SLIDE 1
Towards a Smart Data Transfer Node
Zhengchun Liu, Rajkumar Kettimuthu, Ian Foster, Peter H. Beckman
Towards a Smart Data Transfer Node Zhengchun Liu, Rajkumar - - PowerPoint PPT Presentation
Towards a Smart Data Transfer Node Zhengchun Liu, Rajkumar - - PowerPoint PPT Presentation
The 4th Innovating the Network for Data Intensive Science (INDIS) workshop Towards a Smart Data Transfer Node Zhengchun Liu, Rajkumar Kettimuthu, Ian Foster, Peter H. Beckman Presented by: Zhengchun Liu November 12, 2017, Denver CO Motivation
SLIDE 2
SLIDE 3
Motivation
Computer systems are getting ever more sophisticated, and human-lead empirical- based approach towards system optimization is not the most efficient way to realize the full potential of these modern and complex high performance computing systems.
SLIDE 4
Motivation
Computer systems are getting ever more sophisticated, and human-lead empirical- based approach towards system optimization is not the most efficient way to realize the full potential of these modern and complex high performance computing systems.
๏The effectiveness of parameters are not straightforward or intuitive understandable. ๏The system is dynamic. Fairly impossible to design a one-size-fits-all rule. ๏Parameter space is very big and very time consuming to explore. ๏Environment and platform are different.
SLIDE 5
Motivation
Computer systems are getting ever more sophisticated, and human-lead empirical- based approach towards system optimization is not the most efficient way to realize the full potential of these modern and complex high performance computing systems.
๏The effectiveness of parameters are not straightforward or intuitive understandable. ๏The system is dynamic. Fairly impossible to design a one-size-fits-all rule. ๏Parameter space is very big and very time consuming to explore. ๏Environment and platform are different.
The data transfer nodes (DTN) are compute systems dedicated for wide area data transfers in distributed science environments.
SLIDE 6
Motivation
Computer systems are getting ever more sophisticated, and human-lead empirical- based approach towards system optimization is not the most efficient way to realize the full potential of these modern and complex high performance computing systems. Inspired by work from Google Deepmind about using reinforcement learning to play games (e.g., AlphaGo, Atari). We use reinforcement machine learning methods to discover the “just right” control parameters for data transfer nodes in dynamic environment.
๏The effectiveness of parameters are not straightforward or intuitive understandable. ๏The system is dynamic. Fairly impossible to design a one-size-fits-all rule. ๏Parameter space is very big and very time consuming to explore. ๏Environment and platform are different.
The data transfer nodes (DTN) are compute systems dedicated for wide area data transfers in distributed science environments.
SLIDE 7
Motivation
* Aggregate incoming transfer rate vs. total concurrency (i.e., instantaneous number of GridFTP server instances) at two heavily used endpoints, with Weibull curve fitted.
* Z. Liu, P . Balaprakash, R. Kettimuthu, I. Foster, Explaining wide area data transfer performance. HPDC’17
SLIDE 8
Motivation
* Aggregate incoming transfer rate vs. total concurrency (i.e., instantaneous number of GridFTP server instances) at two heavily used endpoints, with Weibull curve fitted.
* Z. Liu, P . Balaprakash, R. Kettimuthu, I. Foster, Explaining wide area data transfer performance. HPDC’17
Luckily, the optimal operating point of these two endpoints are almost fixed. However, the optimal operating point of most endpoints are dynamical because of continuously changing external load.
SLIDE 9
Reinforcement Learning
[Idea] An agent interacting with an environment, which provides its current state and numeric reward signals after each action the agent takes. [Goal] Learn how to take actions in order to maximize reward.
https://en.wikipedia.org/wiki/Q-learning
SLIDE 10
Reinforcement Learning
[Idea] An agent interacting with an environment, which provides its current state and numeric reward signals after each action the agent takes. [Goal] Learn how to take actions in order to maximize reward.
