slide-1
SLIDE 1

Transactional Consistency and Automatic Management in an Application Data Cache

Dan Ports Austin Clements Irene Zhang Samuel Madden Barbara Liskov MIT CSAIL

Tuesday, October 5, 2010

slide-2
SLIDE 2

Modern web applications face immense scaling challenges

increasingly complex, personalized content e.g. Facebook, MediaWiki, LiveJournal...

Existing caching techniques are less useful

whole-page caches: foiled by personalization database caches: more processing is being done in the application layer

Tuesday, October 5, 2010

slide-3
SLIDE 3

Application-Level Caching

Application Database Cache

Tuesday, October 5, 2010

slide-4
SLIDE 4

e.g. memcached, Java object caches

Application-Level Caching

Application Database Cache

Tuesday, October 5, 2010

slide-5
SLIDE 5

e.g. memcached, Java object caches very lightweight in-memory caches stores application objects (computations), i.e.: not a database replica not a query cache

Application-Level Caching

Application Database Cache

Tuesday, October 5, 2010

slide-6
SLIDE 6

Why Cache Application Data?

Cache higher-level data closer to app needs: DB queries, complex structures, HTML fragments Can separate common and customized content Reduces database load Reduces application server load

  • this matters too (application servers aren’t cheap!)

Tuesday, October 5, 2010

slide-7
SLIDE 7

Existing Caches Add To Application Complexity

No transactional consistency

  • violates guarantees of the underlying DB
  • app. code must deal with transient anomalies

Hash table interface leaves apps responsible for:

  • naming and retrieving cache entries
  • keeping cache up-to-date (invalidations)

Tuesday, October 5, 2010

slide-8
SLIDE 8

Harder Than You Think!

Naming: cache key must uniquely identify value

  • MediaWiki stored list of recent changes with

same key regardless of # days requested (#7541)

Invalidations: require reasoning globally about entire application

  • After editing wiki page, what to invalidate?

Tuesday, October 5, 2010

slide-9
SLIDE 9

Harder Than You Think!

Naming: cache key must uniquely identify value

  • MediaWiki stored list of recent changes with

same key regardless of # days requested (#7541)

Invalidations: require reasoning globally about entire application

  • After editing wiki page, what to invalidate?
  • Forgot editor’s User object – contains edit count

(#8391)

Tuesday, October 5, 2010

slide-10
SLIDE 10

Introducing TxCache

Our cache provides:

  • transactional consistency: serializable, point-in-

time view of data, whether from cache or DB

  • bounded staleness: improves hit rate for

applications that accept old (but consistent) data

  • simpler interface:

applications mark functions cacheable; TxCache caches their results, including naming and invalidations

Tuesday, October 5, 2010

slide-11
SLIDE 11

Application Database TxCache Library Cache

  • TxCache library hides

complexity of cache management

  • Integrates with new

cache server, minor DB modifications (Postgres; <2K lines changed)

  • Together, ensure

whole-system transactional consistency

Tuesday, October 5, 2010

slide-12
SLIDE 12
  • beginRO(staleness), commit(),

beginRW(), abort()

  • make-cacheable(fn)

where fn is a side-effect-free function that depends

  • nly on its arguments and the database state

➔ fn returns cached result of previous call with same inputs if still consistent w/ DB

TxCache Interface

Tuesday, October 5, 2010

slide-13
SLIDE 13
  • beginRO(staleness), commit(),

beginRW(), abort()

  • make-cacheable(fn)

where fn is a side-effect-free function that depends

  • nly on its arguments and the database state

➔ fn returns cached result of previous call with same inputs if still consistent w/ DB

TxCache Interface

That’s it.

Tuesday, October 5, 2010

slide-14
SLIDE 14
  • beginRO(staleness), commit(),

beginRW(), abort()

  • make-cacheable(fn)

where fn is a side-effect-free function that depends

  • nly on its arguments and the database state

➔ fn returns cached result of previous call with same inputs if still consistent w/ DB

TxCache Interface

That’s it. Really!

