slide-1
SLIDE 1

Tracing with Perf tools

Namhyung Kim 2013-11-13 Wed

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 1 / 34

slide-2
SLIDE 2

Outline

1

Introduction

2

Other technologies

3

Kernel-level tracing with perf tools

4

User-level tracing with perf tools

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 2 / 34

slide-3
SLIDE 3

Introduction

tracing

tracking program execution similar to logging

lower-level, more-frequently

code instrumentation

func() { start_time = gettime(); ... end_time = gettime(); runtime = end_time - start_time; printf("%s: %lu\n", __func__, runtime); }

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 3 / 34

slide-4
SLIDE 4

Introduction

perf tool basics

Linux system performance monitoring tool

modern, actively developed command line (stdio, tui) or GUI (gtk)

lives in kernel source tree

easy to keep up with kernel-level change

supports various hw/sw performance events

works for both of user-level and kernel-level counting, sampling and tracing

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 4 / 34

slide-5
SLIDE 5

Introduction

perf event

hardware PMU events kernel software events kernel tracepoint events hardware raw events dynamic software events

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 5 / 34

slide-6
SLIDE 6

Introduction

perf target

existing process or thread (–pid, –tid) user (–uid)

all existing process/thread belong to the user

command line argument

fork & exec new child

system-wide (–all-cpus) cpu (–cpu)

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 6 / 34

slide-7
SLIDE 7

Introduction

perf commands

perf top

live system profiling

perf stat

read performance counter

perf record

recode profiling events

perf report

report performance bottle-neck

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 7 / 34

slide-8
SLIDE 8

Introduction

tracing feature in perf tools

tracepoint events

kernel has various (static) tracing information

perf probe

add trace-able events dynamically

perf script

show every traced record also can run various scripts on it currently python and perl supported

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 8 / 34

slide-9
SLIDE 9

Other technologies

manual instrumentation

what, when, how to record trace info users also want to know the timing info need precise clock source

gettimeofday() clock_gettime() rdtsc or similar

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 9 / 34

slide-10
SLIDE 10

Other technologies

aspect-oriented programming

weaving

combine concerns at compile/run-time primary concern (main logic) cross-cutting concern (secondary logic) join point / pointcut

http://en.wikipedia.org/wiki/Aspect-oriented_programming

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 10 / 34

slide-11
SLIDE 11

Other technologies

compiler-guided instrumentation

gcc supports following options

  • pg (-mfentry)

mcount()

  • finstrument-functions

void __cyg_profile_func_enter() void __cyg_profile_func_exit()

  • finstrument-functions-exclude-{file,function}-list

__attribute__((no_instrument_function))

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 11 / 34

slide-12
SLIDE 12

Other technologies

gprof

profiling tool included in binutils use -pg flag when compile binary (gcc)

  • nly work for the binary

using function tracing and sampling https://sourceware.org/binutils/docs/gprof/

$ gcc -o foo -pg foo.c $ ./foo $ gprof foo

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 12 / 34

slide-13
SLIDE 13

Other technologies

gcov

coverage testing tool included in gcc compiler generates coverage information

count basic block execution

use without optimization generate plain-text output file http://gcc.gnu.org/onlinedocs/gcc/Gcov.html

$ gcc -o foo --coverage foo.c $ ./foo $ gcov foo.c $ cat foo.c.gcov

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 13 / 34

slide-14
SLIDE 14

Other technologies

ptrace

system call to trace process execution

trace new child or attach to existing process

stopped by single step, syscall or signal

check WIFSTOPPED() and WSTOPSIG()

access to address space and registers used by debuggers man ptrace(2)

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 14 / 34

slide-15
SLIDE 15

Other technologies

strace

command line utility to trace syscalls (and signals)

using ptrace

no re-compilation is needed can filter specific syscalls very comprehensive argument parsing

string and structures are dereferenced

http://sourceforge.net/projects/strace/

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 15 / 34

slide-16
SLIDE 16

Other technologies

ltrace

command line utility to trace library calls

using ptrace

usage is almost same as strace add breakpoint at plt entries

and get arguments

filtering as “function@library” also support syscalls and signals http://ltrace.org/

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 16 / 34

slide-17
SLIDE 17

Other technologies

LD_PRELOAD

glibc rtld supports library symbol hooking intercept library call to other implementation

find symbol before default search path

wrap and record necessary info

save original function with dlsym(RTLD_NEXT, sym)

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 17 / 34

slide-18
SLIDE 18

Other technologies

LD_AUDIT

glibc rtld supports library auditing defines set of interfaces

can alter dynamic loader’s behavior library search, opening symbol binding, enter/exit

man rtld-audit(7)

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 18 / 34

slide-19
SLIDE 19

Other technologies

dyninst

user-level dynamic instrumentation API

using ptrace + code patching

patch binary at runtime

mutator process injects snippet code can call function inside the target process need trampoline code to setup arguments

support x86 and ppc http://www.dyninst.org/

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 19 / 34

slide-20
SLIDE 20

Other technologies

ftrace

function tracer for kernel

CONFIG_DYNAMIC_FTRACE using mcount()

can enable/disable dynamically also support other kinds of tracers function filtering

event trigger

trace marker trace-cmd: front-end tool for ftrace

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 20 / 34

slide-21
SLIDE 21

Other technologies

kprobes

insert probes to kernel code dynamically

pre- and post-handler

add a breakpoint basically

execute original instruction as single-step can be optimized to jump instructions

jprobes and kretprobes

access to arguments and return value

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 21 / 34

slide-22
SLIDE 22

Other technologies

uprobes

insert probes to user code dynamically

handler runs in kernel space

add a breakpoint basically

execute original instruction as single-step

uretprobes

access to return value

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 22 / 34

slide-23
SLIDE 23

Other technologies

systemtap

use custom script language (tapset) supports kernel and user level tracing

using kprobes and uprobes

compile kernel module and load at runtime

convert script to C source file compile it with system compiler (gcc)