Agent (Controller)
https://en.wikipedia.org/wiki/Q-learning
SLIDE 11
Reinforcement Learning
[Idea] An agent interacting with an environment, which provides its current state and numeric reward signals after each action the agent takes. [Goal] Learn how to take actions in order to maximize reward.
Agent (Controller) Environment / Object
https://en.wikipedia.org/wiki/Q-learning
SLIDE 12
Reinforcement Learning
[Idea] An agent interacting with an environment, which provides its current state and numeric reward signals after each action the agent takes. [Goal] Learn how to take actions in order to maximize reward.
Agent (Controller) Environment / Object
State St
https://en.wikipedia.org/wiki/Q-learning
SLIDE 13
Reinforcement Learning
[Idea] An agent interacting with an environment, which provides its current state and numeric reward signals after each action the agent takes. [Goal] Learn how to take actions in order to maximize reward.
Agent (Controller) Environment / Object
State St Action At
https://en.wikipedia.org/wiki/Q-learning
SLIDE 14
Reinforcement Learning
[Idea] An agent interacting with an environment, which provides its current state and numeric reward signals after each action the agent takes. [Goal] Learn how to take actions in order to maximize reward.
Agent (Controller) Environment / Object
State St Action At Reward Rt
https://en.wikipedia.org/wiki/Q-learning
SLIDE 15
Reinforcement Learning
[Idea] An agent interacting with an environment, which provides its current state and numeric reward signals after each action the agent takes. [Goal] Learn how to take actions in order to maximize reward.
Agent (Controller) Environment / Object
State St Action At Reward Rt
Learn https://en.wikipedia.org/wiki/Q-learning
SLIDE 16
Reinforcement Learning
[Idea] An agent interacting with an environment, which provides its current state and numeric reward signals after each action the agent takes. [Goal] Learn how to take actions in order to maximize reward.
Agent (Controller) Environment / Object
State St Action At Reward Rt
Learn
St The state of environment (control object) at any given time t
https://en.wikipedia.org/wiki/Q-learning
SLIDE 17
Reinforcement Learning
[Idea] An agent interacting with an environment, which provides its current state and numeric reward signals after each action the agent takes. [Goal] Learn how to take actions in order to maximize reward.
Agent (Controller) Environment / Object
State St Action At Reward Rt
Learn
St The state of environment (control object) at any given time t
At
The corresponding optimal action at any given time t https://en.wikipedia.org/wiki/Q-learning
SLIDE 18
Reinforcement Learning
[Idea] An agent interacting with an environment, which provides its current state and numeric reward signals after each action the agent takes. [Goal] Learn how to take actions in order to maximize reward.
Agent (Controller) Environment / Object
State St Action At Reward Rt
Learn
St The state of environment (control object) at any given time t
At
The corresponding optimal action at any given time t
Rt The actual reward from , i.e., what we want to optimize At
https://en.wikipedia.org/wiki/Q-learning
SLIDE 19
Reinforcement Learning
[Idea] An agent interacting with an environment, which provides its current state and numeric reward signals after each action the agent takes. [Goal] Learn how to take actions in order to maximize reward.
Agent (Controller) Environment / Object
State St Action At Reward Rt
Learn
St The state of environment (control object) at any given time t
At
The corresponding optimal action at any given time t
Rt The actual reward from , i.e., what we want to optimize At
Q-learning
https://en.wikipedia.org/wiki/Q-learning
SLIDE 20
Reinforcement Learning
[Idea] An agent interacting with an environment, which provides its current state and numeric reward signals after each action the agent takes. [Goal] Learn how to take actions in order to maximize reward.
Agent (Controller) Environment / Object
State St Action At Reward Rt
Learn
St The state of environment (control object) at any given time t
At
The corresponding optimal action at any given time t
Rt The actual reward from , i.e., what we want to optimize At
Q-learning
https://en.wikipedia.org/wiki/Q-learning
SLIDE 21
Reinforcement Learning
[Idea] An agent interacting with an environment, which provides its current state and numeric reward signals after each action the agent takes. [Goal] Learn how to take actions in order to maximize reward.