Tuesday, October 5, 2010

slide-15
SLIDE 15

TxCache Library Application

Tuesday, October 5, 2010

slide-16
SLIDE 16

CALL TxCache Library Application

Tuesday, October 5, 2010

slide-17
SLIDE 17

LOOKUP CALL TxCache Library Application

Tuesday, October 5, 2010

slide-18
SLIDE 18

HIT LOOKUP CALL TxCache Library Application

Tuesday, October 5, 2010

slide-19
SLIDE 19

MISS LOOKUP CALL TxCache Library Application

Tuesday, October 5, 2010

slide-20
SLIDE 20

MISS LOOKUP UPCALL CALL TxCache Library Application

Tuesday, October 5, 2010

slide-21
SLIDE 21

MISS LOOKUP UPCALL CALL TxCache Library QUERIES Application

Tuesday, October 5, 2010

slide-22
SLIDE 22

MISS LOOKUP UPCALL CALL INSERT TxCache Library QUERIES Application

Tuesday, October 5, 2010

slide-23
SLIDE 23

MISS LOOKUP UPCALL CALL INSERT TxCache Library QUERIES Application

Tuesday, October 5, 2010

slide-24
SLIDE 24

Outline

  • 1. Application-Level Caching
  • 2. TxCache Interface
  • 3. Ensuring Transactional Consistency
  • 4. Automating Invalidations
  • 5. Evaluation

Tuesday, October 5, 2010

slide-25
SLIDE 25

Consistency Approach

Goal: all data seen in a transaction reflects single point-in-time snapshot

  • Assign timestamp to transaction
  • Know the validity interval of each object

in cache or database: set of timestamps when it was valid

  • Then: transaction can read data if data’s

validity interval contains txn’s timestamp

Tuesday, October 5, 2010

slide-26
SLIDE 26

A Versioned Cache

Cache entries tagged with validity intervals

  • each entry one immutable version of an object
  • allows lookup for value valid at certain time

K1 K2 time K3 K4

Tuesday, October 5, 2010

slide-27
SLIDE 27

A Versioned Cache

Cache entries tagged with validity intervals

  • each entry one immutable version of an object
  • allows lookup for value valid at certain time

K1 K2 time K3 K4

Tuesday, October 5, 2010

slide-28
SLIDE 28

Staleness

Assign transaction an earlier timestamp

  • if consistent with application requirements
  • allows cached data to be used longer

K1 K2 time K3 K4

Tuesday, October 5, 2010

slide-29
SLIDE 29

Staleness

Assign transaction an earlier timestamp

  • if consistent with application requirements
  • allows cached data to be used longer

K1 K2 time K3 K4

Tuesday, October 5, 2010

slide-30
SLIDE 30

Staleness

Assign transaction an earlier timestamp

  • if consistent with application requirements
  • allows cached data to be used longer

K1 K2 time K3 K4

Tuesday, October 5, 2010

slide-31
SLIDE 31

Requires starting a DB transaction at same timestamp

  • internally, snapshot isolation supports this
  • added interface to expose this to cache library

Staleness

Assign transaction an earlier timestamp

  • if consistent with application requirements
  • allows cached data to be used longer

Tuesday, October 5, 2010

slide-32
SLIDE 32

Where Do Validity Intervals Come From?

Tuesday, October 5, 2010

slide-33
SLIDE 33

Where Do Validity Intervals Come From?

Validity of an application object = validity of the DB queries used to generate it

  • library tracks query dependencies

Tuesday, October 5, 2010

slide-34
SLIDE 34

Where Do Validity Intervals Come From?

Validity of an application object = validity of the DB queries used to generate it

  • library tracks query dependencies

Validity of a DB query = validity of the tuples accessed to compute it

  • we modify the DB to report this

Tuesday, October 5, 2010

slide-35
SLIDE 35

Where Do Validity Intervals Come From?

