Drawbacks of standard fittings • Dead Volume. Parts Inventory • • Gaskets Welding • Panel Design • • Particle Generation Assembly • • Twisting of Tubes Footprint • • Male / Female

™ FLOWMECA The RHP Fitting Patent protected

Flange Protection ring Centering ring Gland Ensemble Flange

Gland

Sealing surface Ra 0.4 (10 Ra) Interior surface Ra 0.2 (5 Ra) Gland Surface finish

Protection Ring PTFE Centering Ring Gland Leak Port It's not a gasket

Centering Ring Leak Port

Flanges Screws Silver coated

Metal to metal contact Axial tightening

Standard versus RHP

134 g 42 g Lighter

50 mm 12 mm 80 mm 37 mm 24 mm 28 mm Smaller

No Gasket No Dead Volume Cleaner

Clean Contact

No Twist on the tubes

Standard RHP 10 part numbers 3 part numbers Reduced parts inventory

Standard RHP No Male Female end fittings Reduced parts inventory

Standard RHP 50.8 mm 70.6 mm Reduced footprint

Standard RHP Allen 2.5 mm Easy of assembly • Ease of maintenance

Vacuum leak measurement 3 <1.10-10 atm.cm /s

Vacuum and 200 bar pressure test at 300°C No leak detected on any sample

RHP 1/4” Vacuum tests Leak: 3 <1.10-10 atm.cm /s With protection rings Without protection rings +180°C +550°C +20°C +20°C -100°C -100°C

Helium pressure tests Leak: 3 <1.10-10 atm.cm /s 80 bar 650 bar 20 bar +180°C +180°C +20°C

Oil high pressure tests No detected leak RHP 3/8” RHP 1/4” 1,900 bar 1,600 bar 1,600 bar (burst pipe)

At 1,600 bar pipe bursts

Comparative test A = VCR B = S-VCR C = Parker D = RHP

Comparative test

250 assembly cycles Leak rate: 3 <1.10-10 atm.cm /s

Radioactive Isotope Test D (H ) & T (H ) 2 3 Tritium accumulation in a glove box at 16 bars No leak after 16 days

Drawbacks of standard fittings • Dead Volume Parts Inventory • • Gaskets Welding • • Particle Generation Panel Design • • Twisting of Tubes Assembly • • Male / Female Footprint • ? ?

Applications: UHP Gas Systems UH Vacuum High Pressure Liquids Semi Solids High/Low Temperature

Product: Butt Weld: 1/8” to 4” Tees, Crosses, Ells etc. “Click Pipe”: 1/8” to 1” “And more to come!

RHP winner by technical KO

Weld

Problems related to welding Testing • • Number of Welds Safety • • Deterioration of Tubing Contamination• • Bulky Equipment Personnel Costs • • Clean Area Contamination Maintain Tolerance • • Moisture Retention ? ?

Weld Weld Weld

Patented

Basic Idea

Click Groove Sealing surface Ra 0.4 (10 Ra) A tube

Click pipe

A Click Pipe

Titre

Click Pipe Full

Two tubes

Drawbacks of standard fitting • Dead Volume Parts Inventory • • Gaskets Welding • • Particle Generation Panel Design • • Twisting of Tubes Assembly • • Male / Female Footprint • ? ?

Drawbacks of standard fitting • Dead Volume Parts Inventory • • Gaskets Welding • • Particle Generation Panel Design • • Twisting of Tubes Assembly • • Male / Female Footprint • ? ?

Patented

With some Modular RHP components

Cross Tee Elbow Click-Pipe Straight Flange With only 9 Modular RHP sub-components

RHP Modular Grid 1” x 1”

RHP Modular Grid 1” x 1” components, elbows and tees,

RHP Modular Grid 1” x 1” Components, elbows and tees, tubes and click-pipes,

RHP Modular Grid 1” x 1” Components, elbows and tees, tubes and click-pipes, flanges.

Modular gas panel

-30% to -50% Reduced footprint

Reduced design time -75%

Easy to assemble • Easy to maintain

Main References • Air Liquide Motorola • • Leybold Trikon • • Unaxis Balzers Siemens • • IBM ST Microelectronics • • Argonne Nat Lab Rhône Poulenc • • L'Oréal Matra Marconi Space •

Why IGS Systems ? • Reduced connections. • Fewer welds. • Reduced Footprint. • Lower Cost. • Process improvement • Less dead volume. • ??????

Integrated Gas System • High cost • More Connections • Welding still required • Many different sealing systems • Completely new parts inventory

The Facts • 8 Component IGS Stick has 18 gasketed connections 36 seal planes. • Welds are still required. • Reduced Footprint. Yes BUT $$$ • Cost may be 3-4 X present. • Blocks & Gaskets = dead volume • Process improvement. ???

RHP Modular • Low cost — > Initial — > Replacement • Easily modified • Same parts inventory • Connections — > No Gasket — > No dead volume — > Fewer Connections • Weld free

The Facts • RHP Has 8 gasket free connections. • No welds required. • Reduced Footprint. Yes. • Cost same as present. • No Blocks No Gaskets No dead volume • = Process improvement.
