Tradition Reliability Quality Since 1921

Year 2017

Present

Year 2017

Organization Chart

Power Transformers, Including servis

Turnover in 2016 15,2 mil. EUR

International BEZ Group

Turnover in 2016 41,1 mil. EUR ETD TRANSFORMERS BEZ TRANSFORMERS ELECTRICAL MACHINES

Repairs and servis of Transformers and rotating machinary

Turnover in 2016 3,9 mil. EUR

Distribution Transformers, Including repairs

Turnover in 2016 22,0 mil. EUR

100 % 100 % 100 %

3

Utilization

Power Transformers

Generation and transmission of electricity for great customes Output 6,3 MVA – 1 200 MVA Nominal voltage up to 420 kV

Distribution Transformers

For industry, villages and towns Output 50 kVA – 10 MVA Nominal voltage up to 35 kV TRANSMISSION DISTRIBUTION CONSUMPTION POWER GENERATION 4

Our Customers

5

Mexico Chile

Company results

Year 2016

Revenue progress since 2002

(mil. CZK)

7

Commodities in 2016

8

41% 35% 10% 8% 6% transformadores a 100 MVA transformadores de 100 MVA reactores reparaciones

• tros

Our Certification

Quality Management System acc.to EN ISO 9001 Environmental Management System according to

EN ISO 14001

Metallic Materials Welded Bonds Requirements according to EN ISO 3834-2 Electrotechnical Test Room Accreditation acc. to

EN ISO/IEC 17025

Testing Activities of Test Room E 11 Qualification Certificate Czech Railways Supplier Qualification Certificate Pre-Qualification for Connexio System Supplier of Power Companies in Germany. Eastern and Central Europe 9

10

Certificates Scope Issued by Valid to 1 Certificate for the Quality Management System under EN ISO 9001:2008 Development, production, incl. testing, assembly and service of transformers and other electrical equipment TÜV NORD 11.1.2018 2 Certificate for the Environmental Management System under EN ISO 14001:2004 Development, production, incl. testing, assembly and service of transformers and other electrical equipment TÜV NORD 11.1.2018 3 Certificate for the Occupational Health and Safety Management System under BS OHSAS 18001:2007 Development, production, incl. testing, assembly and service of transformers and other electrical equipment TÜV NORD 11.1.2018 4 Certificate for the Welding Process under EN ISO 3834-2:2005 Designing and manufacturing of power transformers and other parts of vehicles which are not subject to the approval according to standards for railway – rail vehicles TÜV NORD

/

5 Certificate of accreditation for Electrotechnical Testing Laboratory (L1526) under ČSN EN ISO/IEC 17025:2005 Electrical and air handling tests and measurements on industrial plant to the extent as specified in the attached appendix to the certificate. The Czech Institute for accreditation 1.7.2018 6 Certificate of Competence for Testing Activities of the Test room E 11 Measurements and diagnostics of electrical non- rotational machines, analyses of insulating oils, tests

• finsulators and insulator sets, tests of HV metal-

enclosed switchgear, tets of switchgear as specified in the attached appendix to the certificate. Association of High Voltage Testing Plants 31.10.2017 7 Certificate of a Supplier’s Technical Competence for the Czech railways All repairs, manufacturing and technical change of locomotive transformers, chokes and traction switches

• f electric locomotives

Czech railways

/

8 Certificat of pre-qualified supplier in system Connexio for utilities in Germany, Eastern and Central Europe 3.05.04 Transformers - generator 3.05.28 Transformers 10 to 100 MVA 3.05.29 Transformers above 100 MVA Achilles Information GmbH /

Our Certification summary

Trade Fairs

In 2017 we´ll be pleased to welcome you at the following fairs:

• International Electronic and

Electrotechnical Fair, AMPER. Brno, Czech Republic

• International Electrotechnical Fair

Hannover Messe, Germany

• Middle East Electricity (MEE) Dubaj
• EXPO ELÉCTRICA, México
• POWER KAZACHSTAN
• Power&Electricity World Africa,

Johannesburg

11

Manufacturing Programme

Year 2017

Three-phase Regulating Oil Transformers

Three-phase regulating oil transformers with output from 10 to 320 MVA And non-regulating up to 410 MVA, nominal voltage up to 420 kV Nuclear Power Plant Dukovany