Validity of an application object = validity of the DB queries used to generate it

  • library tracks query dependencies

Validity of a DB query = validity of the tuples accessed to compute it

  • we modify the DB to report this

Validity of a tuple = timestamps of creating, deleting transactions

  • multiversion DBs already track this

Tuesday, October 5, 2010

slide-36
SLIDE 36

Computing Query Validity

x y

time

z q

40 45 50

Tuesday, October 5, 2010

slide-37
SLIDE 37

Computing Query Validity

inserted by txn #41

x y

time

z q

40 45 50

Tuesday, October 5, 2010

slide-38
SLIDE 38

Computing Query Validity

inserted by txn #41 deleted by txn #50

x y

time

z q

40 45 50

Tuesday, October 5, 2010

slide-39
SLIDE 39

Computing Query Validity

SELECT * FROM ...;

x y

time

z q

40 45 50

Tuesday, October 5, 2010

slide-40
SLIDE 40

Computing Query Validity

SELECT * FROM ...;

result = {x, y}

x y

time

z q

40 45 50

Tuesday, October 5, 2010

slide-41
SLIDE 41

Computing Query Validity

Intersect validity intervals of tuples accessed

SELECT * FROM ...;

result = {x, y} VALIDITY [41, 48)

x y

time

z q

40 45 50

Tuesday, October 5, 2010

slide-42
SLIDE 42

Computing Query Validity

Intersect validity intervals of tuples accessed

SELECT * FROM ...;

result = {x, y} VALIDITY [41, 48)

x y

time

z q

40 45 50

Tuesday, October 5, 2010

slide-43
SLIDE 43

Lazy Timestamp Selection

Hard to choose timestamp a priori

  • Don’t know access pattern or cache contents
  • Insight: don’t have to choose right away!

K1 K2 time K3 K4

Tuesday, October 5, 2010

slide-44
SLIDE 44

Lazy Timestamp Selection

Hard to choose timestamp a priori

  • Don’t know access pattern or cache contents
  • Insight: don’t have to choose right away!

K1 K2 time K3 K4

Tuesday, October 5, 2010

slide-45
SLIDE 45

Lazy Timestamp Selection

Hard to choose timestamp a priori

  • Don’t know access pattern or cache contents
  • Insight: don’t have to choose right away!

K1 K2 time K3 K4

Tuesday, October 5, 2010

slide-46
SLIDE 46

Lazy Timestamp Selection

Hard to choose timestamp a priori

  • Don’t know access pattern or cache contents
  • Insight: don’t have to choose right away!

K1 K2 time K3 K4

Tuesday, October 5, 2010

slide-47
SLIDE 47

Outline

  • 1. Application-Level Caching
  • 2. TxCache Interface
  • 3. Ensuring Transactional Consistency
  • 4. Automating Invalidations
  • 5. Evaluation

Tuesday, October 5, 2010

slide-48
SLIDE 48

Invalidations

What about objects that are still valid?

  • don’t know their upper validity bound yet!
  • represent as open-ended validity intervals

Later, database notifies cache if object changes; cache truncates interval

K1 K2 time now

Tuesday, October 5, 2010

slide-49
SLIDE 49

Invalidation Tags

How to identify which objects changed?

  • DB doesn’t know which app-level objects are cached

Objects in cache have invalidation tags

  • Modified DB to assign invalidation tags to each query
  • DB generates list of tags affected by each update
  • Cache finds affected objects and updates interval

Tuesday, October 5, 2010

slide-50
SLIDE 50

Invalidation Tags

  • Inval. tags come from query’s access methods
  • TABLE:KEY=VALUE for queries that use index lookups
  • TABLE:* for non-indexed queries (rare)

SELECT * FROM users WHERE name = ‘floyd’; [result] INVALIDATION TAGS users:name=floyd

Tuesday, October 5, 2010

slide-51
SLIDE 51

Invalidation Stream

On each update, DB generates affected tags:

  • for each tuple affected, one tag per index key

Broadcasts to all cache nodes

  • ordered stream, with transaction timestamps

Cache lookups treat unbounded intervals as bounded at last timestamp received

  • avoids invalidate & lookup race conditions

Tuesday, October 5, 2010

slide-52
SLIDE 52

Outline

  • 1. Application-Level Caching
  • 2. TxCache Interface
  • 3. Ensuring Transactional Consistency
  • 4. Automating Invalidations
  • 5. Evaluation

Tuesday, October 5, 2010

slide-53
SLIDE 53

Evaluation

  • How much benefit from adding caching?
  • Does using stale data help?
  • Does consistency hurt performance?