SDT defines user-level tracepoints debuginfo-based dynamic instrumentation http://sourceware.org/systemtap/

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 23 / 34

slide-24
SLIDE 24

Other technologies

LTTng

using custom kernel module for kernel tracing trace kernel and userspace

use MONOTONIC clock for co-relate kernel & user space kernel: tracepoint, function, PMU event, kprobes, timer UST: SDT (need recompile), function, syscall

use CTF (common trace format)

also provides converter and graphical viewer

http://lttng.org/

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 24 / 34

slide-25
SLIDE 25

Other technologies

ktap

use custom script language

based on Lua

integrated interpreter in kernel

no compiler required something like systemtap w/o gcc

tracepoint, function, kprobes, uprobes, timer support x86, arm, ppc, mips safety in sandbox http://www.ktap.org/

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 25 / 34

slide-26
SLIDE 26

Kernel-level tracing with perf tools

perf kmem

kernel slap allocator stat

usage: perf kmem [<options>] {record|stat}

  • i, --input <file>

input file name

  • -caller

show per-callsite statistics

  • -alloc

show per-allocation statistics

  • s, --sort <key[,key2...]>

sort by keys: ptr, call_site, bytes, hit, pingpong, frag

  • l, --line <num>

show n lines

  • -raw-ip

show raw ip instead of symbol

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 26 / 34

slide-27
SLIDE 27

Kernel-level tracing with perf tools

perf sched

various scheduler events

fork, sleep, wakeup, switch, migrate

finding latency

usage: perf sched [<options>] {record|latency|map|replay|script}

  • i, --input <file>

input file name

  • v, --verbose

be more verbose (show symbol address, etc)

  • D, --dump-raw-trace

dump raw trace in ASCII

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 27 / 34

slide-28
SLIDE 28

Kernel-level tracing with perf tools

perf lock

in-kernel locking event CONFIG_LOCK_STAT, CONFIG_LOCKDEP required

usage: perf lock [<options>] {record|report|script|info}

  • i, --input <file>

input file name

  • v, --verbose

be more verbose (show symbol address, etc)

  • D, --dump-raw-trace

dump raw trace in ASCII

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 28 / 34

slide-29
SLIDE 29

Kernel-level tracing with perf tools

perf timechart

system power events

cpufreq, cpuidle, scheduler events

generate SVG image file to see events

usage: perf timechart [<options>] {record}

  • i, --input <file>

input file name

  • o, --output <file>
  • utput file name
  • w, --width <n>

page width

  • P, --power-only
  • utput power data only
  • p, --process <process>

process selector. Pass a pid or name.

  • -symfs <directory>

Look for files with symbols relative to this directory

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 29 / 34

slide-30
SLIDE 30

Kernel-level tracing with perf tools

perf ftrace

front-end to kernel ftrace (WIP)

usage: perf ftrace {live|record|show|report} [<options>] [<command>]

  • r: perf ftrace {live|record|show|report} [<options>] --

<command> [<options>]

  • t, --tracer <tracer>

tracer to use: function_graph or function

  • l, --filter <function[,function,...]>

show only these functions in the trace

  • p, --pid <pid>

trace on existing process id

  • v, --verbose

be more verbose

  • a, --all-cpus

system-wide collection from all CPUs

  • C, --cpu <cpu>

list of cpus to monitor

  • c, --clock <clock>

clock to be used for tracer

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 30 / 34

slide-31
SLIDE 31

User-level tracing with perf tools

perf trace

syscall tracing

with kernel (page fault and sched) information without hurting performance too much

depends on audit library (CONFIG_AUDIT) argument beautifying

get filename from probe:vfs_getname (WIP) usage: perf trace [<options>] [<command>]

  • r: perf trace [<options>] -- [<command>] [<options>]
  • r: perf trace record [<options>] [<command>].
  • r: perf trace record [<options>] -- <command> [<options>]

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 31 / 34

slide-32
SLIDE 32

User-level tracing with perf tools

perf probe

add dynamic probe at runtime

using kprobes and uprobes

depends on libelf and libdw(arf) specify specific address or symbol SDT and argument fetching is in progress

usage: perf probe [<options>] ’PROBEDEF’ [’PROBEDEF’ ...]

  • r: perf probe [<options>] --add ’PROBEDEF’ [--add ’PROBEDEF’ ...
  • r: perf probe [<options>] --del ’[GROUP:]EVENT’ ...
  • r: perf probe --list
  • r: perf probe [<options>] --line ’LINEDESC’
  • r: perf probe [<options>] --vars ’PROBEPOINT’

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 32 / 34

slide-33
SLIDE 33

User-level tracing with perf tools

perf probe event definition

  • a, --add <[EVENT=]FUNC[@SRC][+OFF|%return|:RL|;PT]|SRC:AL|SRC;PT

[[NAME=]ARG ...]> probe point definition, where GROUP: Group name (optional) EVENT: Event name FUNC: Function name OFF: Offset from function entry (in byte) %return:Put the probe at function return SRC: Source code path RL: Relative line number from function entry. AL: Absolute line number in file. PT: Lazy expression of line code. ARG: Probe argument (local variable name or kprobe-tracer argument format.)

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 33 / 34

slide-34
SLIDE 34

User-level tracing with perf tools

Q & A

thanks!

Namhyung Kim Tracing with Perf tools 2013-11-13 Wed 34 / 34