13

13

Three-Phase Non-Regulating Oil Transformers

Three-phase non-regulating oil transformers with output up to 410 MVA and voltage up to 420 kV 300 MVA – JE Mochovce (3. a 4. blok)

14

One-Phase Oil Transformers

One-phase oil transformers with total output of a three-phase set up to 1200 MVA and voltage up to 420 kV 254/3 MVA Dalešice

15

Special Transformers according to Customers Specifications

Regulating and non- regulating transformers according to individual customers specification with different types of winding, cooling and sizes. Autotransformers with output up to 400 MVA and voltage 420 kV 25 MVA Actherm Chomutov

16

Locomotive transformers

Locotransformers according to specific customerʼs requirements Locotransformer for 62 E – 8108kVA, 25 kV

17

Chokes

Chokes for rail vehicles – traction chokes Choke CLVH 550-3m

Reactors

Starting reactors 6,3-22 kV, inductance up to 10 %

18

Repairs, Modernization and Service

Repairs

• Oil transformers with output from 1 to 400 MVA
• Furnace transformers
• Autotransformers

Technical Support

• Transformer testing prior to commissioning
• Transformer Diagnostics
• Transformers Technical checkup

All activities are performed on transformers produced by ourselves as well as by other manufacturers.

19

History

Year 2017

Historical Milestones

• f ETD Transformátory

1921 – establishment of Electrotechnical Engineering plant Škoda 1923 – first transformers 1150 kVA for Elektrozavod in Prague 1950 – production of three-phase transformers 125 MVA, 220 kV

21

Historical Milestones of ETD Transformátory

1979 – one-phase transformers 570 MVA for Mělník 2 Power Plant 1985-86 – production of 6 pcs transformers 250 MVA for Dukovany Power Plant 2000 – three-phase transformer 410 MVA, 410/22 kV for Kolubara Power Plant in Jugoslavia

22

Historical Milestones of ETD Transformátory

23

2004 – New owner and name change 2005 – 2 pcs transformers 150 MVA for Egypt, 5 pcs transformers 20 MVA for Cuba 2009 – 2 pcs transformers 300 MVA for Nuclear Power Plant Jaslovske Bohunice, SR 2011 – Dodání transformátorů pro projekt JE Mochovce 300 MVA, 63 MVA, 32 MVA

Historical Milestones of ETD Transformátory

2014 – Three-phase autotransformer 350 MVA, 400/121/34 kV for Power plant Voľa, Slovakia 2015 – Transformers 2x185MVA; 2x8,25MVA for Mahmoudeia, Egypt

24

Photographs

• references

Year 2017

Transformers Modernization

One-phase transformer produced in Ukraine, 400 MVA, 420/24 kV after modernization and power increasing

26

One-phase transformers 220/3 MVA, 242/15/15 kV VE Orlík – year 2000 Transformer 25 MVA, 220/23 kV Actherm Chomutov – year 2003

Transformer 12,5 MVA, 110/27 kV for traction substation, Czech railways – year 2004

27

Transformer 63 MVA, 110/10,5 kV Vřesová – year 2006 Transformer 25 MVA, 110/13,8 kV Cuba – year 2007

Transformer 300 MVA, 420/15,75 kV Dukovany – year 2008

28

Saturating reactor electronically regulated Russia – year 2010 Regulated reactor for Cuba

Transformer for electronic converters EN 61378 51 MVA Metalworks in Strazske, Slovakia - 2010

29

One-phase transformer, 250 MVA, 420/21 kV for Power Plant Ledvice Three-phase transformer 300 MVA, 420/15,75 kV For Nuclear Power Plant Mochovce, Slovakia

News

Three-phase autotransformer 350 MVA, 400/121/34 kV for Electrical Plant Voľa, Slovakia - 2014

30

News

31

Three-phase transformer 128MVA, 220/13,2 kV, Atacama, Chile - 2015

News

32

Three-phase transformers 210MVA , 55MVA, 2x16MVA, México 2015

Company Headquarters

ETD TRANSFORMÁTORY a.s.

Zborovská 54/22 301 00 Plzeň Czech Republic Tel: +420 373 031 701 Fax: +420 373 031 908 E-mail: etd@etd-bez.cz

33

Thank you for your attention!