Tuesday, October 5, 2010

slide-54
SLIDE 54

RUBiS Benchmarks

RUBiS: simulated eBay-like auction site

  • standard browsing & bidding workload; 85% read-only
  • two datasets: 850 MB (in-memory), 6 GB (disk-bound)

All servers 2x 3.20 GHz Xeon, 2 GB RAM

  • 1 DB server (modified Postgres 8.2.11)
  • 9 frontend/cache servers (Apache 2 / PHP 5)

Tuesday, October 5, 2010

slide-55
SLIDE 55

Cache Performance

(in-memory DB; 2 cache nodes)

1000 2000 3000 4000 5000 0% 20% 40% 60% 80% 100% 64MB 256MB 512MB 768MB 1024MB Cache size

Max throughput (requests/sec) Cache hit rate

Tuesday, October 5, 2010

slide-56
SLIDE 56

Cache Performance

(disk-bound DB; 8 shared web/cache nodes)

Max throughput (requests/sec) Cache hit rate

100 200 300 400 500 600 80% 85% 90% 95% 100% 1GB 2GB 3GB 4GB 5GB 6GB 7GB 8GB 9GB Cache size

Tuesday, October 5, 2010

slide-57
SLIDE 57

Even A Little Staleness Helps

0x 1x 2x 3x 4x 5x 6x 20 40 60 80 100 120 Relative throughput Staleness limit in seconds no caching (baseline) TxCache (in-memory DB) TxCache (disk-bound DB)

Tuesday, October 5, 2010

slide-58
SLIDE 58

Costs of Consistency

Cache misses classified as:

  • compulsory: data never seen
  • staleness: data invalidated & too old to use
  • capacity: data was evicted
  • consistency: data available but inconsistent w/ prior reads

consistency misses configuration (% of total misses) in-memory, 512 MB, 30 s stale 7.8% in-memory, 512 MB, 15 s stale 5.4% in-memory, 64 MB, 30 s stale 0.2% disk-bound, 9 GB, 30 s stale 0.7%

Tuesday, October 5, 2010

slide-59
SLIDE 59

Costs of Consistency

Cache misses classified as:

  • compulsory: data never seen
  • staleness: data invalidated & too old to use
  • capacity: data was evicted
  • consistency: data available but inconsistent w/ prior reads

consistency misses configuration (% of total misses) in-memory, 512 MB, 30 s stale 7.8% in-memory, 512 MB, 15 s stale 5.4% in-memory, 64 MB, 30 s stale 0.2% disk-bound, 9 GB, 30 s stale 0.7%

common to

  • ther caches

}

Tuesday, October 5, 2010

slide-60
SLIDE 60

Costs of Consistency

Verified experimentally by disabling consistency:

transaction can read any data valid in last 30 sec

1000 2000 3000 4000 5000 64MB 256MB 512MB 768MB 1024MB Peak requests/sec Cache size

no caching TxCache no consistency

Tuesday, October 5, 2010

slide-61
SLIDE 61

Related Work

Application-level caches:

  • more flexible than whole-page caches: partial results
  • require explicit management by application
  • no transactional support (e.g. memcached)
  • r transactions only within cache (e.g. JBoss, AppFabric)

Database replication:

  • FAS, Ganymed: keep stale replicas with batched updates
  • can’t apply methods to app-level caching

Tuesday, October 5, 2010

slide-62
SLIDE 62

Conclusion

TxCache: application-layer caching with a simpler programming model

  • provides transactional consistency across both cache

and database

  • automatic management: applications not responsible for

lookups, updates, invalidations

New mechanisms:

  • consistency ensured by tracking object validity intervals
  • automatic database-generated invalidations

Consistency imposes little performance cost

Tuesday, October 5, 2010
