traffic towards median at light rail

bridge

Phase 3

  • Demo east side of Charles St. Bridge (traffic

shifted to newly constructed west side)

  • I‐695 split traffic at light rail bridge

Phase 4

  • Outer loop widening & shoulder construction
  • Shift I‐695 traffic towards outside at light rail

bridge

Phase 5

  • Mill, resurface, final pavement markings
slide-48
SLIDE 48

48 48

Work Zone Impacts & Concerns Work Zone Impacts & Concerns

  • Impacts

– Detour required for SB Lefts onto Ramp 5 during Phase 2 – Detour required during Phase 3 for Ramp 8 (Bellona Rd to I‐695 Outer Loop/I‐83 North) closure – Reduced # lanes along Charles St. in some phases

  • Concerns

– High speeds along I‐695 – Workers killed in work zone crash on top side of beltway in 2005 – Informing involved and outspoken communities – Noise abatement – Providing safety and guidance to drivers navigating the traffic split on the Inner Loop during Phase 3

slide-49
SLIDE 49

49 49

Overview Overview

  • Part 1 –

Presentation

– Rule on Work Zone Safety and Mobility – Highlights of TMP Process

  • Significant Projects
  • Maintenance of Traffic Alternatives Analysis
  • Transportation Management Plans
  • Part 2 – Workshop

– Overview of Project Experience

  • MD 4/Suitland Parkway MOTAA
  • I‐695/Charles Street Interchange TMP

– Group Brainstorming

  • WZ Impact Management Strategies
slide-50
SLIDE 50

50 50

Group Brainstorming Group Brainstorming

  • What are the potential work zone impact

management strategies that could be used to minimize impacts and address concerns?

  • For the strategies your group has identified,

which ones do you consider “feasible” for inclusion in the project?

– Cost vs. benefit – Applicability to project specific characteristics – Receptiveness of community, commuters

slide-51
SLIDE 51

51 51

Questions? Questions?

Contact Info: Contact Info:

Michael Paylor

Team Leader, SHA – OOTS MPaylor@sha.state.md.us 410‐787‐5864

Heather Henck, P.E., PTOE

Project Engineer, RK&K hhenck@rkkengineers.com 410‐462‐9150

Heidi VanLuven, P.E.

Director of Transportation,

  • A. Morton Thomas & Associates

hvanluven@amtengineering.com 410‐752‐6552

More Info: More Info:

http://www.marylandroads.com/Safety/oots/ trafficsignalsandlaws/otr_workzone_guidelines.asp
