Theoretical Calculations to Assist Experimental Crystal Form Screening Jacco van de Streek University of Copenhagen Department of Pharmaceutics and Analytical Chemistry Crystal Structure Prediction: Basics Free energy (p,T) energy structure

slide-1
SLIDE 1

Theoretical Calculations to Assist Experimental Crystal Form Screening

Jacco van de Streek University of Copenhagen Department of Pharmaceutics and Analytical Chemistry

slide-2
SLIDE 2

Crystal Structure Prediction: Basics

structure generation

Free energy (p,T)

energy ranking

slide-3
SLIDE 3

Why Force Fields Do not Work

energy

Typical accuracy Required accuracy (0.1 – 0.01 kcal/mol)

slide-4
SLIDE 4

Dispersion-corrected DFT (DFT-D)

Force fields... RMS = 0.497 Å Predicted Experiment

slide-5
SLIDE 5

Pure DFT... Force fields... RMS = 0.833 Å RMS = 0.497 Å Predicted Experiment

Dispersion-corrected DFT (DFT-D)

slide-6
SLIDE 6

Dispersion-corrected DFT... Pure DFT... Force fields... RMS = 0.833 Å RMS = 0.084 Å RMS = 0.497 Å Predicted Experiment

Dispersion-corrected DFT (DFT-D)

slide-7
SLIDE 7

Elattice = EDFT + EvdW

VASP

  • PAW potentials
  • Plane-wave basis set
  • GGA – PW91 / GGA – PBE
  • 520 eV enery cut-off
  • 0.07 Å-1 k-point spacing
  • Pair potentials
  • Element dependent
  • Hybridisation dependent
  • -C6  r-6

“0 K” calculations, no free energies

  • M. A. Neumann & M.-A. Perrin (2005) J. Phys. Chem. B 109, 15531-15541
  • G. Kresse & J. Hafner (1993) Phys. Rev. B 47, 558-561

Dispersion-corrected DFT (DFT-D)

slide-8
SLIDE 8

Crystal Structure Generation

Parallel tempering Monte-Carlo algorithm Tailor-made force field: accurate force field, fitted to artificial DFT-D reference data for each compound One and two independent molecules in all 230 space groups

  • M. A. Neumann (2008) J. Chem. Phys. B 112, 9810-9829
slide-9
SLIDE 9

Examples: Blind Tests

Crystal Structure Prediction Blind Tests: Blind Tests in 1999, 2001, 2004, 2007 and 2010 Good compounds for validation

  • G. M. Day et al. (2009) Acta Cryst. B65, 107-125
slide-10
SLIDE 10

:

Previous Blind Test Compounds

slide-11
SLIDE 11

Ranking Results (NOT Full Studies)

  • A. Asmadi, M. A. Neumann, J. Kendrick, P. Girard, M.-A. Perrin &
  • F. J. J. Leusen (2009) J. Phys. Chem. B 113, 16303-16313

1 & 2 2 1 1 & 2 4 1 1 1 1 1 & 2 1 1 1 2

slide-12
SLIDE 12

Previous Blind Test Compounds

Conclusion Dispersion-corrected DFT appears to work well for energy-ranking crystal structures (80% success rate)

slide-13
SLIDE 13

Efavirenz

Number of patents: 5 Number of claimed forms: 24 Number of crystal structures known: 0

slide-14
SLIDE 14

Efavirenz

Experimental polymorph screen by Dr Eva Dova (Avantium) Scan of patent literature by Dr Menno Deij (Avantium) The 24 forms boil down to eight distinct forms: A, B, C, D, E, F, H1, N

slide-15
SLIDE 15

Efavirenz (Z'=1-2)

Energy Density A B C D E F H1 N

slide-16
SLIDE 16

Energy B C F N H1 Density A B C D E F H1 N B B B

Efavirenz (Z'=1-2)

slide-17
SLIDE 17

Energy C N H1 Density A B C D E F H1 N Some patents: C most stable (@RT) Some patents: F most stable (@RT) B B B B

Efavirenz (Z'=1-2)

F

slide-18
SLIDE 18

Efavirenz

Form B is disordered, four

  • rientations of the cyclopropane

group are found in the search (ranks 20, 27, 40, 57) Disorder means that our 0 K energies are not reliable

  • S. Cuffini, R. E. Howie, E. R. T. Tiekink, J. L. Wardell &
  • S. M. S. V. Wardell (2009) Acta Cryst. E65, o3170-o3171
slide-19
SLIDE 19
  • Form N is Z'=2
  • One axial -CF3, one equatorial -CF3
  • Requires fully flexible search with Z'=2
slide-20
SLIDE 20

We can solve structures from poor quality laboratory powder patterns, scanned from a patent: low resolution, preferred orientation. Rietveld refinement with TOPAS for form N (Z'=2)

Efavirenz

slide-21
SLIDE 21

What about Forms A, D & E?

Energy C N H1 Density A B C D E F H1 N B B B B F

slide-22
SLIDE 22

Efavirenz

A Z'=3 / Z'=6 [1] B Found, Disordered [2] C Found D Solvate (from TGA) E ? F Found [3] H1 Found N Found

[1] S. Mahapatra, T. S. Thakur, S. Joseph, S. Varughese & G. R. Desiraju (2010) Cryst. Growth Des. 10, 3191-3202 [2] S. Cuffini, R. E. Howie, E. R. T. Tiekink, J. L. Wardell & S. M. S. V. Wardell (2009) Acta Cryst. E65, o3170-o3171 [3] K. Ravikumar & B. Sridhar (2009) Mol. Cryst. Liq. Cryst. 515, 190-198

slide-23
SLIDE 23

Efavirenz

Conclusions

  • Real life very complicated:
  • Z'>2
  • Disorder: entropy contribution
  • Solvates
  • Form E ambiguous
  • Crystal structures from very poor quality powder patterns:

use crystal-structure prediction

  • No more stable form found: it is unlikely that one turns up

in the future

slide-24
SLIDE 24

Current complexity limit

  • Six months on a 64 CPU quad-core Xeon or Opteron cluster
  • Quasicomplete screen for Z'=1 in 230 space groups
  • 50 – 90 % complete screen for Z'=2 in 230 space groups

Bicalutamide

F F F N H N S O HO O O F

Blind Test XX

slide-25
SLIDE 25

Acknowledgements

Marcus Neumann - Avant-garde Materials Simulation Eva Dova - Avantium Menno Deij - Avantium
