www.psl-systemtechnik.de Thermal Conductivity Measuring System Lambda

Pour Point ∙ Asphaltene ∙ Wax ∙ Scale ∙ Gas Hydrate ∙ Viscosity ∙ Drag Reduction ∙ Thermal Conductivity

Thermal Conductivity Measuring System LM

www.psl-systemtechnik.de Thermal Conductivity Measuring System Lambda

Pour Point ∙ Asphaltene ∙ Wax ∙ Scale ∙ Gas Hydrate ∙ Viscosity ∙ Drag Reduction ∙ Thermal Conductivity

Determination of Thermal Conductivity

with the

Measuring System Lambda

www.psl-systemtechnik.de Thermal Conductivity Measuring System Lambda

Pour Point ∙ Asphaltene ∙ Wax ∙ Scale ∙ Gas Hydrate ∙ Viscosity ∙ Drag Reduction ∙ Thermal Conductivity

• Measuring thermal conductivity of fluids, powders

nano fluids and gels

• Based on ASTM D 2717
• Temperature range -30 to +190 °C (-22 to +374 °F)
• Ambient pressure or pressurised up to 35 bar (507.6 psi)
• Small sample volumes from 50 ml
• Stand-alone or PC-controlled

Characteristics

www.psl-systemtechnik.de Thermal Conductivity Measuring System Lambda

Pour Point ∙ Asphaltene ∙ Wax ∙ Scale ∙ Gas Hydrate ∙ Viscosity ∙ Drag Reduction ∙ Thermal Conductivity

• Hot wire is heated up by

a well known amount of electrical energy

• Heat is corried off by inter-

molecular heat transfer

• The wire resitance changes

while cooling down

• The thermal conductivity can be

calculated out of the resistance curve

Measurement Principle

resistance time

www.psl-systemtechnik.de Thermal Conductivity Measuring System Lambda

Pour Point ∙ Asphaltene ∙ Wax ∙ Scale ∙ Gas Hydrate ∙ Viscosity ∙ Drag Reduction ∙ Thermal Conductivity

• Convection causes additonal

heat transfer and would disturb the measurement

• For measuring only the inter-

molecular heat transfer any convection has to be avoided !

• The LT30190 thermoelectric thermostat

provides most accurate and fast zero- convetion tempering

Why use a zero con- vection thermostat?

www.psl-systemtechnik.de Thermal Conductivity Measuring System Lambda

Pour Point ∙ Asphaltene ∙ Wax ∙ Scale ∙ Gas Hydrate ∙ Viscosity ∙ Drag Reduction ∙ Thermal Conductivity

Components: LabTemp 30190

Heating / cooling device with thermoelectrical modules High accuracy and very homogeneous temperature gradient

www.psl-systemtechnik.de Thermal Conductivity Measuring System Lambda

Pour Point ∙ Asphaltene ∙ Wax ∙ Scale ∙ Gas Hydrate ∙ Viscosity ∙ Drag Reduction ∙ Thermal Conductivity

New: Low Temperature with Cooling-Water Precooler

• Temperature range of device

extended down to -50 °C (-58 °F)

• Cost-effective alternative to

cryostats with the same capacity

• Older LTs upgradeable

www.psl-systemtechnik.de Thermal Conductivity Measuring System Lambda

Pour Point ∙ Asphaltene ∙ Wax ∙ Scale ∙ Gas Hydrate ∙ Viscosity ∙ Drag Reduction ∙ Thermal Conductivity

Components: Autoclave and Sensor

• Autoclave

(35 bar, 507.6 psi)

• Inlet / outlet

gas flushing

• Hot-wire,

platinum

www.psl-systemtechnik.de Thermal Conductivity Measuring System Lambda

Pour Point ∙ Asphaltene ∙ Wax ∙ Scale ∙ Gas Hydrate ∙ Viscosity ∙ Drag Reduction ∙ Thermal Conductivity

Reference substance Measurement: Lambda between

• 20 and +180 °C

(-4 to 356 °F)

Measurement Example: Reference Oil

www.psl-systemtechnik.de Thermal Conductivity Measuring System Lambda

Pour Point ∙ Asphaltene ∙ Wax ∙ Scale ∙ Gas Hydrate ∙ Viscosity ∙ Drag Reduction ∙ Thermal Conductivity

Toluene at ambient pressure Measurement: Lambda between

• 20 and +60 °C

(-4 to 140 °F)

Measurement Example: Toluene

www.psl-systemtechnik.de Thermal Conductivity Measuring System Lambda

Pour Point ∙ Asphaltene ∙ Wax ∙ Scale ∙ Gas Hydrate ∙ Viscosity ∙ Drag Reduction ∙ Thermal Conductivity

Applications

• Measuring thermal conductivity of fluids, powders,

nano fluids and gels

• Optimisation of fluid development
• Optimisation of fluid application
• Quality control

www.psl-systemtechnik.de Thermal Conductivity Measuring System Lambda

Pour Point ∙ Asphaltene ∙ Wax ∙ Scale ∙ Gas Hydrate ∙ Viscosity ∙ Drag Reduction ∙ Thermal Conductivity

Thank you for your attention!

If you want to know more www: Product page Measuring System Lambda email: info@psl-systemtechnik.de telephone: +49 5323 962790 We will be pleased to help you.
