April 1, 2019

Edmonton’s Light Rail Transit System CEA - Transportation Connects Alberta

LRT Delivery, COE WSP Canada Scott Macintosh Tamsin Silvester

2

Modal Shift

3

Edmonton’s Future LRT Network Plan

4

LRT Network Plan

Project Concept Planning Preliminary Design & Construction Procurement Readiness Build Valley Line - Southeast ✔ ✔ 2016-2020 Valley Line - West ✔ 2017 - 2019 2020-2027 Metro Line - NAIT to Blatchford ✔ 2017-2019 2020-2024 Metro Line - Blatchford to Campbell Road ✔ 2017-2019 TBD Capital Line - South ✔ 2017-2019 TBD Heritage Valley Park and Ride ✔ ✔ 2017-2020 Downtown Circulator / Centre LRT 2017-2019 TBD TBD

5

Integrating LRT and Land Use

April 1, 2019

High-floor vs. Low-floor LRT

• High-floor LRT vehicle style

○ Capital & Metro Line ○ Equipment located below car train ○ Requires raised platforms/stations

• Low-floor LRT vehicle style

○ Valley Line ○ Equipment located above car train ○ Requires less infrastructure ○ Step-free boarding at street-level (curb height)

6

Integrated Transportation System

April 1, 2019

High-floor Low-floor LRT

7

Integrated Transportation System

8

Balancing Transportation Modes

April 1, 2019

9

Comparative Analysis ITE Nomograph Option Generation

Crossing Assessment Framework

10

Crossing Assessment Framework

11

Crossing Assessment Framework

12

Crossing Assessment Framework

April 1, 2019

LRT Styles - Suburban and Urban

13

14

Urban LRT System

Respecting communities - reduced speed/barriers Better pedestrian, cyclist, and transit connections Aesthetically blending into the environment Smaller stops/stations - closer together (850m)

15

Suburban LRT System

Stops/stations - further apart (>1km) Less urban integration - ballasted track / fencing Higher speeds / barriers and crossing gates

16

• Key Canadian Rail Projects

• High-floor urban/suburban style LRT
• 11.0 km double track
• 9 stations
• 2 Transit centres
• Operations & Maintenance Facility
• CN Walker Railyard / YHT crossing
• 1 new park and ride (St. Albert - regional

integration)

• Concept est. $2.3B (+/- 30%)

17

Metro Line NW Extension

April 1, 2019

18

Metro Line NW Extension

E - W Leg (153 Ave)

Metro Line NW Extension

19

Suburban Areas

• Rear facing housing
• Wider roads with turning

lanes

• Fewer intermediate

connections to the community Traditional signal system with full pre-emption for trains Segregated, fenced LRT with crossing gates at intersections

20

Urban Style Areas

• Front facing housing
• Constrained corridor:

Single lane traffic

• Schools / Retail street-

facing

• Connection to TOD

Transit Signal Priority system No crossing gates at intersections N - S Leg (113a St)

Metro Line NW Extension

21

Crossing Systems

• Current crossing warning

system gates and bells

• New style of LRT for

Edmonton urban integration:

○ no crossing gates at traffic intersections ○ reduced barriers along LRT corridor ○ Use of landscaping and placement of ROW equipment to deter ‘jaywalking’ across the LRT tracks ○ implications for train speeds / crossing warning systems, etc.

April 1, 2019

• Suburban style

○ Full pre-emption ○ Higher speeds ○ Hard delineation (tall fencing, jersey barriers etc.) ○ Ballasted / Direct Fixation Trackwork

• Urban style

○ Transit Signal Priority (TSP) ○ Slower Speeds ○ Soft delineation or barrier free ○ Embedded Trackwork

22

Operational Differences

23

• Phase 1 interface with

Blatchford Development

• A world-leading

sustainable development

• A community that

balances social environmental and economic sustainability

Metro Line NW Phase 1

24

Metro Line NW Phase 1

25

Metro Line NW Phase 1

April 1, 2019

26

Metro Line NW Phase 1

April 1, 2019

Alex Decoteau Stop

27

Valley Line West

April 1, 2019

28

Questions?