Agent (Controller) Environment / Object
State St Action At Reward Rt
Learn
St The state of environment (control object) at any given time t
At
The corresponding optimal action at any given time t
Rt The actual reward from , i.e., what we want to optimize At
Q-learning Policy Gradient
https://en.wikipedia.org/wiki/Q-learning
SLIDE 22
File Transfer Tool(e.g. GridFTP) Knowledge Engine
User
A pool of files to transfer Submission
R e q u e s t R e s p
- n
s e Q u e r y
Network
Chunk size Concurrency Parallelism … …
File System
L e a r n i n g
Achieved Performance (reward)
Action
CPU load RAM load Network load Storage load … …
Environment
1 2 3 4 5 2 6
Destination DTN
Current state
Transfer with action
Smart Data Transfer Node
Workflow
1 A file transfer tool requests a file to transfer from the KE. The KE 2 checks the current DTN state and 3 responds to the transfer tool with a chunk of file and corresponding optimal transfer parameters (the steering action). 4 The transfer tool transfers the associated chunk with the parameters and monitors the aggregate DTN throughout during this transfer. 5 Once completed, DTN’s average aggregate throughput is reported to the KE as a reward for its actions. 6 Based on the reward (encourage or discourage), the KE updates its internal model parameters to improve its decision policy.
SLIDE 23
State, Action and Reward
Context — High performance wide area data transfer scheme
SLIDE 24
๏Wether start transferring a new file chunk (True/False). It controls the total Concurrency. ๏Parallelism used to transfer the file chunk ๏The size of file chunk to transfer. It controls the transfer duration, e.g., command frequency. ๏CPU usage (# of GridFTP instance here); ๏Total number of TCP streams on DTN; ๏The aggregate ingress and egress throughout of the DTN’s network interface card; ๏The aggregate disk read and write throughput. State, Action and Reward
St
Rt At
State Action
๏The aggregated transfer throughput (of all transfers).
Reward
SLIDE 25
Knowledge Engine
Reinforcement learning model architecture
L
- θQ
= 1 N X
t
[Q(St, At) − yt]2 yt = r (St, At) + γQ(St+1, At+1) rθµJ ⇡ 1 N X
t
rAtQ (St, At) rθµµ (St)
Actor Neural Network Critic Neural Network Transfer the file chunk Actor Neural Network Critic Neural Network
Reward (Average total outgoing throughput ) concurrency, parallelism, chunk size
L
- θQ
St St
At
At+1
St+1
Q(St, At) Q(St+1, At+1)
τθµ + (1 − τ) θµT → θµT τθQ + (1 − τ) θQT → θQT
Update weights using
rAtQ (St, At) rθµµ (St)
Update weights using policy gradient Update target Update target
rθQL
minimize L
- D. Silver et al. Deterministic Policy Gradient Algorithms. ICML’14
* * *
SLIDE 26
Results and discussion
Reinforcement learning model accuracy versus DTN’s aggregated throughput (credit) in dedicated environment.
Effectiveness of the knowledge engine (KE) in a dedicated environment. DTN performance increases as the KE’s prediction accuracy improves. (64 iterations per epoch)
L
- θQ
= 1 N X
t
[Q(St, At) − yt]2
SLIDE 27
Results and discussion
Reinforcement learning model accuracy versus DTN’s aggregated throughput (credit) in dedicated environment.
Effectiveness of the knowledge engine (KE) in a dedicated environment. DTN performance increases as the KE’s prediction accuracy improves. (64 iterations per epoch)
L
- θQ
= 1 N X
t
[Q(St, At) − yt]2
It works! The knowledge engine is able to find the optimal operating point and, keep DTN working in the optimal operating region.
SLIDE 28
Results and discussion
Heuristic configuration (2.040 Gbps) Knowledge Engine configuration (2.043 Gbps)
Experiment in shared environment (adding artificial, reproducible external load to storage)
SLIDE 29
Results and discussion ๏GridFTP does not support dynamic concurrency and parallelism. ๏We have to restart GridFTP to apply the new parameters. ๏There is an overhead for changing parameters.
