Theres a Storm Coming. It started with an Idea at OSHUG #49 in late May myStorm A new open hardware FPGA & ARM platform for exploring new cpu architectures MyStorm is a brand new $30 open source hardware platform designed to

slide-1
SLIDE 1

There’s a Storm Coming….

slide-2
SLIDE 2

It started with an Idea at OSHUG #49– in late May

slide-3
SLIDE 3

myStorm – A new open hardware FPGA & ARM platform for exploring new cpu architectures

MyStorm is a brand new $30 open source hardware platform designed to allow the exploration of new processor architectures. A unique combination of a $5 Raspberry Pi Zero, a $2, 32-bit ARM microcontroller and a $5 versatile, low power FPGA – brought to life with innovative open source software.

slide-4
SLIDE 4

myStorm is a $30 Open Hardware FPGA & ARM dev board

slide-5
SLIDE 5

It was Designed, Built, Tested & Manufactured in just 100 Days – this summer

slide-6
SLIDE 6

Designed in EagleCAD

slide-7
SLIDE 7

Using lots of tiny 0402 components

slide-8
SLIDE 8

Prototypes made in Alan’s kitchen

slide-9
SLIDE 9

With lots of beer

slide-10
SLIDE 10

Mr White, Mr Black & Mr Yellow

slide-11
SLIDE 11

Which we then tested

slide-12
SLIDE 12

And got the LEDS to blink – yay!

slide-13
SLIDE 13

So we went to the Pub

  • ur “Saturday office”
slide-14
SLIDE 14

To celebrate with a beer – or three!

slide-15
SLIDE 15

But we needed a bit of help from our friends

slide-16
SLIDE 16

Especially this guy! - Toby Yu

slide-17
SLIDE 17

Toby works in a modern electronics factory – in Shenzhen

slide-18
SLIDE 18

With these girls – Toby’s Angels

slide-19
SLIDE 19

And with a bunch of SMT components

slide-20
SLIDE 20

And this really nice machine

slide-21
SLIDE 21

They built a few more myStorm boards

slide-22
SLIDE 22

Last Saturday!

slide-23
SLIDE 23

Which arrived in Hebden Bridge on Wednesday..

slide-24
SLIDE 24

Just in Time for OSHCamp 2016 (Phew!)

slide-25
SLIDE 25

And relax….Our work here is done

slide-26
SLIDE 26

The Money Shot!

slide-27
SLIDE 27

Apart for the mandatory Kitten Pic!

slide-28
SLIDE 28

Computationally Efficient Adaptive Machine Learning Algorithms implemented on open FPGA hardware - for the effective laser targeting of Feline subjects - just joking……...

slide-29
SLIDE 29

Follow Us On Twitter

#myStorm

  • r find us at myStorm.uk

Ken Boak is @monsonite Alan Wood is @folknology Read about our summer’s journey of discovery at Alan’s “Folknology Labs” blog.