Overhead issue
SLIDE 30
Results and discussion ๏GridFTP does not support dynamic concurrency and parallelism. ๏We have to restart GridFTP to apply the new parameters. ๏There is an overhead for changing parameters.
Overhead issue
Steady Start up Steady Time Throughput
SLIDE 31
Results and discussion ๏GridFTP does not support dynamic concurrency and parallelism. ๏We have to restart GridFTP to apply the new parameters. ๏There is an overhead for changing parameters.
Knowledge engine configuration, adjusted to remove overheads (2.273 Gbps)
With knowledge engine, we get about 11.3% improvement compare with heuristic configuration.
Overhead issue
SLIDE 32
Results and discussion ๏GridFTP does not support dynamic concurrency and parallelism. ๏We have to restart GridFTP to apply the new parameters. ๏There is an overhead for changing parameters.
Knowledge engine configuration, adjusted to remove overheads (2.273 Gbps)
With knowledge engine, we get about 11.3% improvement compare with heuristic configuration.
Overhead issue
Cumulative distribution of throughput
SLIDE 33
Fully unsupervised, does not need labeled historical data; Changes parameters automatically according the state of environment; Training is online, self-optimization; Suitable for any deployment without specialist;
Conclusion
The knowledge engine that powers the conventional data transfer node with smartness are:
SLIDE 34
Future work
SLIDE 35
Future work
Tuning more parameters; Testing in practical environment. Embed in distributed workflow; Smart autonomous science ecosys.;
SLIDE 36
Future work
Knowledge Engine (KE)
ctrl data
KE
storage
ctrl data
KE
storage
ctrl data
Compress Pace Checksum Uncompress Action n Action n Checksum
… …
Source DTN Destination DTN Knowledge Engine KE Network Adaptive routing
high chance
ctrl data
scenario n
ctrl data
destination bottleneck
- f corruption
bottleneck network
Tuning more parameters; Testing in practical environment. Embed in distributed workflow; Smart autonomous science ecosys.;
SLIDE 37
Future work
Perception Layer Application Layer Processing Layer Collective Layer
Storage Knowledge Engine
(Lightweight Machine Learning)
Monitor Steer
Data Control
P2P Communication
Data Control Status Intent
Edge Computing Science Workflows
Intent Intent
Data Transfer Node Knowledge Engine
(Lightweight Machine Learning)
Monitor Steer
Data
P2P Communication
Data Status
Edge Computing
Intent
Compute(HPC, Cloud)
Knowledge Engine
(Lightweight Machine Learning)
Monitor Steer
Data
P2P Communication
Data Status
Edge Computing
Intent
Network Knowledge Engine
(Lightweight Machine Learning)
Monitor Steer
Data
P2P Communication
Data Status
Edge Computing
Intent
Instrument Knowledge Engine
(Lightweight Machine Learning)
Monitor Steer
Data
P2P Communication
Data Status
Edge Computing
Intent Control Control Intent Intent Control Control Intent Intent Control Control Intent Intent Control Control Intent Intent
… … … …
Fabric Layer
Knowledge Engine (KE)
ctrl data
KE
storage
ctrl data
KE
storage
ctrl data
Compress Pace Checksum Uncompress Action n Action n Checksum
… …
Source DTN Destination DTN Knowledge Engine KE Network Adaptive routing
high chance
ctrl data
scenario n
ctrl data
destination bottleneck
- f corruption
bottleneck network
Tuning more parameters; Testing in practical environment. Embed in distributed workflow; Smart autonomous science ecosys.;
SLIDE 38
Thank you for your attention!
U.S. Department of Energy, Office of Science, ASCR, and the program manager Richard Carlson; The Joint Laboratory for System Evaluation (JLSE) at Argonne National Laboratory and the Chameleon project <www.chameleoncloud.org> for providing resources for testbed.
